1.
Practical
full-text search
in PostgreSQL
Bill Karwin
PostgreSQL Conference West 09 • 2009/10/17

2.
Me
• 20+ years experience
• Application/SDK developer
• Support, Training, Proj Mgmt
• C, Java, Perl, PHP
• SQL maven
• MySQL, PostgreSQL, InterBase
• Zend Framework
• Oracle, SQL Server, IBM DB2, SQLite
• Community contributor

3.
Full Text Search

4.
Text search
• Web applications demand speed
• Let’s compare 5 solutions for text search

5.
Sample data
• StackOverflow.com Posts
• Data dump exported September 2009
• 1.2 million tuples
• ~850 MB

6.
StackOverflow ER diagram

7.
Naive Searching
Some people, when confronted with a problem,
think “I know, I’ll use regular expressions.”
Now they have two problems.
— Jamie Zawinsky

8.
Performance issue
• LIKE with wildcards: time: 91 sec
SELECT * FROM Posts
WHERE body LIKE ‘%postgresql%’
• POSIX regular expressions:
SELECT * FROM Posts
WHERE body ~ ‘postgresql’ time: 105 sec

9.
Why so slow?
CREATE TABLE telephone_book (
full_name
VARCHAR(50)
);
CREATE INDEX name_idx ON telephone_book
(full_name);
INSERT INTO telephone_book VALUES
(‘Riddle, Thomas’),
(‘Thomas, Dean’);

10.
Why so slow?
• Search for all with last name “Thomas”
uses
SELECT * FROM telephone_book index
WHERE full_name LIKE ‘Thomas%’
• Search for all with first name “Thomas”
SELECT * FROM telephone_book
WHERE full_name LIKE ‘%Thomas’
doesn’t
use index

11.
Indexes don’t help
searching for substrings

12.
Accuracy issue
• Irrelevant or false matching words
‘one’, ‘money’, ‘prone’, etc.:
body LIKE ‘%one%’
• Regular expressions in PostgreSQL
support escapes for word boundaries:
body ~ ‘yoney’

13.
Solutions
• Full-Text Indexing in the RDBMS
• Sphinx Search
• Apache Lucene
• Inverted Index
• Search Engine Service

14.
PostgreSQL
Text-Search

15.
PostgreSQL Text-Search
• Since PostgreSQL 8.3
• TSVECTOR to represent text data
• TSQUERY to represent search predicates
• Special indexes

16.
PostgreSQL Text-Search:
Basic Querying
SELECT * FROM Posts
WHERE to_tsvector(title || ‘ ’ || body || ‘ ’ || tags)
@@ to_tsquery(‘postgresql & performance’);
text-search
matching
operator

17.
PostgreSQL Text-Search:
Basic Querying
SELECT * FROM Posts
WHERE title || ‘ ’ || body || ‘ ’ || tags
@@ ‘postgresql & performance’;
time with no index:
8 min 2 sec

18.
PostgreSQL Text-Search:
Add TSVECTOR column
ALTER TABLE Posts ADD COLUMN
PostText TSVECTOR;
UPDATE Posts SET PostText =
to_tsvector(‘english’, title || ‘ ’ || body || ‘ ’ || tags);

19.
Special index types
• GIN (generalized inverted index)
• GiST (generalized search tree)

20.
PostgreSQL Text-Search:
Indexing
CREATE INDEX PostText_GIN ON Posts
USING GIN(PostText);
time: 39 min 36 sec

21.
PostgreSQL Text-Search:
Querying
SELECT * FROM Posts
WHERE PostText @@ ‘postgresql & performance’;
time with index:
20 milliseconds

22.
PostgreSQL Text-Search:
Keep TSVECTOR in sync
CREATE TRIGGER TS_PostText
BEFORE INSERT OR UPDATE ON Posts
FOR EACH ROW
EXECUTE PROCEDURE
tsvector_update_trigger(
ostText,
P
‘english’, title, body, tags);

23.
Lucene

24.
Lucene
• Full-text indexing and search engine
• Apache Project since 2001
• Apache License
• Java implementation
• Ports exist for C, Perl, Ruby, Python, PHP,
etc.

25.
Lucene:
How to use
1. Add documents to index
2. Parse query
3. Execute query

26.
Lucene:
Creating an index
• Programmatic solution in Java...
time: 8 minutes 55 seconds

27.
Lucene:
Indexing
String url = "jdbc:postgresql:stackoverflow";
Properties props = new Properties();
props.setProperty("user", "postgres");
run any SQL query
Class.forName("org.postgresql.Driver");
Connection con = DriverManager.getConnection(url, props);
Statement stmt = con.createStatement();
String sql = "SELECT PostId, Title, Body, Tags FROM Posts";
ResultSet rs = stmt.executeQuery(sql);
open Lucene
Date start = new Date(); index writer
IndexWriter writer = new IndexWriter(FSDirectory.open(INDEX_DIR),
new StandardAnalyzer(Version.LUCENE_CURRENT),
true, IndexWriter.MaxFieldLength.LIMITED);

28.
Lucene:
Indexing
loop over SQL result
while (rs.next()) {
Document doc = new Document();
doc.add(new Field("PostId", rs.getString("PostId"), Field.Store.YES, Field.Index.NO));
doc.add(new Field("Title", rs.getString("Title"), Field.Store.YES, Field.Index.ANALYZED));
doc.add(new Field("Body", rs.getString("Body"), Field.Store.YES, Field.Index.ANALYZED));
doc.add(new Field("Tags", rs.getString("Tags"), Field.Store.YES, Field.Index.ANALYZED));
writer.addDocument(doc); each row is
}
a Document
writer.optimize();
writer.close();
with four Fields
finish and
close index

29.
Lucene:
Querying
• Parse a Lucene query define fields
String[] fields = new String[3];
fields[0] = “title”; fields[1] = “body”; fields[2] = “tags”;
Query q = new MultiFieldQueryParser(fields,
new StandardAnalyzer()).parse(‘performance’);
• Execute the query parse search
query
Searcher s = new IndexSearcher(indexName);
Hits h = s.search(q);
time: 80 milliseconds

30.
Sphinx Search

31.
Sphinx Search
• Embedded full-text search engine
• Started in 2001
• GPLv2 license
• Good database integration

32.
Sphinx Search:
How to use
1. Edit configuration file
2. Index the data
3. Query the index
4. Issues

33.
Sphinx Search:
sphinx.conf
source stackoverflowsrc
{
type = pgsql
sql_host = localhost
sql_user = postgres
sql_pass = xxxx
sql_db = stackoverflow
sql_query = SELECT PostId, Title, Body, Tags FROM Posts
sql_query_info = SELECT * FROM Posts WHERE PostId=$id
}

34.
Sphinx Search:
sphinx.conf
index stackoverflow
{
source = stackoverflowsrc
path = /opt/local/var/db/sphinx/stackoverflow
}

35.
Sphinx Search:
Building index
indexer -c sphinx.conf stackoverflow
collected 1242365 docs, 720.5 MB
sorted 88.3 Mhits, 100.0% done
total 1242365 docs, 720452944 bytes
total 357.647 sec, 2014423.75 bytes/sec, 3473.72 docs/sec
time: 5 min 57 sec

36.
Sphinx Search:
Querying index
search -c sphinx.conf -i stackoverflow
-b “sql & performance”
time: 8 milliseconds

37.
Sphinx Search:
Issues
• Index updates are as expensive as
rebuilding the index from scratch
• Maintain “main” index plus “delta” index for
recent changes
• Merge indexes periodically
• Not all data fits into this model

38.
Inverted Index

39.
Inverted index
searchable words
Posts Tags TagTypes
intersection of
words / Posts

40.
Inverted index:
Updated ER Diagram

41.
Inverted index:
Data definition
CREATE TABLE TagTypes (
TagId
SERIAL PRIMARY KEY,
Tag
VARCHAR(50) NOT NULL
);
CREATE UNIQUE INDEX TagTypes_Tag_index ON TagTypes(Tag);
CREATE TABLE Tags (
PostId
INT NOT NULL,
TagId
INT NOT NULL,
PRIMARY KEY (PostId, TagId),
FOREIGN KEY (PostId) REFERENCES Posts (PostId),
FOREIGN KEY (TagId) REFERENCES TagTypes (TagId)
);
CREATE INDEX Tags_PostId_index ON Tags(PostId);
CREATE INDEX Tags_TagId_index ON Tags(TagId);

42.
Inverted index:
Indexing
INSERT INTO Tags (PostId, TagId)
SELECT p.PostId, t.TagId
FROM Posts p JOIN TagTypes t
ON (p.Tags LIKE ‘%<’ || t.Tag || ‘>%’);
90 seconds
per tag!!

43.
Inverted index:
Querying
SELECT p.* FROM Posts p
JOIN Tags t USING (PostId)
JOIN TagTypes tt USING (TagId)
WHERE tt.Tag = ‘performance’;
40 milliseconds

44.
Search Engine Services

45.
Search engine services:
Google Custom Search Engine
• http://www.google.com/cse/
• DEMO ➪ http://www.karwin.com/demo/gcse-demo.html
even big web sites
use this solution

46.
Search engine services:
Is it right for you?
• Your site is public and allows external index
• Search is a non-critical feature for you
• Search results are satisfactory
• You need to offload search processing

47.
Comparison: Time to Build Index
LIKE predicate none
PostgreSQL / GIN 40 min
Sphinx Search 6 min
Apache Lucene 9 min
Inverted index high
Google / Yahoo! offline

48.
Comparison: Index Storage
LIKE predicate none
PostgreSQL / GIN 532 MB
Sphinx Search 533 MB
Apache Lucene 1071 MB
Inverted index 101 MB
Google / Yahoo! offline

49.
Comparison: Query Speed
LIKE predicate 90+ sec
PostgreSQL / GIN 20 ms
Sphinx Search 8 ms
Apache Lucene 80 ms
Inverted index 40 ms
Google / Yahoo! *

50.
Comparison: Bottom-Line
indexing storage query solution
LIKE predicate none none 11,250x SQL
PostgreSQL / GIN 7x 5.3x 2.5x RDBMS
Sphinx Search 1x * 5.3x 1x 3rd party
Apache Lucene 1.5x 10x 10x 3rd party
Inverted index high 1x 5x SQL
Google / Yahoo! offline offline * Service

51.
