Phase E Cost Growth StudyRobert Bitten, Marc Hayhurst, Debra Emmons,The Aerospace CorporationClaude Freaner, Voleak RoeumN...
Outline    •   Introduction    •   Phase E Cost Change using 20 mission data set        – Changes by Phase        – Change...
Introduction  •   Abstract      – Phase E is the payoff for the long awaited development of NASA science        missions a...
Outline    •   Introduction    •   Phase E Cost Change using 20 mission data set        – Changes by Phase        – Change...
20 Mission Detailed Phase E Database* for Cost Growth   Assessment                                          Launch        ...
All Missions Phase E Growth Relative to KDP-B Plan                                                                        ...
Prime Mission Phase E Cost Growth by Phase  50%                                            45%                            ...
Comparison of Growth from KDP-B Plan for Competed vs.Directed Missions                                            60%     ...
Prime Mission Phase E Cost Growth from Launch Plan              Percent Growth for Prime Mission Relative to Plan at Launc...
Prime Mission Phase E Cost Growth from Launch Plan              Percent Growth for Prime Mission Relative to Plan at Launc...
Prime Mission Annual Cost Growth Example                                                                   Venus Flyby    ...
Prime Mission Phase E Cost Growth from Launch Plan              Percent Growth for Prime Mission Relative to Plan at Launc...
Missions Lifetime for Study Data Set                                                                               Planned...
Prime Mission Phase E Cost Growth from Launch Plan               Percent Growth for Prime Mission Relative to Plan at Laun...
Comparison of Annual Cost - Prime vs. Extended Missions               Average Phase E FY Cost (FY11$M) for Prime and Exten...
Extended Mission Cost Growth Due to Anomaly                                                     Cloudsat FY11 Operations  ...
Potential Reasons for Phase E Cost Growth•   Phase E cost estimates for Competed missions may be optimistic     – Competed...
Summary of Phase E Cost Growth for 20 Mission Data Set•   Prime Mission Observations     – Phase E cost projections, on av...
Outline    •   Introduction    •   Phase E Cost Change using 20 mission data set        – Changes by Phase        – Change...
46 Mission Data Set*                     Launch                Mission    Instru-                               Launch    ...
Summary of Phase E Cost vs. Mission Class                                                 Phase E Cost per Mission Class  ...
Average Number of Instruments for Flagship vs. Non-Flagship Missions                                                   Ave...
Summary of Phase E Cost for Non-Flagship Missions                                             Phase E Cost for Non-Flagshi...
Observations for Phase E Cost for Non-Flagship Missions•   Astrophysics missions are most costly on a per instrument basis...
Summary of Phase E Cost for Flagship Missions                                               Phase E Cost for Flagship Miss...
Observations for Phase E Cost for Flagship Missions•   Trends are similar to non-Flagship mission sets as Astrophysics &  ...
Ratio of Phase E Cost for Flagship vs. Non-FlagshipMissions                                                  Ratio of Phas...
Summary of Phase E Cost Growth for 46 Mission Data Set•   As expected, larger missions have greater annual Phase E cost an...
Outline    •   Introduction    •   Phase E Cost Change using 20 mission data set        – Changes by Phase        – Change...
Study Summary•   Phase E Cost Growth Assessment     – On average, Phase E cost increases 42% from the original KDP-B plan ...
