Geosummit



Web mapping with vector data.
Is it the future ?


Cédric Moullet
geo.admin.ch / swisstopo
Web
Raster or vector?
NOW ?




        …millions of tiles….
How do we do that
now ?

          1. Prepare data
          2. Define symbology
          3. Generate tiles
          4. Publish tiles
          5. Render tiles
Do you need
interactions ?

    … workaround required …
Workaround 1: Server roundtrip

                   What can I find at this mouse position ?



Hover in the map
                                                      Let me ask the
                                                           database


                                                              Here is it
                    A point object has been found




Nice highlight !
Workaround 2: binary mask




  You can know that there is « something »
        Mouse interaction possible
Workaround 3: UTF Grid
UTFGrid provides a standard, scalable way of encoding data for hundreds or
thousands of features alongside your map tiles.
                 !######$$$$%%% %%%% % !
                             !#######$$$$%%%     %%%!
                           !!#####    $$$%%%     %%%!
                           !###### $$$$%%% %% %%%   !
                          !!!#### $$$$$%%%% %%%%    !
                       ! !###### $$$$$$%%%%%%%%%%   !
                     ! !!##### $$$$$$$%%%%%%%%%     !
                    !!!!!####      $$$$$$%%%%%%%%%% !
                    !!!!!####      $$$$$$%%%%%%%%%% !
                    !!!!!####      $$$$$%%%%%%%%%%% !
                    !!!!!#####% $$       %%%%%%%%%%%!
                    !!!!!### #          %%%%%%%%%%%%!
                    !!! #####      ''''%%%%%%%%%%%% !
                     !     ###       ('%%%%%%%%%%%% !
                        ) ### # ( ((%%%%%%%%%%%%
                       )) ##      (((((%%%%%%%%%%%%
                                                    !
                                                    !
                                                        Every character is associated
                       )) #
                        )
                                  ****(+%%%%%%%%%%%
                                   %**++++%%%%%%%%%
                                                    !
                                                    !
                                                        to a feature and its attribute
               .
                        , , ------*+++++%%%%%%%%%
                       ,,,,,------+++++++%%%%%%%%
                                                    !
                                                    !
                                                        information
               .. /,,,,,,------++++++%%%%%%%%%      !
               . //,,,,,,------000++000%%%%%%%      !
                  211,,,,,33------00000000%%%%%%    !
                 2221,,,,33333---00000000000%%%%    !
               222222,,,,3635550000000000000%%%     !
               222222,,,,6665777008900000000%%%     !
               22222::66666777788889900000 %%%%     !
               22222:;;;;%%=7%8888890 0         %%%%!
               22222;;;; ==??%%888888 00 %%%%%      !
               222222 ;; =??%%%8888             %%%%!
               222        ;;    ?A>>@@@           B%!
               CCC         ;;    DEE@@@           BB!




                            MapBox demonstrator
Vectors are not rendered


Server roundtrip: slow
Binary mask & UTF: problem with feature overlay
– no vector information
Any chance to render vectors

                   client side ?
Vector in Web: worflow
1. Vector Data   Data stored in a database or in files




                                                     Simplify and generalize data
            2. Prepare Data                          Transform in appropriate format




                                                                                       Service to deliver data
                                               3. Publish Data



                                                                                4. Render Data
                                                                                                                 View data
                                                                                                                 In browser
Technology       Data




Internet     Libraries
Technology
<canvas> is an HTML element            WebGL (Web Graphics Library) is
which can be used to draw              a JavaScript API for rendering
graphics via scripting (usually        interactive 3D graphics within any
JavaScript). Part of HTML5 specs.      compatible web browser without
                                       the use of plug-ins.
                                       Extend canvas capabilities




Scalable Vector Graphics (SVG) is      Vector Markup Language (VML) is
a family of specifications of an       a deprecated XML language used
XML-based file format for two-         to produce vector graphics.
dimensional vector graphics, both
static and dynamic (i.e. interactive
or animated).
OSS Libraries: Leaflet
Web Site: http://leaflet.cloudmade.com/
Source Code: https://github.com/CloudMade/Leaflet/
Demo: http://leaflet.cloudmade.com/examples/geojson-example.html
Vector renderers: SVG, VML

+ Modern, HTML5, CSS3
+ Light
+ Simplicity

-  Limited
-  Less flexibility

Vector rendering: limited to a few hundred of vector objects




           There are of course other + and -… I present only those that seem essential to me
OSS Libraries: Polymaps
Web Site: http://polymaps.org/
Source Code: https://github.com/simplegeo/polymaps
Demo: http://polymaps.org/ex/population.html
Vector renderers: SVG

+ Light

-  Limited
-  Less flexibility
-  Buggy / no IE support

Vector rendering: limited to a few hundred of vector objects




          There are of course other + and -… I present only those that seem essential to me
OSS Libraries: Tile5
Web Site: http://www.tile5.org/
Source Code: https://github.com/DamonOehlman/tile5
Demo: http://www.tile5.org/demos/playground/#geojson/world
Vector renderers: canvas, webGL

+ Light

-  Limited
-  Only one maintainer

Vector rendering: limited to a few hundreds of vector objects




          There are of course other + and -… I present only those that seem essential to me
OSS Libraries: Kothic JS
Web Site: http://wiki.openstreetmap.org/wiki/Kothic_JS
Source Code: https://github.com/kothic/kothic-js
Demo: http://kothic.org/js/
Vector renderers: canvas

+ optimized tile format

-  focus on OSM
-  small community

Vector rendering: limited to a few hundred of vector objects




         There are of course other + and -… I present only those that seem essential to me
OSS Libraries: OpenLayers
Web Site: http://www.openlayers.org/
Source Code: https://github.com/openlayers/openlayers
Demo: http://r2d2.stefanm.com/mapnik/demo.html
Vector renderers: SVG, VML, canvas

+ Very complete
+ Widely used
+ Very good code quality
+ Support all browsers

-  More complex
-  Partial HTML5 support

Vector rendering: limited to a few hundred of vector objects




         There are of course other + and -… I present only those that seem essential to me
Non OSS: GisCloud
Web Site: http://www.giscloud.com/
Demo: http://www.giscloud.com/map/16594/germany-6000000-features
Vector renderers: VML, canvas

+ impressive performance
+ SaaS
+ Replace desktop viewer

-  not standardized (tile format, rendering)
-  bad IE support

Vector rendering: almost unlimited




         There are of course other + and -… I present only those that seem essential to me
Data & Internet




The user can only see
what is on the screen
Bandwidth is limited
Data
        Screen




Always 1280 * 960 pixels
    (or a bit more or a bit less)
Data
               Vector Datasets




                                           7 Go



                       50 Mo


        5 Mo

12 ko



                 Size from 0 to infinite
                        (or a bit less)
Bandwidth: 5 MB/s        Internet
                         1400 s



                 10 s



          1s              7 Go



0.002 s          50 Mo


          5 Mo

 12 ko
Data




Zoom level dependent
strategy
Data
Strategy
- Transfer only visible data (relative size bigger than one
pixel, clustering for points)
-  Simplify geometry depending on zoom level (depending on
pixel size)


Optimization
- Transfer data in binary format (« as » an image, for
example)
-  Reduce coordinate information size by using relative
coordinates
-  Use binary mask
WebGL (Web Graphics Library) is a
JavaScript API for rendering interactive 3D
graphics within any compatible web
                                              Rendering
browser without the use of plug-ins.



WebGL works also for 2D and for raster
Demo – Demo

                     Client reprojection

  Client colorization                          Client rendering

                                  Client transformation
         Client treatment
Thanks Tom Payne – Camptocamp – for the demo implementation (WebGLMaps)
Vector in Web: worflow
1. Vector Data   Data stored in a database or in files




                                                     Simplify and generalize data
            2. Prepare Data                          Transform in appropriate format




                                                                                       Service to deliver data
            Screen                             3. Publish Data
           paradigm


                                                                                4. Render Data
                                                                                                                 View data
                                                                                                                 In browser

                                               No
                                            standard                                                 WebGL
My 2 cents
ü  WebGL offers new possibilities client side
ü  OSS software will soon support WebGL (Ongoing
code sprint about OpenLayers Three)
ü  Data generalization and simplification is essential
(zoom level dependent)
ü  Display models are treated client side (SLD)

-  A standardized vector tile web service is missing
Thank you for your attention




Cédric Moullet
Head of FSDI Web Infrastructure
swisstopo - COSIG

     cedric.moullet@swisstopo.ch


      cedricmoullet                map.geo.admin.ch
