Fluvial Landscapes
Overview
Fluvial Processes
  Basel Level
  Down-cutting and meandering
Drainage
  Watersheds
  Drainage Patterns
Stream fl...
Base Level and Fluvial Landscapes
 A Profound Concept: Water flows downhill
   Abrades and erodes the landscape as it happ...
Higher above base level, water has more potential
energy, which gets converted to kinetic energy as
it flows downslope
  A...
Landforms associated with rivers vary by how
high above base level the river is
  Above base level
     Steep V-shaped val...
Drainage
When rain falls on a landscape, it drains
from higher to lower elevations
  erodes surfaces as it happens
    lar...
Watersheds
 topography directs flow of surface water
 into various downslope areas
 at high points in the topography, surf...
Drainage Patterns
 Pattern relates to
 underlying bedrock
   Type of rock
     Soft sedimentary layers tend to
     produc...
Dendritic
  soft underlying
  sedimentary rock
  exerts no strong
  directional influence
  on the flow of water
  most co...
Trellis
  Occurs where there is intense folding
     antiforms and synforms
     alternating layers of soft and resistant ...
Rectangular
  Occurs on areas with
  resistant bedrock
  Surface flow follows
  rectilinear fracture
  pattern of the rock...
Parallel
  Occur on steep
  slopes
Deranged
  Occur where
  something has
  disrupted normal
  surface patterns and
  proc...
Stream Flow and Fluvial Processes
 Streams run down
 slopes
   Potential energy is
   changed to kinetic
   energy
 Discha...
Load
Dissolved Load
Suspended Load
  Greatest part
Bed Load
  Traction
  Saltation
General Principle: The greater the spee...
Meandering Streams
Erosion and
Deposition
Undercut bank and
point bar
Floodplain

Formation
  Widening of valley through meandering
  process
Features
  Floodplain
  Natural levees
  Oxbow lak...
Entrenched Meanders
Landscape was once near base
level, and meanders formed.
Later, tectonic uplift caused the
river to be...
Deltas
Deposition
  River reaches sea level (base level)
  Velocity decreases dramatically
  Load is deposited
  Distribut...
Flooding
Rating (10-year flood, 100-year flood, etc)
  an expression of probability (10%, 1%, resp.)
Contributing factors
...
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Fluvial Geomorphology
Upcoming SlideShare
Loading in...5
×

Fluvial Geomorphology

12,501

Published on

Published in: Technology
2 Comments
6 Likes
Statistics
Notes
  • I like it, but it seems that transcript doesn't always follow the slides, does it?
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
  • it is very very useful to me. thanks
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
No Downloads
Views
Total Views
12,501
On Slideshare
0
From Embeds
0
Number of Embeds
6
Actions
Shares
0
Downloads
1,234
Comments
2
Likes
6
Embeds 0
No embeds

No notes for slide

Transcript of "Fluvial Geomorphology"

  1. 1. Fluvial Landscapes
  2. 2. Overview Fluvial Processes Basel Level Down-cutting and meandering Drainage Watersheds Drainage Patterns Stream flow and fluvial processes Meandering Streams Floodplains Flooding
  3. 3. Base Level and Fluvial Landscapes A Profound Concept: Water flows downhill Abrades and erodes the landscape as it happens Abrasion = erosion process Creates erosional landforms – drainage patterns, cut banks Carries eroded material downstream as either dissolved, suspended or bed load Load = Transport Load becomes deposited, creating depositional landforms Depositional landforms: Deltas, point bars Base Level: The lowest level that a river can erode down to. Gravity sets the water in motion Ultimately, the water is trying to reach sea level Local impediments to flow create local base levels
  4. 4. Higher above base level, water has more potential energy, which gets converted to kinetic energy as it flows downslope Above base level, more energy directed downwards, more able to erode bedrock - downcutting Closer to base level, energy directed outward with motion, erosion occurs more laterally - meandering
  5. 5. Landforms associated with rivers vary by how high above base level the river is Above base level Steep V-shaped valley walls Narrow stream channels Distinct drainage patterns based on underlying geography Downcutting (erosion) and transportation are the main geomorphological forces acting Closer to base level Wide stream channels (floodplains) Valley walls characterized by terracing Meandering river patterns, river deltas lateral abrasion, transport and deposition Tectonic forces can cause areas close to base level to become uplifted Meandering gives way to downcutting Entrenched meanders, canyons
  6. 6. Drainage When rain falls on a landscape, it drains from higher to lower elevations erodes surfaces as it happens largely an erosional process Occurs above base level - downcutting over time, forms regions of consistent drainage patterns that concentrate runoff into specific streams and rivers watersheds or drainage basins drainage pattern
  7. 7. Watersheds topography directs flow of surface water into various downslope areas at high points in the topography, surface flow separates down different slopes, and channels water into separate drainage systems these high points are called drainage divides or interfluves drainage divides form the boundaries between watersheds
  8. 8. Drainage Patterns Pattern relates to underlying bedrock Type of rock Soft sedimentary layers tend to produce dendritic patterns Igneous or hard sedimentary bedrock tends to produce rectangular patterns streamflow directed through orthogonal rock fractures Folding produces trellis patterns
  9. 9. Dendritic soft underlying sedimentary rock exerts no strong directional influence on the flow of water most common stream pattern a radial pattern occurs when soft layers are uplifted by an igneous intrusion (dome) or on mountain or volcanic peaks
  10. 10. Trellis Occurs where there is intense folding antiforms and synforms alternating layers of soft and resistant rock Common in Appalachia
  11. 11. Rectangular Occurs on areas with resistant bedrock Surface flow follows rectilinear fracture pattern of the rock produces an annular pattern when this occurs on a dome
  12. 12. Parallel Occur on steep slopes Deranged Occur where something has disrupted normal surface patterns and processes, such as glaciation
  13. 13. Stream Flow and Fluvial Processes Streams run down slopes Potential energy is changed to kinetic energy Discharge Speed Channel depth Channel width Fluvial Processes Erosion: abrasion Transport: load Deposition
  14. 14. Load Dissolved Load Suspended Load Greatest part Bed Load Traction Saltation General Principle: The greater the speed, the more load a stream can carry Slowing causes deposition Largest and heaviest materials deposited first
  15. 15. Meandering Streams Erosion and Deposition Undercut bank and point bar
  16. 16. Floodplain Formation Widening of valley through meandering process Features Floodplain Natural levees Oxbow lakes and swamps Meander scars Terraces
  17. 17. Entrenched Meanders Landscape was once near base level, and meanders formed. Later, tectonic uplift caused the river to be raised above base level, recommencing down- cutting, and carving these canyons
  18. 18. Deltas Deposition River reaches sea level (base level) Velocity decreases dramatically Load is deposited Distributaries
  19. 19. Flooding Rating (10-year flood, 100-year flood, etc) an expression of probability (10%, 1%, resp.) Contributing factors Rainfall, of course Oscillations, hurricanes Human activities that increase runoff and reduce soil moisture storage capacity urbanization (increasing paved surfaces) agricultural practices Midwest Flood of 1993, North Carolina flood of 1999 1000 year flood events (0.1% probability of occurring) Contributed to formations of “Dead Zones” Dead Zone (The Zone of Hypoxia in the Gulf of Mexico) Pamlico Sound, NC
