The Art and
 Science of the
Painless Injection
  Edward Brant DDS, MS
     St. James, NY
Welcome, Your Patients
     Thank you




                         2
Origins of my commitment




                       3
With all the benefits of LA-Pts
hate getting the needle




                            4
Benefits of a
Pain Free Practice
• Low stress to pt and operator
• Render care comfortably and
  predictably
• Pt loyalty ...
We Really Need Adequate LA
We Really Need Adequate LA




                        8
Factors Effecting Duration
             In Perio Cases
• Variation in
  individual response
  – Different pts will
    res...
Short Acting
• Short acting
  – pulpal anesthesia = approx 30 min.
  – Soft tissue anesthesia = approx 1.5 hrs
     • Mepi...
• Intermediate Acting
Typical LA’s      – pulpal anesthesia =
                    approx 60 min.
                  – Soft ...
Pharmacology of LA’s
• With infilration anesthesia the amounts
  used can get high in perio cases.
  – Half mouth root pla...
Systemic Effects of Dental LA’s
                     –       Distribution
                         •     once absorbed int...
Pharmacology of LA’s
• How they are metabolized:
  – Liver
  – Enzymes in the bloodstream
• Toxicity depends on [LA] in th...
Maximum Recommended
            Doses for Typical LA’s
• Short acting
  – Mepivicaine 3% (54mg per carpule)
        – Carb...
Half-Life of Dental LA’s
General Rule for Avoiding Toxic Doses

 • One Carpule for every 20 pounds




                                     18
Toxicity depends on how much
      LA is in the bloodstream
• Low/Moderate Overdose
  Levels
  – Confusion
  – Apprehensio...
Toxicity depends on how
      much LA is in the
         bloodstream
• At higher toxic OD levels, the primary
  clinical m...
General
      Considerations
• LA overdose can occur more easily in:
  – Children
  – The ederly
  – Medically complex pts
Overdose of LA - Treatment
• Stop dental treatment
• Oxygen
• Monitor vital signs
• Reassure patient, allow time for drug ...
Why Do We Use Epinephrine

• Retard Systemic Absorption
• Prolonged Effect




                               23
How Much Epi Can We Give?




                       24
Use of Epinephrine in Local
   Anesthetics in Patients With
Significant Cardiovascular Disease
  • Numerous studies have
 ...
Beta Blockers
• Cardioselective(β-1)
   – acebutol(Sectral), atenolol(Tenormin), betaxolol
     (Kerlone), bisoprolol(Zebe...
Why Can’t We Use Epi in
Pregnant Patients?
  • Crosses the Placeneta
  • Pregnancy Category C
    – Evidence of teratogeni...
Pregnancy Risk Classification
   of Local Anesthestics
Recap
•   Why
•   What Do We Use
•   How Do LA’s Work
•   How Much To Use
•   What Happens If We Give Too Much




       ...
Basic Injection
 Technique
• Armamentarium
  – Needle Sizes
    • 30 Gauge
       – smallest used
       – Dark blue
     ...
Workhorses For Infiltration




                          31
Basic Injection Technique
Basic Injection Technique
Placement of the Topical
Basic Injection Technique
"Gate Control Theory"

• "Everyone has two different types of nerves.
  One type transmits pain and the other transmits
  ...
Common Causes of
             Discomfort
• (1) Initial puncture.
   – This can be reduced by use of topical anesthetic and...
Tissue taut vsualize the needle
        tip at membrane
Continuously inject
 while advancing
Tissue taut - pull tissue
over needle tip for initial puncture
Finger Rests, Tissue taut,
mucosa is pulled over needle tip




                           42
Basic Injection Technique
• Continuous Slow Injection while
  advancing
  – Need to deposit at apices and move the
    bol...
44
The Most Pain Free Area to
Inject in the Max Arch
Anatomical Considerations
For Maxillary Arch Infiltration
Walking the LA fluid mesial
and distal
• First carpule – aim to numb the mesial of the
  first molar to the distal of the ...
Walking the LA fluid mesial
• Third carpule –
   – Use Lidocaine and
     inject into original
     site (premolar/canine
...
What If The Palate Needs
       More Pain Control?
• Multiple infiltrations   • Aim for the nasopalatine
                 ...
What If The Palate Needs
More Pain Control?
I Got Tired Of Peeling People
       Off The Ceiling
52
Multiple Intraseptals
• Will give
  overlapping
  areas of
  anesthetize
  palatal
  gingiva
Interseptal Injection
Bend the needle to
 facilitate access
Example of Intraseptal for Palatal anesthesia
Factors Effecting The
   Success of Infiltration in
• Lack of pulpal Anesthesia
  – Canine
  – Molar
• Very Often Palatal
...
Conclusion of Maxillary
Injection Technique
• Questions
• Basic Armamentarium
• Basic Technique
Anatomical Considerations
For Mandibular Arch
• Nerves Of Interest For Infiltration
  – Mental Nerve
  – Long Buccal Nerve...
Basic Mental Foramen
Injection and Anatomy




                        60
61
How Do We Obtain Lingual
Anesthesia?
How Do We Obtain Lingual
Anesthesia?
• The same way we
  obtained palatal
  anesthesia….
  – Multiple Interseptal
    inje...
64
65
Do Not Forget The Crossover
 On The Buccal And The

• Still add LA in the
  floor of the mouth
  just lingual to the
  lat...
Buccal and Lingual Crossover
    Analgesia and PDL of
Contralateral Centaral Incisor




                            67
Supplemental Injection
• PDL Injection
  – Used most
    commonly to
    anesthetize the
    contra-lateral
    central in...
Timeline for Accomplishing Half-mouth Sc and RP
1. Start with about 3 carpules
   – 2 carpules in the max.
           • Ci...
Practically Speaking
 • How do you know when to block the
   lower arch?
   – Self report tooth sensitivity
   – Operator ...
Inferior Nerve Block
Needle insertion point for
block              • Topical
                    • Use 30 g first
                    • Open wi...
Numb the needle tract first




• Use long 30 g needle and inject as you advance
• Not looking for successful block on fir...
Needle Tract
Anesthesia Examples
Needle Tract
Anesthesia Examples
Complications
• Bleeding
• Buccal fat pad
• Epi rxn
• Sensation of throat enlarging
• Sensation of not being able to breat...
For Profound Anesthesia
                 • Tingling and
                   numbness
                   does not mean
     ...
Mylohyoid Nerve
Penetration Depth For Block
                     • Use 27 g
                     • “Need to
                       contact...
Concluding Remarks
• Causes of Discomfort during Injection
  – Choice of needle and anesthetic
  – Initial puncture
    • ...
81
82
Supplemental Injection
• Mylohyoid nerve
Height of Injection
Block Anesthesia Example
               • Use 27 g
               • “Need to contact
                 bone”
              ...
Causes of Discomfort during
    Injection
•   This can be reduced by use of topical anaesthetic and by
    keeping the sur...
Any Questions??????????
How Do We Obtain Lingual
Anesthesia?
Needle Tract
Infiltration on the
 Mandibular Arch
Example of Anesthetizing Cross-over
How Do We Obtain Lingual
Anesthesia?
Mental and buccal nerve




               Nerves Of Interest For Infiltration
                   Mental Nerve
           ...
