Luke Wroblewski: Mobile First Luke Wroblewski: Mobile First Presentation Transcript

  • MOBILEFIRSTLUKE WROBLEWSKIAN EVENT APART 2010 @LUKEW 1
  • Web products should be designed for mobile first.(Even if no mobile version is planned.)Flickr photo by @kevinv033 2
  • Mobile First at GoogleGoogle programmers are doing workon mobile applications first, becausethey are better apps and thats whattop programmers want to develop.–Eric Schmidt, Google CEO 3
  • Mobile First at Facebook Were just now starting to think about mobile first and desktop second for a lot of our products.” -Kate Aronowitz, Design Director FacebookFlickr photo by gscottolson 4
  • Mobile First at Adobe We really need to shift now to start thinking about building mobile first. This is an even bigger shift than the PC revolution.” -Kevin Lynch, CTO AdobeFlickr photo by jdlasica 5
  • MOBILE FIRST1.  GROWTH = OPPORTUNITY2.  CONSTRAINTS = FOCUS3.  CAPABILITIES = INNOVATION 6
  • Mobile Design Considerations•  Multiple screen sizes & densities•  Performance optimization•  Touch targets, gestures, and actions•  Location systems•  Device capabilities 7
  • MOBILE FIRST1.  GROWTH = OPPORTUNITY2.  CONSTRAINTS = FOCUS3.  CAPABILITIES = INNOVATION 8
  • GROWTH = OPPORTUNITYMobile Web growth has outpaced desktop Web growth 8xSmartphone sales will pass PC sales in 2012 PC Desktop Internet Mobile Consumer 100M+ 1B+ 10B+1990 2000 2010 2020Note: PC installed base reached 100MM in 1993, cellphone / Internet users reached 1B in 2002 / 2005 respectively;25 9Source: ITU, Mark Lipacis, Morgan Stanley Research.
  • 10
  • 2006High-end RAZR-inspiredphone with class 12 EDGEhigh-speed data & WAP2.0/xHTML Web browser.2G network GSM 850 / 900 / 1800 / 1900SMS, EMS, MMS, Email, Instant Messaging2 megapixel cameraMusic playerResolution: 176 x 220 pixelsColors: 262,144 (18-bit) 11
  • 12
  • 4,932% IncreaseAT&T mobile data traffic increased 50x in 3 years Motorola Z3 iPhone iPhone 3G iPhone 3GS2006 2007 2008 2009 13Source: AT&T, Morgan Stanley Research.
  • 27% of searches come from 4% of users •  27% of all Yelp searches come from their iPhone application which had 1.4 million unique users in May 2010 •  That month Yelp had 32 million monthly unique users around the world Source: http://officialblog.yelp.com/2010/06/yelp-mobile 14
  • Facebook on the iPhone Create a product, don’t re-imagine one for small screens. Great mobile products are created, never ported. –Brian Fling 15
  • “My goal was initially just to make a mobile companion, but Ibecame convinced it was possible to create a version of Facebookthat was actually better than the website.”–Joe Hewitt 16
  • MOBILE FIRST1.  GROWTH = OPPORTUNITY2.  CONSTRAINTS = FOCUS3.  CAPABILITIES = INNOVATION 17
  • SCREEN SIZE•  Focus on core actions•  Know your users•  Use scalable design 18
  • Screen Size 1024x768 320x480 19
  • Focus on Core Elements In iPhone apps, the main function should be immediately apparent. Minimize the number of controls from which users have to choose. –iPhone Interface Guidelines 20
  • 21
  • Southwest Airlines Mobile App 22
  • 23
  • Screen Size 24
  • Screen Size 25
  • Know your audienceFlickr photo by wertheim 26
  • Expedia Itinerary 27
  • Expedia Itinerary 28
  • Designing For Multiple Screen Sizes 320x480 29
  • Smartphone Screen SizesiPhone 320x480 3.5 in 164ppiPalm Pre 320x480 3.1 in 186ppiPalm Pixie 320x400 2.63 in 194ppiT-Mobile G1 320x480 3.2 in 180ppiMyTouch 3GHTC HeroMotorola Droid 480x854 3.7 in 264ppiNexus One 480x800 3.7 in 252ppiHTC DesireNokia N97 360x640 3.2 in 229ppiNokia N900 800x480 3.5 in 266ppiiPhone4 640x960 3.5 in 329ppi 30
  • The Impact of PPISource: http://mobiforge.com/designing/story/effective-design-multiple-screen-sizes 31
  • The Impact of PPICinema Display 1920x1200 24 in 94ppiNokia N900 800x480 3.5 in 266ppi 32
  • Designing for Multiple Screen Sizes 1.  Define device groups tiny: 84, 96, 101, 128, 130, 132 small: 160, 176 medium: 208, 220, 240 large: 320, 360, 480+ desktop: 800+ 33Source: http://mobiforge.com/designing/story/effective-design-multiple-screen-sizes
  • Designing for Multiple Screen Sizes 1.  Define device groups 2.  Create a default reference design 34Source: http://mobiforge.com/designing/story/effective-design-multiple-screen-sizes
  • Designing for Multiple Screen Sizes 1.  Define device groups 2.  Create a default reference design 3.  Define rules for content and design adaptationSource: http://mobiforge.com/designing/story/effective-design-multiple-screen-sizes 35http://www.littlespringsdesign.com/blog/blog/2009/03/11/photoshop-layout-is-not-your-friend/
  • Designing for Multiple Screen Sizes 1.  Define device groups 2.  Create a default reference design 3.  Define rules for content and design adaptation 4.  Opt for web standards and a flexible layoutSource: http://mobiforge.com/designing/story/effective-design-multiple-screen-sizes 36http://www.alistapart.com/articles/switchymclayout/
  • Visible App Controls 37
  • Hardware Control for Menu 38
  • Make Content the ActionYou should not view the large iPad screen as an invitation to bringback all the functionality you pruned from your your iPhoneapplication. –iPad Interface Guidelines 39
  • 40
  • SPEED•  Keep performance top of mind•  Take advantage of HTML5 41
  • Connection Speed 42
  • Performance TipsReduce Requests & File Size•  Eliminate redirects•  Use CSS sprites to serve multiple images•  Consolidate CSS & Javascript into a single file•  Minify your codeTake Advantage of HTML5•  Load contents lazily•  Use application cache for local content storage•  Use CSS3 and canvas tag instead of images where possible Source: Make the mobile web faster, Jeremy Weinstein 43
  • Performance Matters! 100ms delay results in 1% sales loss. (potential $191M in lost revenue in 2008) 400ms delay results in 5-9% drop in full- page traffic. 500ms delay drops search traffic by 20%. The cost of slower performance increases over time. 1s delay results 4% drop in revenue Fastest 10% of users stay 50% longer than slowest 10%Sources: slideshare.net/stubbornella/designing-fast-websites-presentation & slideshare.net/markstanton/speed-matters 44
  • CONTEXT•  Quick bursts… everywhere•  One-handed 45
  • During a typical day…84% at home80% during misc. times throughout the day74% waiting in lines64% at work 46 Flickr photo by Laughing Squid
  • Use Cases for Mobile Apps •  Access to Facebook via mobile browser grew 112% in the past year to 25.1 million users in January 2010. •  Access to Twitter via mobile browser experienced a 347% jump to 4.7 million users in January 2010. 47
  • People Don’t Stay Long•  Across 650,000 URLs tested…10%9% •  25% of all documents8% were displayed for less than 4 seconds7%6% •  52% of all visits were5% shorter than 10 seconds4%3% •  Peak value was2% located between 2 and 3 seconds1%0% 0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 SECONDS DISPLAYEDSource: Clickstream Study Reveals Dynamic Web, Weboptimization.com 48
  • Where phones usedOne-handed touchFlickr photo by Steve Rhodes 49
  • MOBILE FIRST1.  GROWTH = OPPORTUNITY2.  CONSTRAINTS = FOCUS3.  CAPABILITIES = INNOVATION 50
  • TOUCH•  Simplify your user interface•  Don’t count on hovers 51
  • Nokia smartphone mix Keypad Qwerty Only Touch INCLUDES QWERTY + TOUCH1.1 billion consumers with Nokia devices in 2009 2008 2009 2010 PROJECTED 52Source: Nokia –deices sold. Nokia Capital markets day 2009.
  • Touch Targets Apple recommends a minimum target size: 29px wide 44px tall Source: Matt Legend Gemmell – mattgemmell.com 53
  • Touch TargetsRecommended touchtarget size is 9mm/34pxMinimum touch targetsize is 7mm/26pxMinimum spacingbetween elements is2mm/8pxVisual size is 60-100% ofthe touch target size 54
  • 55
  • Basic Touch GesturesTouch Gestures Platforms Tap iPhone OS Double Tap Android Web OS Drag Windows Phone 7 Flick OS X Pinch Windows 7 Spread RIM 6.0 Press Ubuntu And more... Press & Tap Press & Drag Rotate 56
  • Basic Touch Gestures Tap Briefly touch surface with fingertip. Double Tap Rapidly touch surface twice with fingertip.Images: Dan Willis Research: Craig Villamor & LukeW 57
  • Basic Touch Gestures Drag Move fingertip over surface without losing contact. Flick Quickly brush surface with fingertip.Images: Dan Willis Research: Craig Villamor & LukeW 58
  • Basic Touch Gestures Pinch Touch surface with two fingers and bring them closer together. Spread Touch surface with two fingers and move them apart.Images: Dan Willis Research: Craig Villamor & LukeW 59
  • Basic Touch Gestures Press Press & Tap Touch surface for extended period Press surface with one finger and of time. briefly touch surface with second finger. Press & Drag Press surface with one finger and move second finger over surface without losing contact.Images: Dan Willis Research: Craig Villamor & LukeW 60
  • Basic Touch Gestures Rotate Touch surface with two fingers and move them in a clockwise or counterclockwise direction.Images: Dan Willis Research: Craig Villamor & LukeW 61
  • System-related ActionsImages: Dan Willis Research: Craig Villamor & LukeW 62
  • Object-related ActionsImages: Dan Willis Research: Craig Villamor & LukeW 63
  • Navigation-related Actions www.lukew.com/touchImages: Dan Willis Research: Craig Villamor & LukeW 64
  • Gestures as Input 65
  • Pop-Up Menus on iPhone 66
  • Pop-Up Menus on Android 67
  • Multi-Field Pop-Up Menus on iPhone 68
  • Multi-Field Pop-Up Menus on Android 69
  • Hover Details & Actions 70
  • 71
  • Tooltip with Hover 72
  • LOCATION•  Positioning•  Filtering 73
  • Location as Input 74
  • Location as Input 75
  • Location as Input 76
  • Location Systems Accuracy Positioning Time Battery Life GPS 10m 2-10 minutes (only 5-6 hours on outdoors) most phones WiFi 50m (improves with Almost instant No additional density) (server connect & effect lookup) Cell tower 100-1400m (based on Almost instant Negligible triangulation density) (server connect & lookup) Single Cell 500-2500m (based on Almost instant Negligible Tower density) (server connect & lookup) IP Country: 99% Almost instant Negligible City: 46% US, 53% Intl (server connect & ZIP: 0% lookup)Smartphones: hybrid of GPS, Wifi, and cell tower triangulationLaptops/desktops: WiFi, IP, rarely GPS 77
  • 78
  • AND MORE…•  Orientation•  Audio & Video•  The List Goes On… 79
  • Mobile Device Capabilities•  Application cache for local storage•  CSS3 & Canvas for performance optimization•  Multi-touch sensors•  Location detection•  Device positioning & motion: from an accelerometer•  Orientation: direction from a digital compass•  Audio: input from a microphone; output to speaker•  Video & image: capture/input from a camera•  Push: real-time notifications “instant” to user•  Device connections: through Bluetooth between devices•  Proximity: device closeness to physical objects•  Ambient Light: light/dark environment awareness•  RFID reader: identify & track objects with broadcasted identifiers•  Haptic feedback: “feel” different surfaces on a screen•  Biometrics: retinal, fingerprint, etc. 80
  • Multiple Orientations 81
  • Standard Orientation 82
  • Pivot Orientation 83
  • Orientation Detection in Firefox 3.6Source: http://hacks.mozilla.org/2009/10/orientation-for-firefox/ 84
  • Tilt Scrolling in Instapaper 85
  • Voice as Input 86
  • 87
  • Location & Orientation as Input 88
  • Location & Orientation as Input When discovered by users boosted their sustained traffic by 40 to 50 percent. “It was sort of beyond our expectations. We had no idea.” Yelp CEO, Jeremy Stoppelman 89
  • Awkward Interactions SCAN TO CHECKOUT 90Flickr photo by Nokia Point & Find
  • Images as Input 91
  • SnapTell on iPhone 92
  • Images as Input 93
  • Images as Input 94
  • Images as Input 95
  • Nerd. Found. 96Flickr photo by Nokia Point & Find
  • 97
  • Location Check-in 98
  • Facebook Presence 99
  • Mobile Device Capabilities•  Application cache for local storage•  CSS3 & Canvas for performance optimization•  Multi-touch sensors•  Location detection•  Device positioning & motion: from an accelerometer•  Orientation: direction from a digital compass • •  Audio: input from degrees of motion to speaker Gyroscope: 360 a microphone; output • •  Videocameras: capture/input facing camera Dual & image: front & back from a•  Push: real-time notifications “instant” to user•  Device connections: through Bluetooth between devices•  Proximity: device closeness to physical objects•  Ambient Light: light/dark environment awareness•  RFID reader: identify & track objects with broadcasted identifiers•  Haptic feedback: “feel” different surfaces on a screen•  Biometrics: retinal, fingerprint, etc. 100
  • MOBILE FIRST1.  GROWTH = OPPORTUNITY2.  CONSTRAINTS = FOCUS3.  CAPABILITIES = INNOVATION 101
  • Mobile Design Considerations•  Multiple screen sizes & densities•  Performance optimization•  Touch targets, gestures, and actions•  Location systems•  Device capabilities 102
  • More Information•  @lukew•  www.lukew.comWeb Form Design•  www.rosenfeldmedia.com/ books/webforms/•  Discount code: (25%) 103
