Mongo or Die!How MongoDB powers Doodle or Die        Aaron Silverman             (@Zugwalt)
Doodle or Die@DoodleOrDie
What is Doodle or Die?
TelephonePhrase     Id like some beer!Phrase     Id like some deerPhrase       I see no deerPhrase        I’ve no idea!
Doodle or DieDoodlePhrase         Shining AppleDoodlePhrase      Eat your fruit or DIE!
What Powers Doodle or Die?
Started very, very small            4 Cores          128MB RAM            Node Server           MongoDB Server
Got serious about our servers                     Small - 2GB     8 Cores      MongoDB Server   256MB RAM    Node Server
Called in some Reinforcements                      Large - 5GB    12 Cores        MongoDB Server    1GB RAM     Node Server
In the last 30 Days:• 2,500,000 page views• 100,000 uniques• 35,000 active player accounts• 2,000,000 new doodles and desc...
“Small Data”Mongo DB           • Player Info                   • Chain Info (excluding4 GB data size                     d...
MongoDB - $65 / monthDaily backups to Amazon S3: $16/mo
Amazon S3 - $70 / month
Node - $62/ month
Total Cost To Host: $197/month     MongoDB     $65     Amazon S3   $70     Node        $62     Total       $197
PAAS Provides Easy Upgrade Path
General Principles
Custom _idPartially random string generated usingShortId node module                        ObjectId        ObjectId("4fd0...
• Shorter, less cumbersome in code and  queriesdb.players.findOne({_id: ‘58mwYlTKV’});db.chains.update({_id: ‘58mwYlTKV’},...
Question Oriented Subdocuments  What chain is this player working on right now?  What are this player’s stats?  Which play...
Goal is for most “Questions” to be able tobe answered in one query from one subdocumentdb.players.findOne({_id: ‘58mwYlTKV...
Indexes are designed to make answeringquestions easy!Which player is working on this chain?db.players.ensureIndex({‘game.a...
Doodle or Die Collections
Disclaimer: Much of the original Doodle orDie code and schema were created during aweekend long hackathon!
playersPrimary   chains          groups          sessionsSupport            log
Players
players  game            OftenchainHistory   stats         Query               Frequency  account   login                 ...
players        game               •   activeState                           •   activeChain_id     chainHistory          •...
players                             Chain1            game                            • datePlayed                        ...
players               Chain1       game              • datePlayed                         • dateViewed    chainHistory    ...
players                            •       totalSteps           game                               •       drawSteps      ...
Chains
chains•   activePlayer_id•   activeState•   numSteps•   lastModified       ineligiblePlayer_ids                      steps...
chains           [player_id1                            player_id2,•   activePlayer_id         player_id3•   activeState  ...
chains           [•   activePlayer_id               Step1•   activeState                • player_id•   numSteps           ...
Description Step Content:  • phraseDoodle Step Content:  •   url (points to S3)  •   time  •   numStrokes  •   numDistinct...
Description Step Content:  • phraseDoodle Step Content:  •   url (points to S3)  •   time  •   numStrokes  •   numDistinct...
We plan to stop embedding steps in chains,and link to “doodles” and “descriptions”collections          doodles            ...
How Does it all Work?
players queried for users who are associatedwith the authenticated twitter accountdb.players.find({‘login.twitter.uid’: ‘X...
chains collection searched and atomicallyupdated for unclaimed eligible chain to begiven to player db.chains.findAndModify...
Content saved to chaindb.chains.update({_id: chain._id,           activePlayer_id: player._id}},          {$inc: {numSteps...
Doodle strokes will be saved to S3(but url to S3 and metadata saved to chain){"color":"#000000","size":15,"path":[307,66,3...
Player’s chainHistory retrieveddb.players.find({‘login.urlSafe’: urlSafeUid},          {chainHistory: 1});chainHistory fil...
Stats are loaded from the counting log whichis essentially a bunch of countersincrementeddb.log.find({_id: {$in: [‘2012-06...
Some Additional Doodle or Die Tricks
Build assumptions into queries
Alice and Bob are in an awesome groupgroups:{  _id: ‘8rOIwh2VD’,  members: [     {name: ‘Alice’, dateJoined: ‘2012-05-24’}...
Bugs in our code fail to detect Eve’s trickeryand the update query is run!groups.update(  {_id: ‘8rOIwh2VD’},  {$push:    ...
groups:{  _id: ‘8rOIwh2VD’,  members: [     {name: ‘Alice’, dateJoined: ‘2012-05-24’},     {name: ‘Bob’, dateJoined: ‘2012...
Bake in our assumptions!groups.update(  {_id: ‘8rOIwh2VD’,   ‘members.name’: {$ne: ‘Eve’},   ‘banned.name’: {$ne: ‘Eve’}},...
Always Specify Fields
To assign a player a new chain, we only needtheir _id and game information                   players                    ga...
To load a player’s profile content, we justneed their history, stats, and profile info                   players          ...
We need to assign Bob a new chain, letsfigure out what state he needs nextdb.players.find({name: ‘Bob’});This will fetch a...
Lets specify that we only want our “game”subdocumentdb.players.find({name: ‘Bob’}, {fields: [‘game’]});Hooray! Much less t...
Store Everything!
If you have information available, save iteven if you don’t plan on using it!db.chains.update({_id: ‘2VmVO18hs’},         ...
Some Pain Points
Less obvious database structuremysql> DESC players;+----------------+---------+------+-----+---------+-------+| Field     ...
Data integrity up to applicationMysql> ALTER TABLE players    ADD CONSTRAINT fk_players_chains     FOREIGN KEY (activeChai...
No mature GUI query development tools
If we could start over would we still use MongoDB?
Absolutely!• NoSQL in general is great for rapid prototyping• Fantastic performance• Intuitive language keeps it easy to r...
Questions?@Zugwalt     @DoodleOrDie
