Pairwise and Combinatorial testing can dramatically improve the efficiency and effectiveness of both test design (identifying and document what to test) as well as test execution (the process of executing the test cases).

This presentation, by Justin Hunter, the founder of Hexawise, to members of TISQA, explains how these methods work, highlights empirical evidence that shows this method has been proven to more than double the number of defects found per tester hour in ten separate projects, and highlights a case study of a recent user of the Hexawise test design tool.

Published in: Technology, Education
3 Comments
8 Likes
Statistics
Notes
No Downloads
Views
Total views
13,453
On SlideShare
0
From Embeds
0
Number of Embeds
3,897
Actions
Shares
0
Downloads
592
Comments
3
Likes
8
Embeds 0
No embeds

No notes for slide

Efficient And Effective Test Design

  1. 1. Efficient and Effective Test Design Justin Hunter September 17, 2009 Founder and CEO 1
  2. 2. Intent of today Not “this” “This” (convincing you to buy my (sharing effective methods) tool and give me money) William G. Hunter (my dad, a professor of Larry Ellison (Oracle CEO): Prioritizes applied statistics): Travelled to Nigeria for making boatloads of money through a year with our family to teach / share his software sales (... “not that there’s expertise of Design of Experiments with anything wrong with that”) chemical engineering students there because he thought it would help them do their jobs more efficiently and effectively. 2
  3. 3. Topics I. Welcome II. Introduction / Executive Summary -What challenges does combination testing solve? -How does combination testing work? -Where can it be used and what benefits does it deliver? -What are critical success factors and general lessons learned from 2 dozen projects? -Why isn’t this method of test design more well known and more widespread? III. How the Proof of Concept Pilots Were Conducted -Structure of Pilots -“2 testers in a room w/ Hexawise vs. 4 testers in a room w/out Hexawise” -Three hypotheses that were tested in each case study: - No. 1 - Test design speed: savings of at least 30% - No. 2 - Test execution speed: savings of at least 25% - No. 3 - Cost of defect resolution: savings of at least 20% IV. Blue Cross Blue Shield North Carolina Case Study - - What kind of testing projects were chosen? Why? - Findings for each of the three hypotheses - Were targeted savings achieved? - Ease of use / change management - How easy was it to learn? ...to implement? - Lessons learned - What went well? ... not so well? ... any surprises? - Turning the “speed v. quality” dial - How will efficiencies created be used? - Implications - Will you use Hexawise again? Why? Why not? Where? 3
  4. 4. Hexawise is a new test design tool. It is available through a SaaS (software as a service) model. Sign up for a free trial. http://hexawise.com/users/new (Only 4 required questions) 4
  5. 5. . What vs. How Treat these two topics separately for this presentation: . . . . . . . . . . What Should be Tested? . How Should it be Tested? . . . • H/W Configurations . • What combinations should be . • S/W Configurations . tested together? • User Types . . • Test scripts in what order? • Business Rules . . • Sequences of Pathways . . • Data . • Features . . • Products Selected . . • Primary Actions . . • What Level of Detail . . ... or anything else that seems relevant . 5
  6. 6. What vs. How - Implications What Should be Tested? How Should it be Tested? • H/W Configurations • What combinations should be • S/WNo change Configurations here: tested together? • User Types This should continue • Test scripts in what order? • to be SME-driven. Business Rules We have a better way: • What Level of Detail • Sequences of Pathways Use Hexawise to determine • Data what variables should be tested when (and in what • Features combinations). Our • Products Selected scientifically-proven • Primary Actions optimization methods create ... or anything else that seems relevant better tests, faster. 6
  7. 7. Benefits Summary Challenges Addressed: Too long to identify and document test cases - (manual process) Inefficient test cases - (redundant testing and missing holes) High defect resolution costs - (defects found late) Order of Magnitude Benefits Delivered: Assuming: 100 testers @ $100 / hour 1,500 hours / year per tester spent on test design and test execution ~ $5 million / year in benefits 7
  8. 8. Hexawise solves a constant problem: “There are way too many options to test everything. What should we test?” ...884,736 possible tests x 5 options x 2 options x 2 options ...13,824 possible tests 6 browser choices x 2 options x 4 options x 2 options x 3 options x 4 options x 4 options x 2 options x 4 options x 2 options x 2 options = 884,736 possible tests... x 2 options x 2 options x 2 options x 4 options x 4 options x 2 options x 2 options x 3 options x 2 options x 2 options x 2 options x 2 options This single web page could be tested with = 13,824 possible tests... 72,477,573,120 possible tests 8
  9. 9. First, users input details of an application to be tested... 9
  10. 10. Next, users create tests that will cover interactions of every valid pair of values in as few tests as possible. (1) Browser = “Opera” tested with (2) View = “Satellite?” Covered. (1) Mode of Transport = “Walk” tested with (2) Show Photos = “Y”? Covered. (1) Avoid Toll Roads = “Y” tested with (2) Show Traffic = “Y (Live)” ? Covered. (1) Browser = IE6 tested with (2) Distance in = KM and (3) Zoom in = “Y” ? That is a 3-way interaction. It might not be covered in these 35 tests. See next page. 10
  11. 11. It also creates more thorough tests for all combinations involving 3 values, as below, or 4, 5 or even 6 values. (1) Browser = IE6 tested with (2) Distance in = KM and (3) Zoom in = “Y” ? Covered. Any 3 valid values you can imagine? Yes, at least 1 of the 184 tests will cover all 3 together. If even higher quality is desired, all possible 4, 5, or 6-way interactions could be tested for. 11
  12. 12. It also creates mixed-strength solutions. This results in relatively more tests focused on selected priority areas. (1) Browser = IE6 tested with (2) Distance in = KM and (3) Zoom in = “Y” ? Covered. Any 3 valid values you can imagine? Yes, at least 1 of the 184 tests will cover all 3 together. If even higher quality is desired, all possible 4, 5, or 6-way interactions could be tested for. 12
  13. 13. One of the advantages of this approach is that it creates coverage data... Every test plan has a finite number of valid combinations of parameter values (involving, in this case, 2 parameter values). The chart below shows, at each point in the test plan, what percentage of the total possible number of relevant combinations have been covered. In this set of test cases, as in most, there is a significant decreasing marginal return. % Coverage by Number of Tests 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 2 4 7 9 11 14 16 18 21 23 25 28 13
  14. 14. ... which is useful in determining “How much testing is enough?” / “When should we stop testing?” If you found three defects in this test plan’s first 50 tests, you would find approximately one more defect in the next 200 tests. 0 25 50 75 100 125 150 175 14200 225 250
  15. 15. Standard Benefits Test Test Bug Design Execution Fixing Time Time Costs Faster by at least Faster by at least Lower by at least 30% 25% 20% 15
  16. 16. Benefits Data These benefits numbers are backed by empirical data. Small proof of concept pilots can be done w/in 2 weeks. Source: “Combinatorial Testing” IEEE Computer, August, 2009. Dr. Rick Kuhn, Dr. Raghu Kacker, Dr. Jeff Lei, and Justin Hunter. 16
  17. 17. Benefits Data ~85% of bugs can be identified by 2-way solutions during testing provided the tester inputs the defect-triggering features or data ranges or configuration options. Source: “Combinatorial Testing” IEEE Computer, August, 2009. Dr. Rick Kuhn, Dr. Raghu Kacker, Dr. Jeff Lei, and Justin Hunter. 17
  18. 18. Hexawise Characteristics I. Easy to Use (3 simple screens, made for SW testers) II. Powerful (2-way to 6-way) III. Flexible (mixed strength coverage) IV. Insightful (“charting for everyone”) V. Customizable (for both training and integration) VI. Easy to Collaborate (e.g., notes with questions) 18
  19. 19. Common Misperceptions Change management is not always straightforward. Resistance to new ideas and different ways of doing things is common. Using pairwise and combinatorial test case generators is no exception; there are many objections raised by people hearing about it for the first time, including the ones on the next few slides... 19
  20. 20. SME Objections: Chess The Experts Reality Kasparov and Karpov: • No contest • Computers will never beat • Not even close GrandMasters • They lack the necessary: • Artistry • Instincts • Strategic insight 20
  21. 21. SME Objections: Manufacturing The Experts Reality (from the (in the 50’s, 60’s, 80’s to current) and 70’s...) • The “Design of Three phases: Experiments” methods that • It won’t work Hexawise employs • It won’t work here are proven and widely practiced • “I thought of it first” • Toyota: “An engineer who does not understand Design of Source: Dr. George Box, applied statistician Experiments is not (Has helped dozens of manufacturing companies an engineer.” use Design of Experiments methods to handle combinatorial explosions over a 30+ year career). 21
  22. 22. SME Objections: Software Testing Reality The Experts • Test design times decrease by >30% Three phases: • Defects found per • It won’t work tester hour often • It won’t work here more than double • “Oh wow.... It does • More defects are work here.” found earlier p. 95 • More defects are found overall 22
  23. 23. Objection: “It can’t test my ‘unique’ application.” Belief / Misconception The Reality We’re “different” because we have a: None of these make a difference. Hexawise can (and does) deliver dramatic benefits • Different industry or whenever you can’t (or don’t want to) test every single possible use case. • Different programming language or • Different phase of testing or Hexawise is being used successfully by hundreds of users in all kinds of different: • Different type of application or • Different type of defect we’re • Industries looking for • Programming languages • Phases of testing • Types of applications 23 20
  24. 24. “Not all variables are = important” Want to test some stuff “more”? 3 approaches: 1. (Blunt Approach) “IE7 is way more common than Opera and Safari” “Clean”: add IE7 twice. IE7 tested twice as much but number of required tests might increase. “Cheat”: include “Opera or Safari” as a variable But now: is Safari tested at least once with “No. of stops in trip = 3”? Maybe. II. (Subtle Approach) “Car directions are more common than public transit directions” or “Errors are more likely in XYZ new feature” “Clean” solution: add each parameter in their order of importance For parameters with a small number of values: “mission accomplished” If Y/N: 60% of “Freebies” will automatically be “Y”, 40% will be “N” For parameters with a small number of values “no freebies” / nothing changes III. (Math Whiz Approach) “Interactions between these [5] features are more likely to cause defects than with the rest of the variables” See “mixed strength solutions” (slide 11). 24
  25. 25. Questions before case study I. Welcome II. Introduction / Executive Summary -What challenges does combination testing solve? - How does combination testing work? - Where can it be used and what benefits does it deliver? - What are critical success factors and general lessons learned from 2 dozen projects? ? - Why isn’t this method of test design more well known and more widespread? III. How the Proof of Concept Pilots Were Conducted -Structure of Pilots -“2 testers in a room w/ Hexawise vs. 4 testers in a room w/out Hexawise” -Three hypotheses that were tested in each case study: - No. 1 - Test design speed: savings of at least 30% - No. 2 - Test execution speed: savings of at least 25% - No. 3 - Cost of defect resolution: savings of at least 20% IV. Blue Cross Blue Shield North Carolina Case Study - - What kind of testing projects were chosen? Why? - Findings for each of the three hypotheses - Were targeted savings achieved? - Ease of use / change management - How easy was it to learn? ...to implement? - Lessons learned - What went well? ... not so well? ... any surprises? - Turning the “speed v. quality” dial - How will efficiencies created be used? - Implications - Will you use Hexawise again? Why? Why not? Where? 25
  26. 26. Blue Cross Blue Shield NC - Overview and Benefits What are the benefits of Hexawise/combination testing... ...to the automated testing team? 1. Effective test data generation - Using a scientific approach to generate data is more efficient. The combinatorial data gathered from the Hexawise tool is far better than having a tester make an estimation based on past experience. Our experience has shown that by using the tool we can create test that have greater depth and breadth. 2. Having automatic generation of this data lends itself well to be adapted to test automation. The tool outputs CSV files which can be imported into an automation tool. Therefore fresh data can be at your disposal very quickly. ... to manual testers? 1. While we did not use the tool for this purpose the above benefits would apply equally. 2. However, the fact that you can use the tool to reduce the amount of test cases you run yet maintain a high amount of coverage is a benefit. 26
  27. 27. BCBSNC What were the challenges with using Hexawise? 1. The integration of the data to the automated tests was not as easy as we first thought. We had to develop some Excel macros to convert the Hexawise data into data that we could plug directly in to our test automation (i.e. - We had to convert ranges (output from Hexawise ) into a single number within the range. Also, in one particular case, we had to change the format because of the complexity of the test we were doing. We could not just use the row/ column format output from Hexawise. But these development tasks were one time tasks that we do not have to repeat each test cycle therefore our next cycle will benefit from the investment in time. 2. Sometimes understanding how to capture certain types of data input (or modeling) in the tool was challenging. 27
