NUMA and Virtualization, the case of Xen Dario Faggioli, dario.faggioli@citrix.comAugust 27-28, 2012,          Dario Faggi...
NUMA and Virt. And XenTalk outline:      ●   What is NUMA            –   NUMA and Virtualization            –   NUMA and X...
NUMA and Virt. And XenTalk outline:      ●   What is NUMA            –   NUMA and Virtualization            –   NUMA and X...
What is NUMA ●   Non-Uniform Memory Access: it will take longer                          Access     to access some regions...
What is NUMA                                     ●   Groups of processors                                         (NUMA no...
What is NUMASince:      ●   (most of) memory is                       NODE      NODE          allocated at task          s...
NUMA and VirtualizationShort lived tasks are just fine... But whatabout VMs?                      NODE                   N...
NUMA and XenXen allocates memory from all the nodeswhere the VM is allowed to run (when created)                       NOD...
NUMA and XenXen allocates memory from all the nodeswhere the VM is allowed to run (when created)            NODE       NOD...
NUMA and XenXen allocates memory from all the nodeswhere the VM is allowed to run (when created)How to specify that?vCPU p...
NUMA and Virt. And XenTalk outline:      ●   What is NUMA            –   NUMA and Virtualization            –   NUMA and X...
Automatic Placement 1.What happens on the left is better than   what happens on the right        NODE              NODE   ...
Automatic Placement 2.What happens on the left can be avoided:   look at what happens on the right        NODE            ...
Automatic Placement                                            1.VM1 creation        NODE              NODE               ...
NUMA Aware SchedulingNice, but using pinning has a majordrawback:                           NODE                   NODE   ...
NUMA Aware SchedulingDont use pinning, tell the scheduler wherea VM prefers to run (node affinity)                        ...
Experimental ResultsTrying to verify the performances of: ●   Automatic placement (pinning) ●   NUMA aware scheduling     ...
Testing Placement                       (thanks to Andre Przywara from AMD) ●   Host: AMD Opteron(TM) 6276,     64 cores, ...
Some Traces about             NUMA Aware SchedulingAugust 27-28, 2012,        Dario Faggioli,San Diego, CA, USA    dario.f...
Benchmarking Pinning and           NUMA Aware Scheduling ●   Host: Intel Xeon(R) E5620, 16 cores, 12 GB RAM,     2 NUMA no...
Benchmarking Pinning and           NUMA Aware Scheduling1 vCPU per VM:                       20% to 16% improvement!August...
Benchmarking Pinning and           NUMA Aware Scheduling2 vCPUs per VM:                         17% to 13% improvement!Aug...
Benchmarking Pinning and           NUMA Aware Scheduling4 vCPUs per VM:                                                   ...
Some Traces about             NUMA Aware SchedulingAugust 27-28, 2012,        Dario Faggioli,San Diego, CA, USA    dario.f...
Some Traces about             NUMA Aware SchedulingAugust 27-28, 2012,        Dario Faggioli,San Diego, CA, USA    dario.f...
NUMA and Virt. And XenTalk outline:      ●   What is NUMA            –   NUMA and Virtualization            –   NUMA and X...
Lots of Room for                  Further Improvement!Tracking ideas, people and progress on  http://wiki.xen.org/wiki/Xen...
Dynamic Memory                         MigrationIf VM2 goes away, it would be nice if wecould change VM1s (or VM3s) node a...
IO NUMADifferent devices can be attached todifferent nodes: needs to be considered duringplacement / schedulingAugust 27-2...
Guest NUMAIf a VM is bigger than 1 node, should it know?NODE                  NODE            NODE                        ...
Ballooning and SharingBallooning should be                        Sharing, should weNUMA aware                            ...
Inter-VM Dependences Are we sure the situation on the right is always better? Might it be workload dependant (VM cooperati...
Benchmarking and             Performances EvaluationHow to verify we are actually improving: ●   What kind of workload(s)?...
NUMA and Virt. And XenTalk outline:      ●   What is NUMA            –   NUMA and Virtualization            –   NUMA and X...
Thanks!                      Any Questions?August 27-28, 2012,           Dario Faggioli,San Diego, CA, USA       dario.fag...
Upcoming SlideShare
Loading in...5
×

NUMA and Virtualization, the case of Xen

6,671

Published on

Published in: Technology
2 Comments
4 Likes
Statistics
Notes
No Downloads
Views
Total Views
6,671
On Slideshare
0
From Embeds
0
Number of Embeds
9
Actions
Shares
0
Downloads
101
Comments
2
Likes
4
Embeds 0
No embeds

No notes for slide

Transcript of "NUMA and Virtualization, the case of Xen"

  1. 1. NUMA and Virtualization, the case of Xen Dario Faggioli, dario.faggioli@citrix.comAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  2. 2. NUMA and Virt. And XenTalk outline: ● What is NUMA – NUMA and Virtualization – NUMA and Xen ● What I have done in Xen about NUMA ● What remains to be done in Xen about NUMAAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  3. 3. NUMA and Virt. And XenTalk outline: ● What is NUMA – NUMA and Virtualization – NUMA and Xen ● What I have done in Xen about NUMA ● What remains to be done in Xen about NUMAAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  4. 4. What is NUMA ● Non-Uniform Memory Access: it will take longer Access to access some regions of memory than others ● Designed to improve scalability on large SMPs ● Bottleneck: contention on the shared memory busAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  5. 5. What is NUMA ● Groups of processors (NUMA node) have their own local memory ● Any processor can access any memory, including the one not "owned" by its group (remote memory) ● Non-uniform: accessing local memory is faster than accessing remote memoryAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  6. 6. What is NUMASince: ● (most of) memory is NODE NODE allocated at task startup, CPUs CPUs task A task A ● tasks are (usually) free to run on any processorBoth local and remote mem Aaccesses can happenduring tasks life MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  7. 7. NUMA and VirtualizationShort lived tasks are just fine... But whatabout VMs? NODE NODE CPUs CPUs VM2 VM1 VM1 mem VM1 FOREVER!! mem VM2 MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  8. 8. NUMA and XenXen allocates memory from all the nodeswhere the VM is allowed to run (when created) NODE NODE CPUs CPUs VM2 VM1 VM1 mem mem VM1 VM1 mem mem VM2 VM2 MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  9. 9. NUMA and XenXen allocates memory from all the nodeswhere the VM is allowed to run (when created) NODE NODE NODE NODE CPUs CPUs CPUs CPUs VM2 VM1 mem mem VM1 VM1 mem mem VM2 VM2 MEM MEM MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  10. 10. NUMA and XenXen allocates memory from all the nodeswhere the VM is allowed to run (when created)How to specify that?vCPU pinning during VM creation (e.g., in the VMconfig file)August 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  11. 11. NUMA and Virt. And XenTalk outline: ● What is NUMA – NUMA and Virtualization – NUMA and Xen ● What I have done in Xen about NUMA ● What remains to be done in Xen about NUMAAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  12. 12. Automatic Placement 1.What happens on the left is better than what happens on the right NODE NODE NODE NODE CPUs CPUs CPUs CPUs VM1 VM1 mem mem mem VM1 VM1 VM1 MEM MEM MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  13. 13. Automatic Placement 2.What happens on the left can be avoided: look at what happens on the right NODE NODE NODE NODE CPUs CPUs CPUs CPUs VM2 VM1 VM1 VM2 mem mem mem VM1 VM1 VM2 mem VM2 MEM MEM MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  14. 14. Automatic Placement 1.VM1 creation NODE NODE time: pin VM1 to the CPUs CPUs first node VM1 VM2 2.VM2 creation time: pin VM2 to the mem mem VM1 VM2 second node, as first one already has another VM pinned to This now happens MEM MEM it Automatically within libxlAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  15. 15. NUMA Aware SchedulingNice, but using pinning has a majordrawback: NODE NODE CPUs CPUs VM3 VM1 VM2 VM1 mem mem When VM1 is back, VM1 VM2 It has to wait, even if There are idle CPUs! mem VM3 MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  16. 16. NUMA Aware SchedulingDont use pinning, tell the scheduler wherea VM prefers to run (node affinity) NODE NODE CPUs CPUs Now VM1 can run immediately: VM3 VM1 VM1 VM2 remote accesses Are better than not Patches almost running at all! mem mem ready (targeting VM1 VM2 Xen 4.3) mem VM3 MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  17. 17. Experimental ResultsTrying to verify the performances of: ● Automatic placement (pinning) ● NUMA aware scheduling (automatic placement + node affinity)August 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  18. 18. Testing Placement (thanks to Andre Przywara from AMD) ● Host: AMD Opteron(TM) 6276, 64 cores, 128 GB RAM, 8 NUMA nodes ● VMs: 1 to 49, 2 vCPUs, 2GB RAM each. nr. vCPUs Node 14 0 12 1 12 2 12 3 12 4 12 5 12 6 12 7August 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  19. 19. Some Traces about NUMA Aware SchedulingAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  20. 20. Benchmarking Pinning and NUMA Aware Scheduling ● Host: Intel Xeon(R) E5620, 16 cores, 12 GB RAM, 2 NUMA nodes ● VMs: 2, 4, 6, 8 and 10 of them, 960MB RAM. Different experiments with 1, 2 and 4 vCPUs per VM ➔ SPECjbb2005 executed concurrently in all VMs ➔ 3 configurations: all-cpus, auto-pinning, auto-affinity ➔ Exp. repeated 3 times per each configurationAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  21. 21. Benchmarking Pinning and NUMA Aware Scheduling1 vCPU per VM: 20% to 16% improvement!August 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  22. 22. Benchmarking Pinning and NUMA Aware Scheduling2 vCPUs per VM: 17% to 13% improvement!August 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  23. 23. Benchmarking Pinning and NUMA Aware Scheduling4 vCPUs per VM: 0.2% to 8% gap from auto-affinity to auto-pinning 16% to 4% improvement from all-cpus to auto-affinityAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  24. 24. Some Traces about NUMA Aware SchedulingAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  25. 25. Some Traces about NUMA Aware SchedulingAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  26. 26. NUMA and Virt. And XenTalk outline: ● What is NUMA – NUMA and Virtualization – NUMA and Xen ● What I have done in Xen about NUMA ● What remains to be done in Xen about NUMAAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  27. 27. Lots of Room for Further Improvement!Tracking ideas, people and progress on http://wiki.xen.org/wiki/Xen_NUMA_Roadmap ● Dynamic memory migration ● IO NUMA ● Guest (or Virtual) NUMA ● Ballooning and memory sharing ● Inter-VM dependencies ● Benchmarking and performances evaluationAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  28. 28. Dynamic Memory MigrationIf VM2 goes away, it would be nice if wecould change VM1s (or VM3s) node affinityon-line NODE NODE CPUs CPUs VM3 VM2 VM1 Also targeting mem mem And move its VM1 VM1 VM2 Memory accordingly! Xen 4.3 mem VM3 MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  29. 29. IO NUMADifferent devices can be attached todifferent nodes: needs to be considered duringplacement / schedulingAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  30. 30. Guest NUMAIf a VM is bigger than 1 node, should it know?NODE NODE NODE Pros: performancesCPUs CPUs CPUs (especially HPC)VM1 VM2 VM1 VM2 VM1 Cons: what if thingsmem mem mem changes?VM1 VM1 VM2 VM1 VM2 ● live migrationMEM MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  31. 31. Ballooning and SharingBallooning should be Sharing, should weNUMA aware allow that cross-node? NODE NODE NODE NODE CPUs CPUs CPUs CPUs VM1 VM2 VM3 VM1 VM2 mem mem mem mem VM1 mem VM3 VM1 VM2 VM1 mem shmem !! VM2 Remote access! MEM MEM MEM MEMAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  32. 32. Inter-VM Dependences Are we sure the situation on the right is always better? Might it be workload dependant (VM cooperation VS. competiotion) NODE NODE NODE NODE CPUs CPUs CPUs CPUs VM2 VM3 VM1 VM2VM1 VM3 mem mem mem mem VM1 VM3 VM1 VM2 mem mem VM2 VM3 MEM MEM MEM MEM August 27-28, 2012, Dario Faggioli, San Diego, CA, USA dario.faggioli@citrix.com
  33. 33. Benchmarking and Performances EvaluationHow to verify we are actually improving: ● What kind of workload(s)? ● What VMs configuration?August 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  34. 34. NUMA and Virt. And XenTalk outline: ● What is NUMA – NUMA and Virtualization – NUMA and Xen ● What I have done in Xen about NUMA ● What remains to be done in Xen about NUMAAugust 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
  35. 35. Thanks! Any Questions?August 27-28, 2012, Dario Faggioli,San Diego, CA, USA dario.faggioli@citrix.com
