Energy Usage in South AfricanPermanent Mould (Die Casting)         Foundries         Carl Reinhardt             KJJC Tradi...
Disclaimer• Casting Services has relied substantially upon information provided  by the literature and by experts in the f...
Energy Costs Money• Don’t waste it     • Insulation     • Unburnt fuel     • Dross build up     • Wasted heat – often easi...
Energy Cost Money– Use it well   • Yield      – Casting Yield      – Machining Yield   • Rejects   • Metal Losses   • Don’...
Energy Costs Money– Use the most cost effective  • For your area  • For your furnace type  • For your metal type          ...
South African Foundries• Data  – How much Energy Do we Use?  – Data  – How much does it cost?  – Data  – How much do the d...
The Data           The Data must be                   relevant                   The Data must be                   compar...
South African Foundries• Permanent Mould Foundries  – Die casting     • Gravity        – Conventional        – Tilt       ...
Gravity Die CastingHigh Pressure Die Casting (Cold Chamber)                         Counter Gravity                       ...
South African Foundries• Other types of foundries  – Anything that isn’t a permanent mould foundry  – This data is collect...
The Data• Data Collected from site visits to foundries  between July 2009 to September 2009• Data from 38 Permanent mould ...
Types of Foundries          Data Collected from• 13 (+8 from Sept 2008) foundries who  engage in    • High Pressure Die Ca...
Types of Foundries          Data Collected from• Another 15 Foundries who do  – Gravity Casting  – Tilt (and Counter Gravi...
Types of Foundries              Data Collected from• A further 9 foundries  – Who do       • Gravity die casting       • L...
The Data• Total GJ (Energy usage of all 38 foundries over 12 month period)   – 447 453 GJ   – This is enough to theoretica...
The Data                              Total Energy Consum ption                                        Energy Cost        ...
The Data                                     Yield                                                                        ...
The Data                                     Yield                                                                  Yield ...
Dross                                                              Z n D rB ss Per cent ag e er cent ag e                 ...
The Data• Reject Rate  – Over half of the companies did not record their rejects    formally.  – Three quarters of them di...
Types of FoundriesData Collected from    Are you still with me?               21
Calculations to GJApproximate Calculation factors*•   Electricity – kWh to GJ – kWh x 3600/1000/1000•   Natural Gas – Norm...
The Costs of Energy in SA                                                                    R/GJ                         ...
Real Cost• According to Energy Workshop in USA August 2009• Efficiency of Furnaces• Furnace types for different Fuels   – ...
Real Cost to Heat Metal• Real Cost – Cost to put energy into metal              R/Metal GJ  – Depends on Furnace type – th...
Real Energy Cost to Heat Metal wrt Furnace type                                                              Efficiency   ...
Real Energy Cost to Heat Metal wrt Furnace type                               High Cost (low efficiency)                  ...
Conclusion• Use best energy for your area  – Find out how much different energy types cost    in your area• Use and setup ...
