datamapper
the persistence framework
who am I?
(Booth 501)
DataMapper
datamapper
object relational
     mapper
like activerecord
like activerecord
★ DB adapters     ★ many-to-many

★ migrations      ★ -through

★ associations    ★ polymorphic

 ★ one-...
drops into Rails
       1.0
(or merb)
   0.9
architecture
Application    Merb        Rails

                 DataMapper

  Adapters    DO.rb YAML   IMAP

Data Stores
some caveats
work in progress
    0.9   1.0
be prepared for code
why did we build it?
identity map
Foo[1]   Foo

         id = 1



Foo[1]     ...
foo[1] == foo[1]
     #=> true
loadedset
foo.all

Foo      Foo      Foo       Foo     Foo      Foo
id = 1   id = 2   id = 3   id = 4   id = 5   id = 6

  ...      ...
composite keys
belongs_to :project,
  :child_key => [:name, :tag]
legacy data
naming conventions
       (yours)
naming conventions
          underscored
   foo::barBaz => foo/bar_baz
naming conventions
   underscoredandpluralized
   foo::barBaz => foo_bar_bazs
naming conventions
underscoredandpluralizedwithoutmodule
          foo::barBaz => bazs
naming conventions
               yaml
    foo::Bar => foo/bars.yaml
support for multiple
     databases
     (even in the same model)
Post.all(:repository => :legacy)
Post.all
  # :repository => :default
prepared statements
        1.0
custom types
embedded values
      1.0
Employments          Employment

      id: int         id<Integer>
  person_id: int
                    person<Person>
   ...
declared properties
    property :id, :key => true
robust queries
Child.all(
  “mother.last_name.like” =>
    “Jane%”,
  :name.like => “Jim”
)
dirty tracking
modularity
unified interface for
      drivers
•connections
• commands
• readers
• cursors (forward-only)
• quoting
• transactions
Connection     Connection      Connection     Connection      Connection

                              Connection Pool


...
works today on:
mysql, sqlite, postgres
fast, written in C
simple interface for
     adapters
•read by key
• read by query
• update by key
• update set
• delete
• (optional: transactions)
salesforce adapter in
       200 LOC
Errors

Operators

Naming
Conventions

~/.salesforce

Build Query

Load Result Set

Similar CRUD

Demo
what does it look like?
Zoo.all(
  :age.gt => 30,
  :name.not =>
    [“bob”, “jones”]
)
SELECT
  “age”, “name”, “description”
FROM “zoos”
WHERE
  (“age” > 30) AND
  (“name” NOT IN
    (“bob”, “jones”))
Zoo.first.eql? Zoo.first
          #=> true
Zoo.all.map {|x| x.animals }
        how many queries?
                2
we call this
strategic eager loading.
lazy loading
class Post
  include DataMapper::Resource
  property :id, Fixnum,
    :serial => true
  property :title, String
  property...
posts = Post.all
SELECT “id”, “title”
FROM “posts”
return two objects
    ids 1 and 2
posts.first.body
SELECT “body”
FROM “posts”
WHERE (“id” IN (1,2))
posts.map{|x| x.body}
SELECT “body”
FROM “posts”
WHERE (“id” IN (1,2))
lazy loaded grouping
class Post
  include DataMapper::Resource
  property :id, Fixnum,
    :serial => true
  property :title, String,
    :lazy...
you can go off the
   golden path
class Post
  include DataMapper::Resource
  property :title, String

  repository(:legacy) do
    property :title, String,...
Post.all(:repository => :legacy)

repository(:legacy) do
  Post.all
end
Post.all

Post.all(:repository =>
  :default)

repository(:default) do
  Post.all
end
naming conventions
repository(:legacy).adapter.
  resource_naming_convention =
    DM::
    NamingConventions::
    Unders...
naming conventions
repository(:legacy).adapter.
  resource_naming_convention =
    lambda do |klass|
      “tbl#{klass.cam...
default repository
class Post
  include DataMapper::Resource
  def self.default_repository_name
    :legacy
  end
end
import data
Post.copy(:legacy, :default)

Post.copy(:legacy, :default,
  :created_at.gt =>
    Date.today - 365)
         ...
import data
class Post
  property :title, String

  repository(:legacy) do
    property :title, String,
      :field => “T...
custom types
primitives
 Trueclass, string, text, float, fixnum,
bigdecimal, datetime, date, object, class
custom types
class Post
  include DataMapper::Resource
  property :title, String
  property :author, FullName
  property :...
class FullName < DM::Type
  primitive String
  size 100

  def self.load(str)
    str.split(“, ”).reverse
  end

  def sel...
class Csv < DM::Type
  primitive String
  size 65355

  def self.load(str)
    FasterCSV.parse(value)
  end

  def self.du...
Post.create!(
  :title => “New Post”,
  :author => [“Yehuda”, “Katz”],
  :metadata => [
    [“Some”, “Sample”, “Data”],
  ...
in the database
  Title        “New Post”



Author       “Katz, Yehuda”


           “Some,Sample,Datan
Metadata
        ...
and it’s lazy-parsed
custom stores
stores are uris
mysql://user@localhost
setting up
DataMapper.setup(
  :default,
  “mysql://user@localhost”
)
database.yml
development:
  default:
    adapter: mysql
    database: app_dev
    user: person
    password: sekrit
database.yml
legacy:
  adapter: sqlite3
  database: config/l3g.db
yaml:///fixtures


                  1.0
ssh+yaml://
fixtures.engineyard.com/
       fixtures
                          1+
database.yml
test:
  default:
    adapter: yaml
    database: app_test.db
  legacy:
    adapter: yaml
    database: l3g_te...
making fixtures
Post.copy(:default, :fixtures)

rake db:copy_fixtures
validations
class Product
  include DataMapper::Resource
  property :title, String
  property :price, String,
            validates_le...
class Product
  include DataMapper::Resource
  property :title, String
  property :number, String,
    :format =>
      /d...
class Product
  include DataMapper::Resource
  property :title, String
  property :number, String,
    :format => proc {|n...
class Product
  include DataMapper::Resource
  property :title, String
  property :number, String,
    :length => 2..10,
 ...
class Product
  include DataMapper::Resource
  property :title, String
  property :number, String,
  validates_length_of :...
thank you.
any questions?
</railsconf>
