  1. 1. SWTBot UI test automation framework Cristian Tepus – Software Engineer
  2. 2. Introduction <ul><li>SWTBot is an open-source Java based UI/functional testing tool for testing SWT and Eclipse based applications. </li></ul><ul><li>SWTBot project is in Incubation Phase in Eclipse </li></ul><ul><li>Latest version is </li></ul><ul><li>Similar to a click-robot, it solves SWT handling complexity by providing easy UI API </li></ul><ul><li>SWTBot’s API can integrate in JUnit framework in order to develop and run test cases </li></ul>
  3. 3. Starting with example <ul><li>SWTWorkbenchBot bot = new SWTWorkbenchBot(); </li></ul><ul><li>// click on a button with the given text </li></ul><ul><li>SWTBotButton button = bot. button ( &quot;Hello, World!&quot; ); </li></ul><ul><li>button. click (); </li></ul><ul><li>// click on the File>New menu item </li></ul><ul><li>SWTBotMenu file = bot. menu ( &quot;File&quot; ); </li></ul><ul><li>SWTBotMenu new = file. menu ( &quot;New&quot; ); new. click (); </li></ul>
  4. 4. Finding widgets <ul><li>// find the textbox that has a label 'Username:‘ </li></ul><ul><li>SWTBotText username = bot.textWithLabel(&quot;Username:&quot;); </li></ul><ul><li>// Easily identify buttons using the tooltip </li></ul><ul><li>SWTBotToolbarButton save = bot.toolbarButtonWithTooltip(&quot;Save&quot;); </li></ul><ul><li>// find windows using the window title </li></ul><ul><li>SWTBotShell shell =;New Project Wizard&quot;); </li></ul><ul><li>You can find controls using: </li></ul><ul><li>text </li></ul><ul><li>label </li></ul><ul><li>group </li></ul><ul><li>tooltip </li></ul><ul><li>ids </li></ul><ul><li>combination of all or any of the above </li></ul>
  5. 5. Custom matchers <ul><li>import static org.eclipse.swtbot.swt.finder.matchers.WidgetMatcherFactory .*; </li></ul><ul><li>// match : </li></ul><ul><li>// widgets of type 'Label' </li></ul><ul><li>// with regular expression 'Welcome, <USERNAME>' </li></ul><ul><li>Matcher matcher = allOf( </li></ul><ul><li>widgetOfType(Label. class ), </li></ul><ul><li>withRegex( &quot;Welcome, .*&quot; ) ); </li></ul><ul><li>// get the label that matches the matcher </li></ul><ul><li>SWTBotLabel label = new SWTBotLabel((Label) bot. widget (matcher)); </li></ul>
  6. 6. Perform actions on widgets <ul><li>button. click (); </li></ul><ul><li>radioButton. select (); </li></ul><ul><li>comboBox. select ( “Option 12&quot; ); </li></ul><ul><li>text. typeText ( “This is a demo string&quot; ); </li></ul><ul><li>tree. expandNode ( &quot;MyProject&quot; , &quot;src&quot; , &quot;com&quot; , &quot;example&quot; , &quot;; ); </li></ul>
  7. 7. Querying widgets for state <ul><li>SWTBot provides a few operations to query the state of widgets. Some generic queries like: getText(), isEnabled(), isVisible() are available on all widgets </li></ul><ul><li>Ex. </li></ul><ul><li>boolean checked = checkbox. isChecked (); </li></ul><ul><li>boolean selected = radio. isSelected (); </li></ul>
  8. 8. Screenshots <ul><li>SWTBot generates a screenshot when an error occurs. The screenshot will be saved and available within the test plugin’s directory </li></ul>
  9. 9. Test Execution <ul><li>SWTBot framework allows for tests to be executed in 2 ways: </li></ul><ul><li>Manually, by launching them from launch configuration (similar with junit tests); </li></ul><ul><li>From command line, using shell script or ant. For this mode, headless execution framework is necessary (see for more details) </li></ul>
  10. 10. What’s new in Eclipse Helios <ul><li>Updated to support Junit 4.8 instead 4.7 (included Categories). </li></ul><ul><li>Bug Fixes: </li></ul><ul><ul><li>300103 - SWTBotGefEditor.directEditType does not work </li></ul></ul><ul><ul><li>301260 - SWTBotGefEditor.mouseDrag(String,int,int) doesn't drag node, it reduces them </li></ul></ul><ul><ul><li>305430 - Create the parent screenshot dir when capturing the screenshot. </li></ul></ul>
  11. 11. Useful links <ul><li> </li></ul><ul><li> </li></ul><ul><li> </li></ul><ul><li> </li></ul><ul><li> </li></ul><ul><li> </li></ul>
