    Introduction to Messenger APIs Introduction to Messenger APIs Presentation Transcript

    • Prerequisites
      • HTTP
      • URIs, URI parameters, and URL encoding
      • Request / Response Headers
      • HTTP content
      • RESTful
      • APIs use HTTP GET, POST, and the less common PUT, DELETE
      • Override using HTTP POST and URI parameter “_method=[put,delete]”
      • JSON
      • No XML support
      • Content-Type: application/json;charset=utf-8
    • Authentication
      • Standard Oauth
      • Direct Oauth
      • Consumer key must have read/write access for Y! Messenger
      • Programmatic authentication
      • No browser
      • Other mobile integration friendly optimizations
      • Accuracy of timestamp restriction is relaxed if you use PLAINTEXT oauth signature
      • Pitfall – consumer key / consumer secret sent in the clear
    • Introduction to the Messenger APIs
      • Types of communication
      • Client to Server communication (typically user actions)
      • Send an instant message
      • Login into messenger
      • Server to Client communication (… but client initiated)
      • Someone send you an instant message
      • Someone tries to add you to their buddy list
    • Client to Server API’s
      • Session Management
      • Login (POST /session)
      • Dynamic capabilities (mailAlerts/fileXfer/buzz/smiley) per login session
      • Supply presence information at login
      • Get back the contact or group list in the response
      • Look for the URI parameter ‘fieldsBuddyList’ or ‘fieldsGroupList’
      • Logout (DELETE /session)
      • Keepalive (PUT /session/keepalive)
      • Client heartbeat
      • Presence Management
      • Update your presence information (PUT /presence)
      • State (available, busy, idle, invisible)
      • Custom message
    • Client to Server API’s
      • Message Management
      • Instant Message (POST /message/{network}/{id})
      • No Interop (msn/hotmail/etc)
      • Contact/Group Management
      • Fetch your contact or group list
      • Now supports fetching a subset of your AddressBook data
      • Add a contact (PUT /group/{groupname}/contact/…)
      • Delete a contact (DELETE /group/{grpname}/conta..)
    • Server to client api’s
      • What is a Notification?
      • An event targeted to a logged in session
      • Most common notification types
      • message
      • Typically an incoming instant message
      • buddyInfo
      • Information about a contact that just logged into messenger
      • Information about contacts online when you first login
      • buddyStatus
      • A buddy updated their presence information (state/custom message)
      • logoff
      • A buddy went offline
      • buddyAuthorize
      • Someone is trying to add you to their buddy list
      • The accept or denial response to an add request you previously sent
    • Server to client api’s
      • Notification Sequence Number
      • All notifications have a sequence number unique to the session
      • Incremental integer
      • Unlikely, but design for skips in the sequence counter
      • Design to be able to skip unknown notification types
      • Retrieving Notifications
      • Periodic Polling
      • Provide start sequence number and optional count
      • Limited to under once every 5-10 seconds
      • Does not support persistent connections
      • Comet Style Push (Long Poll)
      • Provide start sequence number and optional idleTimeout
      • Expected that client will always maintain an available long poll
      • Supports HTTP 1.1 and persistent connections
    • More than just basic IM FEATURES
      • File Transfer
      • Send and Receive files
      • Remember to indicate ‘fileXfer’ clientCapability at login
      • Display Images
      • Upload and update your custom display image
      • Retrieve the display images for your contacts
    • Getting started - Sample Session guidelines
      • Obtain your credentials
      • Login (POST /session)
      • Request for groups list in the response
      • Look at URI parameter ‘fieldsGroupList’
      • Information about your buddies
      • Don’t request for information using Group or Contact List Management APIs
      • Wait for buddyInfo notifications for all online buddies
      • Automatically also subscribed for delta notifications (buddyStatus/logoff/etc)
      • Triggers any offline messages received
      • Look for offlineMessage notification type
      • < Other API calls. Don’t forget /keepalive>
      • Logout (DELETE /session)
    • DIRECT OAUTH
      • Consumer key must have read/write access to Y! Messenger
      • Exchange UserId/Password for PART
      • PART = Pre-Approved Request Token
      • Programmatic solution
      • Exchange PART for Access Token / Handle
      • Date/Time issue on mobile devices
      • Accuracy requirement relaxed if you use PLAINTEXT oauth signature method
      • Access token expiration
      • Looking to extend this for Y! Messenger only consumer keys
      • Refresh access token as needed using Handle
    • Q & A
