  • Monitoring SharePoint doesn’t change when the application is virtualized. Use the same tools such as PerfMon, SharePoint Health Analyzer, and diagnostic logging. For monitoring SQL you can continue to use native tools. On top of monitoring SharePoint you can pinpoint bottlenecks by using vSphere monitoring such as esxtop and vSphere Client performance graphs.When trying to identify bottlenecks focus on resources that are queuing such as CPU or I/O versus relying on time-based measurements.
  • Monitoring SharePoint doesn’t change when the application is virtualized. Use the same tools such as PerfMon, SharePoint Health Analyzer, and diagnostic logging. For monitoring SQL you can continue to use native tools. On top of monitoring SharePoint you can pinpoint bottlenecks by using vSphere monitoring such as esxtop and vSphere Client performance graphs.When trying to identify bottlenecks focus on resources that are queuing such as CPU or I/O versus relying on time-based measurements.
  • Monitoring SharePoint doesn’t change when the application is virtualized. Use the same tools such as PerfMon, SharePoint Health Analyzer, and diagnostic logging. For monitoring SQL you can continue to use native tools. On top of monitoring SharePoint you can pinpoint bottlenecks by using vSphere monitoring such as esxtop and vSphere Client performance graphs.When trying to identify bottlenecks focus on resources that are queuing such as CPU or I/O versus relying on time-based measurements.
  • With each version VMware has been increasing the performance and scalability by leaps and bounds.Any lingering performance concerns relating to VMware virtual machines are clearly due to a lagging perception from very early generations which had limited capabilities.
  • SharePoint performance is much more than I/O, it’s the user experience throughout all layers.
  • The VMware Solutions team performed load testing on vSphere and SharePoint 2010. The purpose of the testing was to determine the overhead placed, if any, by the virtualization of SharePoint, and the difference between a scaled up approach versus a scaled out approach.The Visual Studio Team Suite was used to generate load based on Microsoft recommendations. Workloads of 80 reads, 10 writes and 10 searches were used for physical to virtual comparisons and web front-end scale tests. A 60-10-10 workload was used for SQL scale testing. To create a continuous workload zero think time was configured. A real user would take time between Web requests, the load generator configured for zero think time provides a stead load on the environment.
  • Virtual and physical SharePoint web front-ends were tested to measure the difference in equally sized configurations. Results show that the difference between a physical and virtual Web front-end is very little even in high utilization scenarios.
  • In the SQL server scale out test a more database intensive workload was run, generating more writes and searches. As in the web front-end tests the scaled out design was able to achieve higher throughput than the scaled up design.
  • Virtualization adds new software layers and new types of interactions between the database and the hardware components. While the general methodology for monitoring and troubleshooting database performance does not change, VMware provide additional tools for monitoring and troubleshooting at the physical host level. Host-level monitoring: the vSphere Client and the esxtop and resxtop utilities.vSphere Client:GUI interface, primary tool for observing performance and configuration data for one or more ESX/ESXi hostsDoes not require high levels of privilege to access the data Resxtop/Esxtop Gives access to detailed performance data of a single ESX/ESXi hostProvides fast access to a large number of performance metricsRequires root-level accessRuns in interactive, batch, or replay mode
  • Refer to slide
  • The first step in modeling a production workload is to estimate the amount of activity you expect the users to generate. If you are deploying SharePoint for the first time in your organization, you must do a bit of educated guesswork on the expected user activity.If you’re upgrading from SharePoint 2007, you can analyze the existing environment to estimate the expected load in SharePoint 2010. To do this, you can either mine IIS logs or use information gathered by a third-party monitoring solution. Having current usage information greatly simplifies the capacity planning process and Microsoft provides the capability to use exiting IIS logs for load testing. To use an existing environment as a baseline requires the material listed in the slide from Microsoft:Whether you are deploying a new environment or upgrading from SharePoint 2007, you must define the expected user workload by using the criteria in the table below. Again, if you have an existing environment, this information can be gathered from the IIS logs; if you’re starting from scratch, you’ll need to estimate these values. Microsoft has published several case studies (available at http://technet.microsoft.com/en-us/library/cc261716.aspx) profiling different types of user load to help with your estimation process.
  • Microsoft has published a set of topologies ranging from small deployments to large enterprise farm implementations (see http://technet.microsoft.com/en-us/library/cc263044.aspx) that you can use as a starting point for your architecture. After you have chosen a topology, you can use the recommended server role requirements to plan resource allocation for your SharePoint virtual machines.
  • Monitoring SharePoint doesn’t change when the application is virtualized. Use the same tools such as PerfMon, SharePoint Health Analyzer, and diagnostic logging. For monitoring SQL you can continue to use native tools. On top of monitoring SharePoint you can pinpoint bottlenecks by using vSphere monitoring such as esxtop and vSphere Client performance graphs.When trying to identify bottlenecks focus on resources that are queuing such as CPU or I/O versus relying on time-based measurements.
  • The Configuration and Central Administration databases tend to be relatively small. Microsoft recommends that you allocate:- 2GB for the configuration database – The configuration database can eventually grow beyond 1GB, but it grows at a very slow rate; approximately 40MB for each 50,000 site collections.- 1GB for the central administration database.Because Configuration database transaction logs can be quite large, Microsoft recommends that you change the recovery model for the database from full to simple. In addition, if using SQL Server database mirroring to provide availability for the Configuration database, Microsoft recommends that you use the full recovery model.Disk throughput requirements for the Configuration and Central Administration databases are minimal.Every SharePoint environment is unique; therefore, estimating the disk capacity and throughput required for content databases is not a precise activity. The Microsoft guidelines in this slide can help estimate the initial size of your deployment. Over time, as you monitor the production environment, you can easily adjust to changing disk capacity and throughput requirements using VMware features such as VMware Storage vMotion™.
  • The Configuration and Central Administration databases tend to be relatively small. Microsoft recommends that you allocate:- 2GB for the configuration database – The configuration database can eventually grow beyond 1GB, but it grows at a very slow rate; approximately 40MB for each 50,000 site collections.- 1GB for the central administration database.Because Configuration database transaction logs can be quite large, Microsoft recommends that you change the recovery model for the database from full to simple. In addition, if using SQL Server database mirroring to provide availability for the Configuration database, Microsoft recommends that you use the full recovery model.Disk throughput requirements for the Configuration and Central Administration databases are minimal.
  • Planning a deployment of SharePoint virtual machines to vSphere is mostly about properly allocating compute resources to maximize application performance. As an example, this refers to Microsoft’s Departmental Collaboration Environment Technical Case Study (SharePoint Server 2010) at http://technet.microsoft.com/en-us/library/ff758649.aspx, which is a live, production workload that was documented to aid in the design process. The server role requirements from the case study are used to determine the virtual machine configurations and the appropriate hardware for the ESX/ESXi hosts. Then the initial deployment of the SharePoint virtual machines is mapped to the ESX/ESXi hosts to avoid overcommitment of host resources. To make this architecture work in a virtual environment, some important modifications were made to the case study:- The SQL Server hosting the content databases calls for 16 processor cores and 32GB of memory. Because this exceeds current vSphere limitations for vCPU allocation (maximum of 8 cups in vSphere 4.1), this large SQL Server was split into two SQL Server virtual machines with 8vCPUs each. The memory was left at 32GB, which is likely much more than is required for this workload, but can be adjusted after you have monitored for actual memory usage.- Some SQL Server configurations in this case study specify Direct Attached Storage (DAS) for the TempDB databases; however, placing all storage on the SAN enables key VMware features, such as vMotion, DRS, HA, and Storage vMotion. Links to original storage recommendations are included in the resource requirements table below.This case study is used for illustration purposes only to demonstrate resource allocation and mapping of SharePoint virtual machines to ESX/ESXi hosts. You should always plan your own environment using Microsoft Best Practices and case study examples. Figure 10 is from Departmental collaboration environment technical case study (SharePoint Server 2010) at http://technet.microsoft.com/en-us/library/ff758649.aspx.
  • Refer to slide.
  • Refer to slide.
  • Refer to slide.
  • Refer to slide.
  • Refer to slide.
  • Refer to slide.
  • Business Production Bundle Maximize the benefits of virtualizing business critical applications by enabling fully automated disaster recovery, dynamic security & automated operations.Over 60% of VMware customers have progressed into the Business Production phase of their virtualization journey and have already virtualized one or more of their business critical applications such as Microsoft® Exchange, SQL, Oracle®, SAP® and Java™ with confidence1In addition to providing built-in availability, efficiency and automation, virtualization unlocks the potential for fully automated disaster recovery, dynamic security and proactive management of performance, capacity and compliance. The Business Production Bundle enables customers in this phase of the virtualization journey to experience the full benefits of virtualizing their business critical applications. At a Glance  The Business Production Bundle delivers disaster recovery, security and automated operations for virtualized business critical applications in one convenient bundle.  This bundle requires customers to have VMware vSphere (ESXi 4.1 and above) and vCenter Server (4.0 and above) Products in the bundle:VMware vCenter Site Recovery Manager 5 Enterprise EditionVMware vShield App 5, with Data SecurityVMware vCenter Operations AdvancedPricing 25 VM Pack, $17,630 75 VM Pack, $52,890TimingSept 2011 pricelist (direct) and Oct 2011 pricelist (channel)  Refer Business Production Bundle Internal FAQ on VMvault for more details https://www.gosavo.com/vmware/Document/Document.aspx?id=2373723&view=
  • vSphere performance features help to improve the performance of virtualized applications like SharePoint 2010. Features like memory compression, transparent page sharing, and memory ballooning can help to drive up consolidation ratios.Refer to table regarding features and descriptions.
  • The upper table is from Microsoft’s Enterprise intranet collaboration environment technical case study example (available at http://technet.microsoft.com/en-us/library/ff758650.aspx), which services over 69,000 unique users per day.At this time there are no definitive guidelines on what might be considered “normal” usage for SharePoint 2010 users; however, there is some information in the SharePoint 2007 TechNet documentation (http://technet.microsoft.com/en-us/library/cc261795%28office.12%29.aspx) that may give you an idea on what to expect in terms of user load. You can use the Requests Per Second Per User value to calculate the overall RPS that you must support. For example, 5,000 concurrent, “heavy” users each at 60 requests per hour would translate into .017 requests per second per user or 85 requests per second (RPS) for the system as a whole.
  • When monitoring SharePoint using PerfMon or MOM/SCOM note the baselines for the counters in this table. Use these baselines to determine any performance bottlenecks in the SharePoint application.

Bca1931 final Bca1931 final Presentation Transcript

  • BCA1931Design, Deploy, and OptimizeSharePoint 2010 on VMwareItzik Reich, EMC CorporationAlex Fontana, VMware, Inc.
  • Disclaimer This session may contain product features that are currently under development. This session/overview of the new technology represents no commitment from VMware to deliver these features in any generally available product. Features are subject to change, and must not be included in contracts, purchase orders, or sales agreements of any kind. Technical feasibility and market demand will affect final delivery. Pricing and packaging for any new technologies or features discussed or presented have not been determined.2
  • Agenda Introduction and Benefits SharePoint on vSphere Performance SharePoint on vSphere Capacity Planning • Workload Modeling and Architectural Design • SQL Server Capacity and Performance • Deploying to ESX/ESXi SharePoint on vSphere Availability and Recovery • High Availability • Disaster Recovery • Backup and Recovery Customer Case Study with EMC More Information3
  • SharePoint – What is it? Mostly an intranet portal for collaboration It can be customized for all sorts of uses Varies from insignificant to critical http://www.topsharepoint.com4
  • Key Benefits – Virtualizing SharePoint Consolidation  Achieve 2-10x consolidation ratio, especially for larger deployments Performance  Improved front end performance with more, smaller WFEs rather than few large WFEs Availability  VM-based protection for SharePoint provides homogeneous high availability (VMware HA) Business Continuity  Simplified DR management with vCenter Site Recovery Manager Maintenance  Live migration of SharePoint virtual machines (VMware vMotion) Load Balancing  Maximized overall performance with balanced HW utilization across the farm (VMware DRS)5
  • Virtualizing Server Roles in SharePoint Server Roles/Priority What to Consider 1st Web Front End / Query CPU – User concurrency, Search requests Scaling out is more efficient Network – segment vNICs and vSwitches 2ndApplication (Excel, Doc Conv, etc) CPU – Application dependent Scaling out is more efficient 3rd  Redundant (Non redundant in MOSS 2007) Index/Crawl  CPU – Crawling, indexing (depends on content type/size)  Scale out (Up only with MOSS 2007)  Memory intensive CPU – Document updates, Search, Backup 4th VMFS/RDM SQL Scale up/out (VMware ≤32 vCPU) Failover Clustering, Mirroring, VMware HA Understanding your existing workload is better than any best practice!!! 6
  • Agenda Introduction and Benefits SharePoint on vSphere Performance SharePoint on vSphere Capacity Planning • Workload Modeling and Architectural Design • SQL Server Capacity and Performance • Deploying to ESX/ESXi SharePoint on vSphere Availability and Recovery • High Availability • Disaster Recovery • Backup and Recovery Customer Case Study with EMC More Information7
  • Maximum Scalability and Performance With vSphere 5 Application’s Performance Requirements 95% of Apps VMware Inf. VMware VMware ESX 1 ESX 2 Require 3.0/3.5 vSphere 4 vSphere 5% of Applications CPU 1 to 2 CPUs 1 VCPUs 2 VCPUs 4 VCPUs 8 VCPUs 32 VCPUs Memory < 4 GB at peak 2 GB per VM 3.6 GB per VM 16/64 GB per VM 256 GB per VM 1,000 GB per VM Network <2.4 Mb/s <.5Gb/s .9 Gb/s 9 Gb/s 30 Gb/s >36Gb/s IOPS < 10,000 <5,000 7,000 100,000 300,000 1,000,000 8
  • SharePoint Performance – The User Experience Domain Controller SQL Server Authentication Document Storage Web Front End Request − Content/Metadata − Search Type Of Acceptable user − System Examples Server operation Network Client response time • Browsing to the home page ‒ CPU Common <3 seconds • Browsing to a document library BLOB ‒ Memory • Creating a subsite Creating a list Uncommon ‒ HBA/CNA • <5 seconds Storage ‒ NIC Uploading a document to a document library • Backing up a site (Optional) Rare • Creating a site collection <7 seconds BLOB http://technet.microsoft.com/en-us/library/cc287790(office.12).aspx Retrieval/Creation9
  • SharePoint 2010 Performance Test Logical Architecture Workload • Root portal configured with collaboration template • 260GB content, approximately 600K items in 10 site collections • Incremental crawl every four hours and weekly full crawl VSTS load generator – Zero think time (per Microsoft guidelines) Transaction mix – 80-10-10 read-write-search Real world settings – IIS logging on, SharePoint caching disabled10
  • Physical versus Virtual Study Physical versus virtual Web front end (WFE) comparison shows the overall request per second (RPS) differs very little, even at higher CPU saturation levels Physical Versus Virtual WFE CPU Comparison 50 45 Physical Virtual 40 35 RPS Physical 30 Virtual 25 Physical 20 Virtual 15 10 5 0 1 CPU (95%+ Saturation) 2 CPU (75-90% Saturation)11
  • Scaling Out the SQL Server Back-End 60-20-20 Mix Test compares one SQL instance versus two SQL instances Scaling out SQL Server provides better throughput! Test with your workload for best SQL server scale out throughput12
  • Performance Monitoring vSphere Client: • GUI interface, primary tool for observing one or more ESX/ESXi hosts • Does not require high levels of privilege Resxtop/Esxtop • Gives access to detailed performance data of a single ESX/ESXi host • Provides fast access to a large number of performance metrics • Requires root-level access • Runs in interactive, batch, or replay mode In-guest Monitoring tools • SQL Server: Perfmon, Profiler, Dynamic Manage Views • Use ESX Counters in PerfMon for more accurate results - http://vpivot.com/2009/09/17/using-perfmon-for-accurate-esx-performance-counters/13
  • Agenda Introduction and Benefits SharePoint on vSphere Performance SharePoint on vSphere Capacity Planning • Workload Modeling and Architectural Design • SQL Server Capacity and Performance • Deploying to ESX/ESXi SharePoint on vSphere Availability and Recovery • High Availability • Disaster Recovery • Backup and Recovery Customer Case Study with EMC More Information14
  • Capacity Planning Process Summary Estimate User Activity Select a starting point architecture Map out resource requirements by server role (virtual machine requirements) Plan the ESX/ESXi host hardware configuration (ESX/ESXi host requirements) Perform initial placement exercise to verify resource allocations and failover headroom15
  • Estimating User Activity Upgrading from SharePoint 2007 • Mine IIS logs and utilize Microsoft or 3rd party testing tools • SharePoint 2010 Load Testing Kit http://technet.microsoft.com/en-us/library/ff823736.aspx. • Visual Studio 2008 Team System http://www.microsoft.com/downloads/en/details.aspx?FamilyID=d95598d7-aa6e-4f24- 82e3-81570c5384cb&DisplayLang=en. • Visual Studio 2008 Service Pack 1 http://www.microsoft.com/download/en/details.aspx?displaylang=en&id=10986 New installation Enterprise Intranet Collaboration Environment Technical Case Study Example http://technet.microsoft.com/en-us/library/ff758650.aspx • Requests per second Workload Characteristics Value Average daily RPS 157 • Concurrent users Average RPS at peak time 350 • Total daily users Total number of unique users per day 69,702 • Total daily requests Average daily concurrent users 420 Peak concurrent users at peak time 1,433 Total number of requests per day 18,866,52716
  • Selecting a Starting Point Architecture SharePoint 2010 topologies SharePoint 2010 Medium Topology Example • Published Microsoft topologies from small to large enterprise farms • Use recommended role requirements to plan resource allocation for VMs • http://technet.microsoft.com /en-us/library/cc263044.aspx SharePoint Server 2010 technical case studies • Published Microsoft technical case studies illustrating existing production environments • Select the case study that is most applicable to your organizations expected usage patterns http://technet.microsoft.com/en-us/library/cc261716.aspx.17
  • SharePoint Farm Topologies Small le out approach = More servers ? Sca Medium LargeWeb Web Servers Groups MOSS SP H/W 2007 2010 RAM >2GB 8GB >3.0GHz >2.5GHz CPU Web/Query Web User requests Crawling/Admin Dual Quad Features that impact SQL Server Sizing • The size of content databasesApplication App Servers Groups MOSS •SP The addition of service applications or features H/W 2007 2010 into the environment RAM 4GB 8GB • The use of SQL Server mirroring >2.5GHz >2.5GHz App Query/Crawl App Query Crawl Central Admin CPU Dual • Quad The frequent use of files larger than 15MB /Office/OtherDatabase MOSS SP H/W 2007 2010 RAM >2GB 8 - 64GB >2.5GHz CPU >2.0GHz All DBs Quad Search DBs SharePoint DBs Search DBs SharePoint DBs Content DBs 18
  • SQL Server Capacity and Performance19
  • A Day in the life of SharePoint…SQL Server CPU The majority of load comes from systematic operations…20
  • A Day in the life of SharePoint…SQL Server Storage I/O Plan for user load peaks, not systematic peaks…21
  • Database Sizing Central Administration • 2GB capacity; minimal disk throughput required Configuration Database • 2GB capacity; minimal disk throughput required • Can slowly grow beyond 1GB; approx. 40MB for every 50K site collections • Transaction logs can be large; change recovery model from full to simple unless mirroring Content Databases Database size = ((D × V) × S) + (10KB × (L + (V × D))) • D = the number of documents you expect to host • S = the average size of each document • L = the number of list items in the environment; start with 3 X D and adjust • V = the approximate number of document versions22
  • SQL Server Storage Best Practices Plan for performance in addition to capacity Search database and temp database are the most demanding for disk I/O. Search database is write intensive when crawling. When possible, place SQL transaction log and database files on physically separate disk pools Place transaction log files on RAID1/0 volumes/pools for high write performance and faster rebuilds Most of SharePoint data (content databases) can use RAID5 volumes • RAID5 for more read intensive workloads (common, mainly publishing farms) • RAID1/0 for higher random write workloads (heavy collaboration, tempdb, search) • RAID 6 usually for higher availability with large amount of drives (Virtual Pools)23
  • Deploying to ESX/ESXi24
  • Virtual Machine Resource Allocation Virtual CPUs • Allocate the minimum requirement and adjust as needed; use HotAdd. • If overcommitting processors, monitor %RDY, %MLMTD, and %CSTP • Keep NUMA node size in mind with sizing virtual machines Virtual Memory • “Right-size” memory allocations for efficient use of host memory • Use vSphere 4.1 to take advantage of memory compression • If overcommitting memory, monitor SWAP /MB: r/s, w/s and MCTLSZ Storage • Understand I/O requirements for each application tier to avoid performance degradation due to under-provisioned storage • Use redundant paths to storage – Dual host-bus adapters or teamed network interface cards connected to separate switching infrastructures • Avoid partition misalignment by creating VMFS partitions from within the vSphere client – If creating VMFS from the CLI use fdisk to align25
  • Sample Architecture on vSphere Based on Microsoft’s departmental collaboration environment technical case study (SharePoint Server 2010) at http://technet.microsoft.com/en-us/library/ff758649.aspx The SQL Server configuration exceeded vSphere 4.1 limitations for vCPU allocation (maximum of 8 in vSphere 4.1), this large SQL Server was split into two SQL Server virtual machines with 8vCPUs eachDepartmental Collaboration Environment Technical Case Study on vSphere Sample Architecture26
  • Agenda Introduction and Benefits SharePoint on vSphere Performance SharePoint on vSphere Capacity Planning • Workload Modeling and Architectural Design • SQL Server Capacity and Performance • Deploying to ESX/ESXi SharePoint on vSphere Availability and Recovery • High Availability • Disaster Recovery • Backup and Recovery Customer Case Study with EMC More Information27
  • SharePoint 2010 Availability What to protect? (Service Level Agreements) • Recovery Point Objectives (RPO) • Recovery Time Objectives (RTO) • Recovery Level Objectives (RLO) How to protect? • Tools and technologies available from SharePoint 2010 natively • VMware vSphere additions28
  • High Availability29
  • SharePoint 2010 with Application-Aware HA Protects all SharePoint server roles from hardware and application failure Does not require complex cluster setup or standby resources Fully integrated with VMware HA and vCenter30
  • VMware HA and High Availability Database Mirroring SharePoint 2010 is mirroring-aware Provides redundancy for SharePoint 2010 databases Protection against HW/SW failures and DB corruption Storage flexibility (FC, iSCSI, NFS) RTO in few seconds VMware HA + Database Mirroring • Seamless integration, virtual machines rejoin mirroring session after VMware HA recovery • Can shorten time that database is in unprotected state • Reduces synchronization time after virtual machine recovery31
  • Disaster Recovery32
  • Disaster Recovery with Site Recovery Manager (SRM) Relies on storage replication Allows creation, maintenance, and execution of automated process to facilitate site recovery Safe testing without impacting production environment Improves hardware utilization with co-located test/dev with DR Self-documenting33
  • Backup and Recovery34
  • What to Backup SharePoint 2010 Server Farm Servers Front End, Application, Index, Search, SQL SQL Server Databases Web Applications Site Collections SitesConfiguration, Search, Serv ices, and so on Content Databases Lists (document libraries, events, contacts, and the like) Documents and Items35
  • VMware Data Recovery (VDR) Quick, simple, and complete data protection for your SharePoint VMs with VDR, a disk-based backup and recovery solution Integrated with vCenter to enable centralized and efficient management of backup jobs Useful for small environments Can be used for SQL Server if the service is STOPPED36
  • SharePoint 2010 Backup using EMC Replication Manager37
  • Summary vSphere provides the foundation for high performance SharePoint environments Virtualized SharePoint instances perform very well compared to equally sized physical instances Tests of both Web front-end and SQL virtual machines show scaling out can provide increased throughput Monitoring virtualized SharePoint remains the same as a physical deployment with additional visibility into the underlying infrastructure Use VMware HA to protect SharePoint from downtime; for higher availability, consider: • Symantec Application HA for more granular control at the service level • Combining VMware HA with SQL Server Mirroring Use SRM for site recovery; co-locate test/dev and recovery VMs38
  • Agenda Introduction and Benefits SharePoint on vSphere Performance SharePoint on vSphere Capacity Planning • Workload Modeling and Architectural Design • SQL Server Capacity and Performance • Deploying to ESX/ESXi SharePoint on vSphere Availability and Recovery • High Availability • Disaster Recovery • Backup and Recovery Customer Case Study with EMC More Information39
  • Customer Use Case A Global company – 50,000 Employees Is among the top 15 companies in it’s segmentation Designed and Implemented fully virtualized SharePoint Solution for 120,00 Seats based on VMware vSphere & EMC Technologies Solution Building Blocks Replication Manager SRM 4.1 vSphere 4.1 EMC VMAX40
  • SAN Layout Considerations • Dedicated FA ports for Production, UAT & Test environments • Dedicated FA ports for replication (mount hosts access) V-MAX • Shared/dedicated SRDF ports • ESX ports connectivity to SAN as redundant conf. • All FA/SRDF ports connected to high- speed SAN ports as redundant conf.41
  • Thin Provisioning in VMware vSphere Environments Decisions, Decisions, Decisions….. vSphere provides native thin provisioning VMAX provided array thin provisioning (Virtual Provisioning) • Either one can be used, no performance penalty in any of them • Both features can be used simultaneously but doing so increases risk • We debated where to implement it.. • Decided on the Array level…why? VMAX Virtual Provisioning simplifies drive and DA workload distribution • Provides additional benefits besides optimizing storage use • Ensure enough paths and TDEVs to support the workload VMAX Virtual Provisioning provides additional benefits • Zero Reclaim and Rebalancing42
  • Storage Layout Decisions Traditional Array Design Revolutionary Array (RAID 5 / 10 / SSD Design (Storage Tiering) Proven Fairly New Very costly Hugh Savings Not Flexible Highly Dynamic We decided to go with Storage Tiering but why? Saving money is an important thing but wasn’t the success criteria here.. The dynamic nature of the customer SharePoint environment was!43
  • EMC Symmetrix FAST VP – overview  Automatic storage tiering for Virtual Provisioning thin pools  Analysis and data movement at sub-LUN level: • Spreads data from a single thin device across multiple pools • Places very active parts of a LUN on high- EFD performing EFDs • Places less active parts of a LUN on higher- FC capacity, more cost-effective FC or SATA drives • Moves data at the extent group level - 7,680 KB  Moves data based on user-defined policies and SATA application performance needs  Data movement is automatic and nondisruptive 44 44
  • EMC FAST in Action EMC Storage with an active ESX Cluster VMware VMware VMware VMware All Fibre Channel Disk Drives Disk Resources are ~80% Busy45
  • EMC FAST in Action Add Flash Drives and Apply FAST Policy VMware VMware VMware VMware Tiered Storage 5% Flash Drives 65% FC Drives 30% SATA 68% Less Disk I/O Contention 2.5X Faster Disk Response Time46
  • Where did the customer use FAST VP Is VMAX FAST VP a good fit for SharePoint 2010? • Yes, but for maximum efficiency, it depends on which storage role • Search Index component ? No • Highly changing, throw-away data • Search Query component ? Yes • Highly-read data with small burst write changes • TempDB? Yes • The same blocks are re-used on disk and performance of TEMPDB directly affects SharePoint performance request - TempDB is used in every SharePoint request • Helps to handle unanticipated performance requirements47
  • Balancing the I/O OK, so the storage will balance itself but Path Fault with PowerPath/VE what about the Queues up until we reach vSphere server the storage subsystem layer.. The Customer evaluated PowerPath/VE PowerPath/VE We were able to achieve up to X 2.5 the performance compared with RR HBA HBA Why? FC, iSCSI, FCoE FC, iSCSI, FCoE Because it does a predictive load balancing.. Storage Storage Port Port48
  • Set it and Forget it It also helped the customer to find out about a flaky fiber cable using the VSI (Virtual Storage Integrator) Plugin VMware vCenter Server 49
  • This customer loves to take replicas on their SharePointenvironment But how do you take 40 Replicas? Yes, 40…50
  • Enabling the SharePoint Team Self-provision and refresh dev/test environments • Single console simplifies replica management • Wizards step through the process for replica management Replica 1 Replica 2 Replica 3 Replica 4 HIGHEST • User roles facilitate self-sufficiency Replication Manager Administrator • PRIVILEGES USER ROLE Power Database Administrator Integrate pre- and post-processes Database Administrator • Schedule jobs or run ad hoc Power User • Auto-expire replicas based Operator on retention policies LOWEST51
  • Selecting A 3rd Party BLOB Software…Your SharePoint SQLServer is NOT a FileServer!52
  • Selecting A 3rd Party BLOB Software…So let’s redirect theseFiles OUTSIDE of theSQL Database53
  • Selecting A 3rd Party BLOB Software… Together with the customer, we evaluated some 3rd party BLOB software and decided on Metalogix StoragePoint We reduced the content DB by 90%54
  • SharePoint 2010 DR: Virtualized Farm (Full Replication) SharePoint Farm A Primary Site Secondary Site • Resource/Protection Group VMs VMs level granularity • Active/Active (Sync distances) or Active/Passive (Async VMs distances) VMs • Failover automation: VMs VMs • VMware Site Recovery Manager (SRM) Protection VMs Groups for all server roles VMs Databases Databases BLOB Store SRDF/S BLOB Store 55 E
  • Automated Site Failback with VSI 456
  • To Cluster or Not to Cluster…. Microsoft Clustering VMware HA (MSCS) Node Resource Failover Full VM Failover Application Specific Application / OS agnostic Complex to set up VERY easy to set up Costly Cheap We decided to go with VMware HA but why? Ease of use was the key decision making..57
  • Key Takeaways SharePoint is more than just SQL… • Leverage EMC Proven solutions and Best Practices for SharePoint storage, networking and compute design • FAST, FAST Cache, VP improve efficiency & performance but require proper planning • Use RBS to improve scalability and TCO and in some cases, performance Full farm virtualization has great advantages over physical/hybrid configurations • Horizontal scaling is more efficient • The best FULL farm protection when Integrated with EMC replication • Simplifies, accelerates and automates SharePoint DR! (SRM) EMC’s SharePoint VSS based replication can significantly accelerate replication and recovery of SharePoint • A must for large deployments (TBs) • Protects all farm components, not just content (solution dependent) • Fast and simple Item level recovery while integrating with EMC partners (e.g. Kroll)58
  • Agenda Introduction and Benefits SharePoint on vSphere Performance SharePoint on vSphere Capacity Planning • Workload Modeling and Architectural Design • SQL Server Capacity and Performance • Deploying to ESX/ESXi SharePoint on vSphere Availability and Recovery • High Availability • Disaster Recovery • Backup and Recovery Customer Case Study with EMC More Information59
  • Resources • Visit us on the Web to learn more about specific apps http://www.vmware.com/solutions/business-critical-apps/ • Best practices, reference architectures, and case studies • Microsoft Apps (Exchange, SQL, SharePoint) • Oracle • SAP • Check out the VMTN user communities • Email (Exchange, Lotus, BlackBerry) http://communities.vmware.com/community/vmtn/general/emailapps • EMC SharePoint solutions http://www.emc.com/solutions/application- environment/microsoft/solutions-for-microsoft-office-system- sharepoint.htm • Metalogix • http://www.microsoft.com/casestudies/Case_Study_Detail.aspx?CaseStud yID=400001075960
  • Introducing: Business Production Bundle Maximize the benefits of virtualizing business critical applications NewAutomated Disaster Recovery vCenter Site Recovery Manager Business Production BundleDynamic Security vShield App with Data Security vCenter Site Recovery Manager vShield App with Data SecurityAutomated Operations vCenter Operations Advanced vCenter Operations Advanced vSphere vSphere vSphere 61
  • Questions62
  • 63
  • BCA1931Design, Deploy, and OptimizeSharePoint 2010 on VMware
  • vSphere Performance Enhancements Feature Description VMware ESX®/VMware ESXi™ attempts to keep a virtual machine assigned to its home NUMA Support NUMA-node. Because memory for the virtual machine is allocated from the home node memory access is local and provides the best performance possible Transparent Page Page sharing allows the hypervisor to reclaim the redundant copies of memory created Sharing when multiple virtual machines run the same operating system and applications The balloon driver allows the hypervisor to reclaim host physical memory if memory Memory Ballooning resources are under contention. This is done with little to no impact to the performance of the application Pages elected to be swapped that can be compressed are stored in a compression cache Memory Compression in main memory. When required, pages are decompressed from compression cache versus paging out from disk Applications that can benefit from large pages on native systems, such as MS SQL, can Large Memory achieve similar performance improvement on a virtual machine backed with large Page Support memory pages Para-virtualized Network High-performance virtual I/O adapters that can provide greater throughput while requiring and Storage Controllers lower CPU utilization Distributed Resource As resource utilization fluctuates within a VMware vSphere® cluster, workloads are Scheduler (DRS migrated with no impact to performance or uptime using VMware vSphere® vMotion® and vMotion)65
  • Estimating User Activity (cont.)Enterprise Intranet Collaboration Environment Technical Case Study Example Workload Characteristics Value Average daily RPS 157 Average RPS at peak time 350 Total number of unique users per day 69,702 Average daily concurrent users 420 Peak concurrent users at peak time 1,433 Total number of requests per day 18,866,527SharePoint 2007 User Loads from Microsoft TechNet User Load Request Rate Requests Per Second Per User Light 20 requests per hour. An active user generates a .006 request every 180 seconds Typical 36 requests per hour. An active user generates a .010 request every 100 seconds Heavy 60 requests per hour. An active user generates a .017 request every 60 seconds Extreme 120 requests per hour. An active user generates .034 a request every 30 seconds66
  • Key Metrics to Monitor for ESX/ESXi Host /Resource Metric Description VM %USED Both CPU used over the collection interval (%)CPU %RDY VM CPU time spent in ready state %SYS Both Percentage of time spent in the ESX host VMkernel Memory ESX/ESXi host swaps in/out from/to disk (per Swapin, Swapout Both virtual machine, or cumulative over host)Memory Amount of memory reclaimed from resource pool by MCTLSZ (MB) Both way of ballooning READs per second, Both Reads and writes issued in the collection interval WRITEs per second DAVG/cmd Both Average latency (ms) of the device (LUN)Disk Average latency (ms) in the VMkernel, also known as KAVG/cmd Both “queuing time” Average latency (ms) in the guest. GAVG = DAVG + GAVG/cmd Both KAVG MbRX/s, MbTX/s Both Amount of data transmitted per second PKTRX/s, PKTTX/s Both Packets transmitted per secondNetwork %DRPRX, Both Drop packets per second %DRPTX 67
  • Key Metrics for SharePointResource Metric Description Processor usage over a period of time. Consistently high utilization can adversely affect performance. Remember to count "Total" inCPU % Processor Time multiprocessor systems. Maintain balanced performance between cores by also measuring individual core utilization Physical memory available for allocation. Insufficient memory leads to Available Mbytes excessive use of page file and increase in page faults Rate at which faults occur when a page is sought in the file system Cache Faults/sec cache and is not found. Effective use of cache for read and writeMemory operations can have a significant effect on performance Rate at which pages are read from or written to disk to resolve hard Pages/sec page faults. Increases in page faults indicate system-wide performance degradation High page file utilization can mean an increase in hard page faults, % UsedPaging File monitor this counter along with Pages/sec and Available Mbytes to % Used Peak determine if allocated memory is inadequate Disk Reads/sec Number of disk reads and writes per second Disk Writes/secDisk Avg. Disk sec/Read Average latency (seconds) of reads and writes of data from disk Avg. Disk sec/WriteNetwork Total Bytes/sec Rate at which data is sent and received through the network interface 68
  • VMware HA and Failover Clustering Supports two-node cluster Failover cluster nodes can be physical or virtual or any combination of the two Host attach (FC) or in-guest (iSCSI) Supports RDM only VMware HA + failover clustering • Seamless integration, virtual machines rejoin clustering session after VMware HA recovery • Can shorten time that database is in unprotected state Failover clustering now supported with VMware HA with vSphere v4.1 http://kb.vmware.com/selfservice/microsites/search.do?language=en _US&cmd=displayKC&externalId=103795969
