Continuous delivery-with-maven

Real-World Strategies for Continuous Delivery with Maven and Jenkins John Ferguson Smart

Consulta nt Trainer Mentor Author Speaker CoderJohn Fer guson S mar t

Continuous Delivery Getting value to the business. Fast. 3

But what is Continuous Delivery? A build tool? A CI tool? Automated tests? Automated quality? Automated deployment?

Yes...and No

Continuous Delivery is an attitude

Deliver business value more frequently

Value can also come in the form of fast feedback

Give power back to the business

The ‘eternal beta’ strategy

Principles of Continuous Delivery

Principle #1Every build is a potential release

Principle #2Eliminate manual bottlenecks

Principle #3Automate wherever possible

Principle #4Have automated tests you can trust

Build PipelinesThe conveyer belts of Continuous Delivery

Compile and unit test Package and deploy DEV Acceptance tests Deploy to QA QA Deploy to PROD PROD

Compile and unit testEach commit is a potential release Package and deploy DEV Acceptance tests Deploy to QA QA Deploy to PROD PROD

Compile and unit test Package and deploy DEV Acceptance testsWe reuse the same binaries Deploy to QA QA Deploy to PROD PROD

Compile and unit test Package and deploy DEV Acceptance testsAutomated tests give us confidence in our build Deploy to QA QA Deploy to PROD PROD

Compile and unit test Package and deploy DEV Acceptance testsAutomated, repeatable deployments QA Deploy to QA Deploy to PROD PROD

Continuous Delivery with Maven Why does it have to be so hard?!

The Maven lifecycle compile test-compile test package integration-test verify install deploy

The Maven lifecycleCompile and unit test mvn test compile test-compile test Integration tests mvn verify compile test-compile test package integration-test verify

The Maven lifecycleCompile and unit test mvn test compile test-compile test compile test-compile Integration tests mvn verify test package integration-test verifyDeploy to repository compile mvn deploy test-compile test package integration-test verify deploy

The Maven Release Process 1.0.0-SNAPSHOT 1.0.0-SNAPSHOT mvn release 1.0.0

The Maven Release Process mvn release:prepare• Check that there are no uncommitted changes in the sources• Check that there are no SNAPSHOT dependencies• Change the version in the POMs from x-SNAPSHOT to a new version (you will be prompted for the versions to use)• Transform the SCM information in the POM to include the final destination of the tag• Run the project tests against the modified POMs to confirm everything is in working order• Commit the modified POMs• Tag the code in the SCM with a version name (this will be prompted for)• Bump the version in the POMs to a new value y-SNAPSHOT (these values will also be prompted for)• Commit the modified POMs

The Maven Release Process mvn release:prepare compiletest-compile test package 1.0.0 integration-test verify 1.0.1-SNAPSHOT1.0.0-SNAPSHOT 1.0.1-SNAPSHOT

The Maven Release Process mvn release:perform compile test-compile test 1.0.0 package integration-test verify install deploy 1.0.0

The Maven Release ProcessMaven: You build a new release whena snapshot build is good enough Continuous Delivery: Any build is a potential release

Options?Make Maven work for you

Beware duplication!Build and unit test mvn test Integration tests mvn verify Code coverage... mvn site

Minimize build jobs for the main build Default build mvn install compile test integration-test verify install

Split unit and integration tests <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-surefire-plugin</artifactId> <version>2.11</version> <configuration> <skip>true</skip> </configuration> <executions> <execution> <id>unit-tests</id> <phase>test</phase> <goals> <goal>test</goal> </goals> <configuration> <skip>false</skip> <includes> <include>**/When*.*</include> </includes> <excludes> <exclude>%regex[.*integration.*When.*]</exclude> </excludes> </configuration> </execution> <execution> <id>integration-tests</id> <phase>integration-test</phase> <goals> <goal>test</goal> </goals> <configuration> <skip>false</skip> <includes> <include>%regex[.*integration.*]</include> </includes> </configuration> </execution> Using package conventions </executions> </plugin>

Split unit and integration tests <groupId>org.apache.maven.plugins</groupId> <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-surefire-plugin</artifactId> <artifactId>maven-surefire-plugin</artifactId> <version>2.11</version> <version>2.11</version> <configuration> <configuration> <skip>true</skip> <skip>true</skip> </configuration> </configuration> <executions> <execution> <id>unit-tests</id> <phase>test</phase> <goals> <goal>test</goal> </goals> <configuration> <skip>false</skip> <includes> <include>**/When*.*</include> </includes> <excludes> <exclude>%regex[.*integration.*When.*]</exclude> </excludes> </configuration> </execution> <execution> <id>integration-tests</id> <phase>integration-test</phase> <goals> <goal>test</goal> </goals> <configuration> <skip>false</skip> <includes> <include>%regex[.*integration.*]</include> </includes> </configuration> </execution> Using package conventions </executions> </plugin>

Split unit and integration tests <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-surefire-plugin</artifactId> <execution> <version>2.11</version> <configuration> <id>unit-tests</id> <skip>true</skip> <phase>test</phase> </configuration> <goals> <executions> <execution> <goal>test</goal> <id>unit-tests</id> </goals> <phase>test</phase> <goals> <configuration> <goal>test</goal> <skip>false</skip> </goals> <includes> <configuration> <skip>false</skip> <include>**/When*.*</include> <includes> </includes> <include>**/When*.*</include> <excludes> </includes> <excludes> <exclude>%regex[.*integration.*When.*]</exclude> <exclude>%regex[.*integration.*When.*]</exclude> </excludes> </excludes> </configuration> </configuration> </execution> </execution> <execution> <id>integration-tests</id> Excluding integration tests from the test phase <phase>integration-test</phase> <goals> <goal>test</goal> </goals> <configuration> <skip>false</skip> <includes> <include>%regex[.*integration.*]</include> </includes> </configuration> </execution> Using package conventions </executions> </plugin>

Split unit and integration tests <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-surefire-plugin</artifactId> <version>2.11</version> <configuration> <skip>true</skip> </configuration> <executions> <execution> <id>unit-tests</id>Run only integration tests in the integration-test phase <phase>test</phase> <goals> <goal>test</goal> </goals> <execution> <configuration> <id>integration-tests</id> <skip>false</skip> <includes> <phase>integration-test</phase> <include>**/When*.*</include> <goals> </includes> <goal>test</goal> <excludes> <exclude>%regex[.*integration.*When.*]</exclude> </goals> </excludes> <configuration> </configuration> <skip>false</skip> </execution> <execution> <includes> <id>integration-tests</id> <include>%regex[.*integration.*]</include> <phase>integration-test</phase> <goals> </includes> <goal>test</goal> </configuration> </goals> </execution> <configuration> <skip>false</skip> <includes> <include>%regex[.*integration.*]</include> </includes> </configuration> </execution> Using package conventions </executions> </plugin>

CompileDefault build Unit Test mvn deploy Package Integration Test

CompileDefault build Unit Test mvn install Package Integration Test Jenkins Artifactory Plugin

CompileDefault build Unit Test mvn install Package Integration Test mvn deploy:deploy

Eliminate waste

Run code coverage with the integration tests compile test-compile Integration tests mvn verify test package integration-test verify Test coverage mvn cobertura compile test-compile Duplication! test package integration-test cobertura Creates its own instrumented JAR files

JACOCOJava Code Coverage Code coverage on the flyDoesn’t mess with your JAR files

Run code coverage with the integration tests<plugin> <groupId>org.jacoco</groupId> <artifactId>jacoco-maven-plugin</artifactId> <version>0.5.10.201208310627</version> <executions> <execution> <id>jacoco-initialize</id> <goals> <goal>prepare-agent</goal> </goals> Measure code coverage </execution> after the integration tests <execution> <id>jacoco-site</id> <phase>post-integration-test</phase> <goals> <goal>report</goal> </goals> </execution> </executions></plugin>

<plugin>Run code coverage with the integration tests <groupId>org.jacoco</groupId> <artifactId>jacoco-‐maven-‐plugin</artifactId> <executions> <execution> <goals> <goal>prepare-‐agent</goal> </goals> </execution> <execution> <id>check</id> <goals> <goal>check</goal> Define minimum coverage </goals> <phase>post-‐integration-‐test</phase> <configuration> <check> <classRate>95</classRate> <instructionRate>95</instructionRate> <methodRate>90</methodRate> <branchRate>95</branchRate> <complexityRate>95</complexityRate> <lineRate>95</lineRate> </check> </configuration> </execution>

Run code coverage with the integration testsIntegration tests/test compile test-compile mvn install test coverage package integration-test verify Uninstrumented JAR Coverage checks and report

Minimal overheadBuild Time Normal build With JaCoCo

Reuse binaries wherever possible Default build 1.0.203Deploy to TESTAcceptance Tests 1.0.201 1.0.202 1.0.203Deploy to UAT

Have a separate acceptance test suite Acceptance Tests TEST UAT PROD

Take code quality seriously Checkstyle Findbugs

Take code quality seriouslyCode quality metrics mvn site

Take code quality seriously Pick and choose your metricsCode quality metrics mvn pmd:check mvn findbugs:check mvn checkstye:checkstyle Fail the build if there are violations

Avoid the Maven Release PluginDon’t sweat the version numbers

Developers always work on a SNAPSHOT version 1.0-SNAPSHOT This number is pretty arbitrary

Jenkins sets a release candidate version at the start of the build pipeline 1.0-SNAPSHOT 1.0.203 This number is a build counter

This version goes through the build pipeline 1.0.203 Unit tests Acceptance tests Code quality metrics Deploy to TEST

This version goes through the build pipeline 1.0.203 1.0.204 1.0.205 Unit tests Acceptance tests Code quality metrics Deploy to TEST Acceptance Tests 1.0.203 1.0.204 1.0.205

Create a new release branch Update the version number Build and test release candidate Did it work? No YesDrop release branch Push release branchNotify everyone Deploy release candidate

Create a new release branch Update the version number Build and test release candidate 1.0.203 Did it work? No YesDrop release branch Push release branchNotify everyone Deploy release candidate

Create a new release branch Update the version number Versions Plugin Build and test release candidate mvn versions:set -DnewVersion=1.0.203 Did it work? No YesDrop release branch Push release branchNotify everyone Deploy release candidate

Create a new release branch Update the version number Build and test release candidate Did mvn verify ... it work? No YesDrop release branch Push release branchNotify everyone Deploy release candidate

And make it visible The Build Pipeline plugin

Let’s see it in action! TEST UAT PROD Jenkins

Let’s see it in action!

initial-build code-qualitydeploy-to-test acceptance-testsdeploy-to-uat acceptance-testsdeploy-to-prod

initial-build Links to binary artifacts in ArtifactoryRelease candidate number

initial-buildLinks to binary artifacts in Artifactory

initial-build Use a parameterized build to configure the major build version Users can override the default major version

initial-build Create a new branchUpdate the version in the pom files Build the binaries

initial-build Conditional build step plugin If the build succeeds... Commit the changes and push the branch to the repository

initial-build If the build fails... Delete the branch

initial-buildDeploy the release candidate to Artifactory

initial-build Deploy to the test environment Target platform

initial-build<plugin> <groupId>com.jelastic</groupId> <artifactId>jelastic-maven-plugin</artifactId> <version>1.6</version> <configuration> <email>${jelastic.username}</email> <password>${jelastic.password}</password> <context>${jelastic.context}</context> <environment>${jelastic.environment}</environment> <api_hoster>app.jelastic.servint.net</api_hoster> </configuration></plugin>

initial-build Archive binaryUpdate the build description

initial-build Archive binaryPass the release branch to the next build job

initial-buildDon’t start a new build pipeline ifone is currently running.

initial-build code-qualityPass in the release we want to build against deploy-to-test acceptance-tests deploy-to-uat acceptance-tests deploy-to-prod

initial-build code-quality deploy-to-testBuild from the release candidate branch acceptance-tests deploy-to-uat acceptance-tests deploy-to-prod

initial-build code-qualityCopy the WAR file from the initial build deploy-to-test acceptance-tests deploy-to-uat acceptance-tests deploy-to-prod

initial-build code-qualitydeploy-to-test acceptance-testsdeploy-to-uat ...deploy this WAR file acceptance-testsdeploy-to-prod

initial-build code-qualitydeploy-to-test acceptance-testsdeploy-to-uat acceptance-testsdeploy-to-prod the acceptance tests ...and run

initial-build code-quality deploy-to-test acceptance-tests deploy-to-uatWhat platform do we run the acceptance test against acceptance-tests deploy-to-prod

initial-build code-quality deploy-to-test acceptance-tests deploy-to-uatBuild promotion status acceptance-tests deploy-to-prod

initial-buildCopy the WAR file from the initial build... code-quality deploy-to-test acceptance-tests deploy-to-uat ...and deploy it to UAT acceptance-tests deploy-to-prod

A build promotioninitial-build deploy to production process to code-quality deploy-to-test acceptance-tests deploy-to-uat acceptance-tests deploy-to-prod

Build pipeline for an overview of the process

Thank You John Ferguson Smart Email: john.smart@wakaleo.com Web: hHp://www.wakaleo.com TwiHer: wakaleo
