    • 1. Exact Inference in Bayesian Networks using MapReduce
      Alex Kozlov
      Cloudera, Inc.
    • 2. About Me
      About Cloudera
      Bayesian (Probabilistic) Networks
      BN Inference 101
      CPCS Network
      Why BN Inference
      Inference with MR
      Results
      Conclusions
      2
      Session Agenda
    • 3. Worked on BN Inference in 1995-1998 (for Ph.D.)
      Published the fastest implementation at the time
      Worked on DM/BI field since then
      Recently joined Cloudera, Inc.
      Started looking at how to solve world’s hardest problems
      3
      About Me
    • 4. Founded in the summer 2008
      Cloudera helps organizations profit from all of their data. We deliver the industry-standard platform which consolidates, stores and processes any kind of data, from any source, at scale. We make it possible to do more powerful analysis of more kinds of data, at scale, than ever before. With Cloudera, you get better insight into their customers, partners, vendors and businesses.
      Cloudera’s platform is built on the popular open source Apache Hadoop project. We deliver the innovative work of a global community of contributors in a package that makes it easy for anyone to put the power of Google, Facebook and Yahoo! to work on their own problems.
      4
      About Cloudera
    • 5. Nodes
      Edges
      Probabilities
      5
      Bayesian Networks
      Bayes, Thomas (1763)
      An essay towards solving a problem in the doctrine of chances, published posthumously by his friend
      Philosophical Transactions of the Royal Society of London, 53:370-418
    • 6. Computational biology and bioinformatics (gene regulatory networks, protein structure, gene expression analysis)
      Medicine
      Document classification, information retrieval
      Image processing
      Data fusion
      Gaming
      Law
      On-line advertising!
      6
      Applications
    • 7. 7
      A Simple BN Network
      T
      F
      Rain
      Rain
      T
      F
      0.4
      0.6
      F
      0.2
      0.8
      0.1
      0.9
      T
      Sprinkler
      Sprinkler, Rain
      T
      F
      0.01
      0.99
      F, F
      0.8
      0.2
      F, T
      Wet Driveway
      0.9
      0.1
      T, F
      0.99
      0.01
      T, T
      Pr(Rain | Wet Driveway)
      Pr(Sprinkler Broken | !Wet Driveway & !Rain)
    • 8. 8
      Asia Network
      Pr(Visit to Asia)
      Pr(Smoking)
      Pr(Lung Cancer | Smoking)
      Pr(Tuberculosis | Visit to Asia)
      Pr(Bronchitis | Smoking)
      Pr(C | BE )
      Pr(X-Ray | Lung Cancer or Tuberculosis)
      Pr(Dyspnea | CG )
      Pr(Lung Cancer | Neg X-Ray & Positive Dyspnea)
    • 9. JPD = <product of all probabilities and conditional probabilities in the network> = Pr(A, B, …, H)
      PAB =
      SELECT A, B, SUM(PROB) FROM JPD GROUP BY A, B;
      PB = SELECT B, SUM(PROB) FROM PAB GROUP BY A;
      Pr(A|B) = Pr(A,B)/Pr(B) – Bayes’ rule
      CPCS is 422 nodes, a table of at least 2422 rows!
      9
      BN Inference 101 (in Hive)
    • 10. 10
      Junction Tree
      Pr(E | F )
      Pr(Tuberculosis | Visit to Asia)
      Pr(G | F )
      AB
      EFG
      Pr(Visit to Asia)
      Pr(F)
      B
      Pr(C | BE )
      EG
      Pr(H | CG )
      BCE
      CE
      CEGH
      C
      Pr(Lung Cancer | Dyspnea) =
      Pr(E|H)
      CD
      Pr(D| C)
    • 11. 11
      CPCS Networks
      422 nodes
      14 nodes describe diseases
      33 risk factors
      375 various findings related to diseases
    • 12. 12
      CPCS Networks
    • 13. Choose the right tool for the right job!
      • BN is an abstraction for reasoning and decision making
      • 14. Easy to incorporate human insight and intuitions
      • 15. Very general, no specific ‘label’ node
      • 16. Easy to do ‘what-if’, strength of influence, value of information, analysis
      • 17. Immune to Gaussian assumptions
      It’s all just a joint probability distribution
      13
      Why Bayesian Network Inference?
    • 18. Map & Reduces
      14
      B1C1E1
      Keys
      Map
      B1C1E2
      A1B1
      B1
      Reduce
      B1C2E1
      A2B1
      B1C2E2
      A1B2
      B2C1E1
      ∑ Pr(B1| A) x ∑ Pr(D| C1)
      B2
      B2C1E2
      A2B2
      B2C2E1
      B2C2E2
      Pr(C| BE) x ∑ Pr(B1| A) x ∑ Pr(D| C1)
      Aggregation 2 (x)
      B1C1E1
      B1C1E2
      C1D1
      B1C2E1
      C1
      Aggregation 1 (+)
      C2D1
      B1C2E2
      C1D2
      B2C1E1
      B2C1E2
      C2
      BCE
      C2D2
      B2C2E1
      B2C2E2
    • 19. for each clique in depth-first order:
      MAP:
      Sum over the variables to get ‘clique message’ (requires state, custom partitioner and input format)
      Emit factors for the next clique
      REDUCE:
      Multiply the factors from all children
      Include probabilities assigned to the clique
      Form the new clique values
      the MAP is done over all child cliques
      15
      MapReduce Implementation
    • 20.
      • Topological parallelism: compute branches C2 and C4 in parallel
      • 21. Clique parallelism: divide computation of each clique into maps/reducers
      • 22. Fall back into optimal factoring if a corresponding subtree is small
      • 23. Combine multiple phases together
      • 24. Reduce replication level
      16
      Cliques, Trees, and Parallelism
      C6
      C5
      C4
      C3
      C2
      C1
      Cliques may be larger than they appear!
    • 25. CPCS:
      The 360-node subnet has the largest ‘clique’ of
      11,739,896 floats (fits into 2GB)
      The full 422-node version (absent, mild, moderate, severe)
      3,377,699,720,527,872 floats (or 12 PB of storage, but do not need it for all queries)
      In most cases do not need to do inference on the full network
      17
      CPCS Inference
    • 26. 1‘used an SGI Origin 2000 machine with sixteen MIPS R10000 processors (195 MHz clock speed)’ in 1997
      2Macbook Pro 4 GB DDR3 2.53 GHz
      310 node Linux Xeon cluster 24 GB quad 2-core
      18
      Results
    • 27. Exact probabilistic inference is finally in sight for the full 422 node CPCS network
      Hadoop helps to solve the world’s hardest problems
      What you should know after this talk
      BN is a DAG and represents a joint probability distribution (JPD)
      Can compute conditional probabilities by multiplying and summing JPD
      For large networks, this may be PBytes of intermediate data, but it’s MR
      19
      Conclusions
    • 28. Questions?
      alexvk@{cloudera,gmail}.com
    • 29. BACKUP
      21
    • 30. Conditioning nodes (evidence) – do not need to be summed
      Bare child nodes’ values sum to one (barren node) – can be dropped from the network
      22
      Optimizing BN Inference 101
      Noisy-OR (conditional independence of parents)
      Context specific independence (based on the specific value of one of the parents)
      T
      F
      0.01
      0.99
      FF
      0.8
      0.2
      FT
      Wet grass
      0.9
      0.1
      TF
      0.99
      0.01
      TT
    • 31. 23
      GeNIe package
    • 32. No updates – have to compute clique potentials from all children and assigned probabilities
      Tree structure
      The key encodes full set of variable values (LongWritable or composite)
      The value encodes partial sums (proportional to probabilities)
      No need for TotalOrderPartitioning (we know the key distribution)
      Need custom Partitioner and WritableComparator (next slide)
      Need to do the aggregation in the Mapper (sum, next slide)
      24
      MapReduce Implementation
    • 33. Build on top of old 1997 C program with a few modifications
      An interactive command line program for interactive analysis
      Estimates running time from optimal factory plan and
      Either executes it locally
      Ships a jar to a Hadoop cluster to execute
      25
