InduSoft Water Wastewater Webinar Bill Glover

  1. 1. William Glover
  2. 2. Water
  3. 3. City of Rock Hill South Carolina
  4. 4. Lake Wylie - SC 23,000 Residences/Commercial customers Water supply North Carolina
  5. 5. Re-Use Water System Reuse Clearwell Clarifier Influent TowerSettling Flocculator Basins Power Building Drain Pump Sludge Pump FilterSection Lab Chemical Chemical Building Control Room Admin Building High Service Clearwells Pump Station
  6. 6. Re-Use Water System Reuse Clearwell Clarifier Influent TowerSettling Flocculator Basins Power Building Drain Pump Filter Sludge Pump Section Chemical Lab Building Chemical Control High Room Service Pump Station Clearwells
  7. 7. City of Rock HillWastewater Facility Wastewater facility is also run by Indusoft and Think & Do New Project for Upgrade (See last page)
  8. 8. Influent Stage Pre- Filtratio Water enters Facility n Pumped Directly from Lake Wylie Lime Silo WMS Influent Lime Silo WinPLC Terminator Iboco Dinnectors DinRail
  9. 9. Settling Basins/Flocculator Flocculator Separates high density Solid particles Entry Piping to Flocculators
  10. 10. Flocculator WinPLC Terminator Flocculators WinPLC Control System: • Controls paddle mixers • Monitors levels • Monitors Temperature
  11. 11. FlocculatorDrives Panel Flocculator Separates/Removes high density particles Removes suspended solid particles Relays WMS Flocculators GS Drives Entry Piping to Folocculators Terminator GS Drives Customer replaced AB Drives With ADC GS Drives AB Reactors remain from original installation
  12. 12. Settling Basins Medium size particles separated Trac Vac – vacuums particles – Communicates this to the WinPLC Settling Basins WinPLC Terminator WinPLC Terminator Iboco
  13. 13. Carbon Sand Filters Final Filtering of water Water is forced thru sand Particles removed Chemicals added. Carbon Sand Filter Area
  14. 14. Carbon Sand Filters Final filtration of water Carbon Sand Filters WinPLC controls • Valves, Water flow & levels • Backwash controls, • Chemical injections Carbon Sand • All 6 filters are “synched” with flow rate Filter Area • C-more panel for each filter C-more WinPLC Terminator PB/PL/SW Filter Controls WMS Console Filter Controls Console
  15. 15. Filter Station – HMI Thin Client InduSoft Thin Client InduSoft Thin Client 9 - Thin Client HMI stations are located throughout the facility From the main menu, any station can show any part of the facility Status of nearly every major function can be seen from anywhere in the plant
  16. 16. Chemicals – Lime Silo WMS MSP WinPLC GS Drive Terminator I/O Signal Conditioners Lime Silo Post filter Control Panel Pipe Gallery Lime Silo
  17. 17. Chemical DistributionControl Panel HW Enclosures WinPLC C-more Terminator I/O Chemical Storage Master Chemical Control station Chemical Distribution Controls pumps, flow rates, levels Master Control Panel 5 other control panels also in this area
  18. 18. Drain Pump Panel • Three door panel • Two - 100 HP Durapulse Note: all outdoor panels • Pumps process water that is not used to Clarifier are air conditioned • Clarifier in re-use area is holding tank for re-use water (FUEL team is launching this product) WinPLC Durapulse Rhino WMS WinPLC Rhino Durapulse Durapulse Signal Conditioners Panel Drain Pump
  19. 19. Clarifier - holding Tankfor Wastewater Clarifier
  20. 20. ClearwellsReady to Pump to Water Towers orConsumer Use Clearwell Water has been treated Clearwell Ready to be pumped For Consumer-Use OR For pumping to Water Towers
  21. 21. High Service Pump Six High Service Pumps Pump water for consumer use OR Pump water to one of four water WMS towers WinPLC High Service Pump Control Panel
  22. 22. Sludge Pump Panel Pumps process water from Flocculators and settling basins to to wastewater treatment facility • Twin Durapulse 100 HP on pumps WinPLC • Win PLC DuraPulse • Rhino P.S. Drives Rhino • Breakers • Dinnectors Signal Conditioners WinPLC Sludge Pump Control Panel
  23. 23. Powerhouse ControlCabinet Monitors all power into plant Generators & Power Distribution HW enclosure Assures power 100% of the time. WinPLC Terminator Terminator Iboco Generators Power House Control Cabinet
  24. 24. Power House Power house Controls & Servers InduSoft Redundant • 6 - Think & Do Servers Servers • InduSoft HMI Dual Redundant Server – • Serves 9 thin-client HMI • Ethernet (Fiber) backbone Think & Do Think & Do Think & Do Think & Do HMI Servers Bill Glover Think & Do Servers Inteworx Jon White City of Rock Hill
  25. 25. Re-use AreaUV filters and HMI Thin-Client UV Filter Area Treats re-use water Sold at high discount For sprinkler/industrial use InduSoft HMI Thin-Client Application 1 of 9 in system Shows Local Status UV Filters in Re-use Area Status of all stations
  26. 26. Reuse – Sand Filter Control C-moreRe-use Sand Filter PLC DirectLogic PLC C-more Touch Panel DirectLogic PLC Reuse – Sand Filter Control Cabinet
  27. 27. Re-Use Water System Reuse Clearwell Clarifier Influent Tower Settling Flocculator Basins Power Sludge Pump Building Drain Pump FilterSection Chemical Building WinPLC Station Pump Clearwells Station Think & Do Station InduSoft Thin Client DirectLogic PLC
  28. 28. Dutchman CreekSewage Pump Station C-more
  29. 29. Dutchman CreekSewage Pump Station WMS WMS WMS Rhino Rhino C-more Relays WMS Relays Iboco Din Rail WMS Redundant Dinnectors WinPLC Systems Dinnectors WinPLC WinPLC
  30. 30. William Gloverwglover@inteworx.net 770-886-6166 ext.111 www.inteworx.net

×
