Automotive Spice ® Requirements for Development Process and Tools Markus Korn Hirschmann Car Communication GmbH Intland Us...
About Hirschmann Car Communication <ul><li>USA </li></ul><ul><li>Detroit </li></ul><ul><li>Mexico </li></ul><ul><li>Juarez...
Employees 800 Employees thereof 120 Engineers
Business Units Antenna Systems Tuner Systems Integrated antenna systems Roof and rod antennas <ul><ul><li>Hybrid (analog/d...
Hirschmann Car Communication in the car environment Electronics Telematics Car Diagnostic Radio-Tuner TV-Tuner Antenna Sys...
Content This presentation wants… …  to show the major requirements of Automotive Spice to your development process …  to f...
What is Automotive Spice? ISO/IEC 12207 Software Life Cycle Processes  ISO/IEC 15504 Information technology  Process asses...
Process Assessments <ul><li>PRM  describes </li></ul><ul><li>processes </li></ul><ul><li>base practices </li></ul><ul><li>...
The Process Groups and Processes of the  Reference Model Management Project management Risk management Contract Agreement ...
What are Automotive SPICE ®  Requirements for your Processes? There are defined  Base Practices  that a process must perfo...
Engineering Processes and bidirectional Traceability system architectural design customer requirements system requirements...
The Reality is … system architectural design customer requirements system requirements software requirements software arch...
How to establish all that Traceability? If you do not want to implement and maintain SW interfaces You should check your t...
The Tools in our System Development system architectural design customer requirements system requirements software require...
The Trackers and CMDB „Backend“ System Requirements Software Requirements Tasks System Test Software Test Bugs System Elem...
Customer Requirements There are defined methods and tools for requirements interchange e.g. Doors eXchange Codebeamer Docu...
System Requirements System Requirements Specification as a Wiki Page Provide additional information, images, hierarchical ...
The System Requirement Ticket We need to relate the system requirements with the customer requirements Each requirement in...
The System Requirement Ticket We need to relate the system requirements with the customer requirements Add Association   ...
Traceability customer requirements system requirements Established for both Doors exchange and other requirements document...
System Architectural Design Block diagrams describing the system CMDB Category „ System Element“ DEMUX xy DC/DC µC Name We...
CMDB Items and Tickets Block System Architectural Design URL CMDB Item Relation System Requirement Tickets System Requirem...
Traceability Maintenance: <ul><li>add CMDB items/URLs if necessary </li></ul><ul><li>check all CMDB items in document‘s as...
Software Requirements As with system requirements: The SW Requirements Specification is a Wiki Page Provide additional inf...
The SW Requirement Ticket System Requirements Add new SW requirement ticket from within system requirement ticket SW Requi...
Traceability Maintenance: Whenever block diagram is updated – additionally to the slide system requirements <ul><li>check ...
SW Architectural Design We use Rhapsody to design our SW +  powerful design tool +  simulations without target HW -  devel...
Offer Images from Rhapsody in Codebeamer Package 1 Package 2 Package 3 Name <ul><li>each top level design element  (packag...
SW Architectural Design Software Architectural Design is a Wiki page <ul><li>provides all textual information necessary to...
CMDB Items and Tickets Software Architectural Design SCM commit CMDB Item Relation Software Requirement Tickets Software R...
Traceability system architectural design customer requirements system requirements software requirements software architec...
Code Creation code is implemented SVN Repository Remark header of a package/function links to design http://.../cb/wiki/34...
CMDB Items, Tickets and Repository Software Requirements Relation Software Requirement Tickets Task Ticket SVN Repository ...
Traceability system architectural design customer requirements system requirements software requirements software architec...
The Test Processes test specification for software units software integration test specification software test specificati...
Summary <ul><li>If you have interfaces in your tool chain: </li></ul><ul><li>you must maintain them </li></ul><ul><li>in m...
