  1. 1. SharePoint 2010 and Remote BLOB Storage<br />Thierry Gasser<br />
  2. 2. What is Remote BLOB Storage?<br />RBS is a feature of SQL 2008 and R2 !<br />Provides the ability to store BLOBs outside of a SQL database<br />Includes one easy Filestream provider which can be used to store BLOBs on an NTFS filesystem<br />SharePoint 2010 fully supports 3rd party Filestream<br />
  3. 3. Why Remote BLOB Storage?<br />Pro:<br />Potential performance improvements when storing for BLOBs that are larger than 1 MB<br />Potential storage cost savings from SAN to Fileshare (SAS)<br />In environments with frequent updates, fragmentation issues are easier to address <br />Cons:<br />RBS out of the box does not support<br />Database snapshots<br />Database mirroring<br />Encryption<br />More admin to manage the farm and SQL<br />Recommended to use a 3rd party provider which cost money. <br />
  4. 4. Process Flow – Saving a File<br />SharePoint WFE<br />7. Back to User<br />SharePoint Object Model<br />2. Enforce Business Logic<br />1. Save Request<br />RBS Client Library<br />Relational Access<br />3. Save BLOB<br />5. Return BLOB ID<br />6. Save Metadata & BLOB ID<br />BLOB Store<br />Provider Library<br />4. Write BLOB<br />SQL Server<br />BLOB<br />Store<br />Content<br />DB<br />Config<br />DB<br />
  5. 5. Install and Configuration<br />Step 1 - Enable FILESTREAM<br />
  6. 6. Install and Configuration<br />Step 2 - Enable FILESTREAM support in SQL<br />EXEC sp_configurefilestream_access_level, 2<br />Reconfigure<br />
  7. 7. Install and Configuration<br />Step 3 - Provision a BLOB Store – Create Master Key<br />use [WSS_Content]<br />if not exists (select * from sys.symmetric_keys where name = N'##MS_DatabaseMasterKey##')create master key encryption by password = N'Admin Key Password !2#4'<br />
  8. 8. Install and Configuration<br />Step 4 - Provision a BLOB Store – Add FilestreamFilegroup<br />use [WSS_Content]<br />if not exists (select groupname from sysfilegroups where groupname=N'RBSFilestreamProvider')alter database [WSS_Content]<br /> add filegroupRBSFilestreamProvider contains filestream<br />
  9. 9. Install and Configuration<br />Step 5 - Provision a BLOB Store – Add File to Filegroup<br />use [WSS_Content]<br />alter database [WSS_Content] add file (name = RBSFilestreamFile, filename = 'c:BlobstoreWSS_Content') to filegroupRBSFilestreamProvider<br />
  10. 10. Install and Configuration<br />Step 6 - Enable RBS on First SharePoint Server<br />msiexec /qn /lvx* rbs_install_log.txt /i RBS_X64.msi TRUSTSERVERCERTIFICATE=true FILEGROUP=PRIMARY DBNAME="WSS_Content" DBINSTANCE="DC" FILESTREAMFILEGROUP=RBSFilestreamProvider FILESTREAMSTORENAME=FilestreamProvider_1<br />On Subsequent Servers<br />msiexec /qn /lvx* rbs_install_log.txt /i RBS_X64.msi DBNAME="WSS_Content" DBINSTANCE="DBInstanceName" ADDLOCAL="Client,Docs,Maintainer,ServerScript,FilestreamClient,FilestreamServer"<br />
  11. 11. Install and Configuration<br />Step 7 - Use PowerShell to activate provider<br />$site = get-spsitehttp://siteurl<br />$rbss = $site.ContentDatabase.RemoteBlobStorageSettings<br />$rbss.Installed()<br />True<br />$rbss.Enable()<br />$rbss.SetActiveProviderName($rbss.GetProviderNames()[0])<br />$rbss<br /> Enabled ActiveProviderNameMinimumBlobStorageSizeUpgradePersistedProperties<br /> --------- ---------------------- ---------------------------- ------------------------------<br /> True FileStoreProvider_1 0 { }<br />
  12. 12. Installation – Next Steps<br />RBS works at the database level. When you create another database in the same farm<br />[Run the SQL commands]<br />msiexec /qn /lvx* rbs_install_Log.txt /i rbs_X64.msi REMOTEBLOBENABLE=1 FILESTREAMPROVIDERENABLE=1 DBNAME=<WSS_Content> FILESTREAMSTORENAME=FilestreamProvider_1 ADDLOCAL=EnableRBS,FilestreamRunScript DBINSTANCE=<DBInstanceName>><br />[PowerShell to Enable Provider]<br />
  13. 13. Advanced Configuration<br />Use PowerShell Configure the minimum size of content to be stored in the BLOB<br />Files smaller than this will be stored in the content database<br />$db= Get-SPContentDatabase–Site http:/[URL of site collection]$db.RemoteBlobStorageSettings.MinimumBlobStorageSize= [number of bytes]#db.Update()<br />
  14. 14. NTFS Configuration Best Practices<br />Configure AV to quarantine rather than delete infected files<br />Disable the generation of 8.3 names when files are created<br />fsutilbehavior set disable8dot3 1<br />Disable updating the last access time for a file when it is accessed<br />fsutilbehavior set disablelastaccess 1<br />
  15. 15. NTFS Configuration Best Practices<br />Perform regular defragmentation of volume(s) holding BLOB data<br />Disk quotas can be used to restrict storage<br />Configure the cluster size for volume(s) to host BLOB data to 64 KB<br />This must be done when the volume is formatted<br />format F: /FS:NTFS /V:MyFILESTREAMContainer /A:64K <br />
  16. 16. When should I use RBS with SharePoint?<br />I am a SharePoint Foundation user <br />Limitations on database size with SQL 2008 Express require the use of RBS.<br />Automatically configure RBS + FILESTREAM for WSS 3.0 users during upgrade!<br />I am an enterprise user with a large amount of content in SharePoint<br />MS recommendation is approximately 1TB or more, though you can still save costs if you have less data.<br />Research and planning are needed. Talk to providers!<br />
  17. 17. Performance Impact, some sample<br />SharePoint expects providers to have the following performance impact:<br />Throughput: 5 -10% degradation<br />Average Response time: Impact should be minimal as file size increases<br />SQL CPU Usage: 20% for small files, minimal impact for large files<br />
  18. 18. Read Throughput<br />
  19. 19. How do I Migrate BLOB Data to RBS?<br />Use Power shell Commandlet - Migrate<br />Moves BLOBs from current location to the current Active RBS Provider store. <br />Does deep copy of BLOBs – one BLOB at a time<br />Live Migration – no downtime is required<br />Migration processcan be terminated and resumed<br />
  20. 20. Migrate()<br />Use PowerShell to EXTERNALIZE all content<br />$site = get-spsite http://siteurl<br />$rbss = $site.ContentDatabase.RemoteBlobStorageSettings<br />$rbss.Migrate()<br />
  21. 21. Migrate()<br />Use PowerShell to INTERNALIZE all content<br />$site = get-spsite http://siteurl<br />$rbss = $site.ContentDatabase.RemoteBlobStorageSettings<br />$rbss.SetActiveProviderName(“”)<br />$rbss.Migrate()<br />$rbss.Disable() <br />$rbss<br /> Enabled ActiveProviderNameMinimumBlobStorageSizeUpgradePersistedProperties<br /> --------- ---------------------- ---------------------------- ------------------------------<br /> False 0 { }<br />
  22. 22. Backup and Restore<br />Order of Operations<br />
