Creating ResponsiveHTML5 TouchInterfacesStephen Woods
Stephen WoodsFront End Engineer       Flickr
On the desktop weworry about browsers-moz-transform:rotate(-270deg);-moz-transform-origin: bottom left;-webkit-transform: ...
On mobile we worryabout devices.
ScreenSizesMedia Queries,Break points,liquid layoutshttp://www.alistapart.com/articles/responsive-web-design/
iPhone 3GS 256mb RAMGeekbench: 271
iPhone 3GS 256mb RAMGeekbench: 271      ==
Modern mobiledevices are crappy  computers withdecent video cards.
PerceivedPerformance
On the desktop it’seasy...  Throw up a spinner.
Touch interfaces aretactile.
Touch interfaces aretactile.   Feedback must be        continuous.
When the interface  stops movingduring a gesture it feels like it died
Respect Convention
Mobile hasconventionstoo
Mobile hasconventionstoo
TouchEvent• touchstart - fires once• touchmove - fires continuously• touchend - fires once
The touches Array• You only get one on Android• You get up to 11 on iOS• Each touch gives you position  information, and s...
iOS Gesture Events• gesturestart• gesturechange• gestureend
iOS Developer      Libraryhttp://bit.ly/iOS-guide
Making Gestures Work • Prioritize user feedback • Use hardware acceleration • Manage your memory
Prioritize User-feedback• Don’t do any loading during gestures• Treat the DOM as write-only (do your  own math)• When at a...
Write-Only DOM• DOM touches are really expensive• You know where everything is• Use matrix transforms to queue up  positions
Swipe Basicsdistance = e.touches[0].pageX - startX;translate3d(+distance+px,0px,0px)
Snap back/snap      forward• Keep track of last position, use  transitions with easing to snap back• Pick a swipe distance...
A Word about scrolling• Use native if at all possible:• -webkit-overflow-scrolling:      touch;• If not, use a library to ...
Image © Brian LalorUsed with permission   Pinch to Zoom   (there will be math)
Why you can’t use native Pinch to      Zoom
First:Use Matrix TransformsMinimize DOM touches, make your transformssimpler in the long run
http://xkcd.com/184/
It’s Not That Hard!transform:          Translatematrix(1, 0, 0, 1, 10, 10);         Scale
With HardwareAcceleration... (matrix3d)            [                [1,0,0,0],                [0,1,0,0],                [0...
Transforms keep  complex statewithout DOM reads
What is happening?• Determine Center of the touch points• Determine the scale factor  (touch.scale)• Scale the element by ...
The Naive Example
The Naive Example
The Naive Example
The Right Example
The Right Example
The Right Example
Breakdown
Breakdown
Breakdown
Breakdown
translateX =scalePointX * (newWidth - oldWidth)            newWidth;
Pro Tips• Beware the virtual pixels• Moving the transform-origin won’t  really work• Remember to snap back
The Flickr Touch   Light Box
UntitledBy protohiro
UntitledBy protohiro
UntitledBy protohiro
UntitledBy protohiro
Swiping Process• Event Listener on top level for touch  events• Only visible nodes move via  translate3d• Rebuild next/pre...
Performance Tricks• Aggressive Pruning• Clean off css transforms/transitions• Write-only DOM.• Do as little as possible du...
Frustrating         Limitations• Retina screen is huge, device  memory is small• Hardware acceleration is a crash  festiva...
Stephen Woods                                  @ysawImage Credits (http://flic.kr/y/kQ5cLh)http://www.flickr.com/photos/wafe...
Creating Responsive HTML5 Touch Interfaces
Creating Responsive HTML5 Touch Interfaces
Creating Responsive HTML5 Touch Interfaces
Upcoming SlideShare
Loading in...5
×

Creating Responsive HTML5 Touch Interfaces

28,977

Published on

Published in: Technology
0 Comments
52 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
28,977
On Slideshare
0
From Embeds
0
Number of Embeds
2
Actions
Shares
0
Downloads
369
Comments
0
Likes
52
Embeds 0
No embeds

No notes for slide
  • \n
  • I built the mobile lightbox (on a great backbone from the flickr FE team)\n
  • The flickr mobile lightbox. Swiping, zooming, pretty smooth, very natural for the device.\nI’m going to talk about how we made it, but I am going to talk a lot of concepts that came out of the work first\n
  • \n
  • They all run webkit, they all have css3, transforms, etc.\nYou’ll have to do a lot of testing on screen sizes of course...but..\n
  • People have covered this topic very well elsewhere\n
  • \n
  • \n
  • \n
  • but this is going to change...\n
  • An awesome experience is possible.\n
  • \n
  • \n
  • Remember the teleporter control in stng? It had a control like in the original series, but touch\nIt needs to feel right, that means immediate feedback is continuous, rather than momentary.\n
  • The rational for snap back and momentum scroll (always give feedback)\n\n
  • We all know the conventions of desktop software\nMost people respect it when building interfaces\n
  • Slide to unlock, swipe to go forward and back, pinch to zoom, tap and hold\ni) don't break what users expect: swipes & Pinches\nexample: user reaction to m.flickr lack of pinch zoom\n
  • \n
  • Ice cream sandwich caveat noted.\nI don’t know what the eleventh touch point is for\n
  • Considered harmful, Don’t waste your time with this crap, just do the math, its way easier than forking\n
  • Best reference in the universe for this\n
  • \n
  • DOM reads aren’t free, most JS-dom stuff is blocking\nMinimize writes as well of course, but that is obvious when you just do the math your self\n
  • Don’t be insecure, math is math, no need to keep checking positions\nMore on matrices later. Remember reads aren’t free, don’t do them\n
  • use average of multiple touches if you want it to be multi-finger swipe\nYou probably shouldn’t override os gestures\nprioritize user feedback! When the user is swiping you are doing nothing else\nsnapback, snap forward. Just keep track of the place to snap back to and go there\n
  • (native uses physics, generally unecessary)\n\n
  • limitation of -webkit-overflow-scrolling: it bounces the whole page!\n
  • \n
  • You have ZERO control. Your interface elements are going to slide all over and resize\nYou could try position:fixed, but what about touch points? Font size? \nOk, you can work around all that, but that is going to be a hassle, especially when you consider\nthat pinch zoom isn’t that complex\n
  • If you have multiple transforms to apply, you can apply them to the matrix and combine the changes into one DOM write\nNot as scary as it looks\n
  • The cartoon everyone uses for this\nMatrix is a transformation applied to the vector representing the position\nYeah, you don’t really need to understand that for anything I’m talking about here, because we aren’t rotating, shearing, anything like that\n\n
  • This is the 2d\n
  • The 1s are the scale, the ts are translation. For pinch zoom (without rotation)\nTHIS IS ALL WE NEED TO KEEP TRACK OF STATE\n
  • \n
  • \n
  • Just apply the scale property to the scale transform of the element\nBreaks the convention. \nIt should feel like the user is stretching the image, not turning a dial\n
  • Just apply the scale property to the scale transform of the element\nBreaks the convention. \nIt should feel like the user is stretching the image, not turning a dial\n
  • Just apply the scale property to the scale transform of the element\nBreaks the convention. \nIt should feel like the user is stretching the image, not turning a dial\n
  • Just apply the scale property to the scale transform of the element\nBreaks the convention. \nIt should feel like the user is stretching the image, not turning a dial\n
  • Just apply the scale property to the scale transform of the element\nBreaks the convention. \nIt should feel like the user is stretching the image, not turning a dial\n
  • Just apply the scale property to the scale transform of the element\nBreaks the convention. \nIt should feel like the user is stretching the image, not turning a dial\n
  • Just apply the scale property to the scale transform of the element\nBreaks the convention. \nIt should feel like the user is stretching the image, not turning a dial\n
  • The touch center point is the point from which the object scales\n
  • The touch center point is the point from which the object scales\n
  • The touch center point is the point from which the object scales\n
  • The touch center point is the point from which the object scales\n
  • The touch center point is the point from which the object scales\n
  • The touch center point is the point from which the object scales\n
  • The touch center point is the point from which the object scales\n
  • The touch center point is the point from which the object scales\n
  • The touch center point is the point from which the object scales\nWith the magic of matrix transforms we can apply both at the same time\n
  • The touch center point is the point from which the object scales\nWith the magic of matrix transforms we can apply both at the same time\n
  • The touch center point is the point from which the object scales\nWith the magic of matrix transforms we can apply both at the same time\n
  • The touch center point is the point from which the object scales\nWith the magic of matrix transforms we can apply both at the same time\n
  • The touch center point is the point from which the object scales\nWith the magic of matrix transforms we can apply both at the same time\n
  • The touch center point is the point from which the object scales\nWith the magic of matrix transforms we can apply both at the same time\n
  • The touch center point is the point from which the object scales\nWith the magic of matrix transforms we can apply both at the same time\n
  • The touch center point is the point from which the object scales\nWith the magic of matrix transforms we can apply both at the same time\n
  • Scale point x is relative to object left, not page\n
  • transform origin will suffer from rounding errors caused by hiDPI virtual pixels\n
  • \n
  • \n
  • \n
  • DOM Layout is very simple. When the lightbox first opens we create three nodes (in addition to the interface, which is also simple) The DOM is also blanked to clear up memory space.\nImages are DIVs\n
  • \n
  • Remember the 256mb of memory!\nNo loading, no calculations during swipes. And no fancy business between event handler and transform,\n that is a critical performance point\n
  • You can’t use a big enough image to really benefit from pinch/zoom (subsampling of large images means they get scaled down)\nHardware accelerated stuff does not seem to manage memory very gracefully\n
