Google C++ Testing Framework in Visual Studio 2008

  1. 1. Using Google Test with Visual Studio 2008 Andrea Francia (Galileian Plus) XPUG (14 aprile 2010) http:// / http:// /
  2. 2. SISMA Project
  3. 3. GOCE-Italy
  4. 4. Contents <ul><li>Basics of C program compilation </li></ul><ul><li>How many C++ testing framework are out there? </li></ul><ul><li>Introduction to Google C++ Testing Framework (aka gtest) </li></ul><ul><li>How to download/compile/link/use gtest (live) </li></ul><ul><li>(Maybe) Some usage examples </li></ul>
  5. 5. Hello World Example // file: hello.c #include <stdio.h> int main( int argc, char * argv[]) { printf( &quot;Hello World &quot; ); }
  6. 6. Steps in C compilation C Preprocessor C Compiler Linker a.out (.exe) hello.c stdio.h hello.i hello.o (.obj) libc.a (.lib) where printf is declared where printf is defined (from /usr/lib/) (from /usr/include)
  7. 7. Which testing framework? <ul><li>According to Wikipedia [1] we have 42 framework for C++ !! </li></ul><ul><li>For comparison: </li></ul><ul><ul><li># of choices for C++: 42 </li></ul></ul><ul><ul><li># of choices for Java: 23 </li></ul></ul><ul><ul><li># of choices for .Net: 21 </li></ul></ul><ul><ul><li># of choices for Objective-C: 5 </li></ul></ul><ul><ul><li># of choices for C: 32 </li></ul></ul>[1]
  8. 8. Narrowing selection <ul><li>The test frameworks chosen: </li></ul><ul><ul><li>CppUnit </li></ul></ul><ul><ul><li>CppUnitLite </li></ul></ul><ul><ul><li>Google C++ Testing Framework </li></ul></ul>
  9. 9. CppUnit <ul><li>Features: </li></ul><ul><ul><li> Created by Michael Feathers [1] </li></ul></ul><ul><ul><li> Opensource </li></ul></ul><ul><ul><li> API similar to JUnit </li></ul></ul><ul><ul><li> The JUnit-like API doesn’t match the C++ features  longer fixtures </li></ul></ul><ul><ul><li> Michael Feathers don’t use it anymore! </li></ul></ul>[1] The author of “Working Effectively with Legacy Code”
  10. 10. CppUnitLite <ul><li>Features: </li></ul><ul><ul><li> Also created by Michael Feathers [1] </li></ul></ul><ul><ul><li> Opensource </li></ul></ul><ul><ul><li> Exploits the features of the language(s) </li></ul></ul><ul><ul><li> => More easily write individual tests </li></ul></ul><ul><ul><li> Michael Feathers still use it. </li></ul></ul>[1] He decided that using CppUnit was too elaborate!
  11. 11. Google C++ Testing Framework <ul><li>Features: </li></ul><ul><ul><li>Written by some guys at Google </li></ul></ul><ul><ul><li> Writing test seems as simple as in CppUnitLite </li></ul></ul><ul><ul><li> Opensource </li></ul></ul><ul><ul><li> Works on many platforms: </li></ul></ul><ul><ul><ul><li>Visual Studio </li></ul></ul></ul><ul><ul><ul><li>XCode </li></ul></ul></ul><ul><ul><ul><li>gcc </li></ul></ul></ul><ul><ul><li>  Documentation available online </li></ul></ul><ul><ul><li>  Seems to be used by many people (at least on </li></ul></ul>
  12. 12. The Winner is <ul><li>Google C ++ Testing Framework </li></ul><ul><ul><li>(a.k.a. gtest) </li></ul></ul>
  13. 13. What do you need? <ul><li>Visual Studio 2008 </li></ul><ul><li>Google Test Package ( </li></ul><ul><li>This guide  </li></ul>
  14. 14. How test are defined <ul><li>// </li></ul><ul><li>#include <gtest/gtest.h> </li></ul><ul><li>TEST( the_compiler , is_able_to_add ) { </li></ul><ul><li>ASSERT_EQ(2, 1+1); </li></ul><ul><li>} </li></ul><ul><li>TEST( the_compiler , knows_when_two_numbers_are_different ) { </li></ul><ul><li>ASSERT_NE(1, 2); </li></ul><ul><li>} </li></ul><ul><li>TEST( the_compiler , knows_who_comes_first ) { </li></ul><ul><li>ASSERT_LT(1, 2); </li></ul><ul><li>ASSERT_GT(2, 1); </li></ul><ul><li>} </li></ul>Suggested nomeclature: A. The system under test. B. The tested features. Note: Autodiscovery! No need of enumerating tests. 1. Include the library headers 2. Write a TEST() for each features 2.1. Write Assertions
  15. 15. The Output Window
  16. 16. The Optional main() function <ul><li>Maybe you would insert a main() function which exercise all the test: </li></ul><ul><ul><li>int main( int argc, char * argv[]) { </li></ul></ul><ul><ul><li>::testing::InitGoogleTest(&argc, argv); </li></ul></ul><ul><ul><li>return RUN_ALL_TESTS(); </li></ul></ul><ul><ul><li>} </li></ul></ul><ul><li>Or you can simply add this lib: gtest_maind.lib </li></ul>
  17. 17. How To Set Up (live) 1/2 <ul><li>Download and unzip </li></ul><ul><ul><li>(from http:// / ) </li></ul></ul><ul><li>Build solution gtest-1.4.0/msvc/gtest.sln </li></ul><ul><li>Create your testing project </li></ul><ul><li>Add this to include path: </li></ul><ul><ul><li>gtest ­ 1.4.0/includes </li></ul></ul><ul><li>Add these to the library path: </li></ul><ul><ul><li>gtest ­ 1.4.0msvcgtestDebuggtest_maind.lib </li></ul></ul><ul><ul><li>gtest-1.4.0msvcgtestDebuggtestd.lib </li></ul></ul>
  18. 18. How To Set Up (live) 2/2 <ul><li>Resolve the remaining errors with some magic: </li></ul><ul><ul><li>Resolve linking error with: </li></ul></ul><ul><ul><ul><li>Use the “Multi-threaded Debug (/MTd)” option </li></ul></ul></ul><ul><ul><li>Resolve the manifest error with: </li></ul></ul><ul><ul><ul><li>A “clean and build” ! </li></ul></ul></ul><ul><li>Make FAIL messages clickable with: </li></ul><ul><ul><li>Setting </li></ul></ul><ul><ul><ul><li>Build Events > Post-Build Event > Command Line </li></ul></ul></ul><ul><ul><li>To value: </li></ul></ul><ul><ul><ul><li>&quot;$(TargetDir)$(TargetFileName)&quot; </li></ul></ul></ul>
  19. 19. Assertions <ul><li>Most used assertion: </li></ul><ul><ul><li>ASSERT_TRUE( condition ); </li></ul></ul><ul><ul><li>ASSERT_FALSE( condition ); </li></ul></ul><ul><ul><li>ASSERT_EQ( expected, actual ); </li></ul></ul><ul><ul><li>ASSERT_NE( val1, val2 ); </li></ul></ul><ul><ul><li>ASSERT_STREQ( expected_str ,  actual_str ); </li></ul></ul>
  20. 20. Expectations <ul><li>Most used expectations: </li></ul><ul><ul><li>EXPECT_TRUE( condition ); </li></ul></ul><ul><ul><li>EXPECT_FALSE( condition ); </li></ul></ul><ul><ul><li>EXPECT_EQ( expected, actual ); </li></ul></ul><ul><ul><li>EXPECT_NE( val1, val2 ); </li></ul></ul><ul><ul><li>EXPECT_STREQ( expected_str ,  actual_str ); </li></ul></ul><ul><li>Expectations vs Assertions: </li></ul><ul><ul><li>If an assertion fails the TEST execution stops </li></ul></ul><ul><ul><li>If an expectation fails the TEST execution continues </li></ul></ul>
  21. 21. References <ul><li>Feathers, Michael C (2004).  </li></ul><ul><li>Working Effectively with Legacy Code. </li></ul><ul><li>Prentice Hall.  ISBN   0-13-117705-2 . </li></ul><ul><li>Exploring the C++ Unit Testing Framework Jungle </li></ul><ul><ul><li> </li></ul></ul><ul><li>Compiler, Assembler, Linker and Loader: a brief story: </li></ul><ul><ul><li> (spiega pure il formato ELF!) </li></ul></ul><ul><li>Google C++ Testing Framework </li></ul><ul><ul><li>http:// / </li></ul></ul><ul><li>Tutorial Google Test con Visual Studio 2008 </li></ul><ul><ul><li> </li></ul></ul>
  22. 22. <ul><li>Grazie dell’ascolto! </li></ul><ul><li>(soprattutto alla mia fidanzata ;) </li></ul>
