Resin Application Server and Cloud discussed by Paul Cowan

Resin Application Server
Paul Cowan - InfoQ
Interview
Caucho Home | Contact Us | Caucho Blog | Wiki | Application Server

InfoQ - Paul Cowan Discusses the Resin
Application Server and Cloud

About Paul Cowan
• Software Engineer working on the Resin
application server at Caucho Technology

• Focusing on dependency injection,
concurrency, high-speed messaging, and
distributed caching

• 11 years of experience
• Started with NetDynamics
• Prior to Caucho worked as Senior Architect
with NAVTEQ
• Traffic.com division


“Where do you see Resin
in terms of the wider
Cloud landscape?”


Resin and the Cloud
Landscape
• Resin ﬁts on the elastic JEE application layer
• We don’t sell the service or provide it to you
• Not PaaS
• Not SaaS
• We are a infrastructure provider/vendor
• You get the Resin software
• You build your Cloud on it


“Can you tell us a little bit
about how your Cloud
support is architected?”


Resin Cloud Support
Architected
• Triad hub-and-spoke
architecture

• Hub
• Three Primary Servers
• Constantly
communicating with
each other

• Spoke
• Elastic Spoke Servers
• Add or Remove as


“Why did you go for a
hub-and-spoke rather
than say a peer-to-peer
cluster?”


Hub-and-Spoke vs. Peer-
to-Peer
• Most cases easier to have 3 primary servers
• IP addresses are known
• No need for auto-discovery
• Creates problems in EC2 environments

• Hub architecture with 3 primary servers
• Responsible for caching data
• Maintaining the knowledge of Cloud architecture
• Eliminates a lot of issues you get with true peer-to-
peer network


Basic Hub-and-Spoke
Conﬁguration

Dynamic&&
Spoke&
Server&
Triad& Triad&
A&
Server& Server&
1& 2&

Triad&
Server& Dynamic&&
3& Spoke&
Server&
B&


Basic Hub-and-Spoke
Conﬁguration
Load(increases.(
Spin(a(new(server((
Dynamic&& Dynamic(( up(
Spoke& Spoke(
Server& Server(
Triad& Triad&
A& C(
Server& Server&
1& 2&

Triad&
Server& Dynamic&&
3& Spoke&
Server&
B&


“How do you keep the network
traffic to a reasonable level as
the number of spikes grows?”


Keeping Network Traffic at
Reasonable Level as Spikes
Grow
• Messaging based on Hessian Network Protocol
(HMTP)

• During distributed sessions
• Only update your session data when the data
changes
• Hashing session
• Triad master will have a hash of what current data is
• Spoke server veriﬁes latest data
• “Here is my hash, do I have the latest data?”
• If hashes match very little data needs to be sent


New Server Dynamically Joining
Cloud

Dynamic((
Spoke(
Triad&Server&1& Server(
192.168.1.10& A(

Triad&Server&2&
192.168.1.11&

Triad&Server&3&
192.168.1.12&


New Server Dynamically Joining
Cloud
Spin up a new VM instance and add it to the cluster. It talks to the triad to
join

Dynamic((
Spoke(
Dynamic((
Spoke(
Ask for latest
Triad&Server&1&
192.168.1.10&
Server( Server(
B(
application
versions
A(

Triad&Server&2&
192.168.1.11&

Triad&Server&3&
192.168.1.12&


“How do I conﬁgure the
typology of the cluster?”


Configuring Typology of
Cluster
• Resin keeps it simple
• Primarily a single JAR file with configuration file
• Same configuration file
• Triad
• Web tier
• Any cluster tiers
• Spokes

• Triad servers spun up
• Usually static on different machines


Conﬁguring Typology of
Cluster
• Elastic servers spun up
(continued)

• Using single command line
• Easy to bring them up and down as needed


“How does Resin support Cloud
deployment and distributed
versioning?”


Cloud Deployment and
Distributed Versioning on Resin
• Based on HMTP messaging system
• Forms basis for distributed cache
• Distributed versioning based in Git
• Internal version of Git library
• Pushing a WAR or an application to Triad servers
• Git is used to internally push out to all other servers


Cloud Deployment and
Distributed Versioning on Resin
(continued)
• Sessions in Cloud are tied to Git version of
application
• A number of sessions running off one version of
application
• Push a new version
• Resin keeps that version of application until all
sessions are over
• New sessions coming in will get new version of
application


“You’ve got replicated session
state across the machines?
What’s the overhead like for
that; for actually replicating the
session?”


Overhead for Replicated Session
State Across Machines
• Pretty low
• Only need to replicate to the server that is handling that
session

• Using sticky sessions
• With a lease
• Same session goes to the same server and push session
update to Triad

• Conﬁgurable
• When to Push
• Push after every update


Overhead for Replicated Session
State Across Machines (continued)
• Hashing sessions and comparison with master
and spoke servers
• Cuts down on network traffic


“What’s the Watchdog
system and why is that
important for Cloud
deployment?”


Watchdog System
• Resin always runs with two processes
• Watchdog is the secondary process that
controls Resin

• When you start up a Resin server
• Watchdog starts up ﬁrst and starts up Resin for you
• Monitors health of Resin system
• Automatically restarts if there is an issue


Watchdog System
(continued)

• Cloud environment advantage
• Watchdog system maintains health of servers
• Prevents losing track of elastic servers
• Reports any noticed issues
• Health system is external process
• Can detect when Resin is having issues


“Can you describe some
of the other reports I can
get out of the health
system? You have post-
mortem reports for
instance.”

Health System Reports
• Watchdog Report
• Prior to or leading up to a restart
• Produce a report from the data we were tracking at the
time

• PDF Report
• Tread dump
• Heap dump
• Stack dump
• JMX dump


Health System Reports
(continued)

• PDF Report (continued)
• Goes through all JMX
• Dump out attributes and values
• Can do profiling if you want
• Internal native profiling library
• Can profile for a period of time
• Monitoring other attributes in system, for example:
• CPU Usage
• Memory usage
• File descriptors
• Produces a “snapshot” PDF


“And you do JIT proﬁling
as well, I think I’m right in
saying?”


JIT Proﬁling
• Health system is very conﬁgurable
• Any period of time
• From a certain end response to a certain issue


“How does what you offer
compare to some of the other
JavaEE vendors? WebLogic has
some similar features, for
instance.”


Comparing Resin to other
JavaEE Vendors
• Positioned between Tomcat and WebLogic
• Enterprise quality server
• Elastic
• Health System
• Administration System
• More lightweight
• Only 23 MB download
• 6 second start-up time


Comparing Resin to other
JavaEE Vendors (continued)
• For customers who want enterprise quality that
don’t need the heavyweight full JEE stack

• Support JEE 6 Web Proﬁle


“You also have an
anomaly detection
feature. Could you tell us
a bit about that and where
that idea came from?”

Anomaly Detection
Feature
• Organically rose from need to support
customers
• As well as a lot of our health system
• Result from an actual customer having thread
spike issues
• Noticed the issue in produced graphs
• Unable to tell what was happening
• Needed a snapshot at the time of issue


Anomaly Detection
Feature
• Monitors virtually any statistic in your JMS
(continued)

• i.e. number of threads
• Sees unusual spike in amount of threads
• Snapshot report is triggered

• Invaluable in providing support
• Detecting something unusual happening while its
happening
• Creating a snapshot of the system to use for
debugging
