Introduction to Dojo Yoav Rubin, IBM Research – Haifa, yoav@il.ibm.com
What is Dojo <ul><li>A toolkit that enables the creation of modern web applications </li></ul><ul><li>An open source proje...
What is Dojo built of <ul><li>Core </li></ul><ul><ul><li>Basic libraries: Ajax , events, DOM querying, animation, dnd, i18...
Dojo core
<ul><li>“ In theory there is no difference between theory and practice. In practice there is” </li></ul><ul><li>Yogi Berra...
DOM buffering <ul><li>The DOM is the internal representation of the page within the browser </li></ul><ul><ul><li>Can be m...
CSS engine buffering <ul><li>CSS allows the developer to set how things are presented on the browser </li></ul><ul><ul><li...
Enhancements to core JavaScript <ul><li>Handling arrays </li></ul><ul><ul><li>dojo.forEach, dojo.some, dojo.every, dojo.fi...

Name spaces <ul><li>A name space is an “region” in the product/ project </li></ul><ul><li>Dojo allows developers to define...
Name spaces – using a name space <ul><li>Create a resource:  </li></ul><ul><ul><li>dojo.provide(“MySotware.MyClass”) </li>...
Communication  <ul><li>The three layers of communication in a web application: </li></ul><ul><ul><li>Within the client sid...
Client side communication: point to point <ul><li>Each method invocation of each object can be  listened by another object...
Client side communication: publish/subscribe <ul><li>Topic – object can broadcast a topic  </li></ul><ul><ul><li>alongside...
Client - server communication  <ul><li>Contact your server </li></ul><ul><ul><ul><ul><li>dojo.{xhrGet, xhrPut, xhrPost, xh...
Objects – OO and manipulation <ul><li>Simulating class declaration using  dojo.declare </li></ul><ul><ul><li>You need to p...
A few more goodies  <ul><li>Internationalization – using a resource bundle based on the locale </li></ul><ul><li>Localizat...
Dijit
What is dijit <ul><li>The dojo component that is responsible for handling widgets </li></ul><ul><li>Fully accessible </li>...
What is a widget <ul><li>A widget is an object, that contains not just logic, but also a way to be presented on the screen...
Using widgets <ul><li>Declarative - using widgets in the markup </li></ul><ul><li><button  dojoType =“dijit.form.Button”><...
General widgets <ul><li>General purpose widgets that are used to make a web page more “application-like”  </li></ul><ul><l...
Layout widgets <ul><li>A layout widget is a widget that contains other widgets and defines how they will be placed on the ...
Form widgets <ul><li>Form widgets are widgets that are used to get input from users, usually as part of a web form </li></...
What makes a widget <ul><li>A widget is composed of two resources </li></ul><ul><ul><li>A .js file that contains the logic...
What makes a widget – cont. <ul><li>Dojo allows the template and the widget’s object to interact </li></ul><ul><ul><li>By ...
<div>  <table> <tbody> <tr> <td dojoAttachPoint=“v1”>….</td> <td dojoAttachEvent=“onclick:a”></td> </tr> <tbody> </table> ...
Widget’s lifecycle <ul><li>Widgets have a predefined lifecycle – from creation to destruction </li></ul><ul><li>The develo...
Themes  <ul><li>A theme is a general look to a page </li></ul><ul><li>Several themes are defined in dijit </li></ul><ul><l...
Themes - tundra
Themes – Soria
Themes - Nihilo
dojoX
What is dojoX <ul><li>The experimental part of dojo </li></ul><ul><li>Many projects are included within it (~50) </li></ul...
What is included in dojox <ul><li>Many widgets – general, form and layout </li></ul><ul><li>Syntax highlighting </li></ul>...
How to use dojo <ul><li>Download it  </li></ul><ul><ul><li>http:// www.dojotoolkit.org /   </li></ul></ul><ul><li>Place it...
More info <ul><li>http:// www.dojotoolkit.org /   </li></ul><ul><li>http:// dojocampus.org /   </li></ul><ul><li>There are...
Questions?
