Sarcoidosis<br />
Sarcoidosis<br /><ul><li>Sarcoidosis is a multisystem disorder  characterized by the presence of noncaseatinggranulomas.</...
Incidence and Prevalence<br /><ul><li>Disease can affect people of any age, race and gender.
20 to 40 years of age.
Most cases are Sporadic . 5 % of patients – FH of Sarcoidosis.</li></li></ul><li>Pathophysiology<br />Granulomas are Patho...
granulomas form in response to antigens that are resistant to "first-responder" inflammatory cells such as neutrophils and...
The antigenic triggering agents cause activation of the Helper T-cell and Macrophages <br /><ul><li>Activated Helper T-cel...
Giant cells are fused Macrophages-Langerhans giant cells. </li></ul>The central epithelioid and giant cells are surrounded...
All granulomas, regardless of cause, may contain additional cells and matrix. These include lymphocytes, neutrophils, eosi...
CYTOPLASMIC INCLUSION BODY Schaumann body (arrow) is common in sarcoidosis but is nonspecific.<br />
Clinical Manifestations<br />50% patients are asymptomatic<br />Abnormal "routine" chest radiograph<br />Symptomatic patie...
Clinical Manifestations<br />Respiratory symptoms are most common<br />Cough, chest discomfort, and dyspnea <br />Symptoms...
Lungs<br />First site involved<br />Begins with alveolitis involving small bronchi and small blood vessels <br />Alveoliti...
Noncaseating granuloma in lung is the characteristic lesion of sarcoidosis.<br />
CASEOUS NECROSISCellular destruction in TB granuloma appears as clumped debris (arrows). This necrosis does not occur in s...
M. tuberculosis BACILLI Caseous necrosis is most common in TB, but Gram negative, acid fast bacilli must be identified to ...
SUBPLEURAL GRANULOMA IN LUNG<br />
Eyes<br />25% have eye lesions<br />Blurred vision, pain, photophobia and dry eyes<br />Chronic uveitis leads to glaucoma,...
CONJUNCTIVITIS<br />
PAPILLEDEMA Often associated with 7th nerve facial palsy.<br />
Skin<br />33% have skin lesions<br />LOFGREN'S SYNDROME; acute triad of erythemanodosum, joint pains, and bilateral hilara...
NAKED GRANULOMA Young granulomas (arrows) in the skin with no surrounding rim of mononuclear cells.<br />
ERYTHEMA NODOSUM These reddish raised lesions. <br />
Skin<br />Lupus pernio- indurated blue purple swollen shiny lesions on nose, cheeks, lips, ears and fingers. <br />Papules...
LUPUS PERNIO <br />
RAISED PLAQUESThese raised plaques are the result of coalescence of nodules.<br />
PSORIASIS LIKE LESIONS These small white lesions closely resemble psoriasis.<br />
Liver<br />33% have hepatomegaly or biochemical evidence of disease <br />Symptoms usually absent<br />Cholestasis, fibros...
Musculoskeletal<br />Acute polyarthritis with fever is common<br />Arthritis is self limited<br />Chronic destructive bone...
PUNCHED OUT LYTIC LESIONS Focal osteolytic lesions in the fingers are most common abnormality.<br />
LACY TRABECULAR PATTERN Osteolysis has left a lacy trabecular pattern in this phalanx (arrow)<br />
DEFORMING LESIONS Advanced sarcoidosis with osteolytic lesions of the distal forearm, wrist, and bones of the hand<br />
SCLEROTIC LESION Rare and often in the axial skeleton.<br />
NASAL BONE LESION Nasal sarcoidosis can lead to osteolysis of the nasal bone (arrows).<br />
Heart<br />25% have cardiac involvement.<br />Sarcoidosis can affect any part of the heart.<br />Mostly Asymtomatic.<br />...
Cardiac Sarcoidosis<br />Arrhythmias<br />Heart blocks- common<br />Heart failure- Restrictive to Dilated CMP.<br />Perica...
Cardiac Sarcoidosis<br />Difficult to Dx.<br />Screening and Dx can be done by :<br />ECG ,Holter monitoring ,ECHO<br />Nu...
CNS<br />Neurosarcoidosis affects 15 percent of sarcoidosis patients. <br /> Some people with neurosarcoidosis will recove...
nerve inflammation and damage <br />peripheral neuropathy <br /><ul><li>Granulomas in the meninges (or more rarely in the ...
 MR IMAGE  Temporal lobe sarcoid lesion (arrow)<br />
Nervous System<br />Optic nerve dysfunction-Blurring,doublevision,blindness.<br />seizures<br />Paresthesias<br />Encephal...
<ul><li> CNS symptoms are not usually the first or only sign of sarcoidosis.</li></ul>Rarely Neurosarcoidosis is the only ...
Kidney<br />Granulomatous interstitial nephritis produces renal failure<br />Develops over a period of weeks to months<br ...
Kidney<br />Increased calcium absorption in the gut<br />Related to high levels of circulating 1,25-dihydroxy vitamin D pr...
Lymph Nodes<br />Lymphadenopathy<br />Intrathoracic nodes enlarged in 75-90% patients including hilar nodes and paratrache...
Enlarged B/L Hilar, RT paratracheal .<br />
CALCIFIED LYMPH NODES late manifestation in 5% of patients.<br />
PARACARDIAC LYMPH NODE<br />
ABDOMINAL LYMPHADENOPATHY Multiple enlarged paraaortic, paracaval, and porta hepatis lymph nodes (arrows).<br />
GASTRIC SARCOID Granuloma involves the gastric antrum leading to irregular nonspecific narrowing.<br />
COLONIC SARCOID Irregular narrowing of the rectosigmoid has the appearance of inflammatory disease or malignancy.<br />
Lab Abnormalities<br />Lymphocytopenia<br />Mild eosinphilia<br />Increased E.S.R<br />Hyperglobulenemia<br />
Lab Abnormalities<br /><ul><li>ACE levels elevated 60- 80%.
Activated macrophages produce ACE.
Non Specific-Hodgkins,histoplasma,leprosy
 ACE levels tested regularly to check the severity of the disease and to monitor the response to therapy.</li></li></ul><l...
STAGE I Thoracic lymphadenopathy. Normal lung parenchyma. (50%)<br />
STAGE II Hilar and mediastinal lymphadenopathy. Abnormal lung parenchyma. ( 30% )<br />
STAGE III Abnormal lung parenchyma. No lymphadenopathy. ( 15% )<br />
STAGE IV Permanent lung fibrosis. (20%)<br />
MILIARY SARCOIDOSIS CT shows well defined lung nodules less than 5mm in diameter. This pattern is rare.<br />
ALVEOLAR SARCOIDOSIS Multiple lung masses are an unusual form of sarcoidosis, resembles lung metastases.<br />
Lung Function Test<br />Lung function abnormalities for interstitial lung disease with decreased lung volumes and diffusin...
Radiography<br />“Egg shell” calcification of hilar nodes<br />Plural effusions<br />Cavitations<br />Atelectasis<br />Pne...
Lymph nodes with rim (eggshell) calcification (arrow) are rare in sarcoidosis but common in silicosis.<br />
MOST COMMON PATTERN Bilateral symmetric hilar and right paratracheal mediastinal adenopathy.<br />
Diagnosis<br />Difficult to differentiate from chronic infections, fungal diseases, T.B. and lymphoma. <br />Based on comb...
Diagnosis<br />Identify noncaseatinggranulomas<br />Transbronchial biopsies positive in 65-95%, even if no lung parenchyma...
Diagnosis<br />KVEIM TEST-Like Mantoux. <br />Involves injecting standardized preparation of sarcoid tissue material into ...
Diagnosis<br />Test not always positive <br />Test material not approved for sale by FDA. <br />
Differential Diagnosis<br />1.Hodgkin's disease:<br /> Mediastinal lymphadenopathy predominates in the anterior mediastinu...
   2. Pulmonary tuberculosis:<br /><ul><li> Nodal enlargement   is unilateral in about 80% of tuberculosis cases.
 Lymph nodes are less well demarcated than in sarcoidosis.
 Lymphadenopathy is almost always associated with ipsilateral lung disease</li></li></ul><li>3.Fungal infections:<br /><ul...
Coccidioidomycosis</li></ul>   Lymphadenopathy may be unilateral or bilateral and is usually associated with parenchymal d...
4.Bronchogenic carcinoma:<br /> Unilateral hilar lymphadenopathy is common. <br />The appearance of the primary lung cance...
5.Metastatic lymph node enlargement: <br />Primary cancer in the kidney,  prostate gland, or the UGI tract usually involve...
Prognosis<br />Good<br />In 15-20% remains active or recurs intermittently. <br />50% have some permanent organ dysfunctio...
