Vetebra
Nanite
George Palmer
Background processing

• Work should be moved to the background
  to stop application server load
• This keeps website responsive
• Useful for: images, videos, web services,
  slow database queries....anything that isn’t
  quick!
Current background
       offerings
• Fork into background of rails process
  •   eg spawn, run_later

• Record to database (or file) and
  background daemon picks up from there
  •   eg background_job, delayed_job

• Fork onto some kind of queue
  •   eg backgroundRB, beanstalk, starling with workling
Introducing Nanite

• Developed by EngineYard
• Gives presence - we know what’s available
• Handles failure
• Instant scalability
• Event based architecture
Pre-reqs

• Erlang
 • Not R12B5 (the version installed by
    MacPorts)
• RabbitMQ
 • Untar to erlang lib directory - most
    likely /usr/local/lib/erlang/lib
AMQP
• Advanced Message Queuing Protocol
• Enterprise quality protocol developed by
  several financial institutions
• Includes wire protocol to ensure language
  neutral
• RabbitMQ implements AMQP 0.8
Installing AMQP for Ruby


$ sudo gem install eventmachine
$ git clone git://github.com/tmm1/amqp.git
$ cd amqp && rake gem && sudo gem install
  amqp-<version>.gem
Nanite
         NA                         A   Nanite
   Thin                                 Actor
          a M                       M
   App
         ni Q                       Q   Nanite
  Server
         te P                       P   Actor

Nanite Mappers   m e s s a g e s   Nanite Agents

         NA                         A   Nanite
  Ruby a M                          M   Actor
  Script ni Q                       Q   Nanite
         te P                       P   Actor
Nanite Mappers
• Control and track work
• Unlimited number can be run that get
  updates from mapper exchange
 •   mapper exchange itself is just a heartbeat and
     registration MQ

• Run either inside Rails/MERB app (on Thin)
  or via command line
Nanite Agents
• Do the work
• A given nanite agent can have multiple
  actors
• Scale by adding more agents
• Pings the mapper exchange every
  @ping_time seconds to report health
Nanite Actors

class Manor < Nanite::Actor
 expose :name

 def name(vars)
  # Do something interesting here
  :result => “RubyManor”
 end
end

Nanite::Dispatcher.register(Manor.new)
Agent directory
        structure
+ myagent
 + actors
  - manor.rb
 + files
 - init.rb
 - config.yml
Agent config.yml
---
:vhost: /nanite   # Allow multiple agents with different queues [compulsory]
:user: nanite     # Username for queue
:pass: testing    # Password for queue
:identity: barney # Can be auto-generated but useful to send work to specific
                  # agents
:file_root: path   # where to store any transfered files
:format: marshal # or :json


# Additional options include host and port. All options can be passed into
# nanite command so can avoid config file if want
Getting Started...

• Start RabbitMQ
 •   /usr/local/lib/erlang/lib/rabbitmq/sbin/rabbitmq-
     server

• On first run nanite/bin/rabbitconf
 • Sets up RabbitMQ with a vhost and users
     for that vhost (more on this later)
Starting agents
• cd <agentdir> && <nanite basedir>/bin/
  nanite
• I’ve been using:
  cd <agentdir> && <nanite basedir>/bin/
  nanite -t <identity> &
• Could be managed better through a
  daemon/monitoring system though
Offloading work to
        Nanite
• Use the following code:
  Nanite.request(callable, params = ‘’,   options =
  {}) {|res| # use res to do something}


 •   callable is the actor and method - eg ‘/manor/
     name’

 •   params are parameters for the callable method -
     eg ‘2008’

 •   options includes timeout, target and the routing
     algorithm - more on this later
Interfaces into the
         Mappers
• Via console:
 • nanite/nanite-mapper -i
• Via command line:
 • See nanite/examples/cli.rb
• Via Rails/MERB app:
 • See next slide....
Rails/MERB & Nanite
# Updates the user
def update
 ...
 if (@user.save)
    Nanite.request(‘/updates/twitter’, ‘georgio_1999’) {|res|
      # This block won’t execute until the event fires
      @user.status = res[:status]
      @user.save
    }
 end
end

def ajax_call
 # Must use database for state and not Nanite job
end
Allocation of work
• The pings are used by the mappers to find
  the healthiest nanite agents
• If a nanite agent doesn’t ping inside a
  window it is removed from the active list
  (until it does ping again)
  • perfect for busy or error hit nanites
• The default routing algorithm is based on
  server load
Routing options
• In options argument of        Nanite.request   you
  can choose:

 • selector
   •   :least_loaded (default), :all, :random, :rr

 • target - use this to target a specific agent
 • timeout - override the default timeout
    (60s)
Custom algorithms
• Nanites report state with their ping
  •   By default this is the server load

• Can override this by adding code to agent
  init.rb
  •   Nanite.status_proc = lambda
      { MyApp.some_statistic_indicating_load }


  •   Must be comparable

• Can use with existing routing algorithms or
  create own more complex ones
File transfers
• Nanite can handle file transmission
 • Agents subscribe (for all actors) in init.rb
    or Actors subscribe individually:
    •   Nanite.subscribe_to_files(domain)


  • Mappers send via:
    •   Nanite.broadcast_file(filepath, opts)


    •   where opts can contain :domain
        and :destination (destination filename)
The beauty of JSON
• Nanite is built on top of AMQP, so if the
  queue items are serialised using JSON...
  • Then Nanite isn’t needed at the agent
    side
  • Any AMQP implementing daemon can
    read message and respond
  • Useful for legacy code (or legacy people)
Understanding Security
• Security is implemented using RabbitMQ’s
  vhosts and username/passwords
• The username/password is defined in
  config.yml for each nanite
• Need to configure RabbitMQ using the
  rabbitmqctl command

• Generally one vhost per application
Let’s play
• cd <git_resources>/nanite/examples/myagent
• ../../bin/nanite -t <identity> -h <host>
    •      Let’s use fullname for identity - eg georgepalmer

    • Should see something like:
  # subscribing to file broadcasts for foobar

  # loading actor: /Users/georgepalmer/work/git_resources/nanite/examples/myagent/actors/gems.rb

  # loading actor: /Users/georgepalmer/work/git_resources/nanite/examples/myagent/actors/mock.rb

  # quot;advertise_servicesquot;

  # [quot;/gems/listquot;, quot;/mock/listquot;]
Resources

• RabbitMQ: http://www.rabbitmq.com
• Ruby AMQP with RabbitMQ tutorial:
  http://hopper.squarespace.com/blog/2008/7/22/simple-amqp-library-for-ruby.html




• Nanite: http://github.com/ezmobius/nanite
    •     Doc isn’t great, code is very readable
