Found                                                 hallway!          The User as a Sensor:Navigating Users with Visual ...
NavigationHumans navigate using: »Path integration »Landmark identificationSighted people primarily rely on vision       ...
Users with Visual ImpairmentsNavigate using compensatory senses (touch, sounds, smell)Landmark identification is significa...
Navigation Systems  gpsoutdoors             indoors           ✅                 Human Computer Interaction Lab            ...
Indoor Localization Techniques        compass        stepdead reckoning    beacons            sensors - inaccurate     +ac...
Can we developa better system?
Veeringoutdoors             indoors                     Human Computer Interaction Lab                         University ...
Dead Reckoning Localization                         Step counter                              Compass                     ...
DoorHallwayintersection
DoorHallwayintersection
DoorHallwayintersection Wall
DoorHallwayintersection Wall
DoorHallwayintersection Wall
Combining techniques        compass        stepdead reckoning             beacons                   sensors               ...
RepresentationKML 3D model                     navigable map               Geometry parser                                ...
Direction provision     Shortest path using A*     Generate Directions:      1.Move to a landmark      2.Turn direction ...
Direction provision     Shortest path using A*     Generate Directions:      1.Move to a landmark      2.Turn direction ...
Interface“Follow the wall to your right  until you reach a hallway         intersection”                                 H...
Interface“Follow the wall to your right  until you reach a hallway         intersection”                                 H...
Interface“Follow the wall to your right                                           Found  until you reach a hallway        ...
Interface“Follow the wall to your right                                           Found  until you reach a hallway        ...
Interface“Follow the wall to your right                                           Found  until you reach a hallway        ...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Particle Filtersx particles have location and weight.Location updated using distribution of error in steps & compasswei...
Prior studies     Intersection                   20 steps                      Door   Door                15 steps        ...
User StudyEngineering Building (hallways/labs/offices)11 paths over two 2 floorsLandmarks (hallway intersection, doors, wa...
ParticipantsSix users with visual impairments.3 Female, average age: 51.8 (SD=18.2)3 Total Blind, 2 legal blind, 1 low ...
Ground Truth                     VS    StarGazer                    Sketchup Model$2,000                    took 3 hours t...
ResultsQuantitative »85% of paths completed successfully »Average error: 1.85 meter »Door counting had lowest success rat...
Future workImprove step detection / avoid scuttlingEvaluation in more complex environmentsPlanning more reliable paths....
questions?             Human Computer Interaction Lab                 University of Nevada, Reno
Upcoming SlideShare
Loading in …5
×

The User as a Sensor: Navigating Users with Visual Impairments in Indoor Spaces using Tactile Landmarks

719 views

Published on

Indoor navigation systems for users who are visually impaired typically rely upon expensive physical augmentation of the environment or expensive sensing equipment; consequently few systems have been implemented. We present an indoor navigation system called Navatar that allows for localization and navigation by exploiting the physical char- acteristics of indoor environments, taking advantage of the unique sensing abilities of users with visual impairments, and minimalistic sensing achievable with low cost accelerometers available in smartphones. Particle filters are used to estimate the user’s location based on the accelerometer data as well as the user confirming the presence of anticipated tactile land- marks along the provided path. Navatar has a high possibility of large-scale deployment, as it only requires an annotated virtual representation of an indoor environment. A user study with six blind users determines the accuracy of the approach, collects qualitative experiences and identifies areas for improvement.

Published in: Technology, Education
0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total views
719
On SlideShare
0
From Embeds
0
Number of Embeds
3
Actions
Shares
0
Downloads
46
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide
  • Hi, I am Eelke Folmer and I'm to present an indoor navigation system for users that are visually that I developed with my two of my graduate students Navid Fallah, Ilias Apostolopoulos and my colleague Kostas Bekris. \n\n
  • \n
  • In navigation humans basically use the following two technique: \n\n1) path integration where users update their current position using proprioceptive data. \n2) landmark based identification where users locate themselves by recognizing landmarks that is stored on a map.\nUsing both techniques together can be used for exploring new environments and building a cognitive map of the environment by observing landmarks. \n\nSighted people primarily rely on vision to recognize landmarks. \n
  • but people with visual impairments must rely on their compensatory senses such as touch, sounds and smell. \nThough for path integration no significant differences in path integration abilities between sighted an blind users have been found, landmark identification and cognitive mapping is significantly slower, which leads to reduced mobility and a lower quality of life for users with visual impairments. \n\n
  • Several human navigation systems have been developed which can be distinguished into outdoor and indoor systems. \nWhereas outdoor systems typically use GPS for localizing the user, indoor navigation systems must use a different technique as GPS signals cannot be retrieved indoors. \n
  • Exisitng Indoor navigation systems typically use one of the following three techniques: \n\n1) dead reckoning localization uses low cost sensors, such as a compass and pedometer to update the user’ s position based on observed motion. These techniques are cheap but inaccurate as error in location estimation propagates over time \n2) beacon based systems, embed identifiers such as RFID tags in the environment where a sensor senses a particular identifier upon which the user can be localized. These systems are accurate but often prohibitively expensive to install Though tags themselves are cheap installing them in a large environments such as an airport is not. \n3) sensing based approaches typcially equip the user with a number of sensors, such as camera and locate the user by detecting pre-existing features of indoor spaces that have been recorded on a prior map. Though this technique can be accurate, from a usability point of view it requires the user to carry a number of sensors and computer equipment. For users with visual impairments this is undesirable as they often already carry a cane and assistive devices such as a braille reader.\n
  • So given that few of these systems have been implemented at a large scale, we basically set out to investigate if investigated \n\nSo our idea was can we design a navigation system that is cheap to implement and easy to use for users with visual impairments? So we started our project by analyzing navigation in indoor environments more closely. \n
  • \n
  • So you need accurate localization to be able to avoid veering, e.g. when a user is navigating and deviating from the provided path. But you can argue that veering is less of a problem in indoor environments than it is in outdoor environments as navigation is naturally constrained by the physical environment, such as walls and doors. \nSo you could argue that maybe for indoor navigation super precise localization is not required. \n
  • From the three indoor locatlization techniques dead reckoning is not very precise but it can be implemented using features that are present in most smartphones, e.g., accelerometers and a compass. So you don’t have to hook up the user with a bunch of sensors or add RFID tags to your environment. \n\nA problem with dead reckoning is that errors in estimating the user’s location propagate and accumulate over time. but this can be avoided by periodically synchronizing the user’s location with known landmarks in the environment, which could be hallway intersections, a door or a water cooler. \n\n \n
  • Now lets look at how blind people navigate familiar environments using a cognitive map they have of this evnrionment. . So the user navigates and senses their environment with a cane. Okay so the user finds a wall, hey it finds a hallway intersection. \n\nSo the identification of landmarks and in this case tactile landmarks, such as walls, hallway intersections and doors that can be recognized with a cane alread plays a major role in how blind people navigate. \n\n
  • Now lets look at how blind people navigate familiar environments using a cognitive map they have of this evnrionment. . So the user navigates and senses their environment with a cane. Okay so the user finds a wall, hey it finds a hallway intersection. \n\nSo the identification of landmarks and in this case tactile landmarks, such as walls, hallway intersections and doors that can be recognized with a cane alread plays a major role in how blind people navigate. \n\n
  • Now lets look at how blind people navigate familiar environments using a cognitive map they have of this evnrionment. . So the user navigates and senses their environment with a cane. Okay so the user finds a wall, hey it finds a hallway intersection. \n\nSo the identification of landmarks and in this case tactile landmarks, such as walls, hallway intersections and doors that can be recognized with a cane alread plays a major role in how blind people navigate. \n\n
  • Now lets look at how blind people navigate familiar environments using a cognitive map they have of this evnrionment. . So the user navigates and senses their environment with a cane. Okay so the user finds a wall, hey it finds a hallway intersection. \n\nSo the identification of landmarks and in this case tactile landmarks, such as walls, hallway intersections and doors that can be recognized with a cane alread plays a major role in how blind people navigate. \n\n
  • So we propose a navigation system that seamlessly integrates with how users with visual impairments already navigate and we do this by combining elements of existing indoor navigation systems. \n\nWe’re using deadreckoning because it can be implemtned on a smartphone but we increasing the accuracy of dead reckongin using a sensor / beacon based approach, where we turn the user into a sensor by having them confirm presence of anticipated tactile landmarks along their path. \n\n
  • For representing our environment we use a 3D model, as that can convey information such as ramps and low ceilings that are impediments to a blind user. Models are created in Sketchup and a simple geometry parser turns this into a navigable 2D map which is more suitable for path planning. \nThe parser extracts navigable space, and identifies landmarks such as doors, slopes, and hallway intersections. \nOther types of landmarks are manually added to the 2d map.\nThe use of 3d models as opposed to 2d models is further motivated as such models are becoming increasingly available on Google Earth. \n
  • Using the 2D map and a start and target location we compute the shortest path using A-star. \nWe then parse this path into directions which are of the form: \nMove to a landmark where we use strategies such as wall following and door counting. \nTurn directions, or an action on a landmark such as open a door. \n
  • These directions are provided to the user using synthetic speech. \nUsers provide input to our system by confirming the successful execution of the command by tapping their screen upon which the next direction is provided. \n
  • These directions are provided to the user using synthetic speech. \nUsers provide input to our system by confirming the successful execution of the command by tapping their screen upon which the next direction is provided. \n
  • These directions are provided to the user using synthetic speech. \nUsers provide input to our system by confirming the successful execution of the command by tapping their screen upon which the next direction is provided. \n
  • These directions are provided to the user using synthetic speech. \nUsers provide input to our system by confirming the successful execution of the command by tapping their screen upon which the next direction is provided. \n
  • These directions are provided to the user using synthetic speech. \nUsers provide input to our system by confirming the successful execution of the command by tapping their screen upon which the next direction is provided. \n
  • A problem with this approach is that we are dealing with a lot of uncertainty, the sensors we’re using are noisy and there is uncertainty in the user input. So we are using a technique from the field of robotics which is a bayesian filtering called particle filters. Each particle contains an estimation of where the user is located and how probable this estimate is. \nThe particle locations are updated based on a distribution of error in steps detected and compass information. \nWeights are updated based on map information and on the user’s confirmation of landmarks. \nparticles with low weight are replaced with new ones to improve the localization. \nThe particle filters will also allow for self correction, e.g., we can detect whether a user has passed a landmark are able to generate new directions. \nWe use multiple filters as to also incorporating a different estimates for the user’s step length. \nThough this technique is pretty computational expensive but it can run on most recent smartphones. \n
  • A problem with this approach is that we are dealing with a lot of uncertainty, the sensors we’re using are noisy and there is uncertainty in the user input. So we are using a technique from the field of robotics which is a bayesian filtering called particle filters. Each particle contains an estimation of where the user is located and how probable this estimate is. \nThe particle locations are updated based on a distribution of error in steps detected and compass information. \nWeights are updated based on map information and on the user’s confirmation of landmarks. \nparticles with low weight are replaced with new ones to improve the localization. \nThe particle filters will also allow for self correction, e.g., we can detect whether a user has passed a landmark are able to generate new directions. \nWe use multiple filters as to also incorporating a different estimates for the user’s step length. \nThough this technique is pretty computational expensive but it can run on most recent smartphones. \n
  • A problem with this approach is that we are dealing with a lot of uncertainty, the sensors we’re using are noisy and there is uncertainty in the user input. So we are using a technique from the field of robotics which is a bayesian filtering called particle filters. Each particle contains an estimation of where the user is located and how probable this estimate is. \nThe particle locations are updated based on a distribution of error in steps detected and compass information. \nWeights are updated based on map information and on the user’s confirmation of landmarks. \nparticles with low weight are replaced with new ones to improve the localization. \nThe particle filters will also allow for self correction, e.g., we can detect whether a user has passed a landmark are able to generate new directions. \nWe use multiple filters as to also incorporating a different estimates for the user’s step length. \nThough this technique is pretty computational expensive but it can run on most recent smartphones. \n
  • A problem with this approach is that we are dealing with a lot of uncertainty, the sensors we’re using are noisy and there is uncertainty in the user input. So we are using a technique from the field of robotics which is a bayesian filtering called particle filters. Each particle contains an estimation of where the user is located and how probable this estimate is. \nThe particle locations are updated based on a distribution of error in steps detected and compass information. \nWeights are updated based on map information and on the user’s confirmation of landmarks. \nparticles with low weight are replaced with new ones to improve the localization. \nThe particle filters will also allow for self correction, e.g., we can detect whether a user has passed a landmark are able to generate new directions. \nWe use multiple filters as to also incorporating a different estimates for the user’s step length. \nThough this technique is pretty computational expensive but it can run on most recent smartphones. \n
  • A problem with this approach is that we are dealing with a lot of uncertainty, the sensors we’re using are noisy and there is uncertainty in the user input. So we are using a technique from the field of robotics which is a bayesian filtering called particle filters. Each particle contains an estimation of where the user is located and how probable this estimate is. \nThe particle locations are updated based on a distribution of error in steps detected and compass information. \nWeights are updated based on map information and on the user’s confirmation of landmarks. \nparticles with low weight are replaced with new ones to improve the localization. \nThe particle filters will also allow for self correction, e.g., we can detect whether a user has passed a landmark are able to generate new directions. \nWe use multiple filters as to also incorporating a different estimates for the user’s step length. \nThough this technique is pretty computational expensive but it can run on most recent smartphones. \n
  • A problem with this approach is that we are dealing with a lot of uncertainty, the sensors we’re using are noisy and there is uncertainty in the user input. So we are using a technique from the field of robotics which is a bayesian filtering called particle filters. Each particle contains an estimation of where the user is located and how probable this estimate is. \nThe particle locations are updated based on a distribution of error in steps detected and compass information. \nWeights are updated based on map information and on the user’s confirmation of landmarks. \nparticles with low weight are replaced with new ones to improve the localization. \nThe particle filters will also allow for self correction, e.g., we can detect whether a user has passed a landmark are able to generate new directions. \nWe use multiple filters as to also incorporating a different estimates for the user’s step length. \nThough this technique is pretty computational expensive but it can run on most recent smartphones. \n
  • A problem with this approach is that we are dealing with a lot of uncertainty, the sensors we’re using are noisy and there is uncertainty in the user input. So we are using a technique from the field of robotics which is a bayesian filtering called particle filters. Each particle contains an estimation of where the user is located and how probable this estimate is. \nThe particle locations are updated based on a distribution of error in steps detected and compass information. \nWeights are updated based on map information and on the user’s confirmation of landmarks. \nparticles with low weight are replaced with new ones to improve the localization. \nThe particle filters will also allow for self correction, e.g., we can detect whether a user has passed a landmark are able to generate new directions. \nWe use multiple filters as to also incorporating a different estimates for the user’s step length. \nThough this technique is pretty computational expensive but it can run on most recent smartphones. \n
  • A problem with this approach is that we are dealing with a lot of uncertainty, the sensors we’re using are noisy and there is uncertainty in the user input. So we are using a technique from the field of robotics which is a bayesian filtering called particle filters. Each particle contains an estimation of where the user is located and how probable this estimate is. \nThe particle locations are updated based on a distribution of error in steps detected and compass information. \nWeights are updated based on map information and on the user’s confirmation of landmarks. \nparticles with low weight are replaced with new ones to improve the localization. \nThe particle filters will also allow for self correction, e.g., we can detect whether a user has passed a landmark are able to generate new directions. \nWe use multiple filters as to also incorporating a different estimates for the user’s step length. \nThough this technique is pretty computational expensive but it can run on most recent smartphones. \n
  • \n
  • So prior to the user study I present today we did two studies. \nthe first study we conducted with blindfolded users where we evaluated the effectiveness of metric directions versus landmark based directions, where we found that landmark based directions containing fewer but more distinguishable landmarks gave much better performance.\n\nAs the localization was performed offline, a second study with blindfolded users explored runtime direction provision and localization on the phone, where we also explored the use of multiple filters for estimating user’s step length.\n
  • In this study we tested our system with the intended target demographic. \nStudies were performed in our engineering building. Multiple floor building with hallways, labs, \n\nWe created 11 paths over two different floors. Landmarks included doors, hallway intersections water coolers and floor transitions. This image shows the map of the second floor. \n
  • We recruited six users with visual impairmetns trhough the local chapter of the national federation of hte blind. \n3 were female and the average age was 51 years. \n3 of these users were totally blind, 2 legally blind and one had low vision. \n\nAll used a cane for navigation. Most importantly none of hte subjects had been in the engineering building before. \n
  • For ground truth measurment we used a commercial beacon based localization system called stargazer. \nReflective tags are installed in the ceiling and the user wears a camera and computing equipment on a belt to localize the user. This system has an accuracy of about 2cm. From a cost perspective it is interesting to note that the beacon based system took two students 3 days to install and cost $3,000 where our 3d model took one student about 3 hours to create and annotate\n
  • Users were able to complete 85% of the paths succesfully which we defined as being able to reach the target destination with their cane. \nWe found an average localization error of 1.85 error which seems large but that is within the sensing range of a blind user. \n\nQualitaitve results were acquired through interviews and a questionnaire. \nOverall users found the directions easy to foloow, \n\nPaths that involved counting doors had the lowest succesrate as it becomes more difficult to pick up steps. \n
  • One thing we would like to investigate in future work is test our system in more complex environmetns, the engineering building has narrow hallways, so it is difficult to get lost. Other environments, for example, a library or airport contain more open spaces where veering will become a larger problem. \n\nOne promising area to address this is with regard to path planning, where currently the system computes the shortest path using A* this may not always be the most reliable\n
  • \n
  • The User as a Sensor: Navigating Users with Visual Impairments in Indoor Spaces using Tactile Landmarks
