Software Patterns for Reusable Design




Robert S. Hanmer

June, 2009
About me

   MSCS, Northwestern University, 1987.
   Working at Northwestern University Med School & computer center
    b...
Agenda

1. Design, Reusable & Software Patterns

2. What is a Software Pattern?

3. Pattern Communities

4. Using Patterns...
Design,
     Reusable
         & Software Patterns
Design
As a noun:

5 a: an underlying scheme that governs functioning, developing, or unfolding …
  b: a plan or protocol ...
Reusable
Adjective: capable of being used again or repeatedly
                                                            ...
Reusable Design
Design and design elements that are

     Modular

     Flexible
     Usable more than once

     Can be c...
Software Patterns
“The pattern is, in short, at the same time a thing, which happens in the world,
and the rule which tell...
9 | Software Patterns for Reusable Design | June 2009   All Rights Reserved © Alcatel-Lucent 2009
What is a Software Pattern?




10 | Software Patterns for Reusable Design | June 2009   All Rights Reserved © Alcatel-Luc...
Pattern: Leaky Bucket Counters

Context: A system that is intended to recognize and correct problems
 automatically. In th...
Leaky Bucket Counters (2)

Solution: Each failure group that is to be watched has a counter
 (the leaky bucket counter) wh...
Leaky Bucket Counters (3)

Resulting Context: A system in which errors are isolated and handled (by taking
 devices out of...
What is a Pattern?

A proven solution

     Rule of 3

More than an algorithm

     A pattern explains the context when it...
Patterns Are:

A resolution of forces

A form of architectural and design documentation

Relationships that cuts across sy...
Patterns are useful for:

Learning from what has worked in the past

     Not re-inventing the wheel

     Not repeating p...
Patterns Will Not:

… make you an instant expert

… provide a “turn the crank” approach to software

… eliminate the need ...
Depth of Patterns

Some patterns are at a very low-level:

     An example solution: Use a shift to multiple or divide by ...
The Quality Without A Name

“There is a central quality which is the root criterion of life and spirit in a man, a
town, a...
Patterns Handbook

Patterns build the handbook of software design and construction

     Patterns available in reference b...
The Pattern Almanac

Published 3/2000

Summarizes all the published,
widely available patterns
Indices based upon pattern
...
What is a Pattern Language?

A collection of patterns that work together

A collection of patterns that build upon each ot...
An Example Pattern Language

Telecom IO

     A specialized set of patterns for defining the human-machine interface has
 ...
Telecom IO Pattern Intents
Alarm Grid                                   Group alarms into grids to help the workers identi...
Telecom IO




                                                                                                     PLoPD-...
What is a Software Pattern?

A description of a reusable proven design element

     with enough information to recreate t...
Pattern Communities




27 | Software Patterns for Reusable Design | June 2009   All Rights Reserved © Alcatel-Lucent 2009
Pattern Communities

The Hillside Group

     A worldwide organization to make the life of people touching software better...
Patterns Community

Pattern movement origins
     1989-1992
         Advanced C++ Programming Styles & Idioms by James Cop...
“Culture”

 “5a: the integrated pattern of human knowledge, belief, and behavior that
depends upon man's capacity for lear...
Writers’ Workshops

Good patterns are highly reviewed and refined.



Writers’ Workshop from the literature/poetry communi...
After writing, workshopping and revising: publish

Patterns are meant to be read!

     Conference proceedings
         hi...
Pattern Ethics

Buschmann’s rule: Never capture your own ideas in a pattern

   - Focus on broad, lasting, positive patter...
Using Patterns




34 | Software Patterns for Reusable Design | June 2009   All Rights Reserved © Alcatel-Lucent 2009
“Patterns Generate Architectures”

Johnson, OOPSLA ’92

“Documenting Frameworks using Patterns”

Documented a framework us...
Documenting Architecture

Patterns are useful to document built systems.

     Allows maintenance engineers a snapshot of ...
Assisting Design

If you were designing an alarm component for a system, the Telecom IO Alarm
patterns might be helpful.

...
Designing with Relevant Patterns

When starting a project that patterns and pattern languages might be useful for:

Create...
Using a Pattern language … “Never the same way twice.”

Applying a pattern language is not a “turn the crank” exercise.

E...
Where do you find the patterns that you need?

Pattern Almanac

     Lists all the patterns published up to mid-2000.

Web...
Writing and Collecting Patterns
Pattern mining

“… don’t count on being able to ‘mine’ a pattern language. A pattern language
comes together like a jigsaw...
Digging deeper

What is required for this pattern to work?

What if absent would mean that this cannot work?

What’s missi...
Pattern Refactoring

   Real Time and Resource Overload is an example of pattern refactoring.
   It combines patterns from...
Pattern Refactoring (2)

The pattern you are about to write to complete a language might already have
been written by some...
Pattern Research
                                      Current Efforts

                                      The Open Pro...
Handbook of Software Architecture

Grady Booch is collecting The Handbook of Software Architecture.
http://www.handbookofs...
HCI Repository
Martijn van Welie has a repository of HCI patterns that many say is the
cornerstone of the HCI community. h...
Open Problem

Finding appropriate patterns

     Many sources: books, web, articles

     Many patterns with the same name...
Patterns in your Community




50 | Software Patterns for Reusable Design | June 2009   All Rights Reserved © Alcatel-Luce...
Bioinformatics Open Source Patterns

How can you make use of patterns to foster development of “better”
  bioinformatics s...
Wrapup
We’ve looked at

What pattern and pattern languages look like

Pattern communities

Some ways of using patterns

Some idea...
Software Patterns for Reusable Design

A software pattern is a description of modular proven solution to a design
problem ...
References
                                      Sources of more information




55 | Software Patterns for Reusable Desig...
References (1)

  Alexander, C. et. al. A Pattern Language. New York: Oxford University Press. 1977.
  Alexander, C. The T...
References (2)

 Harrison, N., B. Foote, H. Rohnert, eds. Pattern Languages of Program Design-4.
     Reading, MA: Addison...
www.alcatel-lucent.com
                          www.alcatel-lucent.com




58 | Software Patterns for Reusable Design | J...
