Microblogging with XMPP
        Real Time Web
Who am I?

• Name: Stoyan Zhekov
• Private: married, 3 kids (boys)
• Work: Software Engineer
• Contact: xmpp: //zh@jabber....
Today

• XMPP (Jabber)
• Microblogging
• Microblogging with XMPP
• My program - xmpp4r, ramaze, sequel
• Questions
Why?

• Web 3.0 ? - Real Time Web?
• RSS is not enough (SUP)
• XMPP (Jabber)
• Webhooks
XMPP (Jabber)
London-Calcutta, message + reply
              (Peter Saint-Andre)


• 1800:   2 years (ship)
• 1914:   1 month (steamship...
XMPP (history)

• 1998: Jeremie Miller - ICQ - AIM (perl)
• 1999: First rellease
• 2001: Jabber Software Fondation
• 2004:...
What is XMPP?

• JID: node@server/Resource
• Open Protocol
• Decentralized - no central server
• RFC 3290 (core), 3291 (me...
What is XMPP? (2)
• Bidirectional, streaming XML
• One first level tag: <stream>
• 3 second level tags:
   • <presence> - p...
XMPP Features

• Build-in presence
• One-to-one IM (u2u, a2u, a2a)
• Groupchat
• Geolocation
• Security - SSL, TLS
Not only for geeks

• 50 000+ servers, 50+ million users
• Wall Street
• US Department of Defense
• Cisco, Google, Apple
•...
You on XMPP

• Free account - jabber.jp etc.
• GTalk for domains
• Install your own server:
    • ejabberd (erlang) - prod...
Libraries

• For a lot of OSes and languages
• loudmouth (C)
• xiff (flash)
• smack (java)
• xmpp4r (ruby)
Microblogging
Microblogging

• Web 2.0
• What is it?
   • Status changes
   • Short notes (140 limit)
   • Media files
Big players

• Twitter
• Jaiku
• identi.ca (laconi.ca) - OSS
• Tumblr - http://tt.zhekov.net/
• FriendFeed, Lifestream.fm
Microblogging with XMPP
   http://www.microblog.org/
Almost Real Time

• XMPP bots (Jaiku, Identi.ca, FriendFeed)
• GNIP - http://www.gnipcentral.com/
• RSS-to-XMPP
   • http:...
Microblogging with XMPP

• Web 3.0 (Real Time Web)
• PubSub - XEP-0060
• BOSH - XEP-0124
• XEP-XXXX
• ....
Too complicated :(
Am I stupid...? :(
My own program
Design

• XMPP bot
• Simple API
• Simple web frontend
• Models: juick.com , kwippy.com
Components

• models.rb - connection to the DB
• bot.rb - XMPP
• api.rb - service, scaling
• web.rb - browser view
Models
• “Things”
   • User
   • Micro
• “Relations”
   • Subscribe - User-to-User
   • Subscribe - User-to-Micro
   • Lik...
Relations (Sequel)
class User < Sequel::Model(:users)
 one_to_many :micros do |ds|
  ds.filter(:parent_id => nil)
 end
 one...
Ruby XMPP Libraries

• xmpp4r - Roster, vCard etc.
• xmpp4r-simple - easy to use
• jabber4r - Thread based :(
XMPP Bot

• http://tr.im/emxmpp (nutrun.com)
• EventMachine - libevent, Deferrable
• Plugins - http://tr.im/modular
Concurrency
EM.run do
 EM::PeriodicTimer.new(1) do
  ...
      EM.spawn do
       worker = Worker.new
       worker.callba...
Plugins 1/3
PluginFactory.load quot;pluginsquot;
...
def PluginFactory.load( dirname )
    Dir.open( dirname ).each do |fn...
Plugins 2/3
class Plugin
   include EM::Deferrable

  def process( args = {} )
    sleep(0.05)
    set_deferred_status :su...
Plugins 3/3
class NickPlugin < Plugin
  def process(args = {})
   begin
     ...
     set_deferred_status :succeeded
   re...
Simple API (json)

• /users - list of users
• /user/<nick>/<secret> - info for user
• /status/<nick>/<secret> - presence
•...
Web (Ramaze)
class MainController < Ramaze::Controller
  def u nick
   begin
     @user = User.find_by_user(nick)
     subs...
<Demo>
To Do

• Commands parser - Ragel?
• OAuth or http://xmppid.net/
• TokyoCabinet
• XMPP Component -    http://github.com/jul...
Conclusion

• XMPP - good, open protocol
• xmpp4r-simple - good, easy to use
• eventmachine - good network library
• seque...
Questions?
</stream:stream>
Upcoming SlideShare
Loading in...5
×

Microblogging via XMPP

6,418

Published on

Published in: Technology
1 Comment
21 Likes
Statistics
Notes
No Downloads
Views
Total Views
6,418
On Slideshare
0
From Embeds
0
Number of Embeds
6
Actions
Shares
0
Downloads
156
Comments
1
Likes
21
Embeds 0
No embeds

No notes for slide

Microblogging via XMPP

  1. 1. Microblogging with XMPP Real Time Web
  2. 2. Who am I? • Name: Stoyan Zhekov • Private: married, 3 kids (boys) • Work: Software Engineer • Contact: xmpp: //zh@jabber.jp
  3. 3. Today • XMPP (Jabber) • Microblogging • Microblogging with XMPP • My program - xmpp4r, ramaze, sequel • Questions
  4. 4. Why? • Web 3.0 ? - Real Time Web? • RSS is not enough (SUP) • XMPP (Jabber) • Webhooks
  5. 5. XMPP (Jabber)
  6. 6. London-Calcutta, message + reply (Peter Saint-Andre) • 1800: 2 years (ship) • 1914: 1 month (steamship) • 1950: 1 week (airmail) • 1980: 2 days (overnight mail) • 1994: 10 min (email) • 1999: 1 sec (IM)
  7. 7. XMPP (history) • 1998: Jeremie Miller - ICQ - AIM (perl) • 1999: First rellease • 2001: Jabber Software Fondation • 2004: XMPP RFCs (IETF)
  8. 8. What is XMPP? • JID: node@server/Resource • Open Protocol • Decentralized - no central server • RFC 3290 (core), 3291 (messaging) • XMPP extension protocols (XEP)
  9. 9. What is XMPP? (2) • Bidirectional, streaming XML • One first level tag: <stream> • 3 second level tags: • <presence> - presence, subscribtion • <message> - asynchronous • <iq> - synchronous
  10. 10. XMPP Features • Build-in presence • One-to-one IM (u2u, a2u, a2a) • Groupchat • Geolocation • Security - SSL, TLS
  11. 11. Not only for geeks • 50 000+ servers, 50+ million users • Wall Street • US Department of Defense • Cisco, Google, Apple • NTT ?
  12. 12. You on XMPP • Free account - jabber.jp etc. • GTalk for domains • Install your own server: • ejabberd (erlang) - production • openfire (java) - easy to install / use
  13. 13. Libraries • For a lot of OSes and languages • loudmouth (C) • xiff (flash) • smack (java) • xmpp4r (ruby)
  14. 14. Microblogging
  15. 15. Microblogging • Web 2.0 • What is it? • Status changes • Short notes (140 limit) • Media files
  16. 16. Big players • Twitter • Jaiku • identi.ca (laconi.ca) - OSS • Tumblr - http://tt.zhekov.net/ • FriendFeed, Lifestream.fm
  17. 17. Microblogging with XMPP http://www.microblog.org/
  18. 18. Almost Real Time • XMPP bots (Jaiku, Identi.ca, FriendFeed) • GNIP - http://www.gnipcentral.com/ • RSS-to-XMPP • http://notify.me/ • http://notifixio.us/ (WP plugin)
  19. 19. Microblogging with XMPP • Web 3.0 (Real Time Web) • PubSub - XEP-0060 • BOSH - XEP-0124 • XEP-XXXX • ....
  20. 20. Too complicated :(
  21. 21. Am I stupid...? :(
  22. 22. My own program
  23. 23. Design • XMPP bot • Simple API • Simple web frontend • Models: juick.com , kwippy.com
  24. 24. Components • models.rb - connection to the DB • bot.rb - XMPP • api.rb - service, scaling • web.rb - browser view
  25. 25. Models • “Things” • User • Micro • “Relations” • Subscribe - User-to-User • Subscribe - User-to-Micro • Like - User-to-Micro
  26. 26. Relations (Sequel) class User < Sequel::Model(:users) one_to_many :micros do |ds| ds.filter(:parent_id => nil) end one_to_many :subs, :extend => UserFindOrCreate many_to_many :publishers, :class => :User, :join_table => :subs end
  27. 27. Ruby XMPP Libraries • xmpp4r - Roster, vCard etc. • xmpp4r-simple - easy to use • jabber4r - Thread based :(
  28. 28. XMPP Bot • http://tr.im/emxmpp (nutrun.com) • EventMachine - libevent, Deferrable • Plugins - http://tr.im/modular
  29. 29. Concurrency EM.run do EM::PeriodicTimer.new(1) do ... EM.spawn do worker = Worker.new worker.callback {jabber.deliver(message.from, quot;Donequot;)} worker.process end.notify ... end end class Worker include EM::Deferrable def process ... set_deferred_status :succeeded end end
  30. 30. Plugins 1/3 PluginFactory.load quot;pluginsquot; ... def PluginFactory.load( dirname ) Dir.open( dirname ).each do |fn| next unless ( fn =~ /[.]rb$/ ) require quot;#{dirname}/#{fn}quot; end end
  31. 31. Plugins 2/3 class Plugin include EM::Deferrable def process( args = {} ) sleep(0.05) set_deferred_status :succeeded end end
  32. 32. Plugins 3/3 class NickPlugin < Plugin def process(args = {}) begin ... set_deferred_status :succeeded rescue set_deferred_status :failed end end end class NickFactory < PluginFactory INFO=<<INFO verb: NICK author: Stoyan Zhekov description: Get or set the nickname for some user INFO def create() return NickPlugin.new() end end
  33. 33. Simple API (json) • /users - list of users • /user/<nick>/<secret> - info for user • /status/<nick>/<secret> - presence • /micros/<page>/<format> - list of micros • /micro/<id>/<secret> - micro + comments
  34. 34. Web (Ramaze) class MainController < Ramaze::Controller def u nick begin @user = User.find_by_user(nick) subset = @user.micros.reverse @micros, @pager = paginate(subset, :limit => PAGE) rescue Exception => e flash[:error] = quot;Error: #{e.to_s}quot; redirect :/, :status => 302 end end end
  35. 35. <Demo>
  36. 36. To Do • Commands parser - Ragel? • OAuth or http://xmppid.net/ • TokyoCabinet • XMPP Component - http://github.com/julien51/babylon • Real PubSub?
  37. 37. Conclusion • XMPP - good, open protocol • xmpp4r-simple - good, easy to use • eventmachine - good network library • sequel - good ORM • ramaze - good web apps framework
  38. 38. Questions?
  39. 39. </stream:stream>
