1. Cloth Heating Jackets
Features
Before After
Centipede 2®
See Pages 84 - 87
Ideal for a Wide Range of
Applications
• Ability to heat and insulate all components of a system
• Diameters as small as ¼” (6mm)
• Flanges, VCR nuts, valves, unistruts, etc.
• Uniform temperatures throughout entire line or component
• Easy on-off installation with durable and reusable hook and loop
fasteners
• High temperature capabilities
• Up to 250°C for Class 10 Clean rooms
• Up to 593°C for Class 100 Clean rooms
• Energy efficient design
• Patented grounded heating element
• Exceptional durability
• Compatible with Centipede 2®
Temperature Control System or
existing control system
Benefits
• Economically reduces condensation build-up and contamination
• Increased productivity
• Decreased maintenance
• Energy-savings
• Safe and cool to the touch (meets SEMI S2 standards)
• Long service life: BriskHeat's typical heating jacket life is 10+ years. No
need for aftermarket parts
80
Y o u r H e a t i n g S p e c i a l i s t s i n c e 1 9 4 9
Toll Free: 800-848-7673 Phone: 614-294-3376 w w w .BriskHeat. c o m Email: bhtsales1@briskheat.com Fax: 614-294-3807
© BriskHeat Corporation. All Rights Reserved. 16-03
CLOTHHEATERS
ANDINSULATORS
C L O T H H E A T I N G J A C K E T S
M.S. Jacobs & Associates Pittsburgh, PA USA
www.msjacobs.com

2. • Gas Lines
• Exhaust Lines
• Forelines
• Abatements
• Valves
Cloth Heating Jackets Cont.
• Tanks, drums, cylinders and
vessels
• Laboratory equipment
• Analytical equipment
• Vacuum bake-out
• Emission testing
• Fluid delivery systems
• Small and unique geometries
Ability to engineer a solution for your
EXACT needs
81Toll Free: 800-848-7673 Phone: 614-294-3376 w w w .BriskHeat. c o m Email: bhtsales1@briskheat.com Fax: 614-294-3807
Y o u r H e a t i n g S p e c i a l i s t s i n c e 1 9 4 9
© BriskHeat Corporation. All Rights Reserved. 16-03
CLOTHHEATERS
ANDINSULATORS
C L O T H H E A T I N G J A C K E T S

3. Contact your local BriskHeat®
representative to have a
cloth heating jacket designed for your application.
How to Order:
Cloth Jacket Design Options
What are the Different Parts of a Cloth Jacket?
Liner and Facing Material (Inside and Outside cloth material):
• PTFE - Standard facing material. Up to Class 10 environments.
Exposure temperature up to 500˚F (260˚C).
• BriskClean Cloth - For cleanroom Class 10 environments.
Exposure temperatures up to 600˚F (315˚C).
• Silicone Cloth - Adds moisture and chemical resistance.
Exposure temperatures up to 500˚F (260˚C).
• Samox®
- Highest temperature material. Up to Class 100 environments.
Exposure temperatures up to 1100˚F (593˚C)
• Aluminum - Facing material option.
Exposure temperature up to 450˚F (232˚C).
• Fiberglass Cloth - Liner material option.
Exposure temperature up to 900˚F (482˚C). Up to Class 100 environments.
Closure Options:
• Hook and Loop Fastener
• Hook and Lace
• Grommets
Insulation (placed in between liner and facing):
Fits your application based upon process temperatures.
BriskHeat’s industry leading engineers will design your
system with the correct amount of insulation. Insulation will
make your system energy efficient and touch-safe.
Built-In Low-Limit Alarm Thermostat Options:
• 180°F (82°C) with 30°F (17°C) differential
• 248°F (120°C) with 50°F (28°C) differential
Other Temperatures Available
Other Temperatures Available
Built-in Controlling/
High Limit Thermostat Options:
• 180°F (82°C)
• 248°F (120°C)
• 302°F (150°C)
• 347°F (175°C)
• 392°F (200°C)
• 500°F (260°C)
• 120-600 VAC
• Single Phase
• 3 Phase (Wye)
• 3 Phase (Delta)
• 60 Hz.
• 50 Hz.
• DC
Voltage Options:
Power Plug / Connector Options:
• Mate-N-Lock
• Twist Lock
• CPC Connector
• Bare Wire
• Other Electrical
Connections Available
• Platinum RTD PT100
• Type J Thermocouple
• Type K Thermocouple
• Thermistor
• Other Temperature
Sensors Available
Temperature Sensor Options:
Durable and Flexible Mutli-stranded
Resistance Wire
Patented Grounded Heating Element
for Your Safety
Resistance Wire Spaced Tightly for
Optimal Heat Uniformity
Insulated for Superior Thermal Efficiency
and Cool-to-the-Touch Safety
Material Options Designed for Your
Environment including Class 10 Clean rooms
PTFE BriskClean
Silicone Samox®
Aluminum Fiberglass
