INTRODUCTION• Thyroid nodules - common clinical findings - prevalence -  4% to 7% of adult population.•   Common in women....
• Difficult by clinical evaluation alone to make a correct  diagnosis. Hence it is essential that correct diagnosis is  ma...
AIMS AND OBJECTIVES• To study the advantage of FNAC as a simple procedure  for the diagnosis of goiter and to utilize it o...
MATERIALS AND METHODS• A prospective study was conducted at ASRAMS  hospital, Eluru from June 2010 to May 2012.• 221 patie...
• Careful palpation of the thyroid was done to guide  precisely the location for doing aspiration.• Details of the procedu...
• The material gets collected in the bore by capillary  suction. The needle hub was attached to air-filled syringe  and th...
• Out of 221 patients, 76 patients underwent surgeries like  hemithyroidectomy, subtotal and near total  thyroidectomies.•...
RESULTS AND OBSERVATIONS• Study design:        The present study deals with the fine needle  aspiration cytology of simple...
• Pre-operative diagnosis by FNAC was compared with  histopathology reports of the operative specimens.• The important obs...
Table1:Age distribution with SexAge in    Females           Males            TotalYears         No.    %      No.         ...
Table2: Duration Of ComplaintsDuration of complaints          %                         No.    Upto 6 months         99   ...
Table 3:Presenting ComplaintsPresenting complaint    No.      %Swelling front neck     82    37.1SolitaryDiffuse          ...
Table 4: Size of the swellingSize            No       %1-5 cm          157      716-10 cm         64       29Total        ...
Table 5: Hormone levelsTSH           No       %Normal        177      80Decreased     31       14Increased     13        6...
Table 6: Adequacy of sample Adequacy         No    % Satisfactory     219   99 Unsatisfactory    2     1 Total            ...
Table 7 : Nature of sampleNature of aspirate       No.     %Colloid                  77     34.84Hemorrhagic              ...
Table 8: Lesions on FNAC        Lesion   No.Benign           204Follicular       10Malignant         5Inadequate        2T...
Table 9: Benign lesions in present study               Disease                    No.   %Simple colloid goiter            ...
Table 10: Simple colloid and nodular goiter on            cytological study with Age and SexAge in         Females        ...
Table 11: Histopathology results of 76 patients        Benign              72        Malignant           4        Total   ...
Table 12: Distribution of malignant cases (n=4)  Papillary carcinoma                         2  Follicular variant of papi...
Table 13: Histopathological diagnosis Vs Cytological diagnosis        Diagnosis               Histology   Cytology        ...
Table 14 : Cytological diagnosis in 76 patients         Diagnosis             No.   % Simple & nodular colloid      40    ...
Table 15 : Correlation of Cytological diagnosis with           final Histopathological diagnosis                          ...
Table 16: Results of False negativesDiagnosis             FNAC            Histopathological                     diagnosis ...
• Cyto-histological concordance in the diagnosis of goiter  is 95.7%.(68/71 cases).• Analysis of the FNAC results obtained...
Fig 1: Colloid goiter. Abundant thick colloid with fewclusters of follicular epithelial cells(H&E, scanner view)
Fig 2: Colloid goiter. Varying sized follicles lined by flattened epithelium filled with colloid (H&E,x 10)
Fig 3: Nodular colloid goiter. Clusters and sheets of follicular cells with colloid background(H&E, x10)
Fig 4: Nodular colloid goiter. Monolayered sheet of follicular                       cells(H&E,x 40)
Fig 5: Nodular colloid goiter with cystic degeneration. Cyst                macrophages(H&E,x 10)
Fig 6: Multinodular goiter. External surface showing               nodules of varying size
Fig 7: Multinodular goiter. Cut surface showing nodules of               varying size filled with colloid
Fig 7: Multinodular goiter. Multiple colloid filled nodules        separated by fibrous septa(H&E,x 10)
Fig 8: Nodular goiter with Cystic degeneration. Cyst wall        with adjacent normal thyroid (H&E,x 10)
Fig 9: Hyperplastic goiter. 3-D cluster of follicular cells                      (H&E,x 40)
Fig 10: Hyperplastic goiter. 3-D fragments of follicular cells                        (H&E, x40)
Fig 11: Hyper plastic goiter. Scalloping of colloid                   (H&E,x 40)
Fig 12: Hashimoto’s thyroiditis. Lymphocytic infiltration of    follicular cells and hurthle cell change (H&E,x 40)
Fig 12: Hashimoto’s thyroiditis. Lymhocytic infiltration of         follicular cells and hurthle cell change
Fig 24: Hashimoto’s thyroiditis. Hurthle cells (H&E,x 40)
Fig 14: Hashimoto’s thyroiditis. Prominent lymphocytic   infiltration of thyroid follicles (H&E,scanner view)
Fig 15: Hashimoto’s thyroiditis. Normal follicular epithelium  along with follicular epithelium with hurthle cell change  ...
Fig 15: Hashimoto’s thyroiditis. Hurthle cell change and          lymphocytic infiltration (H&E,x 40)
Fig 12: Follicular neoplasm. Cut surface showing a solitary                  well encapsulated nodule
Fig 16: Follicular neoplasm. A repetitive acinar pattern                      (H&E,x 40)
Fig 17: Follicular neoplasm. Repetitive acinar pattern                      (MGG,x 40)
Fig 5: Microfollicular adenoma. Intact fibrous capsule  around a follicular adenoma (H&E,scanner view)
Fig 7: Papillary carcinoma. Branching papillae with          fibrovascular core (H&E,x 10)
Fig 8: Papillary carcinoma. Papillae lined by cuboidal   epithelium with optically clear nuclei (H&E,x 40)
Fig 9: Follicular variant of papillary carcinoma. Optically                  clear nuclei (H&E,x 40)
Fig 12: Follicular carcinoma. Capsular invasion (H&E,x 10)
Fig 13: Follicular carcinoma. Capsular invasion (H&E,x 10)
Discussion• Thyroid nodules are a common clinical problem.• In iodine deficient areas the incidence of goiters among  thyr...
• The present study deals with the fine needle aspiration  cytology of goiters in 221 patients of which 76 of them  underw...
Table 17: Comparison of AgeStudies          Range of age   Median age                   in years      in yearsMahar et al ...
Table 18: Comparison of SexStudies            Total   Males   Females   M:F ratio                   casesMubarik et al    ...
Table 19: Comparison of Age and Sex for Simple and Nodular goiterStudies            Median age in   Female to Male        ...
Table 20: Comparison of TSH levelsStudies          Normal   Decreased   Increased   TotalBasharat et al     48         2  ...
Table 21: Comparison of Presenting SymptomsStudies       Swelling   Pain   Dysphagia Palpitation   Weight   Total         ...
Table 22: Comparison of Size of the Swelling  Studies          1-5cm   6-10cm   Total  Basharat et al    35       15      ...
Table 23: Comparison of lesions on FNACStudies       Benign   Follicular   Malignant Inadequate   TotalHanda et al    381 ...
Table 24: Comparison of Individual Lesions on CytologyDisease               Nongrum Bhatta et al Mosawi et   Mubarik et   ...
Table 25: Comparison of Cyto-HistologicalConcordance in the Diagnosis of Goiter  Studies          No.       %  Mathur et a...
Table 26: Comparison of False Negativity Rate     Studies          No. of FN cases   FNR     Mahar et al           6/125  ...
• False negative rates reported in literature range from 1.5  to 9%.• The false negative FNAC results may occur because of...
• Intermediate FNAC results and  cytodiagnostic errors are unavoidable due to  overlapping cytological features, particula...
Table 27: Comparison of diagnostic values in goiterStudies      Sensitivit Specificity Positive   Negative Diagnostic     ...
CONCLUSION• It is concluded that FNAC is a simple, minimally invasive  first line diagnostic procedure for evaluation of s...
• FNAC is highly sensitive and specific diagnostic  procedure. But it can give false negative result. So final  diagnosis ...
