The document discusses the operator pattern in Kubernetes for managing stateful services. It describes how operators define custom APIs using CustomResourceDefinitions and create controllers that react to changes in the API to manage applications and infrastructure. Operators allow automating tasks like backups, scaling, healing and configuration that are difficult to do at the application level alone. Some examples of using operators for services like Kafka and Elasticsearch are provided.

1. The Operator Pattern
1
Managing Stateful Services in Kubernetes
Jakob Karalus, @krallistic

2. 2
• Data Science + DevOps
• Codecentric
• CKA
• Twiiter: @krallistic
• Github: github.com/krallistic
$whoami

3. 3
• Write some Deployment, Services, Configmaps etc
• Deploy them to K8s
• Maybe create a Helm Chart
• YAML YAML YAML
Normal Kubernetes Deployment

4. 4
Success?!

5. 5
• Backups?
• Upscaling? Reshuffle Data?
• Downscaling? Without Dataloss?
• Healing? Restore Backups?
• Configuration? Tedious Templating?
But Day 2 Operations?

6. If only we could automate this!
6
In a Kubernetes native way!

7. 7
Operators
Kubernetes
Apache Kafka
Operator

8. 8
• Human Operational Software
• Custom Software
• Kubernetes Native:
• CustomResourceDefinition
• So lets write one:
• High Level
Operators

9. • Defines a new API
• Seamless integration
with existing API
• Kubectl support
9
CustomResourceDefinition
apiVersion: apiextensions.k8s.io/v1beta1
kind: CustomResourceDefinition
metadata:
name: crontabs.stable.example.com
spec:
group: stable.example.com
version: v1
scope: Namespaced
names:
plural: crontabs
singular: crontab
kind: CronTab
shortNames:
- ct
validation:
# openAPIV3Schema is the schema for validating
custom objects.

10. • Actual Object in new API
• No functionality.
10
CustomResourceDefinition
apiVersion: "stable.example.com/v1"
kind: CronTab
metadata:
name: my-new-cron-object
spec:
cronSpec: "* * * * */5"
image: my-awesome-cron-image
replicas: 5

11. 11
• Operator create WATCH on
CR Objects
• Analyze difference Actual vs
Desired State
• Act on changes
Control Loop
Observe
Analyze
Act

12. Kafka Basics
12
Broker 0
Topic: “test”
Partitions: 4
Replicas: 2
Partition 0 – Replica 0
Partition 2 – Replica 1
Partition 3 – Replica 1
Broker 1 Broker 2
Partition 0 – Replica 1
Partition 1 – Replica 1
Partition 2 – Replica 0
Partition 1 – Replica 0
Partition 3 – Replica 0
Topic: “hello”
Partitions: 8
Replicas: 3

13. 13
Create Cluster
Kind:
KafkaCluster
Name: analytics
Replicas: 3
ADD Event
Kind: ConfigMap
Name: kafka
Data: |
Kind: Statefulset
Name: analytics
Replicas: 3
Image: Kafka
POST
Create Pods

14. 14
Downsize Cluster
Kind:
KafkaCluster
Name: analytics
Replicas: 2
Update Event
Desired:
Kind: Statefulset
Name: analytics
Replicas: 2
Image: Kafka
UPDATE
Current:
Kind: Statefulset
Name: analytics
Replicas: 3
Image: Kafka
Cluster
Rebalanced
Rebalance
Topic
Delete Pod

15. 15
Rebalance Topics with Hot Partitions

16. Elasticsearch Postgres Tensorflow
16
Other Operators

17. 17
• Are we reinventing the Wheel?
• Helm?
• Mesos Frameworks?
• Nomad Custom Scheduler?
• Docker Swarm Plugins?
Take a step back

18. 18
• Helm itself a Operator (somewhat, working on it
https://github.com/kubernetes/helm/issues/3089) )
• Controllers
• Operator = Controller + CRD
• Operator = External Software
• Controller = Internal
• Only do operators if you cant solve it with Helm.
Operators vs Helm vs Controller

19. 19
• Create API Spec
• Generate some Objects needed by Informer etc (Since 1.8)
• See: https://blog.openshift.com/kubernetes-deep-dive-code-generation-
customresources/ (Excellent, by sttts)
• Generator Controller
• Informer
• Main
Code!

20. 20
• Microservices, single Deployment
• Stateless, use CRD for States
• Operations should be Idempotent
• Leverage K8S Objects as most as possible
• CRD should be versioned, backwards compatible
Best Practice Operators

21. Questions? Discuss!
21

22. 22
• Custom Resource Definitions
• API Aggregation
• Initializers
• Scheduler Extenders
• Custom Schedulers
• Flex Volumes
• Cloud Provider
• CRI & CNI
• Admission Webhook
Kubernetes Extensibility

23. 23
Task Mesos Kuberentes
Custom Resource Placement Write a framework Write a custom scheduler
Special resource init Write a framework Initializer
API access Every Framework has its own API Unified API
Special lifecyle Write a framework Kubernetes Operator
Custom execution Write a framework + executioner CRI Interface + Scheduler
Comparison
