Geometric Tolerancing

  1. 1. Geometric Tolerancing<br />Design for Manufacture<br />Geometric tolerancing<br />Agreed by ISO 1001 included in BS308 <br />(drawing standard) <br />Author: Leicester College<br />Date created:<br />Date revised: 2009<br />Abstract: <br />Geometric tolerancing is a method which is widely used in industry when the more basic systems of tolerancing component features does not provide the required accuracy. <br />The system of geometric tolerancing id detailed together with the particular features of the system.<br />© Leicester College 2009. This work is licensed under a Creative Commons Attribution 2.0 License. <br />
  2. 2. These files support the Edexcel HN unit – Design for Manufacture (NQF L4)<br />For further information regarding unit outcomes go to Edexcel.org.uk/ HN/ Engineering / Specifications<br />Geometric Tolerancing<br />
  3. 3. Geometric Tolerancing<br />Purpose – <br /><ul><li>Geometric tolerance symbols give precise indication of GEOMETRIC requirement for a given feature / drawing
  4. 4. Symbols universally understood
  5. 5. Used when normal dimensioning and tolerancing are not sufficient for requirements of component / operation</li></li></ul><li>Geometric Tolerancing<br /><ul><li>Only use geometric tolerancing if it is absolutely necessary to the required design function
  6. 6. It adds to the cost of both manufacture and inspection</li></li></ul><li>Geometric Tolerancing<br />The symbols used represent a range of potential geometric features of a form of feature<br />Four types<br /><ul><li>Form
  7. 7. Orientation
  8. 8. Location
  9. 9. Runout</li></li></ul><li>Geometric Tolerancing<br />Symbol construction<br />
  10. 10. Geometric Tolerancing<br />Tolerance frame<br />This type of frame used when no datum is required<br />This type of frame used when a datum is specified – mandatory for some geometric features<br />
