1.
From PSD to WordPress Theme:
Bringing designs to life
Derek Christensen

2.
(name)
(email) derek@derekchristensen.com
(website)
media-spine.com
@derekdac
quora.com/Derek-Christensen
github.com/derekdac

3.
designer v developer
• most designers are not developers. there are
things that look good on a poster that don't work
well on a website
• walk before you run – as you start out, don’t try
to be too unique
• if you’re a designer, sit with a developer for a few
days to learn some of the constraints that exist
• if you’re a developer, sit with a designer for a few
days to learn some of the elements of good
design

4.
considerations
• overlapping design elements
• custom font
• clouds cut in half
• category icons in two colors
• background texture overlay
• only front page design provided
• not sliced

5.
slicing
• identify the elements
• transparent background
• slice
• save for web and devices

6.
things to remember
• you don’t have to slice everything at once
• don’t slice text unless you really need to
– use CSS3 @font-face instead
– don’t use images for words in menus
• CSS sprites
• multiple use of the same image - slice
once, reuse

7.
layer-based slicing
• faster
• flatten and combine layers
• less control

8.
building your own theme

9.
starter/base themes
• skeleton
• bones
• starkers
• roots
• hybrid
• thesis
• genesis

10.
child theme
/********************************************************
Theme Name: Whim
Theme URI: http://whimapp.com
Description: A custom theme for Whim based on the Bones starter
theme
Author: Derek Christensen
Author URI: http://www.media-spine.com
Version: 1.0
Tags: html5, framework, css3, development
Template: bones
********************************************************/

11.
start building
• low-hanging fruit
• hundreds of right ways to do it – the perfect is
the enemy of the good
• study and understand the structure of your
parent theme

12.
body {
/* Fallback if browser cannot support CSS3 gradients */
background-color: #abc5df;
background-image: url("background_tall.jpg") ;
background-position: top;
background-repeat: repeat-x fixed;
background: -webkit-gradient(radial, center center, 0, center
center, 460, from(#fff), to(#abc5df)); /* Safari 4-5, Chrome 1-9 */
background: -webkit-radial-gradient(circle, #fff, #abc5df); /* Safari
5.1+, Chrome 10+ */
background: -moz-radial-gradient(circle, #fff, #abc5df); /* Firefox 3.6+ */
background: -ms-radial-gradient(circle, #fff, #abc5df); /* IE 10 */
}

13.
footer {
background-color:#394253;
height:185px;
margin-top:0;
border-top:0;
padding: 0 0 0 0;
}

14.
#content {
width: 960px;
margin: 0 auto;
padding: 0;
}

15.
body:before {
display: block;
height: 0px;
content: url(background_cloud.png);
float: right;
}
:before selector inserts content before the content of that element

16.
#slideshow {
background-image: url(background_skyline.png);
background-position: right bottom;
background-repeat: no-repeat;
}

17.
<div id="content" class="clearfix">
<div id="slideshow" class="clearfix">
<div id="iphone" class="clearfix">
</div> <!-- end #iphone -->
<div id="text" class="clearfix">
</div><!-- end #text -->
<div id="download" class="clearfix">
</div> <!-- end #download -->
</div> <!-- end #slideshow -->
</div> <!-- end #content -->

18.
#iphone{
height: 575px;
width: 300px;
background-image: url(iphone4frame.png);
background-repeat: no-repeat;
float: left;
}

19.
#text {
background: transparent;
height: 250px;
width: 620px;
color: #394253;
font-family: Arial, Helvetica, Verdana;
font-size: 14pt;
text-decoration: none;
float:right;
}

20.
#download{
background-image: url(download.png);
background-repeat: no-repeat;
height:135px;
}

21.
@font-face {
font-family: SerifBD;
src: url('serifbd.ttf');
}

22.
h1, .h1, h2, .h2, h3, .h3 {
font-family: SerifBD, Arial, Helvetica, Verdana;
color: #394253;
}
h2, .h2 {
margin: 0 0 7px 0;
}
h3, .h3 {
margin: 0 0 7px 0;
font-size: 14pt
}
h1 a, h2 a, h3 a {
font-family: SerifBD, Arial, Helvetica, Verdana;
color: #394253;
}

23.
nav[role=navigation] {}
nav[role=navigation] .menu ul {
background: transparent;
padding-top: 32px;
}
nav[role=navigation] .menu ul li {}
nav[role=navigation] .menu ul li a {
color: #394253;
display: block;
padding: 10px 20px;
font-family: SerifBD, Arial, Helvetica, Verdana;
font-size: 14pt;
}
nav[role=navigation] .menu ul li a:hover {
background: #fff;
-moz-border-radius: 17px;
-webkit-border-radius: 17px;
border-radius: 17px;
}
nav[role=navigation] .menu ul li.current-menu-item a, .nav ul li.current_page_item a {
background: #fff;
-moz-border-radius: 17px;
-webkit-border-radius: 17px;
border-radius: 17px;
}

24.
<body <?php body_class(); ?>>
<div id="container">
<header role="banner">
<div id="inner-header" class="clearfix">
<nav role="navigation" class="clearfix">
<?php bones_main_nav();?>
</nav>
</div> <!-- end #inner-header -->
</header> <!-- end header -->

25.
header[role=banner] {
position: relative;
width: 960px;
margin: 0 auto;
padding: 0;
}

26.
#navigation{
width: 620px;
float: right;
}

27.
<p id="logo">
<a href="<?php echo home_url(); ?>" rel="nofollow">
<img src="wp-content/themes/whim/WhimLogo.png" />
</a>
</p>

28.
#logo{
width: 340px;
margin-bottom:0px;
float:left;
}

29.
http://whimapp.com

30.
tools
• e-text editor (Like textmate, but for windows)
• XAMPP
• adobe photoshop (or gimp)
• adobe illustrator (or inkscape)
• firebug for firefox

31.
web resources
• http://slideshare.net/derekdac/
• http://css3please.com/
• http://css-tricks.com/
• http://nettuts.com/
• http://stackexchange.com/
• http://fontsquirrel.com/
• http://yoast.com/wordpress-theme-anatomy/

32.
questions?
(name)
(email) derek@derekchristensen.com
(website)
http://slideshare.net/derekdac/
