ATOMIC STRUCTURE   -: made easy:-                  by           M.,Anwar Sohail  Bachelor of Science and Education Master ...
Democritus’ atom      [Hypothetical / Not based on             experiments]   Democritus proposed   that matter is compose...
Dalton’s atomic theory        (1808)    [Based on experiments] Every element is made of tiny,  unique particles called at...
Discovery of     fundamental or   subatomic particles The electrons, protons and neutrons  are called fundamental particle...
Canal Rays and Protons               (1886)      Eugene Goldstein noted streams of positively charged       particles in ...
Discovery of Electrons (1897)   Electrons are discovered   by J.J. Thompson when high   voltage is applied across a sealed...
Discovery of      Neutrons (1932) James Chadwick in 1932 analyzed  the results of α-particle scattering  on thin Be films...
Characteristics of    subatomic particles at a            glance08/19/12   Mr. Sohails   8
Thomson’s Atomic               model(1898)           (Also called Plum-pudding                     model)                 ...
Rutherford’s Alpha           particles scattering            experiment (1911)      Rutherford       bombarded Alpha     ...
Inference from Rutherford’s                   experiment      Almost all the Alpha       particles passed       through t...
Rutherford’s Alpha Rays Scattering Experiment             Most of the Alpha Particles passed Through.Alpha        OneParti...
Rutherford’s Atomic model                 (1920)   Based on his experiment he postulated a     model. The important postul...
Atomic (z)# and Mass #  Atomic # is the # of protons present   inside the nucleus of an atom.  It’s unique to each eleme...
Mass # (A)  Mass # is the sum of the # of protons   and neutrons present inside the   nucleus of an atom. Therefore, must...
Isotopes     Atoms of the same element with      different mass #.     They have 1.   Same atomic # 2.   Same symbol 3. ...
Isotopic Symbol                               Net ChargeMass # (A)Atomic # (Z)                              Symbol08/19/12...
The 3 Nuclie of H isotopesP                   P                      PN                   N                      NZ       ...
Average Atomic Mass   Weighted average of the atomic    masses of all the naturally occurring    isotopes of an element i...
Calculating Average        Atomic Mass  (Mass of A*%) + (Mass of B*%)                        100   Complete Average Atomic...
Isotones Isotones are atoms of different  elements with same # of neutrons. Examples: S – 32 and P – 31 Ca – 40 and K ...
Problems with Rutherford’s                    model      As per the classical laws of Physics: if a particle       (elect...
Band spectrum      When white light is passed through a       prism, it splits in to 7 different colors and       they ap...
Line Spectrum or Atomic              emission spectrum     When electricity is passed through a tube filled      with a g...
Absorption             spectrum       An absorption spectrum is formed by        shining a beam of white light through a ...
Characteristics of Light08/19/12   Mr. Sohails   26
Characteristics of Light   Velocity (c): Distance traveled by light in 1 second.    It’s a constant 3.00 x 10 8 m/s    c=...
Frequency, Wavelength & Energy             relationshipsWhen frequency increases: Energy increases Wavelength decreasesW...
Bohr’s atomic model   Neils Bohr presented his atomic      model retaining the basic idea      of Rutherford’s model. The ...
Bohr’s model                      Continued:-   4. More than one energy      levels are possible for an      electron. How...
Modern Model               or    Wave Mechanical Model               or   Quantum Mechanical Model          of the atom08/...
Particle nature of light(1901)            Max Plancks Quantum Theory    Max Planck studied the radiation emitted by vario...
DeBroglie’s           Dual nature of electron    Based on Planck’s quantum     theory and Bohr’s quantized     orbits, De...
Heisenberg’s uncertainty                 principle Its impossible to find out both the position and the  speed of an elec...
Splitting of Bohr’s Spectral lines                       Introduction to            Orbitals/Quantum #s With a regular spe...
Principle Quantum #   Bohr’s spectral lines.   = Energy Level or Bohr’s atomic orbits.   Values: any # 1,2,3,….so on fr...
Azimathul Quantum # l   Splitting of Bohr’s spectral lines under high resolution    spectroscope.   = sub energy Levels ...
Magnetic Quantum # (m) Splitting of high resolution lines in  magnetic field. Also called angular momentum Q #. # of m ...
Figure out the m values1.     How many m values are there for s orbital?2.     What are they?3.     How many m values are ...
Spin Quantum # (s) Indicates electron spin in the orbital or  electron cloud (either clockwise or  counterclockwise) Val...
Atomic Orbitals   As it is impossible to locate an electron’s exact    position at a given time, therefore:   The area a...
Orbitals and Electrons  Energy level          Types of         # of Orbitals         Electrons        Total # of electrons...
s Orbitals           There is one s Orbitals in each energy level                   Each one can hold 2 electrons.08/19/12...
p Orbitals             There are 3 p Orbitals in each energy level                   (from 2nd energy level on wards)  Eac...
d Orbitals           There are 5 p Orbitals in each energy level                  (from 3rd energy level on wards)Each one...
What does the modern      atom look like?08/19/12   Mr. Sohails   46
Electron Configuration   Arrangement of electrons in the various orbitals    of the atom of an element is called electron...
Atomic Orbital Energy            Diagram08/19/12   Mr. Sohails   48
End of           Pr esentation        Remember the Atomic              Structure.  It is the key to learn Chemistry08/19/1...
