Towards Interactive Network Forensics and            Incident Response             Matthias Vallentin             UC Berke...
MotivationWhat do the following activities have in common?    Network troubleshooting    Incident response    Network fore...
MotivationWhat do the following activities have in common?    Network troubleshooting    Incident response    Network fore...
MotivationWhat do the following activities have in common?    Network troubleshooting    Incident response    Network fore...
Outline1. Incident Response and Network Forensics2. Operational Network Monitoring using Bro3. Building an Interactive Ana...
About4th -year PhD student at UC Berkeley, advised by Vern PaxsonWorking with researchers at ICSI/ICIR and the AMPlabInter...
Outline1. Incident Response and Network Forensics2. Operational Network Monitoring using Bro3. Building an Interactive Ana...
Use Case #1: Classic Incident Response    Goal: fast and comprehensive analysis of security incidents   Often begins with ...
Use Case #2: Network Troubleshooting    Goal: find root cause of component failure   Often no specific hint, merely symptoma...
Use Case #3: Combating Insider Abuse    Goal: uncover policy violations of personnel   Analysis procedure: connect the dot...
Outline1. Incident Response and Network Forensics2. Operational Network Monitoring using Bro3. Building an Interactive Ana...
Basic Network Monitoring               Internet             Tap          Local Network                                   M...
High-Performance Network Monitoring:     The NIDS Cluster [VSL+ 07]      Internet                    Tap                Lo...
The Bro Cluster                                   Internet              Tap               Local NetworkWe run it operation...
The Bro Network Security Monitor    Fundamentally different from other IDS    Real-time network analysis framework    User ...
From Packets to High-Level Descriptions of ActivityEvent declaration type connection: record { orig: addr, resp: addr, ......
From Packets to High-Level Descriptions of ActivityEvent declaration type connection: record { orig: addr, resp: addr, ......
Event Extraction with BroEvent and data model     Rich-typed: first-class networking types (addr, port, subnet, . . . )    ...
After the Fact: Bro Logs      Policy-neutral by default: no notion of good or bad             Forensic investigations high...
After the Fact: Bro Logs                           17 / 36
Log AnalysisWhat do we do with Bro logs?    Process (ad-hoc analysis)    Summarize (time series data, histogram/top-k, qua...
Log AnalysisWhat do we do with Bro logs?    Process (ad-hoc analysis)    Summarize (time series data, histogram/top-k, qua...
Outline1. Incident Response and Network Forensics2. Operational Network Monitoring using Bro3. Building an Interactive Ana...
From Ephemeral to Persistent Activity   Bro events                                                        User Interface  ...
From Ephemeral to Persistent Activity                               Bro Apache                     Events   Query   Result...
Today’s Open-Source Solutions for Analytics                                              22 / 36
Caveats in Real-Time Analytics1. Getting poor performance       Batch processing (MapReduce)       Architectural flaws (infl...
Inspiration1. Dremel         Columnar storage         Nested data model2. Bigtable         Sharding: distributed tablets3....
Design Philosophy Touch Stones [Lam11]Storage    Keep data sorted → reduce seeks, easy random entry    Shard with access l...
Design Philosophy Touch Stones [Lam11]Storage    Keep data sorted → reduce seeks, easy random entry    Shard with access l...
Design Philosophy Touch Stones [Lam11]Storage    Keep data sorted → reduce seeks, easy random entry    Shard with access l...
VAST: Visibility Across Space and TimeVisibility     Deep understanding of the data     Visualization: you know how to do ...
QueriesTwo types 1. Search: historical query 2. Feed: live query → use case: crawl archive first, then make query permanent...
VAST: Architecture Overview                                     Ingest          QueryDistributed architecture    Elasticit...
VAST: Ingestion Architecture                                                       Store                                  ...
VAST: Query Architecture                                                       Store                                      ...
Bitmap Indexes                                        Data        Bitmap Index                                            ...
Conclusion1. Motivation: incident response, network troubleshooting, insider abuse2. The Bro network security monitor     ...
Questions?             33 / 36
References IA. Colantonio and R. Di Pietro.Concise: Compressed ’n’ Composable Integer Set.Information Processing Letters, ...
References IIAndrew Lamb.Building Blocks for Large Analytic Systems.In 5th Extremely Large Databases Conference, XLDB ’11,...
References IIIMatthias Vallentin, Robin Sommer, Jason Lee, Craig Leres, VernPaxson, and Brian Tierney.The NIDS Cluster: Sc...
