Head and Neck
Topographical view
Surface anatomy - neck <ul><li>Hyoid </li></ul><ul><li>Thyroid cartilage </li></ul><ul><li>Cricoid cartilage </li></ul><ul...
Surface anatomy - neck <ul><li>Inion </li></ul><ul><li>Trapezius </li></ul><ul><li>Trasversocostal muscle group </li></ul>...
Bony Landmark Trails
Bony Landmark Trails
Bony Landmark Trails
Muscles of the Head, Neck and Face
Sternocleidomastoid <ul><li>Action </li></ul><ul><ul><li>Bilateral:  Extends the head, assists in respiratio when the head...
Sternocleidomastoid <ul><ul><li>Supine </li></ul></ul><ul><ul><li>Locate the  matoid process, medial clavicle  and the  to...
Sternocleidomastoid <ul><ul><li>Palpate along the borders of the SCM </li></ul></ul><ul><ul><li>Follow it behind the earlo...
Test for SCM
Test for SCM <ul><li>Patient:  Supine with elbows bent and hands beside the head, resting on table </li></ul><ul><li>Fixat...
Scalene muscles <ul><li>Anterior scalene </li></ul><ul><li>Middle scalene </li></ul><ul><li>Posterior scalene </li></ul><u...
Anterior scalene <ul><li>Origin </li></ul><ul><ul><li>TP of 3 rd  through 6 th  cervical vertebrae (ant. tubercle)  </li><...
Middle scalene <ul><li>Origin </li></ul><ul><ul><li>TP of 3 rd  through 7 th  cervical vertebrae (post. tubercle) </li></u...
Posterior scalene <ul><li>Origin </li></ul><ul><ul><li>TP of 5 th  through 7 th  cervical vertebrae (post. tubercle) </li>...
Scalenes as a group <ul><ul><li>Supine </li></ul></ul><ul><ul><li>Cradle the head to allow for easier palpation </li></ul>...
Masseter <ul><ul><li>Supine </li></ul></ul><ul><ul><li>Locate  zygomatic arch  and  angle of the mandible </li></ul></ul><...
Temporalis <ul><ul><li>Supine and locate the zygomatic arch </li></ul></ul><ul><ul><li>Place your finger pads 1 inch super...
Temporalis <ul><ul><li>To locate the insertion site of the temporalis tendon, ask pt. to open her mouth wide </li></ul></u...
Occipitofrontralis <ul><li>Frontalis fibers </li></ul><ul><ul><li>supine </li></ul></ul><ul><ul><li>place fingers on the f...
Splenius muscles
Splenius muslces <ul><li>7. Splenius cervicis </li></ul><ul><li>8. Splenius capitis </li></ul>
Splenius muscles <ul><li>Action </li></ul><ul><ul><li>Entire muscle; bilateral contraction extends the cervical spine and ...
Splenius capitis <ul><ul><li>Prone, locate the upper fibers of the trapezius </li></ul></ul><ul><ul><li>Isolate the lat. e...
Both splenii muscles <ul><ul><li>Supine with head rotated 45° away from the side palpating </li></ul></ul><ul><ul><li>Crad...
Suboccipitalis Rectus capitis posterior major Rectus capitis post. minor   Oblique capitis superior Oblique capitis inferior
Suboccipitalis <ul><li>Rectus capitis posterior major </li></ul><ul><li>Rectus capitis posterior minor </li></ul><ul><li>R...
Rectus capitis posterior major <ul><li>A:  Bilateral contraction extends the head. Unilateral contraction rotates the head...
Rectus capitis posterior minor <ul><li>A:  Bilateral contraction extends the head. Unilateral contraction rotates the head...
Oblique capitis superior <ul><li>A:  Bilateral contraction extends the head. Unilateral contraction tilts the head to the ...
Oblique capitis inferior <ul><li>A:  Bilateral contraction extends the head. Unilateral contraction rotates the head to th...
Suboccipitalis <ul><ul><li>Supine position </li></ul></ul><ul><ul><li>Cradle the head in both hands </li></ul></ul><ul><ul...
Suboccipitals <ul><ul><li>Prone position </li></ul></ul><ul><ul><li>Locate lat. edge of the trapezius’ upper fiber </li></...
Test for posterolateral  neck extensor
Test for posterolateral  neck extensor <ul><li>Splenius capitis/cervicis, semispinalis capitis/cervicis, and cervical erec...
Upcoming SlideShare
Loading in …5
×

Head And Neck

18,912 views

Published on

Published in: Health & Medicine
  • Be the first to comment

Head And Neck

  1. 1. Head and Neck
  2. 2. Topographical view
  3. 3. Surface anatomy - neck <ul><li>Hyoid </li></ul><ul><li>Thyroid cartilage </li></ul><ul><li>Cricoid cartilage </li></ul><ul><li>SCM muscle </li></ul><ul><li>Sternum </li></ul><ul><li>Chassaignac’s tubercles </li></ul><ul><li>Sternal notch </li></ul>
  4. 4. Surface anatomy - neck <ul><li>Inion </li></ul><ul><li>Trapezius </li></ul><ul><li>Trasversocostal muscle group </li></ul><ul><li>C7 spinous process </li></ul><ul><li>T1 spinous process </li></ul><ul><li>Nuchal ligament </li></ul><ul><li>Post. facet joint </li></ul><ul><li>Suboccipital muscle </li></ul><ul><li>Greator occipital nerve </li></ul>
  5. 5. Bony Landmark Trails
  6. 6. Bony Landmark Trails
  7. 7. Bony Landmark Trails
  8. 8. Muscles of the Head, Neck and Face
  9. 9. Sternocleidomastoid <ul><li>Action </li></ul><ul><ul><li>Bilateral: Extends the head, assists in respiratio when the head is fixed </li></ul></ul><ul><ul><li>Unilateral: Tilts the head to the same side, rotates the head to the opposite side </li></ul></ul><ul><li>Origin </li></ul><ul><ul><li>Sternal head: Manubrium </li></ul></ul><ul><ul><li>Clavicular head: Medial third of the clavicle </li></ul></ul><ul><li>Insertion </li></ul><ul><ul><li>Mastoid process and superior nuchal line </li></ul></ul><ul><li>Innervation </li></ul><ul><ul><li>Acessory nerve and direct branches from the cervical plexus (C1-2) </li></ul></ul>
  10. 10. Sternocleidomastoid <ul><ul><li>Supine </li></ul></ul><ul><ul><li>Locate the matoid process, medial clavicle and the top of the sternum </li></ul></ul><ul><ul><li>Ask pt. to raise his head very slightly off the table as you palpate SCM </li></ul></ul>
  11. 11. Sternocleidomastoid <ul><ul><li>Palpate along the borders of the SCM </li></ul></ul><ul><ul><li>Follow it behind the earlobe and then down to the clavicle and sternum </li></ul></ul>
  12. 12. Test for SCM
  13. 13. Test for SCM <ul><li>Patient: Supine with elbows bent and hands beside the head, resting on table </li></ul><ul><li>Fixation: If the anterior abdominal muscles are weak, the examiner can provide fixation by exerting firm, downward pressure on the thorax </li></ul><ul><li>Test: Anterolateral neck flexion </li></ul><ul><li>Pressure: Against the temporal region of the head in an obliquely posterior direction </li></ul>
  14. 14. Scalene muscles <ul><li>Anterior scalene </li></ul><ul><li>Middle scalene </li></ul><ul><li>Posterior scalene </li></ul><ul><li>Actions of scalenes muscles </li></ul><ul><ul><li>Unilaterally: Laterally flex the head and neck to the same side, rotate head and enck to the opposite side </li></ul></ul><ul><ul><li>Bilaterally: Elevate the ribs during inhalation, flex the head and neck </li></ul></ul>
  15. 15. Anterior scalene <ul><li>Origin </li></ul><ul><ul><li>TP of 3 rd through 6 th cervical vertebrae (ant. tubercle) </li></ul></ul><ul><li>Insertion </li></ul><ul><ul><li>1 st rib </li></ul></ul><ul><li>Innervation </li></ul><ul><ul><li>Cervical and brachial plexus (C3-6) </li></ul></ul>
  16. 16. Middle scalene <ul><li>Origin </li></ul><ul><ul><li>TP of 3 rd through 7 th cervical vertebrae (post. tubercle) </li></ul></ul><ul><li>Insertion </li></ul><ul><ul><li>1 st rib </li></ul></ul><ul><li>Innervation </li></ul><ul><ul><li>Cervical and brachial plexus (C3-6) </li></ul></ul>
  17. 17. Posterior scalene <ul><li>Origin </li></ul><ul><ul><li>TP of 5 th through 7 th cervical vertebrae (post. tubercle) </li></ul></ul><ul><li>Insertion </li></ul><ul><ul><li>2 nd rib </li></ul></ul><ul><li>Innervation </li></ul><ul><ul><li>Cervical and brachial plexus (C3-6) </li></ul></ul>
  18. 18. Scalenes as a group <ul><ul><li>Supine </li></ul></ul><ul><ul><li>Cradle the head to allow for easier palpation </li></ul></ul><ul><ul><li>Place your finger pad along the ant. and lat. sides of the neck b/w SCM and trapezius </li></ul></ul>
  19. 19. Masseter <ul><ul><li>Supine </li></ul></ul><ul><ul><li>Locate zygomatic arch and angle of the mandible </li></ul></ul><ul><ul><li>Place your fingers b/w these bony landmarks and palpate the surface of the masseter </li></ul></ul><ul><ul><li>Ask pt. to alternately clench and relax her jaw </li></ul></ul>
  20. 20. Temporalis <ul><ul><li>Supine and locate the zygomatic arch </li></ul></ul><ul><ul><li>Place your finger pads 1 inch superior to the arch </li></ul></ul><ul><ul><li>Ask pt. to alternately clench and relax her jaw </li></ul></ul>
  21. 21. Temporalis <ul><ul><li>To locate the insertion site of the temporalis tendon, ask pt. to open her mouth wide </li></ul></ul><ul><ul><li>Locate and explore the coronoid process </li></ul></ul>
  22. 22. Occipitofrontralis <ul><li>Frontalis fibers </li></ul><ul><ul><li>supine </li></ul></ul><ul><ul><li>place fingers on the forehead </li></ul></ul><ul><ul><li>ask pt. to raise his eyebrows </li></ul></ul><ul><li>Occipitalis fibers </li></ul><ul><ul><li>supine or prone </li></ul></ul><ul><ul><li>locate sup. nuchal line </li></ul></ul><ul><ul><li>slide fingers 1 inch superiorly </li></ul></ul>
  23. 23. Splenius muscles
  24. 24. Splenius muslces <ul><li>7. Splenius cervicis </li></ul><ul><li>8. Splenius capitis </li></ul>
  25. 25. Splenius muscles <ul><li>Action </li></ul><ul><ul><li>Entire muscle; bilateral contraction extends the cervical spine and head, unilateral contraction flexes and rotates the head to the same side </li></ul></ul><ul><li>Origin </li></ul><ul><ul><li>Splenius cervicis: Spinous process of T3-T6 vertebrae </li></ul></ul><ul><ul><li>Splenius capitis: Spinous process of C3-T3 vertebrae </li></ul></ul><ul><li>Insertion </li></ul><ul><ul><li>Splenius cervicis: Transverse process of C1-2 </li></ul></ul><ul><ul><li>Splenius capitis: Lateral superior nuchal line, mastoid process </li></ul></ul><ul><li>Innervation </li></ul><ul><ul><li>Lateral branches of dorsal rami of spinal nerves C1-6 </li></ul></ul>
  26. 26. Splenius capitis <ul><ul><li>Prone, locate the upper fibers of the trapezius </li></ul></ul><ul><ul><li>Isolate the lat. edge of the trapezius by extending pt’s head slightly </li></ul></ul><ul><ul><li>Palpate just lateral to the trapezius and follow the oblique fiber up to the mastoid process </li></ul></ul>
  27. 27. Both splenii muscles <ul><ul><li>Supine with head rotated 45° away from the side palpating </li></ul></ul><ul><ul><li>Cradle the head with one hand while the other hand locates the lamina groove of the upper cervical vertebrae </li></ul></ul>
  28. 28. Suboccipitalis Rectus capitis posterior major Rectus capitis post. minor Oblique capitis superior Oblique capitis inferior
  29. 29. Suboccipitalis <ul><li>Rectus capitis posterior major </li></ul><ul><li>Rectus capitis posterior minor </li></ul><ul><li>Rectus capitis superior </li></ul><ul><li>Rectus capitis inferior </li></ul>
  30. 30. Rectus capitis posterior major <ul><li>A: Bilateral contraction extends the head. Unilateral contraction rotates the head to the same side </li></ul><ul><li>O : SP of the axis </li></ul><ul><li>I : Inferior nuchal line of the occiput </li></ul><ul><li>N : Suboccipital </li></ul>
  31. 31. Rectus capitis posterior minor <ul><li>A: Bilateral contraction extends the head. Unilateral contraction rotates the head to the same side </li></ul><ul><li>O : Tubercle of the posterior arch of the atlas </li></ul><ul><li>I : Inferior nuchal line of the occiput </li></ul><ul><li>N : Suboccipital </li></ul>
  32. 32. Oblique capitis superior <ul><li>A: Bilateral contraction extends the head. Unilateral contraction tilts the head to the same side and rotates it to the opposite side </li></ul><ul><li>O : TP of Atlas </li></ul><ul><li>I : Above the insertion of the rectus capitis posterior major </li></ul><ul><li>N : Suboccipital </li></ul>
  33. 33. Oblique capitis inferior <ul><li>A: Bilateral contraction extends the head. Unilateral contraction rotates the head to the same side </li></ul><ul><li>O : Sp of the axis </li></ul><ul><li>I : TP of the atlas </li></ul><ul><li>N : Suboccipital </li></ul>
  34. 34. Suboccipitalis <ul><ul><li>Supine position </li></ul></ul><ul><ul><li>Cradle the head in both hands </li></ul></ul><ul><ul><li>Passively extending the neck a bit </li></ul></ul><ul><ul><li>Locate sup. nuchal line and spinous process of C2 </li></ul></ul><ul><ul><li> Suboccipital span the area between these two landmarks </li></ul></ul>
  35. 35. Suboccipitals <ul><ul><li>Prone position </li></ul></ul><ul><ul><li>Locate lat. edge of the trapezius’ upper fiber </li></ul></ul><ul><ul><li>Palpating beside the level of C1 , place one finger at the lateral edge of the trapezius </li></ul></ul><ul><ul><li>Slowly sink medially into the suboccipitalis </li></ul></ul>
  36. 36. Test for posterolateral neck extensor
  37. 37. Test for posterolateral neck extensor <ul><li>Splenius capitis/cervicis, semispinalis capitis/cervicis, and cervical erector muscles </li></ul><ul><li>Patient: Prone with elbows bent and hands overhead, resting on the table </li></ul><ul><li>Fixation: None necessary </li></ul><ul><li>Test: Posterolateral neck extension, with the face turned toward the side being tested </li></ul><ul><li>Pressure: Against the posterolateral aspect of the head in an anterolateral direction </li></ul>

×
