Apache Hadoop India Summit 2011 talk "Searching Information Inside Hadoop Platform" by Abinasha Karana

  1. 1. Searching Information Inside Hadoop Platform Abinasha KaranaDirector-TechnologyBizosys Technologies Pvt Ltd.abinash@bizosys.comwww.bizosys.com<br />
  2. 2. To search a large dataset inside HDFS and HBase, <br />At Bizosys we started with Map-Reduce and Lucene/Solr<br />
  3. 3. Map-reduce<br />What didn’t work for us<br />Result not in a mouse click<br />
  4. 4. It required vertical scaling with manual sharding and subsequent resharding as data grew<br />Lucene/Solr<br />What didn’t work for us<br />
  5. 5. We built a new search forHadoop Platform <br />HDFS and HBase<br />What we did<br />
  6. 6. In the next few slides you will hear about<br />my learning from designing, developing and benchmarking a distributed, real-time search engine whose Index is stored and served out of HBase<br />
  7. 7. Key Learning<br />Using SSD is a design decision.<br />Methods to reduce HBase table storage size <br />Serving a request without accessing ALL region servers<br />Methods to move processing near the data<br />Byte block caching to lower network and I/O trips to HBase<br />Configuration to balance network vs. CPU vs. I/O vs memory <br />
  8. 8. Using SSD is a design decision<br />1<br />SSD improved HSearch response time by 66% over SATA.However, SSD is costlier. <br />In HBase Table Schema Design we considered “Data Access Frequency”, “Data Size” and “Desired Response Time” for selective SSD deployment.<br />
  9. 9. .. Our SSD Friendly Schema Design<br />Keyword:Reads all for a query.<br />Document: Reads 10 docs / query.<br />Keyword + Document in 1 Table<br />Keyword + Document in 2 Tables<br />SSD deployment is All or none<br />SSD deployment is only for Keyword Table<br />
  10. 10. Key length<br />Value length<br />Row length<br />Row Bytes<br />Family Length<br />Family Bytes<br />Qualifier Bytes<br />Timestamp<br />Key Type <br />Value Bytes<br />4 BYTES<br />1 BYTE<br />4 BYTES<br />4 BYTES<br />2 BYTES<br />BYTES<br />1 BYTE<br />BYTES<br />8 BYTES<br />BYTES<br />2<br />Methods to reduceHBase table storage size<br />Storing a 4 byte cell requires >27bytes in HBase. <br />
  11. 11. .. to 1/3rd<br />Stored large cell values by merging cells<br />Reduced the Family name to 1 Character<br />Reduced the Qualifier name to 1 Character<br />
  12. 12. Serving a request without accessing ALL region servers<br />3<br />Consider a 100 node cluster of HBase and a single search request need to access all of them.<br />Bad Design.. <br />Clogged Network.. <br />No scaling<br />
  13. 13. Index Table was divided on Column-Family as separate tables<br />Scan Table A - 3 Machines Hit <br />Table B<br />Table A<br />Machine 5<br />Machine 4<br />Machine 5<br />4-5 M<br />Machine 3<br />Machine 3<br /><br />Machine 4<br />3-4 M<br />Machine 2<br />Row Ranges<br />2-3 M<br />Machine 3<br />Machine 1<br />1-2 M<br />Machine 2<br />0-1 M<br />Machine 1<br />3<br />And our solution…<br />Scan “Family A” - 5 Machines Hit<br />Family A<br />Family B<br />
  14. 14. Methods to move processing near the data<br />4<br /><ul><li>Sent filtered Rows over network. </li></ul>public class TermFilter implements Filter {<br />public ReturnCode filterKeyValue(KeyValue kv) {<br /> boolean isMatched = isFound(kv);<br /> if (isMatched ) return ReturnCode.INCLUDE;<br /> return ReturnCode.NEXT_ROW;<br />}<br />…<br />E.g. Matched rows for a keyword<br /><ul><li>Sent relevant Fields of a Row over network.
  15. 15. Sent relevant section of a Field over network.</li></ul>public class DocFilter implements Filter {<br />public void filterRow(List<KeyValue> kvL) {<br /> byte[] val = extractNeededPiece(kvL);<br /> kvL.clear();<br /> kvL.add(new KeyValue(row,fam,,val));<br />}<br />….<br />E.g. Computing a best match section from within a document for a given query<br />
  16. 16. Byte block caching to lower network and I/O trips to HBase<br />5<br />Object caching – With growing number of objects we encountered ‘Out of Memory’ exception<br />HBase commit - Frequent flushing to HBase introduced network and I/O latencies.<br /><br />Converting Objects to intermediate Byte Blocks increased record processing by 20x in 1 batch.<br />
  17. 17. Configuration to balance Network vs. CPU vs. I/O vs. Memory <br />6<br />Disk<br />I/O<br />Block Caching<br />Compression<br />Memory<br />CPU<br />Aggressive GC<br />Network<br />IPC Caching<br />Compression<br />In a Single Machine<br />
  18. 18. … and it’s settings<br />Network<br />Increased IPC Cache Limits (hbase.client.scanner.caching)<br />CPU<br />JVM agressive heap ("-server -XX:+UseParallelGC -XX:ParallelGCThreads=4 XX:+AggressiveHeap “)<br />I/O<br />LZO index compression (“Inbuilt oberhumer LZO” or “Intel IPP native LZO”)<br />Memory<br />HBase block caching (hfile.block.cache.size) and overall memory allocation for data-node and region-server.<br />
  19. 19. .. and parallelized to multi-machines<br /><ul><li>HTable.batch (Get, Put, Deletes)
  20. 20. ParallelHTable (Scans)
  21. 21. FUTURE-coprocessors (hbase 0.92 release).</li></ul>Allocating appropriate resources dfs.datanode.max.xcievers, hbase.regionserver.handler.count and dfs.datanode.handler.count<br />
  22. 22. HSearch Benchmarks on AWS<br />Amazon Large instance 7.5 GB Memory * 11 Machines with a single 7.5K SATA drive<br />100 Million Wikipedia pages of total 270GB and completely indexed (Included common stopwords)  <br />10 Million pages repeated 10 times. (Total indexing time is 5 Hours)<br />Search Query Response speed using a <br />regular word is 1.5 sec<br />common word such as “hill” found 1.6 million matches and sorted in 7 seconds<br />
  23. 23. www.sourceforge.net/bizosyshsearch<br />Apache-licensed (2 versions released)<br />Distributed, real-time search<br />Supports XML documents with rich search syntax and various filtration criteria such as document type, field type.<br />
  24. 24. References<br />Initial performance reports (Bizosys HSearch, a Nosql search engine, featured in Intel Cloud Builders Success Stories (July, 2010)<br />HSearch is currently in use at http://www.10screens.com<br />More on hsearch<br />http://www.bizosys.com/blog/<br />http://bizosyshsearch.sourceforge.net/<br />More on SSD Product Technical Specifications http://download.intel.com/design/flash/nand/extreme/extreme-sata-ssd-product-brief.pdf<br />

×
