  1. 1. Transistors Electrical and Electronic Principles © University of Wales Newport 2009 This work is licensed under a Creative Commons Attribution 2.0 License .
  2. 2. <ul><li>The following presentation is a part of the level 4 module -- Electrical and Electronic Principles. This resources is a part of the 2009/2010 Engineering (foundation degree, BEng and HN) courses from University of Wales Newport (course codes H101, H691, H620, HH37 and 001H). This resource is a part of the core modules for the full time 1 st year undergraduate programme. </li></ul><ul><li>The BEng & Foundation Degrees and HNC/D in Engineering are designed to meet the needs of employers by placing the emphasis on the theoretical, practical and vocational aspects of engineering within the workplace and beyond. Engineering is becoming more high profile, and therefore more in demand as a skill set, in today’s high-tech world. This course has been designed to provide you with knowledge, skills and practical experience encountered in everyday engineering environments. </li></ul><ul><li>Contents </li></ul><ul><li>Bipolar Transistors </li></ul><ul><li>Construction process for a depletion planer transistor </li></ul><ul><li>Field Effect Transistors </li></ul><ul><li>Metal Oxide Semiconductor Field Effect Transistors (MOSFET) </li></ul><ul><li>Credits </li></ul><ul><li>In addition to the resource below, there are supporting documents which should be used in combination with this resource. Please see: </li></ul><ul><li>Green D C, Higher Electrical Principles, Longman 1998   </li></ul><ul><li>Hughes E , Electrical & Electronic, Pearson Education 2002 </li></ul><ul><li>Hambly A , Electronics 2 nd Edition, Pearson Education 2000 </li></ul><ul><li>Storey N, A Systems Approach, Addison-Wesley, 1998 </li></ul>Transistors
  3. 3. Bipolar Transistors These are three layer devices, either N-P-N or P-N-P. The operation of each type is the same with the exception that the power supplies are reversed. We will focus on the N-P-N as they are the most common and tend to use positive supplies. The most common way of producing a transistor is by a planar diffusion process. The transistor is effectively created on one face (plane) of a semiconductor material, as shown below: Transistors SiO n n p
  4. 4. Steam is passed over the surface and a layer of oxide is formed. A layer of photo resist is applied to the surface A mask is now placed over the surface The surface is exposed to light which softens the photo resist The mask and light are removed and the softened photo resist dissolved The exposed Silicon Oxide is removed using an acid and then the remaining photo resist is also removed. A gas rich in p dopant is now passes over the surface and a region of p Silicon begins to grow. The oxide layer is removed and the process continues to the next depletion layer. n n p Construction process for a depletion planer transistor
  5. 5. The construction can be thought of as a sandwich of p material as below. The B – base is always the sandwich material The E – emitter is the area that is normally a well in the base area The C – collector is the substrate into which the other areas are formed. Transistors n n p E C B
  6. 6. The emitter always is the one with the arrow. For a pnp transistor the arrow points into the base region. When the junctions are constructed then we will have electron movement similar to the diode and barriers will be set up as below: Transistors E C B n n p E C B
  7. 7. When the transistor is used, voltages are set up around the device. These voltages are called bias voltages and they are of the following form: 0 V + V ++ V - V 0 V + V Note: Base Emitter junction is forward biased and the Collector Base junction is reverse biased Transistors
  8. 8. This has the following effect on the junction potentials: V CB V BE Emitter Base Collector As V BE reaches Vj, electrons in the emitter will flood into the base region where they would normally recombine to produce a base current. e e e e e e e e Transistors
  9. 9. <ul><li>There are a number of factors that affect the minority electrons in the p-type base region. These are: </li></ul><ul><li>During the manufacture of the transistor the base width is made very small and therefore the probability of recombining before reaching the base collector barrier is reduced. </li></ul><ul><li>When the transistor is formed either side of the junctions is formed a depletion region where no carries exist. This is due to the movement of electrons from the n into the p and the filling of the holes in the p material. As we have two depletion regions in the base, the area for recombination is therefore reduced. </li></ul><ul><li>The reverse bias of the base collector region means that an electron in the base will be accelerated towards the barrier. This reduces the likelihood of recombination. </li></ul>Transistors
  10. 10. These effects combine to give the following: The majority of the electrons injected into the base, end up making it across to the collector. The small percentage that recombine form the base current. The ratio of the collector emitter current to the base emitter current gives us the current gain of the transistor. Transistors Electron flow Emitter Base Collector
  11. 11. Ib Ic Ie Ie = Ic + Ib Normally Ic >> Ib and so Ic  Ie Characteristics. There are two characteristics. The input characteristic – this is very similar to the diode characteristic and is a plot of Ib to a base of Vbe. The output characteristic – this is a plot of Ic to a base of Vce annotated by Ib (for different values of Ib). A typical plot is shown. Transistors
  12. 12. What can be seen is that the current flowing for a certain value of base current remains fairly constant as the voltage is increased. Transistors Ib = 10  A Ib = 8  A Ib = 6  A Ib = 4  A Ib = 2  A Ib = 0  A
  13. 13. We will examine how this device is used later in the module. The value of current gain hfe can be given by: Transistors
  14. 14. Field Effect Transistors There are two types of FET: The Junction Field Effect Transistor (JFET or JUGFET) This uses a rod of doped silicon with a collar of opposite doped material defused into the rod. Transistors n p Source S Drain D Gate G
  15. 15. This can be shown in the following way: This is referred to as an n channel JFET as the conduction from drain to source takes place via a channel of n-type material. If the materials were reversed then this would be a p channel. Transistors n p S D G
  16. 16. When the device is constructed there exists a depletion region either side of the junction that is effectively a non-conduction region. This is shown dotted red on the diagram. This effectively reduces the cross sectional area of the channel – hence increasing its resistance. If the gate is made negative then little or no current will flow as the junction is reverse biased but this will increase the size of the depletion region and when the gate voltage Vg reaches a certain level the channel cuts off. This is called the cut-off voltage V CUT-OFF Transistors
  17. 17. If we were to plot the current flow through the device against the gate voltage we would have a graph of the form: Transistors
  18. 18. The voltages to the JFET are normally as shown below: This leads to a modification of the depletion region. Consider a voltage on the gate less than the cut-off with a positive voltage on the drain. Transistors D S G 0V -ive +ive n p S D G 0V -ive +ive
  19. 19. The depletion region gets bigger as we move towards the drain. This is because of the current flowing through the devices causing a voltage drop down its length. The channel is effectively pinched off and this limits the current to a maximum value that is dependent upon Vg. The more negative Vg becomes the smaller the current required to pinch off the channel. Pinching off does not stop the current but it limits it to a maximum value. The output characteristic for such a device is shown. Transistors
  20. 20. 0V -0.2V -0.4V -0.6V -0.8V -1V The gain of this device will be quoted as an output current over an input voltage. We will see how this device is used later in the module.
  21. 21. Metal Oxide Semiconductor Field Effect Transistors (MOSFET) The basic operation of these devices depends upon the reduction or creation of a conduction channel through which current will flow. Let us examine a device that depletes an existing channel. N channel depletion MOSFET Transistors Metal Al SiO n+ n+ n Source Drain Gate p
  22. 22. With no voltage on the gate there is a path from the source to the drain n+  n  n+ and therefore we would have a current flow taking place. If the gate is now made negative then we will have a field set up across the insulating silicon oxide. Note the SiO is very thin usually about 1000 Å, which is 0.1  m and therefore the field will be large even for small voltages. (1V = 10 million V/m) This field will drive away the electrons in the n channel and effectively reduce its cross sectional area. This will increase the channel resistance and reduce the current flow. When the gate voltage is made negative enough the channel disappears and we have cut-off. As with the JFET we will have pinch-off when a current flows through the device and the depletion is distorted.
  23. 23. The characteristic for this device will be very similar to the JFET. The other type of MOSFET starts off with no channel and when a voltage is applied to the gate a channel is created or enhanced. N channel enhancement MOSFET In this device the channel initially with zero gate voltage does not exist. See below Metal Al SiO n+ n+ Source Drain Gate p
  24. 24. With no voltage on the gate there is no flow of current between the source and drain. n+  p  n+ If the gate is now made positive then the large field (once again the SiO is very thin) will attract electrons to the area under the insulating strip. This will result in the channel becoming n type. The greater the positive voltage on the gate, the greater the area of the channel and hence the lower the resistance and the greater the current. We can say that a channel is being enhanced. If we construct p channel devices the opposite polarity is required on the gate to cause the effect. P channel N channel Depletion Positive Negative Enhancement Negative Positive
  25. 25. Drain D Source S Gate G Drain D Source S Gate G 1 Substrate G 2 Gate G The three circuit symbols are for a p-channel MOSFET. (b) can be either depletion or enhancement types, whereas (c) represents specifically an enhancement device. In (a) the substrate is understood to be connected internally to the source. For an n-channel MOSFET the direction of the arrow is reversed. (a) (b) (c) Transistors Drain D Source S
