Caching and tuning fun for high scalability Wim Godden Cu.be Solutions Conference Jan 28, 2011
Who am I ? <ul><li>Wim Godden
Owner of Cu.be Solutions (http://cu.be)
PHP developer since 1997
Developer of OpenX
Zend Certified Engineer
Zend Framework Certified Engineer
MySQL Certified Developer </li></ul>
Who are you ? <ul><li>Developers ?
System/network engineers ?
Managers ?
Caching experience ? </li></ul>
Caching and tuning fun for high scalability Wim Godden Cu.be Solutions Conference Jan 28, 2011
Goals of this tutorial <ul><li>Everything about caching and tuning
A few techniques
-> Increase reliability, performance and scalability
5 visitors/day -> 5 million visitors/day
(Don't expect miracle cure !) </li></ul>
Goals of this tutorial <ul><li>Concepts & techniques
How to do stuff
How  NOT  to do stuff </li></ul>
LAMP
LAMP
LAMP
LAMP
Architecture
Caching
What's caching ?
What is caching ? select * from article join user on article.user_id = user.id order by created desc limit 10
Caching goals - 1 st  goal <ul><li>Reduce # of request
Reduce the load </li></ul>
Caching goals - 2 nd  goal
Some figures <ul><li>Pageviews : 5000 (4000 on 10 pages)
Avg. loading time : 200ms
Cache 10 pages
Avg. loading time : 20ms
-> Total avg. loading time : 56ms
Worth it ? </li></ul>
Caching goals - 3 rd  goal <ul>Send less data across the network / Internet <li>You benefit -> lower bill from upstream pr...
Users benefit -> faster page load
Wait a second... that's mostly frontend stuff ! </li></ul>
Theory of caching DB
Theory of caching DB
Caching techniques <ul>#1 : Store entire pages <li>Company Websites
Blogs
Full pages that don't change
Render -> Store in cache -> retrieve from cache </li></ul>
Caching techniques <ul>#1 : Store entire pages </ul>
Caching techniques <ul>#2 : Store parts of a page <li>Most common technique
Usually a small block in a page
Best effect : reused on lots of pages
Can be inserted on dynamic pages </li></ul>
Caching techniques <ul>#2 : Store parts of a page </ul>
Caching techniques <ul>#3 : Store SQL queries <li>↔ SQL query cache </li><ul><ul><li>Limited in size </li></ul></ul></ul>
Caching techniques <ul>#3 : Store SQL queries <li>↔ SQL query cache </li><ul><ul><li>Limited in size
Resets on every insert/update/delete
Server and connection overhead </li></ul></ul><li>Goal : </li><ul><li>not  to get rid of DB
free up DB resources for more hits ! </li></ul><li>Better : </li><ul><li>store returned object
store group of objects </li></ul></ul>
Caching techniques <ul>#3 : Store SQL queries </ul>
Caching techniques <ul>#4 : Store complex PHP results <li>Not just calculations
CPU intensive tasks : </li><ul><li>Config file parsing
XML file parsing
Loading CSV in an array </li></ul><li>Save resources -> more resources available </li></ul>
Caching techniques <ul>#4 : Store complex PHP results </ul>
Caching techniques <ul>#xx : Your call Only limited by your imagination ! When you have data, think : <li>Creating time ?
Modification frequency ?
Retrieval frequency ? </li></ul>
How to find cacheable data <ul><li>New projects : start from 'cache anything'
Existing projects : </li><ul><li>Look at MySQL slow query log
Make a complete query log (don't forget to turn it off !)
Check page loading times </li></ul></ul>
Caching storage - MySQL query cache <ul><li>Use it
Don't rely on it
Good if you have : </li><ul><li>lots of reads
few different queries </li></ul><li>Bad if you have : </li><ul><li>lots of insert/update/delete
lots of different queries </li></ul></ul>
Caching storage - Database memory tables <ul><li>Tables stored in memory
In MySQL : memory/heap table
↔ temporary table : </li><ul><li>memory tables are persistent
temporary tables are session-specific </li></ul><li>Faster than disk-based tables
Can be joined with disk-based tables
But :  </li><ul><li>default 16MByte limit
master-slave = trouble
if you don't need join -> overhead of DB software </li></ul><li>So : don't use it unless you need to join </li></ul>
Caching storage - Opcode caching <ul>DO ! </ul>
Caching storage - Opcode caching <ul><li>APC </li><ul><li>De-facto standard
Will be in PHP core in 5.4 ? 5.5 ? 6.0 ?
PECL or packages </li></ul><li>eAccelerator
Zend Accelerator </li></ul>
Caching storage - Opcode caching <ul><li>APC </li><ul><li>De-facto standard
Will be in PHP core in 5.4 ? 5.5 ? 6.0 ?
PECL or packages </li></ul><li>eAccelerator
Zend Accelerator
X-Cache
WinCacheForPhp </li></ul>PHP PHP + APC PHP + eAccelerator 42.18 req/sec 206.20 req/sec 211.49 req/sec
Caching storage - Disk <ul><li>Data with few updates : good
Caching SQL queries : preferably not
DON'T  use NFS or other network file systems </li><ul><li>especially for sessions
high latency
locking issues ! </li></ul></ul>
Caching storage - Memory disk (ramdisk) <ul><li>Usually faster than physical disk
But : OS file caching makes difference minimal </li></ul>
Caching storage - Disk / ramdisk <ul><li>Overhead : filesystem access
Limited number of files per directory </li><ul><li>-> Subdirectories </li></ul><li>Local </li><ul><li>5 Webservers -> 5 lo...
-> Hard to scale
How will you keep them synchronized ? </li><ul><li>-> Don't say NFS or rsync ! </li></ul></ul></ul>
Caching storage - APC variable cache <ul><li>More than an opcode cache
Store user data in memory
apc_add / apc_store to add/update
apc_fetch to retrieve
apc_delete
Fast -> huge performance impact </li></ul>
Caching storage - APC variable cache <ul><li>More than an opcode cache
Store user data in memory
apc_add / apc_store to add/update
apc_fetch to retrieve
apc_delete
Fast -> huge performance impact
Session support !
Downside : </li><ul><li>local storage -> hard to scale
restart Apache -> cache = empty </li></ul></ul>
Caching storage - Memcache <ul><li>Facebook, Twitter, Slashdot, … -> need we say more ?
Distributed memory caching system
Key-value storage system </li><ul><li>Keys - max. 250bytes
Values - max. 1Mbyte </li></ul></ul>
Caching storage - Memcache <ul><li>Facebook, Twitter, Slashdot, … -> need we say more ?
Distributed memory caching system
Multiple machines ↔ 1 big memory-based hash-table
Key-value storage system </li><ul><li>Keys - max. 250bytes
Values - max. 1Mbyte </li></ul><li>Extremely fast... non-blocking, UDP (!) </li></ul>
Memcache - where to install
Memcache - where to install
Memcache - installation & running it <ul><li>Installation </li><ul><li>Distribution package
PECL
Windows : binaries </li></ul><li>Running </li><ul><li>No config-files
