Building Tropo Apps with Grails

  1. 1. Building Tropo Appswith GrailsChristopher Bartling
  2. 2. Summary 2■ What is Tropo?■ How do I integrate Tropo with Grails?■ Tropo WebAPI overview■ Lessons learned
  3. 3. Terminology 3■ IVR: Interactive Voice Response■ VoiceXML or VXML:■ CCXML: Call Control XML■ TTS: Text to Speech
  4. 4. What is Tropo? 4■ Cloud-based services for telephony and messaging ■ Make and receive phone calls ■ Use voice recognition ■ Messaging via SMS, IM, or Twitter■ Backed by Voxeo.com ■ Industry leader in IVR and VoIP solutions
  5. 5. Why should I care? 5■ Many applications benefit from voice and messaging user interfaces■ Tropo provides telephony and messaging infrastructure and APIs for integrating these services into your applications ■ Traditionally this was hosted in-house■ APIs insulate developers from needing to write in VoiceXML, CCXML, and other markups
  6. 6. How do I use it with Grails? 6■ Install the Tropo WebAPI Grails plugin (version 0.21) ■ tropo-webapi-grails ■ Provides the TropoBuilder object for building standard Tropo JSON documents ■ TropoService for provisioning and servicing Tropo applications
  7. 7. TropoBuilder 7■ Builds Tropo JSON response documents■ Provides an array of JSON objects to control the Tropo-based applications hosted in the cloud ■ ask, call, conference, hangup, message, on, record, redirect, reject, result, say, session, startRecording, stopRecording, transfer
  8. 8. TropoService 8■ Grails service for administering Tropo applications ■ Abstraction around Tropo’s REST API ■ Create, update, and delete Tropo applications ■ Provision phone numbers, IM addresses, tokens ■ Retrieve information about applications
  9. 9. Tropo.com 9■ Web-based administration UI ■ Create, update, and delete Tropo applications in the cloud ■ Provision telephone numbers (both local and toll- free) and IM accounts for your applications ■ Application debugging tool ■ Billing profile
  10. 10. Tropo Development 10■ Create your Grails application■ Add tropo-webapi-grails Grails plugin■ Create your starting endpoint in your Grails app■ Create application on tropo.com ■ Need externally available starting endpoint for your Grails app ■ Provision local phone number
  11. 11. Tropo WebAPI 11■ Use the TropoBuilder object to create Tropo-compliant JSON objects■ Tropo calls back to your application for instructions on how to power the IVR infrastructure in the Tropo cloud■ You application is a collection of interconnected endpoints, rendering Tropo JSON objects to control the IVR infrastructure in the Tropo cloud
  12. 12. Tropo WebAPI JSON objects 12
  13. 13. session 13■ Sent to your application in the first Tropo request■ The callId field identifies this request body to a unique call in Tropo ■ You will use the callId as the correlation identifier for all requests■ https://www.tropo.com/docs/webapi/session.htm
  14. 14. result 14■ Sent to your application in all subsequent requests from Tropo■ The callId field identifies this request body to a unique call in Tropo ■ You will use the callId as the correlation identifier for all requests■ https://www.tropo.com/docs/webapi/result.htm
  15. 15. say 15■ Say something to the caller ■ Can be TTS or pre-recorded audio ■ Does not wait for user response■ https://www.tropo.com/docs/webapi/say.htm
  16. 16. ask 16■ Say something to the caller and wait for a response from the caller ■ Can be TTS or audio file for say ■ Response can be collected speech or touch-tone keypad (DTMF) ■ The choices object specifies how Tropo handles user input■ https://www.tropo.com/docs/webapi/ask.htm
  17. 17. on 17■ Specifies event handling ■ continue ■ error ■ incomplete ■ hangup■ https://www.tropo.com/docs/webapi/on.htm
  18. 18. hangup 18■ Hangs up the current call.■ https://www.tropo.com/docs/webapi/hangup.htm
  19. 19. record 19■ Plays a prompt and then waits for a response from the caller, which it records■ Responses may be speech recognition or touch-tone keypresses (DTMF)■ At the conclusion of the recording, the collected audio file is sent to FTP or HTTP POST/Multipart Form endpoint
  20. 20. transfer 20■ Transfer an in-progress call to another destination or phone number ■ Can be a phone number or a SIP address■ https://www.tropo.com/docs/webapi/transfer.htm
  21. 21. startRecordingstopRecording 21■ Start and stop recording a call session■ Resultant recording can be sent via FTP or HTTP POST/Multipart form to a URL■ You have to provide an endpoint or FTP server to receive the binary file■ https://www.tropo.com/docs/webapi/startrecording.htm■ https://www.tropo.com/docs/webapi/stoprecording.htm
  22. 22. Lessons Learned 22■ Testing ■ Test call flow in isolation by using a testing Tropo application and a testing endpoint to bootstrap the call session appropriately ■ In the future, look to building an automated test runner that can be scripted and exercise the Grails app through HTTP calls
  23. 23. Lessons Learned 23■ The ask noinput and timeout APIs don’t work well ■ Issues with audio getting played out of sequence ■ Build this functionality into our call flow explicitly using on events
  24. 24. Lessons Learned 24■ Call recording is all or nothing ■ Unable to start and stop recording to allow for omission of sensitive data recording ■ We toggle recording for debugging call flow ■ Keep it off for production usage
  25. 25. Lessons Learned 25■ Call duration can be difficult to determine ■ Maintain a last Tropo callback timestamp on call session domain object ■ Update the timestamp on each Tropo callback invocation ■ Allows approximation of the call duration
  26. 26. Lessons Learned 26■ Abandoned calls can be difficult to determine ■ We used a Quartz job in Grails ■ Periodically inspect in-progress calls ■ If last Tropo callback timestamp is beyond a specified threshold, set the call session to abandoned
  27. 27. Contact Information 27■ Twitter: @cbartling■ Blog: http://bartling.blogspot.com■ https://bitbucket.org/cebartling/tropo-presentations

×
