Release WorkflowDiego Muñozdiego@tuenti.comhttp://twitter.com/Kartones
Agenda•   Some numbers•   Release workflow•   Some tools•   Some rants
Some numbers•   +12M users•   +100 usage minutes / day (avg)•   +200M chat messages / day•   +4M photos uploaded / day (pe...
Release WorkflowBranch   Code   Test   Integrate   Release   Stabilize
Release Workflow: BranchBranch      Code      Test    Integrate   Release   Stabilize•   8-12 branches per release•   Curr...
Release Workflow: Code + TestBranch      Code      Test      Integrate   Release   Stabilize•   Scrum (or at least Agile)•...
Release Workflow: IntegrateBranch     Code     Test   Integrate   Release   Stabilize•   Repo always available•   Only mer...
Release Workflow: ReleaseBranch    Code     Test    Integrate   Release   Stabilize• 2 releases per week (tuesdays & thurs...
Release Workflow: StabilizeBranch     Code     Test    Integrate   Release   Stabilize•   First code push: 8 AM•   Release...
Some tools
DVCS: Mercurial•   http://mercurial.selenic.com/•   Syntax similar to SVN (our old system)•   Easy API to plug our plugins...
Issue Tracking: Trac•   http://trac.edgewall.org/•   User Stories tasks•   Bugs•   Wiki•   Plugins and extensible•   Bottl...
Testing: PHPUnit• http://www.phpunit.de• Some caveats  – Mocking just ‘works’  – PHP process spawning PHP tests• We have: ...
CI: Jenkins• http://jenkins-ci.org/• Previously Hudson too• CI servers farm• Parallelization, plugins, special reports, cu...
Storage: MySQL• Live site storage• Dev. env. storage  – 1 DB per user (to run tests)  – 1 shared DB (common faked data)• B...
File copying: RSync•   http://rsync.samba.org/•   Deployment of code (live & dev)•   Sends deltas/diffs•   Really fast
Configuration: Puppet•   http://puppetlabs.com/•   Production machines•   Jenkins nodes•   VM management / Dev web servers...
Stats: Hadoop•   http://hadoop.apache.org/•   Dedicated cluster•   HBase•   Hive
VirtualBox•   https://www.virtualbox.org/•   Multi-platform•   Accurate and fast emulation of Windows OS•   Bottleneck: RA...
Search: Sphinx•   http://sphinxsearch.com/•   Non-realtime (index based)•   Very fast•   Bottleneck: Index generation on d...
Caching: Memcached• http://memcached.org/• Dev. Behaviour == live behaviour• Tuenti has sent improvements & patches  – UDP...
Some rants
Statics versioning: The good• Browser caching problems gone• Transparent & easy to use by developers• Easy to deactivate f...
Statics versioning: The bad• Dangerous if not careful with non-  production ready files• Waste of bandwith• No dev version...
File bundling: The good•   Less files == faster download & deploy•   Big text file == better HTTP Gzip•   Build time only ...
File bundling: The bad• Firebug debugging harder (big single files)• One syntax error breaks multiple bundled files  – Min...
Our Build script•   Localization•   Minification•   Bundling•   Versioning•   Statics deployment to CDNs•   Deltas of chan...
HipHop• Migrating old code to fully support HipHop  – With PHP 5.3• Obvious speed improvements• Also nice for static code ...
Our Chat•   Erlang (server) + Javascript (client)•   Jabber protocol•   Ejjabberd tweaked (3,5x faster)•   200M msgs/day, ...
exit(0); Sounds interesting?http://jobs.tuenti.com
Upcoming SlideShare
Loading in …5
×

Tuenti Release Workflow

3,031 views

Published on

At Tuenti, we do two code pushes per week, sometimes modifying thousands of files and running thousands of automated tests and build operations before, to ensure not only that the code works but also that proper localization is applied, bundles are generated and files get deployed to hundreds of servers as fast and reliable as possible.

We use opensource tools like Mercurial, MySQL, Jenkins, Selenium, PHPUnit and Rsync among our own in-house ones, and have different development, testing, staging and production environments.
We had to fight with problems like statics bundling and versioning, syntax errors and of course the fact that we have +100 engineers working on the codebase, sometimes merging and releasing more than a dozen branches the same day. We also switched from Subversion to Mercurial to obtain more flexibility and faster branching operations.
With this talk we will explain the process of how code changes in ourcode repository end up in live code, detailing some practices and tips that we apply.

Published in: Technology
  • Be the first to comment

Tuenti Release Workflow

  1. 1. Release WorkflowDiego Muñozdiego@tuenti.comhttp://twitter.com/Kartones
  2. 2. Agenda• Some numbers• Release workflow• Some tools• Some rants
  3. 3. Some numbers• +12M users• +100 usage minutes / day (avg)• +200M chat messages / day• +4M photos uploaded / day (peaks)• +40,000M page views / month• +35K requests / sec (peaks)• +1K servers• +250 employees (~60% techies)• +15K files in the repositories• +8K Tests
  4. 4. Release WorkflowBranch Code Test Integrate Release Stabilize
  5. 5. Release Workflow: BranchBranch Code Test Integrate Release Stabilize• 8-12 branches per release• Current record: 29 branches• Repository per functional area (be, fe, stats, …)• Avg. # lines modified per release: 63K
  6. 6. Release Workflow: Code + TestBranch Code Test Integrate Release Stabilize• Scrum (or at least Agile)• As TDD as possible• Labs• A/B Testing• PoCs• Dark launch
  7. 7. Release Workflow: IntegrateBranch Code Test Integrate Release Stabilize• Repo always available• Only merge with 100% tests ok / TFW approval• QA Regression & manual tests• Fix possible merge/integration problems ASAP
  8. 8. Release Workflow: ReleaseBranch Code Test Integrate Release Stabilize• 2 releases per week (tuesdays & thursdays)• Latest stable changeset from Integration taken previous day 11 AM• Release doc, pre-release meetings• Staging servers to test with live data• We are searching for a Release Manager ;)
  9. 9. Release Workflow: StabilizeBranch Code Test Integrate Release Stabilize• First code push: 8 AM• Release window: 3 hours (normal scenario)• Live error stabilization or rollback• Representatives from all involved teams
  10. 10. Some tools
  11. 11. DVCS: Mercurial• http://mercurial.selenic.com/• Syntax similar to SVN (our old system)• Easy API to plug our plugins and hooks• 100% cross-platform (now Git also but not before)• Commit hooks to check syntax, coding standards…• Bottleneck: – Push/pulls through VPN are slow
  12. 12. Issue Tracking: Trac• http://trac.edgewall.org/• User Stories tasks• Bugs• Wiki• Plugins and extensible• Bottleneck: Sometimes slow, code viewing not optimal
  13. 13. Testing: PHPUnit• http://www.phpunit.de• Some caveats – Mocking just ‘works’ – PHP process spawning PHP tests• We have: – Vastly improved mocking framework – Shell scripts that isolate test batteries – Better integration with Selenium• Bottleneck: Our current FEFW does not cope perfectly with PHPUnit/Selenium
  14. 14. CI: Jenkins• http://jenkins-ci.org/• Previously Hudson too• CI servers farm• Parallelization, plugins, special reports, custom tunnings• Bottleneck: Acceptance tests
  15. 15. Storage: MySQL• Live site storage• Dev. env. storage – 1 DB per user (to run tests) – 1 shared DB (common faked data)• Bottleneck: Slow when running tests
  16. 16. File copying: RSync• http://rsync.samba.org/• Deployment of code (live & dev)• Sends deltas/diffs• Really fast
  17. 17. Configuration: Puppet• http://puppetlabs.com/• Production machines• Jenkins nodes• VM management / Dev web servers config
  18. 18. Stats: Hadoop• http://hadoop.apache.org/• Dedicated cluster• HBase• Hive
  19. 19. VirtualBox• https://www.virtualbox.org/• Multi-platform• Accurate and fast emulation of Windows OS• Bottleneck: RAM of host machine
  20. 20. Search: Sphinx• http://sphinxsearch.com/• Non-realtime (index based)• Very fast• Bottleneck: Index generation on dev & test env.
  21. 21. Caching: Memcached• http://memcached.org/• Dev. Behaviour == live behaviour• Tuenti has sent improvements & patches – UDP patch, random ports• Bottleneck: 32GB RAM / machine practical limit
  22. 22. Some rants
  23. 23. Statics versioning: The good• Browser caching problems gone• Transparent & easy to use by developers• Easy to deactivate for testing
  24. 24. Statics versioning: The bad• Dangerous if not careful with non- production ready files• Waste of bandwith• No dev versioning == browser caching problems
  25. 25. File bundling: The good• Less files == faster download & deploy• Big text file == better HTTP Gzip• Build time only (no need for dev)• Combines perfectly with minification and versioning
  26. 26. File bundling: The bad• Firebug debugging harder (big single files)• One syntax error breaks multiple bundled files – Minimized + Bundled + Error == Real pain• Hierarchy needed to avoid bundling multiple times same files. – Web, external/public page, mobile…• Dev. only errors !
  27. 27. Our Build script• Localization• Minification• Bundling• Versioning• Statics deployment to CDNs• Deltas of changes or full build• …• Bottleneck: Build time
  28. 28. HipHop• Migrating old code to fully support HipHop – With PHP 5.3• Obvious speed improvements• Also nice for static code analysis
  29. 29. Our Chat• Erlang (server) + Javascript (client)• Jabber protocol• Ejjabberd tweaked (3,5x faster)• 200M msgs/day, 1M concurrent users peak,…• 20 machines, ~5 instances per machine• Same behaviour dev/live is critical• We’re searching for Erlang experts ;)
  30. 30. exit(0); Sounds interesting?http://jobs.tuenti.com

×
