Gamatronic Solutions for
Data Centers


 Isio Rosental – Regional Manager LATAM
Gamatronic Solutions for Data
          Centers
Power +: Gamatronic
   Modular UPS
Power+
The Next Generation UPS System


POWER+ is a unique concept in modular UPS power
solutions: it is scalable accordin...
Modular Design Advantages

Scalability
High Efficiency
Flexibility
Redundancy
High Reliability
Low TCO
Gamatronic
             Pioneer of Modular Technology

•   Why did Gamatronic decide to enter the modular market?

•   Why...
Why did Gamatronic decide to enter
            the modular market?

Gamatronic always looks for advanced solutions in orde...
Why a modular solution is good
                     for Data Centers?
Power consumption in Data Center


                 ...
Where Does data center
                      power go?

                               Data Center - Energy Consumption

 ...
How to improve data center
                 efficiency?
•   Rightsizing: match the sizing of IT components
    more closel...
Since when did Gamatronic begin to
    manufacture modular power
            solutions?
 Gamatronic began manufacturing mo...
Where are Gamatronic's modular
solutions presently being installed?
Gamatronic's modular UPS Power+ systems are
presently ...
Where are Gamatronic's modular
solutions presently being installed?


More than 10,000 Power+ modular UPS systems
have bee...
Power+
Advantages
Power+ Grows With Your Business

Power+ is a true modular , user
upgraded system.

As load increases system can be
expande...
Extra High Efficiency

Conventional          Gamatronic                  Your Benefit:
   UPS            Modular UPS POWER...
Savings
     Using an 100kVA/80kW Power+ UPS can save close to 20,000$ in
     5 years, assuming electricity cost of 0.12$...
N+1 Redundancy
    Conventional           Gamatronic                Your Benefit:
       UPS             Modular UPS POWER...
Redundancy



                         +
       6 modules for 50KVA                 Two complete 50KVA units
       N+1 re...
Redundancy
•     Implementing two conventional 50KVA
    units will be much more expensive than one
    unit of 50KVA+10KV...
Reliability

Thanks to the modularity concept, the
Power+ UPS system is super reliable
towards the load.

If a module fail...
Customer Friendly
                         Serviceability

    Conventional             Gamatronic               Your Bene...
User friendly

     Specially designed to adhere
     to high standards
     demanded by office
     environments, Power+
...
Extra High Power Density

 Conventional         Gamatronic              Your Benefit:
    UPS           Modular UPS POWER+...
Green Power
     Green power features:
       3-5% THDi
       Unity power factor
       96% AC/AC efficiency
       98% D...
Green Power
     Results:
      Environmental friendly
      Lowers data center cooling expenses
      Money savings on el...
Green and Clean Power

     Conventional           Gamatronic                 Your Benefit:
        UPS             Modula...
Power+ Models
Power+ UPS family

                        Modular




     Power+ Classic    Power+ Free Style   Power + 19”




29
Power+ FS ( Free Style)

• 19” variant of the
  Power+ UPS

• Sub rack up to
  50KVA ( 20U) or
  100KVA ( 30U)

• Perfect ...
Power+ 19”

• 19” Variant of the
  Power+ UPS up to
  20KVA
• Available in 2
  configurations :
- Sub rack for 10KVA
  (4U...
Power+ UPS family

             Stand Alone




Power+ SA 10KVA        Power + SA 30,40KVA
Power+
      Design &
     Components


33
Design
                              System
                             Controller


    UPS
   modules




             ...
System Controller



                          LCD Panel    Navigation and
                                      Operation...
System Controller
     • System Controller is a redundant device, that
       provides:
           •   All system measurem...
UPS module




37   Inverter            Rectifier
Power+ Static Switch
                                            Inverter,
                                          bypas...
Static switch
     • The Static Switch module (ST/SW) will
       transfer the critical load to bypass in case of
       u...
Battery Connection



40
Power+
      Centralized battery
     Centralized battery of Power+ UPS family


                ~ =              = ~
    ...
Power+
                Centralized battery
     Batteries are charged simultaneously by all modules,
     independent of t...
Power+
     Horizontal Parallel Connection




43
Parallel Connection
     For even more power and extra redundancy,
     Power+ can be put in parallel de-centralized
     ...
Conclusions
Perfect for End Users

• Vertical & horizontal redundancy N+N

• High Reliability due to the modular / redundancy design

...
Power+
     standards Approval


47
Certificates




     EN-62040         ISO9001   EMC




48
Certificates




     UL (for 208v)       CE (for 400v)   Lightning




49
Geye


Control and Management Solution for Data-
      Centers and Computer Rooms
The Geye




•    Perfect “All Built In” solution for control, management and
     monitoring of computer rooms and data-c...
Features




• Accepts input from up to 5 temperature sensors.
• 8 inputs dry contacts.
• 4 outputs dry contacts.
• RS232 ...
Geye main screen
Change your point of view                           Server room

                                              Smoke detec...
References
Clients – Data Centers
References

South Africa
Power+ installation
Telkom HQ.
Total of 4x100KVA
in parallel
References

UK
Installation in
Warwick University.
A Power+ Free Style
(19”) 40KVA with
extended back up
time
References

Chile
VTR, the main provider of
cable TV and broadband
internet in Chile , has the
Power+ for their data-
cent...
References
Russia
Installation in AGAVA
Hosting of Power+
Parallel UPS 400KVA
(Jan 2009 )
References

    South Africa

Installation of Power+
       FS 500KVA
    Parallel System
      (Jan 2009)
Thank you
