Node Powered Mobile
By Tim Caswell
Saturday, June 5, 2010

Node Powered Mobile
By Tim Caswell
Saturday, June 5, 2010

Simple but Different
Saturday, June 5, 2010

What is needed
Saturday, June 5, 2010

What is needed
• Simple Interface
• Light Code
• Networked Data
• Real-Time Data
• Free Deployment
• Open Workflow
Saturday, June 5, 2010

What is needed
• Simple Interface • HTML, SVG, CSS
• Light Code • JavaScript
• Networked Data • HTTP Services
• Real-Time Data • PubSub
• Free Deployment • Browser Apps
• Open Workflow • It’s just text!
Saturday, June 5, 2010

Connect
We’ll use a new node
framework that “connects”
the mobile browser to data
on the server.
Saturday, June 5, 2010

It’s like Japanese Legos
Saturday, June 5, 2010

Pre-Built Blocks
Connect.createServer([
{filter: "log"},
{filter: "body-decoder"},
{filter: "conditional-get"},
{filter: "cache"},
{filter: "gzip"},
{provider: "cache-manifest", root: root},
{provider: "static", root: root}
]);
Saturday, June 5, 2010

And easy too!
Saturday, June 5, 2010

method-override.js
var key;
// Initialize any state (on server startup)
exports.setup = function (env) {
key = this.key || "_method";
};
// Modify the request stream (on request)
exports.handle = function(err, req, res, next){
if (key in req.body) {
req.method = req.body[key].toUpperCase();
}
next();
};
Saturday, June 5, 2010

response-time.js
exports.handle = function(err, req, res, next){
var start = new Date,
writeHead = res.writeHead;
res.writeHead = function(code, headers){
res.writeHead = writeHead;
headers['X-Response-Time'] =
(new Date - start) + "ms";
res.writeHead(code, headers);
};
next();
};
Saturday, June 5, 2010

Well, actually, it’s
not always easy.
Saturday, June 5, 2010

static.js
Saturday, June 5, 2010

static.js
var fs = require('fs'),
Url = require('url'),
Path = require('path');
var lifetime = 1000 * 60 * 60; // 1 hour browser cache lifetime
var DEFAULT_MIME = 'application/octet-stream';
module.exports = {
setup: function (env) {
this.root = this.root || process.cwd();
},
handle: function (err, req, res, next) {
// Skip on error
if (err) {
next();
return;
}
var url = Url.parse(req.url);
var pathname = url.pathname.replace(/..+/g, '.'),
filename = Path.join(this.root, pathname);
if (filename[filename.length - 1] === "/") {
filename += "index.html";
}
Saturday, June 5, 2010

static.js
// Buffer any events that fire while waiting on the stat.
var fs = require('fs'), var events = [];
Url = require('url'), function onData() {
Path = require('path'); events.push(["data"].concat(Array.prototype.slice.call(arguments)));
}
var lifetime = 1000 * 60 * 60; // 1 hourfunction onEnd() {
browser cache lifetime
events.push(["end"].concat(Array.prototype.slice.call(arguments)));
}
var DEFAULT_MIME = 'application/octet-stream';
req.addListener("data", onData);
module.exports = { req.addListener("end", onEnd);
setup: function (env) { fs.stat(filename, function (err, stat) {
this.root = this.root || process.cwd();
}, // Stop buffering events
req.removeListener("data", onData);
handle: function (err, req, res, next) {req.removeListener("end", onEnd);
// Skip on error
if (err) { // Fall through for missing files, thow error for other problems
next(); if (err) {
return; if (err.errno === process.ENOENT) {
} next();
var url = Url.parse(req.url); // Refire the buffered events
events.forEach(function (args) {
req.emit.apply(req, args);
var pathname = url.pathname.replace(/..+/g, '.'),
});
filename = Path.join(this.root, pathname);
return;
if (filename[filename.length - 1] === "/") {
filename += "index.html";
}
Saturday, June 5, 2010

static.js
// Buffer any events that fire while waiting on the stat.
var fs = require('fs'), var events = [];
Url = require('url'), function onData() {
Path = require('path'); events.push(["data"].concat(Array.prototype.slice.call(arguments)));
}
var lifetime = 1000 * 60 * 60; // 1 hourfunction onEnd() {
browser cache lifetime
events.push(["end"].concat(Array.prototype.slice.call(arguments)));
}
var DEFAULT_MIME = 'application/octet-stream';
req.addListener("data", onData);
module.exports = { req.addListener("end", onEnd);
(err);
setup: function (env) { fs.stat(filename, function (err, stat) {
rn;
this.root = this.root || process.cwd();
}, // Stop buffering events
req.removeListener("data", onData);
req.removeListener("end", onEnd);
the file directly using (err, req, res, next) {
handle: function buffers
ile(filename, function error data) {
// Skip on (err,
if (err) { // Fall through for missing files, thow error for other problems
err) {
next(); if (err) {
next(err);
return; if (err.errno === process.ENOENT) {
return;
} next();
var url = Url.parse(req.url); // Refire the buffered events
writeHead(200, {
events.forEach(function (args) {
ontent-Type": Mime.type(filename),
req.emit.apply(req, args);
ontent-Length": pathname = url.pathname.replace(/..+/g, '.'),
var data.length,
});
filename = Path.join(this.root, pathname);
ast-Modified": stat.mtime.toUTCString(),
return;
/ Cache in browser for 1 year
ache-Control": (filename[filename.length - 1] === "/") {
if "public max-age=" + 31536000
filename += "index.html";
end(data); }
Saturday, June 5, 2010

static.js
// Buffer any events that fire while waiting on the stat.
var fs = require('fs'), var events = [];
Url = require('url'), function onData() {
Path = require('path'); events.push(["data"].concat(Array.prototype.slice.call(arguments)));
}
var lifetime = 1000 * 60 * 60; // 1 hourfunction onEnd() {
browser cache lifetime
}; events.push(["end"].concat(Array.prototype.slice.call(arguments)));
}
var DEFAULT_MIME = 'application/octet-stream';
// Mini mime module for static file serving
req.addListener("data", onData);
module.exports = { var req.addListener("end", onEnd);
Mime = {
(err); type: function getMime(path) (err, stat) {
setup: function (env) { fs.stat(filename, function {
rn; var index = path.lastIndexOf(".");
this.root = this.root || process.cwd();
}, if (index < buffering events
// Stop 0) {
return DEFAULT_MIME;
req.removeListener("data", onData);
} req.removeListener("end", onEnd);
the file directly using (err, req, res, next) { type = Mime.TYPES[path.substring(index).toLowerCase()] || DEFAULT_MIME;
handle: function buffers
var
ile(filename, // function error data) {
Skip on (err,
if (err) { return Fall through for missing files, thow error "; charset=utf-8" : type;
// (/(text|javascript)/).test(type) ? type + for other problems
err) { },
next(); if (err) {
next(err);
return; if (err.errno === process.ENOENT) {
return; TYPES : { ".3gp"
} next(); "video/3gpp",
:
var url = Url.parse(req.url); ".a" Refire the buffered events
// : "application/octet-stream",
writeHead(200, { ".ai" : "application/postscript",
events.forEach(function (args) {
ontent-Type": Mime.type(filename), ".aif" req.emit.apply(req, args);
: "audio/x-aiff",
ontent-Length": pathname = url.pathname.replace(/..+/g, '.'), "audio/x-aiff",
var data.length,
".aiff" :
});
filename = Path.join(this.root, pathname);
ast-Modified": stat.mtime.toUTCString(), ".asc"
return; "application/pgp-signature",
:
/ Cache in browser for 1 year ".asf" : "video/x-ms-asf",
ache-Control": (filename[filename.length - 1] === "/") {
if "public max-age=" + 31536000
".asm" : "text/x-asm",
filename += "index.html";
".asx" : "video/x-ms-asf",
end(data); }
".atom" : "application/atom+xml",
".au" : "audio/basic",
Saturday, June 5, 2010 ".avi" : "video/x-msvideo",

static.js
// Buffer any events that fire while waiting on the stat.
var fs = require('fs'), : "video/x-flv",var events = [];
".flv"
".for" : function onData() {
Url = require('url'), "text/x-fortran",
Path = require('path');
".gem" events.push(["data"].concat(Array.prototype.slice.call(arguments)));
: "application/octet-stream",
}
".gemspec" : "text/x-script.ruby",
var lifetime = ".gif" 60: *"image/gif", function onEnd() {
1000 * 60; // 1 hour browser cache lifetime
}; events.push(["end"].concat(Array.prototype.slice.call(arguments)));
".gz" : "application/x-gzip",
".h" : "text/x-c", }
var DEFAULT_MIME = 'application/octet-stream';
// Mini mime module for static file serving
req.addListener("data", onData);
".hh" : "text/x-c",
module.exports ".htm"
= { var Mime = {
: "text/html", req.addListener("end", onEnd);
(err); ".html" : "text/html",
rn; setup: function (env) "image/vnd.microsoft.icon", getMime(path) (err, stat) {
".ico" : { type: function
fs.stat(filename, function {
var index = path.lastIndexOf(".");
this.root = this.root || process.cwd();
".ics" : "text/calendar",
}, ".ifb" : "text/calendar", (index < buffering events
if // Stop 0) {
return DEFAULT_MIME;
req.removeListener("data", onData);
".iso" : "application/octet-stream",
}
: req, res, next) {req.removeListener("end", onEnd);
the file directly ".jar" (err,"application/java-archive",
handle: function buffers
using var type = Mime.TYPES[path.substring(index).toLowerCase()] || DEFAULT_MIME;
ile(filename, // function error: data) {
Skip".java"
on (err, "text/x-java-source",
if (err) { return Fall through for missing files, thow error "; charset=utf-8" : type;
// (/(text|javascript)/).test(type) ? type + for other problems
".jnlp" : "application/x-java-jnlp-file",
err) { },
next();
".jpeg" : "image/jpeg", if (err) {
next(err);
return;
".jpg" : "image/jpeg", if (err.errno === process.ENOENT) {
return; TYPES : { ".3gp" : "video/3gpp",
} ".js" : "application/javascript", next();
var url = Url.parse(req.url); ".a" Refire the buffered events
// : "application/octet-stream",
writeHead(200, { ".json" : "application/json", ".ai" : "application/postscript",
".log" : "text/plain", events.forEach(function (args) {
ontent-Type": Mime.type(filename), ".aif" req.emit.apply(req, args);
: "audio/x-aiff",
ontent-Length": pathname = url.pathname.replace(/..+/g, '.'), "audio/x-aiff",
var data.length, "audio/x-mpegurl",
".m3u" :
".aiff" :
filename = Path.join(this.root, pathname);
".m4v" : "video/mp4", });
ast-Modified": stat.mtime.toUTCString(), ".asc"
return; "application/pgp-signature",
:
/ Cache in browser ".man" year "text/troff",
for 1 :
".asf" : "video/x-ms-asf",
ache-Control": (filename[filename.length - 1] === "/") {
if "public max-age=" + 31536000
".mathml" : "application/mathml+xml",
".asm" : "text/x-asm",
filename += : "application/mbox",
".mbox" "index.html";
".asx" : "video/x-ms-asf",
end(data); } ".mdoc" : "text/troff",
".me" : "text/troff", ".atom" : "application/atom+xml",
".au" : "audio/basic",
".mid" : "audio/midi",
Saturday, June 5, 2010 ".avi" : "video/x-msvideo",

static.js
// Buffer any events that fire while waiting "text/x-c",
".cc" : on the stat.
var fs = require('fs'), : "video/x-flv",var events = [];
".flv" ".chm" : "application/vnd.ms-htmlhelp",
Url = require('url'), "text/x-fortran",
".for" : function onData() { ".class" : "application/octet-stream",
Path = require('path');
".gem" events.push(["data"].concat(Array.prototype.slice.call(arguments)));
: "application/octet-stream", ".com" : "application/x-msdownload",
}
".gemspec" : "text/x-script.ruby", ".conf" : "text/plain",
var lifetime = ".gif" 60: *"image/gif", function onEnd() {
1000 * 60; // 1 hour browser cache lifetime ".cpp" : "text/x-c",
}; events.push(["end"].concat(Array.prototype.slice.call(arguments)));
".crt" : "application/x-x509-ca-cert",
".gz" : "application/x-gzip",
var DEFAULT_MIME = 'application/octet-stream';
".h" : "text/x-c", } ".css" : "text/css",
// Mini mime module for static file serving
req.addListener("data", onData); ".csv" : "text/csv",
".hh" : "text/x-c",
module.exports ".htm"= { var Mime = {
: "text/html", req.addListener("end", onEnd); ".cxx" : "text/x-c",
".html" : "text/html", ".deb" : "application/x-debian-package",
(err);
rn; setup: function (env) "image/vnd.microsoft.icon", getMime(path) (err, stat) {
".ico" : { type: function
fs.stat(filename, function { ".der" : "application/x-x509-ca-cert",
var index = path.lastIndexOf(".");".diff" : "text/x-diff",
this.root = this.root || process.cwd();
".ics" : "text/calendar",
}, ".ifb" : "text/calendar", (index < buffering events
if // Stop 0) { ".djv" : "image/vnd.djvu",
return DEFAULT_MIME;
req.removeListener("data", onData);
".djvu" : "image/vnd.djvu",
".iso" : "application/octet-stream",
}
: req, res, next) {req.removeListener("end", onEnd); ".dll" : "application/x-msdownload",
the file directly ".jar" (err,"application/java-archive",
handle: function buffers
using var type = Mime.TYPES[path.substring(index).toLowerCase()] || DEFAULT_MIME;
// function error: data) {
Skip".java"
on (err, "text/x-java-source", ".dmg" : "application/octet-stream",
ile(filename, return Fall through for missing files, thow error "; charset=utf-8" : type;
if (err) { // (/(text|javascript)/).test(type) ? : "application/msword",
".jnlp" : "application/x-java-jnlp-file", ".doc" type + for other problems
err) { },
next();
".jpeg" : "image/jpeg", if (err) { ".dot" : "application/msword",
next(err);
return;
".jpg" : "image/jpeg", if (err.errno === process.ENOENT) { "application/xml-dtd",
".dtd" :
return; TYPES : { ".3gp" : "video/3gpp", ".dvi"
} ".js" : "application/javascript", next(); : "application/x-dvi",
var url = Url.parse(req.url); ".a" Refire the buffered events : "application/java-archive",
// : "application/octet-stream",
".ear"
writeHead(200, { ".json" : "application/json", ".ai" : "application/postscript",
".log" : "text/plain", events.forEach(function (args) : "message/rfc822",
".eml" {
ontent-Type": Mime.type(filename), ".aif" req.emit.apply(req, args); : "application/postscript",
: "audio/x-aiff",
".eps"
ontent-Length": pathname = url.pathname.replace(/..+/g, '.'), "audio/x-aiff",
var data.length, "audio/x-mpegurl",
".m3u" :
".aiff" :
filename = Path.join(this.root, pathname);
".m4v" : "video/mp4", }); ".exe" : "application/x-msdownload",
ast-Modified": stat.mtime.toUTCString(), ".asc"
return; "application/pgp-signature",
: ".f" : "text/x-fortran",
/ Cache in browser ".man" year "text/troff",
for 1 :
".asf" : "video/x-ms-asf",
".f77" : "text/x-fortran",
ache-Control": (filename[filename.length - 1] === "/") {
if "public max-age=" + 31536000
".mathml" : "application/mathml+xml",
".asm" : "text/x-asm", ".f90"
filename += : "application/mbox",
".mbox" "index.html"; : "text/x-fortran",
".asx" : "video/x-ms-asf",
end(data); } ".mdoc" : "text/troff",
".me" : "text/troff", ".atom" : "application/atom+xml",
".au" : "audio/basic",
".mid" : "audio/midi",
Saturday, June 5, 2010 ".avi" : "video/x-msvideo",

static.js
// Buffer any events that fire while waiting "text/x-c",
".cc" : on the stat.
var fs = require('fs'), : "video/x-flv",var events = [];
".flv" ".chm" : "application/vnd.ms-htmlhelp",
Url = require('url'), "text/x-fortran",
".for" : function onData() { ".class" : "application/octet-stream",
Path = require('path');
".gem" events.push(["data"].concat(Array.prototype.slice.call(arguments)));
: "application/octet-stream", ".com" : "application/x-msdownload",
}
".gemspec" : "text/x-script.ruby", ".conf" : "text/plain",
var lifetime = ".gif" 60: *"image/gif", function onEnd() {
1000 * 60; // 1 hour browser cache lifetime ".cpp" : "text/x-c",
}; events.push(["end"].concat(Array.prototype.slice.call(arguments)));
".crt" : "application/x-x509-ca-cert",
".gz" : "application/x-gzip",
var DEFAULT_MIME = 'application/octet-stream';
".h" : "text/x-c", } ".css" : "text/css",
// Mini mime module for static file serving
req.addListener("data", onData); ".csv" : "text/csv",
".hh" : "text/x-c",
module.exports ".htm"= { var Mime = {
: "text/html", req.addListener("end", onEnd); ".cxx" : "text/x-c",
".html" : "text/html", ".deb" : "application/x-debian-package",
(err);
rn; setup: function (env) "image/vnd.microsoft.icon", getMime(path) (err, stat) {
".ico" : { type: function
fs.stat(filename, function { ".der" : "application/x-x509-ca-cert",
var index = path.lastIndexOf(".");".diff" : "text/x-diff",
this.root = this.root || process.cwd();
".ics" : "text/calendar",
}, ".ifb" : "text/calendar", (index < buffering events
if // Stop 0) { ".djv" : "image/vnd.djvu",
return DEFAULT_MIME;
req.removeListener("data", onData);
".djvu" : "image/vnd.djvu",
".iso" : "application/octet-stream",
} req.removeListener("end", onEnd);
".dll" : "application/x-msdownload",
the file directly ".jar"".bmp" req, "image/bmp", type = Mime.TYPES[path.substring(index).toLowerCase()] || DEFAULT_MIME;
handle: function (err,"application/java-archive",
using buffers : res, next) {
:
var
// function error: data) {
Skip".java"
on (err, "text/x-java-source",
".bz2" : "application/x-bzip2", ".dmg" : "application/octet-stream",
ile(filename, return (/(text|javascript)/).test(type) ? : "application/msword", : type;
type + "; charset=utf-8"
err) { if (err) { : "text/x-c", // Fall through for missing files, thow error for other problems
".jnlp" : "application/x-java-jnlp-file",
".c" ".doc"
}, if (err) { ".dot" : "application/msword",
next(err); next(); ".cab"
".jpeg" : "image/jpeg",
: "application/vnd.ms-cab-compressed",
return;
".jpg" : "image/jpeg", if (err.errno === process.ENOENT) { "application/xml-dtd",
".dtd" :
return; TYPES : { ".3gp" : "video/3gpp", ".dvi"
} ".js" : "application/javascript", next(); : "application/x-dvi",
var url = Url.parse(req.url); ".a" Refire the buffered events : "application/java-archive",
// : "application/octet-stream",
".ear"
writeHead(200, { ".json" : "application/json", ".ai" : "application/postscript",
".log" : "text/plain", events.forEach(function (args) : "message/rfc822",
".eml" {
ontent-Type": Mime.type(filename), ".aif" req.emit.apply(req, args); : "application/postscript",
: "audio/x-aiff",
".eps"
ontent-Length": pathname = url.pathname.replace(/..+/g, '.'), "audio/x-aiff",
var data.length, "audio/x-mpegurl",
".m3u" :
".aiff" :
filename = Path.join(this.root, pathname);
".m4v" : "video/mp4", }); ".exe" : "application/x-msdownload",
ast-Modified": stat.mtime.toUTCString(), ".asc"
return; "application/pgp-signature",
: ".f" : "text/x-fortran",
/ Cache in browser ".man" year "text/troff",
for 1 :
".asf" : "video/x-ms-asf",
".f77" : "text/x-fortran",
ache-Control": (filename[filename.length - 1] === "/") {
if "public max-age=" + 31536000
".mathml" : "application/mathml+xml",
".asm" : "text/x-asm", ".f90"
filename += : "application/mbox",
".mbox" "index.html"; : "text/x-fortran",
".asx" : "video/x-ms-asf",
end(data); } ".mdoc" : "text/troff",
".me" : "text/troff", ".atom" : "application/atom+xml",
".au" : "audio/basic",
".mid" : "audio/midi",
Saturday, June 5, 2010 ".avi" : "video/x-msvideo",

Built-in Filter Modules
• Authentication • Error Handler
• Authorization • Gzip
• Body Decoder • Log
• Cache • Method Override
• Conditional Get • Response Time
• Debug • Session
Saturday, June 5, 2010

Built-in Data Providers
• Static • Cache Manifest
• Rest • Direct
• Router • JSON-RPC
• PubSub • More...
Saturday, June 5, 2010

Raphaël JS
Raphaël is a small
JavaScript library that
should simplify your
work with vector
graphics on the web.
Saturday, June 5, 2010

Multi-Touch Vectors
http://vimeo.com/11610421
Saturday, June 5, 2010

multitouch-demo.js
window.onload = function () {
var R = Raphael(0, 0, "100%", "100%"),
r = R.circle(100, 100, 50),
g = R.circle(210, 100, 50),
b = R.circle(320, 100, 50),
p = R.circle(430, 100, 50);
var start = function () {
this.ox = this.attr("cx");
this.oy = this.attr("cy");
this.animate({r: 70, opacity: .25}, 500, ">");
},
move = function (dx, dy) {
this.attr({cx: this.ox + dx, cy: this.oy + dy});
},
up = function () {
this.animate({r: 50, opacity: .5}, 500, ">");
};
R.set(r, g, b, p).drag(move, start, up);
};
Saturday, June 5, 2010

Creating Shapes
var R = Raphael(0, 0, "100%", "100%"),
r = R.circle(100, 100, 50)
.attr({fill: "hsb(0, 1, 1)"}),
g = R.circle(210, 100, 50)
.attr({fill: "hsb(.3, 1, 1)"}),
b = R.circle(320, 100, 50)
.attr({fill: "hsb(.6, 1, 1)"}),
p = R.circle(430, 100, 50)
.attr({fill: "hsb(.8, 1, 1)"});
Saturday, June 5, 2010

Attaching Events
function start() {
this.ox = this.attr("cx");
this.oy = this.attr("cy");
this.animate({r: 70, opacity: .25}, 500, ">");
}
function move(dx, dy) {
this.attr({cx: this.ox + dx, cy: this.oy + dy});
}
function up() {
this.animate({r: 50, opacity: .5}, 500, ">");
}
R.set(r, g, b, p).drag(move, start, up);
Saturday, June 5, 2010

Let’s combine them!
Saturday, June 5, 2010

• Serving static assets (HTML, CSS,
JS)
• Live Interaction (Pub Sub)
• Performance Tweaks (Cache, Gzip)
• Offline Mode (Cache Manifest)
• HTTP Request Logging
Saturday, June 5, 2010

app.js (stack)
require.paths.unshift("./lib");
var Connect = require('connect');
var root = __dirname + "/public";
module.exports = Connect.createServer([
{filter: "log"},
{filter: "body-decoder"},
{provider: "pubsub", route: "/stream",
logic: Backend},
{filter: "conditional-get"},
{filter: "cache"},
{filter: "gzip"},
{provider: "cache-manifest", root: root},
{provider: "static", root: root}
]);
Saturday, June 5, 2010

app.js (Backend)
var Backend = {
subscribe: function (subscriber) {
if (subscribers.indexOf(subscriber) < 0) {
subscribers.push(subscriber);
}
},
unsubscribe: function (subscriber) {
var pos = subscribers.indexOf(subscriber);
if (pos >= 0) {
subscribers.slice(pos);
}
},
publish: function (message, callback) {
subscribers.forEach(function (subscriber) {
subscriber.send(message);
});
callback();
}
};
Saturday, June 5, 2010

index.html
<!DOCTYPE html>
<html lang="en" manifest="cache.manifest">
<head>
<meta charset="utf-8" />
<meta name="apple-mobile-web-app-capable" content="yes">
<title>Node + Raphaël</title>
<link rel="stylesheet" href="style.css" type="text/css" />
<script src="raphael.js"></script>
<script src="client.js"></script>
</head>
<body>
<div id="holder"></div>
</body>
</html>
Saturday, June 5, 2010

Demo Time!
Saturday, June 5, 2010

http://github.com/extjs/connect
http://twitter.com/creationix
http://raphaeljs.com
http://nodejs.org
Saturday, June 5, 2010

Any
Questions
?
Saturday, June 5, 2010
