New aspects of Cisco UC Interoperability

  1. 1. New aspects of CiscoUC Interoperability #CiscoPlus
  2. 2. What is integration?•  Is my home phone integrated with your home phone?•  Is my corporate email system federated with yours?•  Does integration imply connecting two of the same type of system or different systems?•  The objective: Let me collaborate with Anyone Anywhere #CiscoPlusCA
  3. 3. Cisco Collaboration Architecture Devices Desktop Mobile In-Room Provisioning Federation Conferencing Customer Care Collaboration Enterprise Social Software IP Communications Applications Encryption Maintenance Messaging Telepresence Client Services Medianet Services Client Services Framework Interface Lightweight APIs Administration AAA COMMUNICATION Presence / Location Real-time Messaging Metadata Tagging Policy Session Mgmt Real-time Data Sharing Social Graphing Collaboration Services Operations Scheduling and Authoring Semantic Processing Calendaring Identity Workflow Recording/Playback Search CONTENT Management Services Transcoding Transrating Transcribing Security Services Medianet Services Auto-Discovery Auto-Configuration Resource Control Network Services Transport Signaling QoS #CiscoPlusCA
  4. 4. Session Management #CiscoPlusCA
  5. 5. What is a Session Management Edition cluster ? CUBE CUBE CUBE H323 Trunk MGCP Trunk SIP TrunkA CUCM cluster and SME cluster use exactly the same softwareA CUCM cluster is typically used to register 10,000s of PhonesAn SME cluster is typically used as a platform for Trunk and Dial Plan aggregationBoth CUCM and SME support Voice, Video and Encrypted callsSupport for SME deployments was introduced with UC version 7.1(2)UC version 8.5 introduces a number of features that enhance SME functionality :Improved SIP Trunk and H323 Inter Cluster Trunk functionalityImproved through-cluster routingSIP Normalization and Transparency scripts #CiscoPlusCA
  6. 6. Why deploy Session Management Edition ?An SME cluster at the core of your network allows you to flexibly manage your UC system as it grows and changes……. PSTN Voicemail Conferencing CUBE CUBE System System H323 Unified CM MGCP Session SIP Management Edition Cluster CUCM PBXs/ CUCM CUCM PBXs with PBXs with CUCM/PBX Clusters with Clusters with Clusters with MGCP QSIG MGCP Q931 with SIP QSIG H323 QSIG SIP Trunks to H323 Trunks to Trunks to SME Gateway Trunks to SME Trunks to SME SME SME Trunks Leaf Unified CM Clusters/ Leaf UC Systems An SME cluster can interconnect 1000’s of UC systems using SIP, H323, or MGCP Trunks SME allows you to reduce UC system complexity by centralizing your dial plan and call routing rules in the SME cluster which in turn allows you to simplify the dial plan and management of the connected UC systems #CiscoPlusCA
  7. 7. Reasons for deploying an SME cluster PSTN Voicemail CUBE CUBE Conferencing System System H323 Unified CM MGCP Session SIP Management Edition Cluster PBXs/ CUCM CUCM CUCM Clusters with PBXs with PBXs with MGCP CUCM/PBXs with Clusters with Clusters with MGCPTrunks to Q931 Gateway SIP QSIG Trunks SIP Trunks to H323 Annex M1 H323 QSIG SME Trunks to SME SME Trunks to SME Trunks to SMEA centralized Dial Plan in SME allows you to :Globalize and Normalize the called and calling numbers used by all Leaf systemsManage overlapping number ranges in Leaf systemsConfigure “find me” call routing using Route List and Route GroupsRe-route calls via the PSTN when the device cannot be reached via and IP pathSME Mobility features allow you to offer Single Number Reach functionality to devices on 3rdParty UC systemsSME Normalization scripts allow you to modify any inbound or outbound SIP message andSDP body content – simplifying interoperability with 3rd party UC systems #CiscoPlusCA
  8. 8. SME cluster - PBX aggregation SME migration to a CUCM cluster PSTN CUBE CUBEPSTN PSTN PSTN PSTN PSTN PSTN Phase 1 – PBX Phase 2 – Centralized IP Aggregation PSTN PSTN PSTN CUBE CUBE CUBE CUBE Phase 3 – PBX Phase 4 – CUCM cluster decommissioning #CiscoPlusCA
  9. 9. Extend and Connect Architecture & Call FlowJabber Use Case CUCM CTI Cisco Jabber client Enterprise DN: 3000 CSF/Jabber device DVO-Enabled Office Phone 3000 Remote Destination: 4155551212 Remote Destination: 9195551313 PSTN Home Phone 4155551212 Cisco User PBX Phone 3rd Party 9196661313 PBX CTI applications have limited monitoring and call control capabilities for remote destinations #CiscoPlusCA
  10. 10. Extend and Connect Architecture & Call FlowCTI Remote Device Use Case CUCM CTI Enterprise DN: 3000 CTI Remote Device 3rd-Party DVO-Enabled client Office Phone 3000 Remote Destination: 4155551212 Remote Destination: 9195551313 PSTN Cisco User Home Phone 4155551212 PBX Phone 3rd Party 9195551313 PBX CTI applications have limited monitoring and call control capabilities for remote destinations #CiscoPlusCA
  11. 11. MS Lync Integration #CiscoPlusCA
  12. 12. Different options exist – How to choose the right one? Blended: Customer Full Full Microsoft Microsoft Desktop + Cisco Deployment UC Solution UC Solution Cisco Phone scenario UC Gateway Cisco UC Integration for MOC Cisco Jabber or Lync #CiscoPlusCA 13
  13. 13. Cisco Unified Clients… Cisco Soft Client Architecture Cisco Cisco UC Cisco UC Cisco Developer &Cisco Webex Unified Personal Integration Integration Quad Phone Integrator SDK Connect Communicator for Microsoft for RTXCisco UnifiedInfrastructureServices #CiscoPlusCA
  14. 14. Cisco JabberIntroduction Cisco Enterprise Call Control Video & Desktop Instant Messaging Share Engine Application Jabber Technology Integration (MS Office) Cisco Secure Remote Access Conferencing Cisco Unity Cisco Jabber Webex Connection & CuciLync Collaboration Voice Messaging Environment #CiscoPlusCA
  15. 15. Cisco BYOD ArchitectureOne network, One policy, Unified Management Good #CiscoPlusCA
  16. 16. Different options exist – How to choose the right one? Blended: Customer Full Full Microsoft Microsoft Desktop + Cisco Deployment UC Solution UC Solution Cisco Phone scenario UC Gateway Cisco UC Integration for MOC Cisco Jabber or Lync #CiscoPlusCA 17
  17. 17. Cisco Collaboration Architecture Devices Desktop Mobile In-Room Provisioning Federation Conferencing Customer Care Collaboration Enterprise Social Software IP Communications Applications Encryption Maintenance Messaging Telepresence Client Services Medianet Services Client Services Framework Interface Lightweight APIs Administration AAA COMMUNICATION Presence / Location Real-time Messaging Metadata Tagging Policy Session Mgmt Real-time Data Sharing Social Graphing Collaboration Services Operations Scheduling and Authoring Semantic Processing Calendaring Identity Workflow Recording/Playback Search CONTENT Management Services Transcoding Transrating Transcribing Security Services Medianet Services Auto-Discovery Auto-Configuration Resource Control Network Services Transport Signaling QoS #CiscoPlusCA
  18. 18. Cisco UC Integration for Microsoft What is the Cisco Integration for Microsoft•  The UC Integration provides a Cisco UC client with controls exposed with the Microsoft client interface•  Provides phone presence to OCS/Lync•  Supports Microsoft Office Communicator R2 and Microsoft Lync 2010•  Runs on Microsoft Windows XP SP3, Windows Vista 32/64bit and Windows 7 32/64bit•  Provides soft phone audio and video and desk phone control using UC manager call control•  Visual voicemail with Cisco Unity or Unity Connection•  Desktop collaboration using Cisco MeetingPlace and Webex•  Calling from Microsoft Office, Internet explorer and other applications #CiscoPlusCA
  19. 19. Cisco UC Integration™ for Microsoft Lync Microsoft Client Microsoft Office Communicator Microsoft Lync (shown) User Experience Simply drag or right click a contact to start a voice, video or collaboration session Conversation Voice, Video and Conference calling and in Call Controls Cisco Communication Panel Voicemail, Communications History, Soft phone / Desk phone control Options & Dial #CiscoPlusCA pad
  20. 20. Cisco UC Integration™ for Microsoft LyncHigh Definition Video for Rich Interactions •  Video calls – both in Softphone and Desk Phone mode •  Point to Point & Multipoint calls •  High quality, standards-based H.264 video •  CIF, VGA and HD resolutions supported •  Interoperable with Cisco and 3rd party video solutions •  Leverages CUCM CAC to manage video traffic on the WAN #CiscoPlusCA
  21. 21. Cisco UC Integration™ for Microsoft LyncPhone Presence•  Availability in Lync is updated to reflect Softphone/Hardphone state•  Shows your current Softphone/Hardphone state to your contacts•  Users showed “On the phone” also for calls to Video Bridge, VC stations or any other video system (Cisco or Third Party) #CiscoPlusCA
  22. 22. Microsoft & Cisco InteroperabilityUse cases and Scenarios – SIP-Trunk / Direct-SIP AudioOCS 2007 / Lync 2010 (no media bypass) Front-End Mediation CUCM Lync Clients Pool Server Pool RTaudio G.711OCS 2007 / Lync 2010 (no media bypass), none G.711 on IP-PBX Front-End Mediation CUCM Pool Server Pool Transcoder Lync Clients RTaudio G.711 G.729/iLBC•  The two call flows above show the signaling and media paths in a SIP-trunk interoperability scenario.•  Lync Mediation Server ONLY supports G.711, requires additional transcoding resource if any other codec is used in such an scenario.With CUCM 8.x and above a MTP is not required in this configuration. #CiscoPlusCA
  23. 23. Microsoft & Cisco InteroperabilityUse cases and Scenarios – SIP-Trunk / Direct-SIP AudioLync 2010 (with media bypass) Front-End Mediation CUCM Lync Clients Pool Server Pool G.711 G.711 MTP•  With the introduction of Media Bypass in Lync 2010 the Lync client can initiate direct G.711 not requiring media to be transcoded in the Mediation Server.•  Signaling still has to flow via the Mediation Server.•  Media Bypass mandatorily requires all media to come from a single IP address. Which is the reason why a MTP has to be inserted into this scenario. #CiscoPlusCA
  24. 24. Video Integration with MS #CiscoPlusCA
  25. 25. Microsoft Lync 2010 - video capabilities summary   Point to Point video call: o  Still uses the RTVideo codec as default - CIF, VGA and HD (with Quad Core CPU) as possible resolutions o  Single codec supported for interoperability with standard VC is H263 (max resolution is CIF@15fps)   Multi-Point video call using Internal A/V MCU: o  Support RTVideo codec only o  Support CIF and VGA as resolutions (No HD) o  Support Voice Activated Switching only (no Continuous Presence) o  Utilize Microsoft CCCP as protocol to create, extend and manage the Multi-party Video Conference   Content Sharing: o  Use Microsoft specific solution both for Point to Point and Multi-Point calls (no BFCP support) #CiscoPlusCA
  26. 26. VCS and B2BUA ServiceIntroductionVCS X7.0 introduces the concept of Back to Back User Agent (B2BUA):   Service running on “Lync-OCS Gateway” VCS   Keep standard based and OCS / Lync signalling separate   Recommended scenario (Old way still supported in X7.x, not in X8.x)   Simplified configuration (one menu with all the options listed together)   Publishing VCS Presence into OCS/Lync is supported and strongly recommended to have a full User Experience   Allows interoperability with OCS/Lync Clients connected from Internet through Microsoft Edge Server   AMG is supported and improved in terms of features support (Call Transfer, Hold and Multi-way)   End to End encryption for Media and Signaling #CiscoPlusCA
  27. 27. Lync / VCS Deployment Guidehttp://www.cisco.com/en/US/docs/telepresence/infrastructure/vcs/config_guide/Cisco_VCS_Microsoft_OCS_2007_R2_and_Lync_2010_Deployment_Guide_X7-­‐1.pdf #CiscoPlusCA
  28. 28. UC Gateway Solution for MS Video Interop UC Gateway Video Advanced Media Communication Gateway (AMG) Server (VCS) Scalable and resilient Transcodes Microsoft Interoperability with RTV to HD or VGA Microsoft OCS 2007 R2 standard compliant and Lync 2010 video codec #CiscoPlusCA
  29. 29. MS Office Integration #CiscoPlusCA
  30. 30. Microsoft & Cisco InteroperabilityMicrosoft Applications enabled with Cisco Collaboration Microsoft SharePoint 2007 Cisco Presence Light-Ups W or d Cisco Click to IM/Call Microsoft Outlook 2007 #CiscoPlusCA
  31. 31. Microsoft & Cisco Interoperability d inMicrosoft Applications enabled with Cisco Collaboration Supporte 0(3) CUPC 8. Microsoft Outlook 2010 Cisco Presence Light-ups Cisco Click to IM/Call #CiscoPlusCA
  32. 32. Cisco Jabber #CiscoPlusCA
  33. 33. Introducing Cisco Jabber for WindowsCisco Jabber is our new UC and Collaboration client:  User Interface and experience built to be highly intuitive.  Full Office integration  Standards based Interoperability  Based on the second generation CSF, optimized in terms of memory and resource utilization  Range of extensibility points and application integrations  Also available for Mac #CiscoPlusCA
  34. 34. Voice & Video Call ControlJabber for Windows provides two call control options   Enterprise Call control (ECC) o  ECC allows a customer to integrate Jabber for Windows with Unified Communications Manager. o  ECC provides control of a Cisco desktop phone as well as soft phone operation. o  URI dialling planned with CUCM 9.0   Cloud Call Control [subject to change] o  Only available in cloud deployment o  Provides computer to computer calling between two users of the Webex cloud #CiscoPlusCA
  35. 35. Voice & Video Call Control Desk phone Soft phone Control Operation•  Users can select mode of operation using the system tray icon.•  Drop down list will provide a list of hardware/software associated to user.•  Users can be configured to use just desk phone, just soft phone or both. #CiscoPlusCA
  36. 36. The Cisco Precision Video Engine•  Precision Video Engine is a H.264 AVC software library designed to handle voice and video related tasks•  This library is based on the Video Engine used in the Cisco “Movi” product (*)•  Provides full HD interoperability between Jabber desktop clients and any standard based VC systems•  PVE also provides audio codecs G.711a/u, G.722, G.729a, iLBC (and subject to change AAC-LD, G.722.1)•  PVE supports frame size QCIF to 720p based on attached camera. Note: HD 720p will be possible using DUAL CORE CPU! (*) Note – “Movi” has been recently renamed Cisco Jabber Video for TelePresence #CiscoPlusCA
  37. 37. Desktop Sharing •  Video Desktop Share is based on the BFCP standard. •  Video Desktop Share allow you to share your desktop not only with other Jabber clients but also Telepresence Systems and Rooms...how many customer are waiting for this? •  CUCM 8.6.x needed for BFCP support •  Point to Point and Multipoint (MCU based) scenario are possible Other Jabber Clients Personal Telepresence Systems Telepresence Rooms #CiscoPlusCA
  38. 38. Desktop Sharing Some Screen shot from Tobias Lab..... #CiscoPlusCA
  39. 39. Searching for ContactsSearch and dial bar Auto detect AD/LDAP •  Client (on premise) provides search Recommended pre 8.6(2) Recent across multiple contact Contacts Returned record sources. UC Manager UDS Service •  Clientuses premise) (on predictive Recommend for 8.6(2) + search to refine resolution Local Contacts list as you type. Returned[subject to change] Webex Corporate Directory (Cloud) Directory Contacts Returned #CiscoPlusCA
  40. 40. Solution Summary•  Suggested approach for customer, advantages with Cisco standards based IPT/Video (LCS/OCS can be easily migrated to Jabber)  Full Office integration•  Designed with the goal to optimize resource utilization (CSF2G)•  Supports standard based audio and video codecs•  High Definition 720p (with a Dual Core CPU), also for calls to Video Conference systems•  BFCP Desktop Sharing with any standard Video Device #CiscoPlusCA
  41. 41. Q&A #CiscoPlusCA
  42. 42. We value your feedback. Please be sure to complete the Evaluation Form for this session.Access today’s presentations at cisco.com/ca/plusFollow @CiscoCanada and join the #CiscoPlusCA conversation #CiscoPlus

×
