Unbonded Post Tensioning Construction Applications

  1. 1. AMSYSCO UNBONDED POST-TENSIONINGCommercial Construction Applications Reinforced Concrete Projects
  2. 2. HIGH-RISE HOTEL J.W. Marriott Hotel Indianapolis, IN, USAFloors: 35Schedule: Nov.2008 to Dec.2009 _________________PT: 910,000 ft. (277,000 meters) 473,000 lbs. (215,000 kg)
  3. 3. MID-RISE HOTEL Floors: 17 Schedule: Dec.2004 to Apr.2005Renaissance Hotel _________________Schaumburg, IL, USA PT: 515,000 ft. (157,000 meters) 273,000 lbs. (124,000 kg)
  4. 4. PARKING STRUCTURE Floors: 7 Schedule: 1997Navy Pier Garage _________________Chicago, IL, USA PT: 450,000 ft. (137,000 m) 237,000 lbs. (108,000 kg)
  5. 5. PARKING STRUCTURE Floors: 5 Schedule: Jun.2006 to Oct.2007Indianapolis Airport _________________Parking Garage PT: 4,600,000 ft. (1,402,000 m)Indianapolis, IN, USA 2,440,000 lbs. (1,107,000 kg)
  6. 6. HIGH-RISE RESIDENTIAL 600 Fairbanks Chicago, IL, USA Floors: 42 Schedule: Nov.2006 to Jul.2007 _________________ PT: 747,000 ft. (228,000 m) 396,000 lbs. (180,000 kg)
  7. 7. HIGH-RISE RESIDENTIAL One Museum Park Chicago, IL, USAFloors: 55Schedule: Sept.2008 to Aug.2009 _________________PT: 1,360,000 ft. (415,000 m) 707,000 lbs. (321,000 kg)
  8. 8. RETAIL Floors: 3 Schedule: Jul.2005 to Jan.2006Southgate Market _________________Chicago, IL, USA PT: 749,000 ft. (229,000 m) 397,000 lbs. (180,000 kg)
  9. 9. STADIUM Floors: 5 Schedule: Dec.2007 to Sept.2008Target Field _________________Minneapolis, MN, USA PT: 711,000 ft. (217,000 m) 377,000 lbs. (171,000 kg)
  10. 10. THEATER Floors: 5 Schedule: Dec.2003 to Mar.2004Guthrie Theatre _________________Minneapolis, MN, USA PT: 82,000 ft. (25,000 m) 42,000 lbs. (19,000 kg)
  11. 11. 1200 Windham ParkwayRomeoville, Illinois 60446 United States 1-630-296-8383 www.amsyscoinc.com

×
