Using KML for  Thematic Mapping Bjørn Sandvik thematicmapping.org MSc in Geographical Information Science University of Edinburgh Project Manager at United Nations Association of Norway Tech Talk at Googleplex 12 December 2008
[object Object],[object Object],[object Object],[object Object],[object Object],[object Object],[object Object],[object Object],[object Object],Outline Geo- browsers Thematic mapping techniques KML standard Public datasets Visualisations
Proportional symbols
Proportional symbols #1  Scaling image icons





Mathematical scaling of 2-D point symbols: symbolSize = power(value/maxValue; 1/2) * maxSize   KML for proportional icon images <Style id='sharedStyle'> <IconStyle> <Icon> <href>files/symbol.png</href> </Icon> </IconStyle> <Style> KML <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <styleUrl>#sharedStyle</styleUrl> <Style> <IconStyle> <color>e50066ff</color> <scale>7</scale> </IconStyle> </Style> <Point> <coordinates>106.514,33.42,0</coordinates> </Point> </Placemark> KML
Problem: Size affected by viewport
Not working in Google Maps
Proportional symbols #2  Drawing regular polygons

Problem: Complicated! function  kmlSymbolCalculator ( $longitude, $latitude, $radius, $vertices) { $EARTH_RADIUS_EQUATOR = 6378140.0; $RADIAN = 180 / pi(); $long = $longitude / $RADIAN; $lat = $latitude / $RADIAN; $f = 1/298.257; $e = 0.08181922; $kml = '<Polygon><outerBoundaryIs><LinearRing><coordinates>'; for ( $bearing = 45; $bearing <= 405; $bearing += 360/$vertices ) { $b = $bearing / $RADIAN; $R = $EARTH_RADIUS_EQUATOR * (1 - $e * $e) / pow( (1 - $e*$e *  pow(sin($lat),2)), 1.5); $psi = $distance/$R; $phi = pi()/2 - $lat; $arccos = cos($psi) * cos($phi) + sin($psi) * sin($phi) * cos($b); $latA = (pi()/2 - acos($arccos)) * $RADIAN; $arcsin = sin($b) * sin($psi) / sin($phi); $longA = ($long - asin($arcsin)) * $RADIAN; $kml .= &quot; “ . round($longA,$this->coordDecimals) . &quot;,“  . round($latA,$this->coordDecimals);  } $kml = '</coordinates></LinearRing><outerBoundaryIs></Polygon>'; return $kml; }
Proportional symbols #3  Scaling 3-D Collada objects


Mathematical scaling of 3-D point symbols: symbolSize = power(value/maxValue; 1/3) * maxSize   Making proportional Collada objects  Position   Measure / scale Colorize Google SketchUp <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <Model> <Link> <href>files/object.dae</href> </Link> <altitudeMode>absolute</altitudeMode> <Location> <longitude>106.514</longitude> <latitude>33.42</latitude> <altitude>0</altitude> </Location> <Scale> <x>140000</x> <y>140000</y> <z>140000</z> </Scale> </Model> </Placemark> KML
Chart maps



Using Google Chart API in KML <Style id='sharedStyle'> <BalloonStyle> <text><![CDATA[ <img src='http://chart.apis.google.com/chart ?cht=p&chd=t:20,45,5 &amp;chd=t: $[chartValues] '> ]]></text> </BalloonStyle> </Style> KML <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <styleUrl>#sharedStyle</styleUrl> <Style> <IconStyle> <scale>7</scale> <Icon>   <href> http://chart.apis.google.com/chart?cht=p&chd=t:20,45,5&chs=300x150 &amp;chf=bg,s,ffffff00</href> </Icon> </IconStyle> </Style> <Point> <coordinates>106.514,33.42,0</coordinates> </Point> <ExtendedData> <Data name=&quot;chartValues&quot;> <value>20,45,5</value> </Data> </ExtendedData> </Placemark> KML
Choropleth maps

Prism maps



Problem: Polygon holes
KML used in prism maps Suggestion: <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <styleUrl>#sharedStyle</styleUrl> <Style> <PolyStyle> <color>DC0066FF</color> </PolyStyle> </Style> <MultiGeometry> <Polygon> <extrude>1</extrude> <altitudeMode>absolute</altitudeMode> <outerBoundaryIs> <LinearRing> <coordinates>  110.72,20.06, 2000000  109.26,19.9, 2000000 108.63,19.28, 2000000  108.69,18.51, 2000000 110.05,18.38, 2000000  111.03,19.64, 2000000 (...)  </coordinates> </LinearRing> </outerBoundaryIs> </Polygon> <Polygon> (...) </Polygon> </MultiGeometry> </Placemark> KML <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <styleUrl>#sharedStyle</styleUrl> <Style> <PolyStyle> <color>DC0066FF</color> </PolyStyle> </Style> <MultiGeometry> <Polygon> <extrude>1</extrude> <altitude>2000000</altitude> <altitudeMode>clampToAltitude</altitudeMode>  <outerBoundaryIs> <LinearRing> <coordinates>  110.72,20.06 109.26,19.9 108.63,19.28 108.69,18.51 110.05,18.38 111.03,19.64 (...)  </coordinates> </LinearRing> </outerBoundaryIs> </Polygon> <Polygon> (...) </Polygon> </MultiGeometry> </Placemark> KML
3-D bar maps
3-D bars: One variable
3-D bars: Two variables
Animated maps

Thematic Mapping Engine
Thematic mapping parameters Web Interface PHP Library Web Processing Service KML/KMZ Thematic Mapping Engine Thematic Mapping Engine



Apache MySQL PHP Web server HTML / JavaScript Ext JS Google Earth API Web browser 1. Get list of indicators   2. Get list of available years  3. Make KML/KMZ document 4. Download KML/KMZ file  How it works
MySQL Data Connector Form Handler Database File Server Web server Web browser KML/KMZ files Web server infrastructure Thematic  Mapping  Engine
include ('TME_MySQL_DataConnector.php'); include ('TME_Engine.php'); $dataConnector = new DataConnector(); $dataStore = $dataConnector->getDataStore(68, 2005, 0);  $parameters = array( 'mapType’  => 'choropleth',   'indicator'  => 68,   'year'  => 2005,   'classification' => 'equal' ); $map = new ThematicMap($dataStore, $parameters); $file = $map->getKML(); Application Programming Interface (API)
KML structure Add KML header Technique Choropleth Prism Bar  Image Polygon Collada Type For each year For each feature Technique Choropleth Bar  Image Polygon Collada Type Prism  Add shared style Add shared style Add shared style Add shared style Colourise Collada object(s) Add style and feature Add style and feature Add style and feature Add style and feature Add style and feature Add link to Collada object Add map title and legend <Folder> <Placemark> </Placemark> </Folder> <kml> </kml> Symbol Symbol
Map legends Unclassed Equal intervals Quantiles
[object Object],[object Object],[object Object],[object Object],[object Object],[object Object],Google Earth fix!
thematic mapping.org

More Related Content

Similar to Using KML for Thematic Mapping

Rendering OpenStreetMap Data using Mapnik
Rendering OpenStreetMap Data using MapnikRendering OpenStreetMap Data using Mapnik
Rendering OpenStreetMap Data using Mapnik
Graham Jones

How data rules the world: Telemetry in Battlefield Heroes
How data rules the world: Telemetry in Battlefield HeroesHow data rules the world: Telemetry in Battlefield Heroes
How data rules the world: Telemetry in Battlefield Heroes
Electronic Arts / DICE

Google Mapy (Jaroslav Bengl)
Google Mapy (Jaroslav Bengl)Google Mapy (Jaroslav Bengl)
Google Mapy (Jaroslav Bengl)
Jiří Šmída

Advanced Kml
Advanced KmlAdvanced Kml
Advanced Kml
GoogleTecTalks

R Spatial Analysis using SP
R Spatial Analysis using SPR Spatial Analysis using SP
R Spatial Analysis using SP
tjagger

Beholding the giant pyramid of application development; why Ajax applications...
Beholding the giant pyramid of application development; why Ajax applications...Beholding the giant pyramid of application development; why Ajax applications...
Beholding the giant pyramid of application development; why Ajax applications...
Javeline B.V.

Google maps
Google mapsGoogle maps
Google maps
anupamasingh87

Google maps
Google mapsGoogle maps
Google maps
anupamasingh87

Introducing Modern Perl
Introducing Modern PerlIntroducing Modern Perl
Introducing Modern Perl
Dave Cross

Windows Phone 7 Bing Maps Control
Windows Phone 7 Bing Maps ControlWindows Phone 7 Bing Maps Control
Windows Phone 7 Bing Maps Control
Chris Pendleton

Creating Maps With Style
Creating Maps With StyleCreating Maps With Style
Creating Maps With Style
robertbray

Python And GIS - Beyond Modelbuilder And Pythonwin
Python And GIS - Beyond Modelbuilder And PythonwinPython And GIS - Beyond Modelbuilder And Pythonwin
Python And GIS - Beyond Modelbuilder And Pythonwin
Chad Cooper

How Groovy Helps
How Groovy HelpsHow Groovy Helps
How Groovy Helps
Ken Kousen

Building Complex GUI Apps The Right Way. With Ample SDK - SWDC2010
Building Complex GUI Apps The Right Way. With Ample SDK - SWDC2010Building Complex GUI Apps The Right Way. With Ample SDK - SWDC2010
Building Complex GUI Apps The Right Way. With Ample SDK - SWDC2010
Sergey Ilinsky

Playing with d3.js
Playing with d3.jsPlaying with d3.js
Playing with d3.js
mangoice

ESRI Developer Summit 2008 - Microsoft Virtual Earth
ESRI Developer Summit 2008 - Microsoft Virtual EarthESRI Developer Summit 2008 - Microsoft Virtual Earth
ESRI Developer Summit 2008 - Microsoft Virtual Earth
Chris Pendleton

10 Things You're Not Doing [IBM Lotus Notes Domino Application Development]
10 Things You're Not Doing [IBM Lotus Notes Domino Application Development]10 Things You're Not Doing [IBM Lotus Notes Domino Application Development]
10 Things You're Not Doing [IBM Lotus Notes Domino Application Development]
Chris Toohey

Pycon2011
Pycon2011Pycon2011
Pycon2011
Django Stars

Where20 2008 Ruby Tutorial
Where20 2008 Ruby TutorialWhere20 2008 Ruby Tutorial
Where20 2008 Ruby Tutorial
Shoaib Burq

Hadoop Hive Talk At IIT-Delhi
Hadoop Hive Talk At IIT-DelhiHadoop Hive Talk At IIT-Delhi
Hadoop Hive Talk At IIT-Delhi
Joydeep Sen Sarma


Similar to Using KML for Thematic Mapping (20)

Rendering OpenStreetMap Data using Mapnik
Rendering OpenStreetMap Data using MapnikRendering OpenStreetMap Data using Mapnik
Rendering OpenStreetMap Data using Mapnik

How data rules the world: Telemetry in Battlefield Heroes
How data rules the world: Telemetry in Battlefield HeroesHow data rules the world: Telemetry in Battlefield Heroes
How data rules the world: Telemetry in Battlefield Heroes

Google Mapy (Jaroslav Bengl)
Google Mapy (Jaroslav Bengl)Google Mapy (Jaroslav Bengl)
Google Mapy (Jaroslav Bengl)

Advanced Kml
Advanced KmlAdvanced Kml
Advanced Kml

R Spatial Analysis using SP
R Spatial Analysis using SPR Spatial Analysis using SP
R Spatial Analysis using SP

Beholding the giant pyramid of application development; why Ajax applications...
Beholding the giant pyramid of application development; why Ajax applications...Beholding the giant pyramid of application development; why Ajax applications...
Beholding the giant pyramid of application development; why Ajax applications...

Google maps
Google mapsGoogle maps
Google maps

Google maps
Google mapsGoogle maps
Google maps

Introducing Modern Perl
Introducing Modern PerlIntroducing Modern Perl
Introducing Modern Perl

Windows Phone 7 Bing Maps Control
Windows Phone 7 Bing Maps ControlWindows Phone 7 Bing Maps Control
Windows Phone 7 Bing Maps Control

Creating Maps With Style
Creating Maps With StyleCreating Maps With Style
Creating Maps With Style

Python And GIS - Beyond Modelbuilder And Pythonwin
Python And GIS - Beyond Modelbuilder And PythonwinPython And GIS - Beyond Modelbuilder And Pythonwin
Python And GIS - Beyond Modelbuilder And Pythonwin

How Groovy Helps
How Groovy HelpsHow Groovy Helps
How Groovy Helps

Building Complex GUI Apps The Right Way. With Ample SDK - SWDC2010
Building Complex GUI Apps The Right Way. With Ample SDK - SWDC2010Building Complex GUI Apps The Right Way. With Ample SDK - SWDC2010
Building Complex GUI Apps The Right Way. With Ample SDK - SWDC2010

Playing with d3.js
Playing with d3.jsPlaying with d3.js
Playing with d3.js

ESRI Developer Summit 2008 - Microsoft Virtual Earth
ESRI Developer Summit 2008 - Microsoft Virtual EarthESRI Developer Summit 2008 - Microsoft Virtual Earth
ESRI Developer Summit 2008 - Microsoft Virtual Earth

10 Things You're Not Doing [IBM Lotus Notes Domino Application Development]
10 Things You're Not Doing [IBM Lotus Notes Domino Application Development]10 Things You're Not Doing [IBM Lotus Notes Domino Application Development]
10 Things You're Not Doing [IBM Lotus Notes Domino Application Development]

Pycon2011
Pycon2011Pycon2011
Pycon2011

Where20 2008 Ruby Tutorial
Where20 2008 Ruby TutorialWhere20 2008 Ruby Tutorial
Where20 2008 Ruby Tutorial

Hadoop Hive Talk At IIT-Delhi
Hadoop Hive Talk At IIT-DelhiHadoop Hive Talk At IIT-Delhi
Hadoop Hive Talk At IIT-Delhi


Recently uploaded

Building Production Ready Search Pipelines with Spark and Milvus
Building Production Ready Search Pipelines with Spark and MilvusBuilding Production Ready Search Pipelines with Spark and Milvus
Building Production Ready Search Pipelines with Spark and Milvus
Zilliz

“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
Edge AI and Vision Alliance

System Design Case Study: Building a Scalable E-Commerce Platform - Hiike
System Design Case Study: Building a Scalable E-Commerce Platform - HiikeSystem Design Case Study: Building a Scalable E-Commerce Platform - Hiike
System Design Case Study: Building a Scalable E-Commerce Platform - Hiike
Hiike

Azure API Management to expose backend services securely
Azure API Management to expose backend services securelyAzure API Management to expose backend services securely
Azure API Management to expose backend services securely
Dinusha Kumarasiri

June Patch Tuesday
June Patch TuesdayJune Patch Tuesday
June Patch Tuesday
Ivanti

zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
Alex Pruden

Programming Foundation Models with DSPy - Meetup Slides
Programming Foundation Models with DSPy - Meetup SlidesProgramming Foundation Models with DSPy - Meetup Slides
Programming Foundation Models with DSPy - Meetup Slides
Zilliz

Serial Arm Control in Real Time Presentation
Serial Arm Control in Real Time PresentationSerial Arm Control in Real Time Presentation
Serial Arm Control in Real Time Presentation
tolgahangng

Taking AI to the Next Level in Manufacturing.pdf
Taking AI to the Next Level in Manufacturing.pdfTaking AI to the Next Level in Manufacturing.pdf
Taking AI to the Next Level in Manufacturing.pdf
ssuserfac0301

AWS Cloud Cost Optimization Presentation.pptx
AWS Cloud Cost Optimization Presentation.pptxAWS Cloud Cost Optimization Presentation.pptx
AWS Cloud Cost Optimization Presentation.pptx
HarisZaheer8

Fueling AI with Great Data with Airbyte Webinar
Fueling AI with Great Data with Airbyte WebinarFueling AI with Great Data with Airbyte Webinar
Fueling AI with Great Data with Airbyte Webinar
Zilliz

Let's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with Slack
Let's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with SlackLet's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with Slack
Let's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with Slack
shyamraj55

Monitoring and Managing Anomaly Detection on OpenShift.pdf
Monitoring and Managing Anomaly Detection on OpenShift.pdfMonitoring and Managing Anomaly Detection on OpenShift.pdf
Monitoring and Managing Anomaly Detection on OpenShift.pdf
Tosin Akinosho

GNSS spoofing via SDR (Criptored Talks 2024)
GNSS spoofing via SDR (Criptored Talks 2024)GNSS spoofing via SDR (Criptored Talks 2024)
GNSS spoofing via SDR (Criptored Talks 2024)
Javier Junquera

Columbus Data & Analytics Wednesdays - June 2024
Columbus Data & Analytics Wednesdays - June 2024Columbus Data & Analytics Wednesdays - June 2024
Columbus Data & Analytics Wednesdays - June 2024
Jason Packer

Generating privacy-protected synthetic data using Secludy and Milvus
Generating privacy-protected synthetic data using Secludy and MilvusGenerating privacy-protected synthetic data using Secludy and Milvus
Generating privacy-protected synthetic data using Secludy and Milvus
Zilliz

Nordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptxNordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptx
MichaelKnudsen27

Presentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of GermanyPresentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of Germany
innovationoecd

Choosing The Best AWS Service For Your Website + API.pptx
Choosing The Best AWS Service For Your Website + API.pptxChoosing The Best AWS Service For Your Website + API.pptx
Choosing The Best AWS Service For Your Website + API.pptx
Brandon Minnick, MBA

SAP S/4 HANA sourcing and procurement to Public cloud
SAP S/4 HANA sourcing and procurement to Public cloudSAP S/4 HANA sourcing and procurement to Public cloud
SAP S/4 HANA sourcing and procurement to Public cloud
maazsz111


Recently uploaded (20)

Building Production Ready Search Pipelines with Spark and Milvus
Building Production Ready Search Pipelines with Spark and MilvusBuilding Production Ready Search Pipelines with Spark and Milvus
Building Production Ready Search Pipelines with Spark and Milvus

“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...

System Design Case Study: Building a Scalable E-Commerce Platform - Hiike
System Design Case Study: Building a Scalable E-Commerce Platform - HiikeSystem Design Case Study: Building a Scalable E-Commerce Platform - Hiike
System Design Case Study: Building a Scalable E-Commerce Platform - Hiike

Azure API Management to expose backend services securely
Azure API Management to expose backend services securelyAzure API Management to expose backend services securely
Azure API Management to expose backend services securely

June Patch Tuesday
June Patch TuesdayJune Patch Tuesday
June Patch Tuesday

zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...
zkStudyClub - LatticeFold: A Lattice-based Folding Scheme and its Application...

Programming Foundation Models with DSPy - Meetup Slides
Programming Foundation Models with DSPy - Meetup SlidesProgramming Foundation Models with DSPy - Meetup Slides
Programming Foundation Models with DSPy - Meetup Slides

Serial Arm Control in Real Time Presentation
Serial Arm Control in Real Time PresentationSerial Arm Control in Real Time Presentation
Serial Arm Control in Real Time Presentation

Taking AI to the Next Level in Manufacturing.pdf
Taking AI to the Next Level in Manufacturing.pdfTaking AI to the Next Level in Manufacturing.pdf
Taking AI to the Next Level in Manufacturing.pdf

AWS Cloud Cost Optimization Presentation.pptx
AWS Cloud Cost Optimization Presentation.pptxAWS Cloud Cost Optimization Presentation.pptx
AWS Cloud Cost Optimization Presentation.pptx

Fueling AI with Great Data with Airbyte Webinar
Fueling AI with Great Data with Airbyte WebinarFueling AI with Great Data with Airbyte Webinar
Fueling AI with Great Data with Airbyte Webinar

Let's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with Slack
Let's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with SlackLet's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with Slack
Let's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with Slack

Monitoring and Managing Anomaly Detection on OpenShift.pdf
Monitoring and Managing Anomaly Detection on OpenShift.pdfMonitoring and Managing Anomaly Detection on OpenShift.pdf
Monitoring and Managing Anomaly Detection on OpenShift.pdf

GNSS spoofing via SDR (Criptored Talks 2024)
GNSS spoofing via SDR (Criptored Talks 2024)GNSS spoofing via SDR (Criptored Talks 2024)
GNSS spoofing via SDR (Criptored Talks 2024)

Columbus Data & Analytics Wednesdays - June 2024
Columbus Data & Analytics Wednesdays - June 2024Columbus Data & Analytics Wednesdays - June 2024
Columbus Data & Analytics Wednesdays - June 2024

Generating privacy-protected synthetic data using Secludy and Milvus
Generating privacy-protected synthetic data using Secludy and MilvusGenerating privacy-protected synthetic data using Secludy and Milvus
Generating privacy-protected synthetic data using Secludy and Milvus

Nordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptxNordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptx

Presentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of GermanyPresentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of Germany

Choosing The Best AWS Service For Your Website + API.pptx
Choosing The Best AWS Service For Your Website + API.pptxChoosing The Best AWS Service For Your Website + API.pptx
Choosing The Best AWS Service For Your Website + API.pptx

SAP S/4 HANA sourcing and procurement to Public cloud
SAP S/4 HANA sourcing and procurement to Public cloudSAP S/4 HANA sourcing and procurement to Public cloud
SAP S/4 HANA sourcing and procurement to Public cloud


Using KML for Thematic Mapping

  • 1. Using KML for Thematic Mapping Bjørn Sandvik thematicmapping.org MSc in Geographical Information Science University of Edinburgh Project Manager at United Nations Association of Norway Tech Talk at Googleplex 12 December 2008
  • 2.
  • 4. Proportional symbols #1 Scaling image icons
  • 5.
  • 6.
  • 7.
  • 8.
  • 9.
  • 10. Mathematical scaling of 2-D point symbols: symbolSize = power(value/maxValue; 1/2) * maxSize KML for proportional icon images <Style id='sharedStyle'> <IconStyle> <Icon> <href>files/symbol.png</href> </Icon> </IconStyle> <Style> KML <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <styleUrl>#sharedStyle</styleUrl> <Style> <IconStyle> <color>e50066ff</color> <scale>7</scale> </IconStyle> </Style> <Point> <coordinates>106.514,33.42,0</coordinates> </Point> </Placemark> KML
  • 11. Problem: Size affected by viewport
  • 12. Not working in Google Maps
  • 13. Proportional symbols #2 Drawing regular polygons
  • 14.
  • 15. Problem: Complicated! function kmlSymbolCalculator ( $longitude, $latitude, $radius, $vertices) { $EARTH_RADIUS_EQUATOR = 6378140.0; $RADIAN = 180 / pi(); $long = $longitude / $RADIAN; $lat = $latitude / $RADIAN; $f = 1/298.257; $e = 0.08181922; $kml = '<Polygon><outerBoundaryIs><LinearRing><coordinates>'; for ( $bearing = 45; $bearing <= 405; $bearing += 360/$vertices ) { $b = $bearing / $RADIAN; $R = $EARTH_RADIUS_EQUATOR * (1 - $e * $e) / pow( (1 - $e*$e * pow(sin($lat),2)), 1.5); $psi = $distance/$R; $phi = pi()/2 - $lat; $arccos = cos($psi) * cos($phi) + sin($psi) * sin($phi) * cos($b); $latA = (pi()/2 - acos($arccos)) * $RADIAN; $arcsin = sin($b) * sin($psi) / sin($phi); $longA = ($long - asin($arcsin)) * $RADIAN; $kml .= &quot; “ . round($longA,$this->coordDecimals) . &quot;,“ . round($latA,$this->coordDecimals); } $kml = '</coordinates></LinearRing><outerBoundaryIs></Polygon>'; return $kml; }
  • 16. Proportional symbols #3 Scaling 3-D Collada objects
  • 17.
  • 18.
  • 19. Mathematical scaling of 3-D point symbols: symbolSize = power(value/maxValue; 1/3) * maxSize Making proportional Collada objects Position Measure / scale Colorize Google SketchUp <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <Model> <Link> <href>files/object.dae</href> </Link> <altitudeMode>absolute</altitudeMode> <Location> <longitude>106.514</longitude> <latitude>33.42</latitude> <altitude>0</altitude> </Location> <Scale> <x>140000</x> <y>140000</y> <z>140000</z> </Scale> </Model> </Placemark> KML
  • 21.
  • 22.
  • 23.
  • 24. Using Google Chart API in KML <Style id='sharedStyle'> <BalloonStyle> <text><![CDATA[ <img src='http://chart.apis.google.com/chart ?cht=p&chd=t:20,45,5 &amp;chd=t: $[chartValues] '> ]]></text> </BalloonStyle> </Style> KML <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <styleUrl>#sharedStyle</styleUrl> <Style> <IconStyle> <scale>7</scale> <Icon> <href> http://chart.apis.google.com/chart?cht=p&chd=t:20,45,5&chs=300x150 &amp;chf=bg,s,ffffff00</href> </Icon> </IconStyle> </Style> <Point> <coordinates>106.514,33.42,0</coordinates> </Point> <ExtendedData> <Data name=&quot;chartValues&quot;> <value>20,45,5</value> </Data> </ExtendedData> </Placemark> KML
  • 26.
  • 28.
  • 29.
  • 30.
  • 32. KML used in prism maps Suggestion: <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <styleUrl>#sharedStyle</styleUrl> <Style> <PolyStyle> <color>DC0066FF</color> </PolyStyle> </Style> <MultiGeometry> <Polygon> <extrude>1</extrude> <altitudeMode>absolute</altitudeMode> <outerBoundaryIs> <LinearRing> <coordinates> 110.72,20.06, 2000000 109.26,19.9, 2000000 108.63,19.28, 2000000 108.69,18.51, 2000000 110.05,18.38, 2000000 111.03,19.64, 2000000 (...) </coordinates> </LinearRing> </outerBoundaryIs> </Polygon> <Polygon> (...) </Polygon> </MultiGeometry> </Placemark> KML <Placemark> <name>China</name> <Snippet>1,312,978,855 (2005)</Snippet> <styleUrl>#sharedStyle</styleUrl> <Style> <PolyStyle> <color>DC0066FF</color> </PolyStyle> </Style> <MultiGeometry> <Polygon> <extrude>1</extrude> <altitude>2000000</altitude> <altitudeMode>clampToAltitude</altitudeMode> <outerBoundaryIs> <LinearRing> <coordinates> 110.72,20.06 109.26,19.9 108.63,19.28 108.69,18.51 110.05,18.38 111.03,19.64 (...) </coordinates> </LinearRing> </outerBoundaryIs> </Polygon> <Polygon> (...) </Polygon> </MultiGeometry> </Placemark> KML
  • 34. 3-D bars: One variable
  • 35. 3-D bars: Two variables
  • 37.
  • 39. Thematic mapping parameters Web Interface PHP Library Web Processing Service KML/KMZ Thematic Mapping Engine Thematic Mapping Engine
  • 40.
  • 41.
  • 42.
  • 43. Apache MySQL PHP Web server HTML / JavaScript Ext JS Google Earth API Web browser 1. Get list of indicators 2. Get list of available years 3. Make KML/KMZ document 4. Download KML/KMZ file How it works
  • 44. MySQL Data Connector Form Handler Database File Server Web server Web browser KML/KMZ files Web server infrastructure Thematic Mapping Engine
  • 45. include ('TME_MySQL_DataConnector.php'); include ('TME_Engine.php'); $dataConnector = new DataConnector(); $dataStore = $dataConnector->getDataStore(68, 2005, 0); $parameters = array( 'mapType’ => 'choropleth', 'indicator' => 68, 'year' => 2005, 'classification' => 'equal' ); $map = new ThematicMap($dataStore, $parameters); $file = $map->getKML(); Application Programming Interface (API)
  • 46. KML structure Add KML header Technique Choropleth Prism Bar Image Polygon Collada Type For each year For each feature Technique Choropleth Bar Image Polygon Collada Type Prism Add shared style Add shared style Add shared style Add shared style Colourise Collada object(s) Add style and feature Add style and feature Add style and feature Add style and feature Add style and feature Add link to Collada object Add map title and legend <Folder> <Placemark> </Placemark> </Folder> <kml> </kml> Symbol Symbol
  • 47. Map legends Unclassed Equal intervals Quantiles
  • 48.
