Monday, 5 November 12
Hi.I am chris                        mills.         ‣ Open standards advocate and             Education           agitator...
Monday, 5 November 12
useful stuff         ‣ dev.opera.com         ‣ webplatform.org         ‣ slideshare.net/             chrisdavidmills      ...
in this talk...         ‣ MQ: Beyond width and height         ‣ Other “responsive modules”         ‣ Legacy support       ...
Monday, 5 November 12
A quick flashbackMonday, 5 November 12
In the beginning...         ‣ There wasn’t much RWD         ‣ We only really looked at the             Web        on   des...
Ok. We had wapMonday, 5 November 12
Monday, 5 November 12
Monday, 5 November 12
Then the mobile web                   arrivedMonday, 5 November 12
Then the mobile web                   arrivedMonday, 5 November 12
Then the mobile web                   arrivedMonday, 5 November 12
Then the mobile web                   arrivedMonday, 5 November 12
media types             media="screen"             media="print"Monday, 5 November 12
media types             media="handheld"             media="tv"Monday, 5 November 12
small tv rant             “Searching, browsing,             updating and buffering are             not TV-like. In fact an...
small tv rant             “Searching, browsing,             updating and buffering are             not TV-like. In fact an...
Monday, 5 November 12
Back to the modern      worldMonday, 5 November 12
media queries             media="screen and (max-width: 481px)"             @media screen and (max-width: 481px) {        ...
media queriesMonday, 5 November 12
the mobile problemMonday, 5 November 12
viewport             <meta name="viewport"             content="width=device-width">Monday, 5 November 12
other rwd issuesMonday, 5 November 12
other rwd issuesMonday, 5 November 12
Other                        considerations         ‣ Making replaced elements             responsive         ‣ Bandwidth/...
replaced elementsMonday, 5 November 12
replaced elements             #related img {                   display: block;                   margin: 0 auto;          ...
be warned         ‣ Old IE versions don’t             support max-width, so you’ll             have to fallback to width: ...
file size also                          important         ‣ Users on slow connections             won’t       want to   do...
css resources easy                  to deal with         ‣ Use “mobile first”         ‣ Load smaller resources by         ...
Mobile first                           example             header { background: url(small-             image.png); }      ...
html5 video also                          well served                 <source src="crystal320.webm"             type="vide...
But html images are                 not so lucky              <img src="thats-all-folks.png"> ?Monday, 5 November 12
Various solutions         ‣ http://dev.opera.com/             articles/view/responsive-             images-problem/       ...
adaptive-images         ‣ adaptive-images.com         ‣ Add .htaccess and adaptive-             images.php to       your  ...
the picture element             <picture alt="a picture of something">                   <source src="mobile.jpg">        ...
suggested solutions         ‣ Srcset         ‣ New image formats?         ‣ Defined the media tests in             meta   ...
processing power         ‣ You might want to turn off             effects like shadows,             gradients and animatio...
resolutionMonday, 5 November 12
resolutionMonday, 5 November 12
resolutionMonday, 5 November 12
resolution                        64pxMonday, 5 November 12
resolution                        64px                               48pxMonday, 5 November 12
now we have hi                    fidelity devices         ‣ e.g. iPhone 4s is 960 x 640             pixels     at   326pp...
SOLUTIONS             <img src="500px_image.jpg" width="250">Monday, 5 November 12
SOLUTIONS             @media screen and (-o-min-device-pixel-             ratio: 3/2) {                   body { backgroun...
Monday, 5 November 12
soon to be                        replaced by             @media screen and (resolution: 1.5dppx)             {           ...
tell the truth with                  viewport             <meta name="viewport"             content="width=device-width,  ...
All good but...         ‣ Images may now start to look             a          little   small         ‣ You could serve lar...
control mechanisms         ‣ Currently tricky           ‣ Usual wisdom about web sites                 applies — make page...
supporting older               browsersMonday, 5 November 12
old ie versions         ‣ Lack support for media             queries         ‣ Although we don’t get old IE             on...
solutions         ‣ Provide fallbacks such as             simpler         layouts   or pixels             instead         ...
modernizr             <html lang="en-US" class="no-js">             <head>                   <script src="modernizr.js"></...
modernizr             <html class=" js flexbox canvas canvastext             webgl no-touch geolocation postmessage no-   ...
modernizr css         #wrapper:hover, #wrapper:focus {           transform: rotateX(180deg);         }Monday, 5 November 12
modernizr css         .no-csstransforms3d #wrapper #front {           transition: 0.8s all ease-in;         }         .no-...
modernizr JS         function rotateForm() {           if(Modernizr.cssanimations &&              Modernizr.csstransforms3...
@supports         @supports (display:flex) {           section { display: flex }           ...         }Monday, 5 November...
other responsive         css3 modulesMonday, 5 November 12
other responsive         css3 modulesMonday, 5 November 12
worthy of note         ‣ CSS device adaptation         ‣ Flexbox         ‣ Multi-col         ‣ (Regions, Grids, etc.)Monda...
CSS device                          adaptation         ‣ Because viewport is really             more        of   a CSS typ...
CSS device                        adaptation         <meta name="viewport"           content="width=550,           maximum...
Flex box         ‣ A spec for easier UI             layout         ‣ Makes certain layout tasks             much       eas...
Flex box         <section>           <article id="first"></article>           <article id="second"></article>           <a...
Monday, 5 November 12
Flex box         section {           display: flex;           flex-flow: row;         }         section {           displa...
Monday, 5 November 12
Flex box         section {           display: flex;           flex-flow: row;           align-items: center;         }Mond...
Monday, 5 November 12
Flex box         #first, #third {           order: 2;         }         #second {           order: 1;         }Monday, 5 N...
Monday, 5 November 12
Flex box         #first {           flex: 1;         }         #second {           flex: 1;         }         #third {    ...
Monday, 5 November 12
Flex box         #first {           flex: 1;         }         #second {           flex: 1;         }         #third {    ...
Monday, 5 November 12
multi col          ‣ A spec for breaking content              into      multiple   columns.          ‣ Column widths/numbe...
Multi col         article {           column-width: 20em;           column-gap: 2em;         }Monday, 5 November 12
Monday, 5 November 12
other future                   developmentsMonday, 5 November 12
matchmedia         if (window.matchMedia("(min-width:         400px)").matches) {           /* Do stuff for wider screens ...
script MQ         @media screen and (script) {...}         @media screen and not (script) {...}Monday, 5 November 12
hover MQ         The ‘hover’ media feature is         used to query whether the         primary pointing system used      ...
pointer MQ         @media screen and (pointer: coarse) {...}         ‣ none: The input mechanism of           the device d...
luminosity MQ         @media screen and (luminosity: dim) {...}         ‣ dim: The device is being used           in a dim...
other future MQs         @media (paged) and (interactive:0) {           // I am like a printer         }         @media (p...
other future MQs         @media (touch) and (max-width: 480) {           // looks like an smart phone         }         @m...
other future MQs         @media (remote) {           // TV or set-top box?         }         @media (remote) and (hover) {...
other future MQs         @media (network: v-slow) {...}         “It has been proposed. Most         people agree that it w...
“Subtle”     advertisement   Buy my bookMonday, 5 November 12
game over                                1up   0000000Monday, 5 November 12
game over                01.     dev.opera.com                02.     slideshare.net/chrisdavidmills                03.   ...
