Caching and tuning fun  for high scalability                           Wim Godden                         Cu.be Solutions
Who am I ?Wim Godden (@wimgtr)Owner of Cu.be Solutions (http://cu.be)Open Source developer since 1997Developer of OpenXZen...
Who are you ?Developers ?System/network engineers ?Managers ?Caching experience ?
Caching and tuning fun  for high scalability                           Wim Godden                         Cu.be Solutions
Goals of this tutorialEverything about caching and tuningA few techniques   How-to   How-NOT-to→ Increase reliability, per...
LAMP
Architecture
Our base benchmarkApachebench = useful enoughResult ?                      Single webserver                    Proxy      ...
Caching
What is caching ?                    CACHE
What is caching ?                                             x = 5, y = 2                                                ...
Theory of caching                                                                            DB                           ...
Theory of caching                            DB                    HIT                          Cache
Caching techniques                #1 : Store entire pages           #2 : Store part of a page (block)           #3 : Store...
How to find cacheable dataNew projects : start from cache everythingExisting projects :   Look at MySQL slow query log   M...
Caching storage - DiskData with few updates : goodCaching SQL queries : preferably notDONT use NFS or other network file s...
Caching storage - Disk / ramdiskLocal  5 Webservers → 5 local caches  How will you keep them synchronized ?        → Dont ...
Caching storage - Memcache(d)Facebook, Twitter, YouTube, … → need we say more ?Distributed memory caching systemMultiple m...
Caching storage - Memcache(d)Facebook, Twitter, YouTube, … → need we say more ?Distributed memory caching systemMultiple m...
Memcache - where to install
Memcache - where to install
Memcache - installation & running itInstallation   Distribution package   PECL   Windows : binariesRunning   No config-fil...
Caching storage - Memcache - some notesNot fault-tolerant   Its a cache !   Lose session data   Lose shopping cart data   ...
Caching storage - Memcache - some notesNot fault-tolerant   Its a cache !   Lose session data   Lose shopping cart data   ...
Memcache in code<?php$memcache = new Memcache();$memcache->addServer(172.16.0.1, 11211);$memcache->addServer(172.16.0.2, 1...
Wheres the data ?Memcache client decides (!)2 hashing algorithms :   Traditional       Server failure → all data must be r...
Benchmark with Memcache                      Single webserver             Proxy                    Static         PHP    S...
Memcache slabs            (or why Memcache says its full when its not)Multiple slabs of different sizes :   Slab 1 : 400 b...
Memcache - Is it working ?Connect to it using telnet               STAT pid 2941                                         S...
Memcache - backing up
Memcache - tipPage with multiple blocks ?→ use Memcached::getMulti()                     Hashing  getMulti($array)        ...
Updating data
Updating data                LCD_Popular_Product_List
Adding/updating data$memcache->delete(LCD_Popular_Product_List);
Adding/updating data
Adding/updating data - Why it crashed
Adding/updating data - Why it crashed
Adding/updating data - Why it crashed
Cache stampeding
Cache stampeding
Memcache code ?    Memcache code     Visitor interface        Admin interface                         DB
Cache warmup scriptsUsed to fill your cache when its emptyRun it before starting Webserver !2 ways :   Visit all URLs     ...
Cache stampeding - what about locking ?Seems like a nice idea, but...While lock in placeWhat if the process that created t...
LAMP...          → LAMMP          → LNMMP
NginxWeb serverReverse proxyLightweight, fast10.2% of all Websites
NginxNo threads, event-drivenUses epoll / kqueueLow memory footprint10000 active connections = normal
Nginx - a true alternative to Apache ?Not all Apache modules   mod_auth_*   mod_dav*   …Basic modules are availableSome 3r...
Nginx - Configuration        server {         listen        80;         server_name   www.domain.ext *.domain.ext;        ...
Nginx + PHP-FPM - performance ?                         Single webserver                    Proxy                       St...
Reverse proxy time...
VarnishNot just a load balancerReverse proxy cache / http accelerator / …Caches (parts of) pages in memoryCareful :   uses...
Varnish - backends + load balancing backend server1 {     .host = "192.168.0.10"; } backend server2{     .host = "192.168....
Varnish - VCLVarnish Configuration LanguageDSL (Domain Specific Language)   → compiled to CHooks into each requestDefines ...
Varnish - whatever you wantReal-time statistics (varnishtop, varnishhist, ...)ESI
Varnish - ESIPerfect for caching pages             Header (TTL : 60 min)              In your article page output :       ...
Varnish with ESI - hold on tight !                         Single webserver             Proxy                       Static...
Varnish - what can/cant be cached ?Can :   Static pages   Images, js, css   Pages or parts of pages that dont change often...
ESI → no caching on user-specific content ?                                           Logged in as : Wim Godden           ...
Coming soon...Based on NginxReduces load by 50 – 95%  Requires code changes !  Well-built project → few changes  Effect on...
Whats the result ?
Whats the result ?
FiguresFirst customer :   No. of web servers : 18 → 4   No. of db servers : 6 → 2   Total : 24 → 6 (75% reduction !)Second...
AvailabilityStable at 2 customersStill under heavy developmentBeta : Jul 2012Final : Sep 2012
Tuning
PHP speed - some tipsUpgrade PHP - every minor release has 5-15% speed gain !Use an opcode cache
Caching storage - Opcode caching
DB speed - some tipsUse same types for joins   i.e. dont join decimal with intRAND() is evil !count(*) is evil in InnoDB w...
Caching & Tuning @ frontend        http://www.websiteoptimization.com/speed/tweak/average-web-page/
Frontend tuning1. You optimize backend2. Frontend engineers messes up → havoc on backend3. Dont forget : frontend sends re...
Tuning frontendMinimize requests  Combine CSS/JavaScript files
Tuning frontendMinimize requests  Combine CSS/JavaScript files  Use CSS Sprites
CSS Sprites
Tuning content - CSS sprites
Tuning content - CSS sprites         11 images             1 image         11 HTTP requests      1 HTTP requests         2...
Tuning frontendMinimize requests   Combine CSS/JavaScript files   Use CSS Sprites (horizontally if possible)Put CSS at top...
What else can kill your site ?Redirect loops   Multiple requests       More load on Webserver       More PHP to process   ...
Above all else... be prepared !Have a monitoring systemUse a cache abstraction layer (disk → Memcache)Dont install for the...
So...Cache  But : never delete, always push !  Have a warmup script  Monitor your cache  Have an abstraction layerApache =...
Questions ?
Questions ?
Were hiring !Lots of challengesWork with cutting-edge technologyVaried :   PHP development   System / network architecture...
ContactTwitter             @wimgtrWeb                http://techblog.wimgodden.beSlides                 http://www.slidesh...
Thanks !                     Please...Rate my talk : http://speakerrate.com/talks/9501
