ARC202 - Combating Software Entropy with Design Patterns and Principles<br />Hammad Rajjoub<br />Solutions Architect @ Inf...
Cogito, Ergo , Sum<br />Microsoft MVP – Connected Systems (5+ yrs)<br />Solutions Architect at Infusion<br />The coolest c...
Agenda<br /> Why is Software Complex?<br /> What is bad design?<br /> How to Fix it?<br /> Summary<br /> References<br />Q...
Why is Software Complex<br />Writing new software<br />Mandated to develop new systems<br />Generally from scratch <br />B...
What is bad design?<br />
Bad design is...<br />Hard to change!<br />A single change break lots of other code<br />Rigid<br />Fragile<br />Can’t be ...
How to fix it?<br />Using design principles and practices<br />The Single Responsibility Principle<br />The Open Closed Pr...
Single Responsibility Principle<br />None but Buddha himself must take the responsibility of giving out occult secrets...<...
The Single responsibility principal<br />"A responsibility is a reason to change, a class or module should have one, and o...
The Single Responsibility Principal<br />Responsibility is a ‘Reason for change’<br />Each responsibility is an axis of ch...
BusinessPartnerValidtor Module<br />Example:<br />
BusinessPartnerValidator<br />BusinessPartner<br />Validator<br />DB<br />Trade<br />What is wrong here: Changes if DB cha...
Counterparty Validator – Iter 1<br />internal class BusinessPartnerValidator<br />{<br />public void AssertValid(Trade t)<...
BusinessPartyValidator – Iter 2<br /> internal class BusinessPartnerValidator<br />    {<br />private readonlyBusinessPart...
RefactoredBusinessPartnerValidator<br />BusinessPartner<br />Validator<br />BusinessPartner<br />Source<br />Trade<br />DB...
Open Closed Principle<br />“..this is the heart of Object Oriented Programming...”<br />OCP<br />
The Open Closed Principle<br />Realise that generally systems outlive their expected timelines<br />All software entities ...
Liskov Substitution Principle<br />There is a theory which states that if ever anybody discovers exactly what the Universe...
The Liskov substitution principal<br />“Functions that reference a base class must be able to use objects of derived class...
Using Inheritance for OCP?<br />RateCalculator<br />Trade<br />Option<br />Fee<br />
Trade Rate Calculation<br />public decimal CalulateRate(Trade t)<br />{<br />if (t is Fee)<br />    {<br />return 1.0m;<br...
Fragile: sensitive to any change in Trade Fee Hierarchy</li></li></ul><li>Better Trade Rate Calculation<br /> public abstr...
Design forces implementation</li></li></ul><li>The Liskov substitution principal<br />Be vary of ‘is-a’ relationship<br />...
Dependency Inversion<br />It may be that the old astrologers had the truth exactly reversed, when they believed that the s...
Dependency Inversion Principal<br /><ul><li>High level modules should not depend upon low level modules. Both should depen...
Abstractions should not depend upon details. Details should depend upon abstractions.</li></li></ul><li>BusinessParty Vali...
Better BusinessPartner Validator<br /><Interface><br />IBusinessPartnerSource<br />BusinessPartnerValidator<br />BusinessP...
Extensible BusinessParty Validator<br /><Interface><br />IBusinessPartnerSource<br />BusinessPartyValidator<br />Trade<br ...
DI & IoC<br />IoC is key part of Frameworks<br />Interfaces, Closures & Events<br />Hollywood Principal (Don’t call us, We...
Software Design Metrics<br />
Some Key Design Metrics - Ca<br />Afferent Couplings  - Ca<br />The number of other packages that depend upon classes with...
Some Key Design Metrics<br />Efferent Couplings – Ce<br />The number of other packages that the classes in the package dep...
Some Key Design Metrics<br />Instability – I = Ce / (Ce + Ca)<br />This metric is an indicator of the package's resilience...
Use Visual Studio Code Metrics<br />Maintainability Index<br />Cyclomatic Complexity<br />Depth of Inheritance<br />Class ...
Further reading<br />
What else can I do?<br />ISP: Interface Segregation Principle  Avoid fat interfaces<br />REP: The Release Reuse Equivalen...
Strategic Closure<br />No significant program can be 100% closed<br />Closures cant be complete<br />Closures must be ‘Str...
Summary<br />Remember your application will outlive your expectation<br />Follow these design principles<br />Be Agile!<br...
References<br />Uncle Bob http://butunclebob.com/ArticleS.UncleBob.PrinciplesOfOod<br />Agile Principles, Patterns and Pra...
question & answer<br />
Required Slide<br />Speakers, <br />TechEd 2010 is not producing <br />a DVD. Please announce that <br />attendees can acc...
Required Slide<br />Complete an evaluation on CommNet and enter to win an HTC HD2!<br />
Required Slide<br />© 2010 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product...
