1.
SINGAPORE
PLATFORM, ADVANCED
Hammad Rajjoub
Architect Evangelist, Microsoft Singapore
Windows Azure
AppFabric – The
Middleware for the
Cloud

2.
The Cloud.

3.
All Apps Move To The Cloud.

4.
I would also like ….

5.
Cure for Cancer…

6.
World Peace..

7.
Get rid of Famine…

8.
Finish the book I am writing “on time”…

9.
All Apps Move To The Cloud.

10.
No They Don’t.

11.
Analogy: Rural vs. Urban living ..

12.
• IMAGE COMES HERE..

13.
We need to connect the dots…

14.
Agenda
• Windows Azure AppFabric –The Middleware
for the Cloud
• Building Blocks
• Service Bus

15.
Speaker Intro
• Architect Evangelist at Microsoft
• Published Author
• Microsoft Business Platform Technology Advisor
• Microsoft Cloud Advisory Council
• IASA Speaker and Member
• 7 times MVP
• @hammadrajjoub
• http://www.hammadrajjoub.net

16.
Likewise for software, we need middleware…

17.
… all sorts of middleware, in fact

18.
Windows Azure AppFabric

19.
Windows Azure AppFabric Cache
• A distributed, in-memory cache for apps running in Azure:
– In-memory cache located near your Azure applications
– Based on Windows Server AppFabric Caching
• Benefits:
– Highly scalable with low latency and high throughput
– Can dynamically increase and decrease as needed, without redeploying
or modifying your application
– User doesn’t have to bother with configuration, deployment, or
management of their cache infrastructure

20.
Key Capabilities & Benefits
Web Role
• Easily integrates into existing apps Local Cache
– Cache-Aside Model
– One API for Server and Cloud Output
– ASP.NET Session State Provider Sessions
– ASP.NET Page Output Caching Provider Reference
Data
• Very low latency with Local Cache Activity Data
• Caches any serializable CLR object Resource
– No serialization costs for local caching Data
• Secured w/ Access Control Service
DB

21.
A quick look at Cloud Cache...
DEMO

22.
Windows Azure AppFabric Access Control
Access Control Free till Jan 2012
• Federated Identity and AuthZ for any Application
– Web, Desktop, Mobile
– Identity Providers: OAuth WRAP
• Facebook, Google, Yahoo, Live ID OAuth 2.0
• Active Directory Federation Services 2.0 Access Control
WS-*
Service
• OAuth 2, OAuth WRAP
• WS-Trust 1.3
Open ID Rules
– Tokens Formats Google, Yahoo
• OAuth WRAP SWT Facebook
Websites and web
• SAML 1.1, SAML 2.0 Live ID services
• Authorization Rules

23.
Windows Azure AppFabric
Application Manager
Web Services Workflow
• Application Server Infrastructure
– Deployment and Placement
– Execution Lifecycle
– Scale Out
– High Availability
– Isolation
– Resource Management
– Routing
– Usage Monitoring

24.
Windows Azure AppFabric Service Bus
Service Bus
• Interconnect services across networks
– Naming and Discovery
– Connectivity w/ NAT and Firewall Traversal
– Access Control Integrated Authorization
• Cloud-Based Message-Oriented Middleware
– Next Generation Message Queue Technology
– Rich Publish/Subscribe with Filtering
– Transaction Integration

25.
Windows Azure AppFabric Service Bus
?
Connectivity Messaging Service Integration
Service Relay Queuing Management Routing
Protocol Tunnel Pub/Sub Naming, Discovery Coordination
Eventing, Push Reliable Transfer Monitoring Transformation
Rich options for Reliable, Consistent Content-based
interconnecting transaction-aware management routing, document
apps across cloud messaging surface and service transformation,
network infrastructure for observation and process
boundaries business apps. capabilities coordination.

26.
Queues!
P Queue C
• Reliable, durable storage – up to 1GB per Queue*
• Queues stay in the system once created, no TTL limit
• Max message size 256KB, Sessions allow grouping
• Messaging API, WCF, and HTTP/REST Interfaces

27.
My Queue runs in the cloud. How about yours?
DEMO

28.
Topics!
S C
P Topic S C
S C
• All the Features of Queues + Publish/Subscribe
• Up to 2000 Subscriptions on a Topic
• Each Subscription is a virtual queue getting message copies
• Subscriptions can have filters and actions

29.
We have “Topics” in the cloud. Do you?
DEMO

30.
Bridging on premise messaging with the Cloud
SB Queue C Cloud
On Premise
P MSMQ Broker
• Messages are pushed to MSMQ
• Broker reads off MSMQ and publishes to SB Queue
• Service Bus Queue Client can reads it off the queue

31.
Look ma! I can do HYBRID messaging…
DEMO

32.
Runtime API Choices
Apps
WCF Service Model
WCF Bindings HTTP SOAP
REST WS-*
(Relay Clients)
Service Bus Relay Protocol
Implementation Messaging API
(private)
.NET Framework 4.0 Any Platform
Service Bus

33.
Summary
- The Cloud Middleware
- Service Bus enables connectivity between
On-Premise and Cloud Apps
- AppFabric applications are inherently cloud
ready
- Integration Services will bring BizTalk to the
Cloud

34.
Learn more..
- Rayan’s Master Class on Windows Azure
- Channel9 Videos
- http://channel9.msdn.com/posts/ServiceBusTopicsAndQueues
- http://channel9.msdn.com/Events/BUILD/BUILD2011/SAC-862T
- Windows Azure AppFabric Samples:
- http://www.microsoft.com/download/en/details.aspx?displaylang=en&id=2742
1
- The Developer’s Guide to AppFabric – Alan Smith
- Windows Azure Development Cookbook- Neil McKenzie
- Customer Advisory Team: http://www.windowsazurecat.com/
- @hammadrajjoub - www.hammadrajjoub.net

35.
Thank You
hamadr@microsoft.com /
@hammadrajjoub /
Microsoft Virtual Academy IT Pro Trials Developer Downloads
http://wwww.hammadrajjoub.net

36.
http://azureug.sg
http://www.facebook.com/MWAPSG
